Walkaway ® Brackets When every second counts, you can rely on Walkaway® Brackets to provide instant access to your vital breathing apparatus. All brackets are constructed of steel and are thermoplastic coated. High cycle clips have a multi-layer coating and have been tested to over 50,000 cycles. High cycles are non-abrasive, making them an excellent choice for use with carbon fiber air cylinders. Ship. wt. 1 lb. AS070 - Specify size: 5.4 - 5.8" Diameter: 15 to 30-minute cylinder 6.75" Diameter: 30 to 45-minute cylinder 7.25" Diameter: 60-minute cylinder AS071 - Specify size: 5.4 - 5.8" Diameter: 15 to 30-minute cylinder 6.75" Diameter: 30 to 45-minute cylinder 7.25" Diameter: 60-minute cylinder
AS072 - Specify size: 5.4 - 5.8" Diameter: 15 to 30-minute cylinder 6.75" Diameter: 30 to 45-minute cylinder AS073 - Specify size: 5.4 - 5.8" Diameter: 15 to 30-minute cylinder 6.75" Diameter: 30 to 45-minute cylinder
Meets NFPA Requirements (For installation in cab when equipped with collision restraint strap) AS070 AS071 AS072 AS073 AS074 AS075
Knockdown Walkaway® Bracket (Standard) Knockdown Walkaway® Bracket (High Cycle) Scott Knockdown Walkaway® Bracket (High Cycle) Scott Knockdown Walkaway® Bracket (High Cycle) with PHS Strap Assembled Positive Holding Strap Collision Restraint Strap
AS070
AS071
AS072
AIR SYSTEMS
Load & Lock™ Air Pack Bracket NFPA required ejector spring insures that the SCBA cannot rest in the bracket unsecured, preventing accidental damage to firefighters and equipment The SCBA is easily secured into position with one hand by pressing the SCBA against the spring while securing the latch into the trigger mechanism with the other hand Quick and easy to adjust, while pressing the SCBA against the spring pull the adjustment strap until it is snug NFPA 1901-03 compliant
Ship. wt. 1 lb. AZ451 AZ452 AZ453 AZ454
Load and Lock Bracket Load and Lock Strap Conversion Kit - Includes 2 Seats, 1 Load & Lock Strap Ejector Spring
Quic-Lock Mechanical Bracket One Bracket...Any SCBA Top clamp restraining mechanism
BE297
272
The Quic-Lock is a new mechanical SCBA restraint bracket that fits all SCBAs currently on the market at the time of its design. The bracket has been dynamically tested and held to over 10 g’s. The bracket features an easy-to-use release mechanism. One pull on the release cord and the SCBA is completely free without any tugging or snags. All adjustments that need to be made to accommodate a different SCBA or bottle can be made to the front of the bracket without having to remove it from the seat. The Quic-Lock uses a top clamp restraining mechanism Positionable that holds the SCBA firmly without release cord vibration or rattling. The release mechanism can be positioned to any location, allowing for complete versatility.
Quic-Lock Mechanical Bracket
1.800.323.0244 | www.edarley.com/airsystems
Adjustments can be made without removing bracket from seat
