Gated Ball Valve
Hydrant Gate Valve
Female 2 /2" rocker lug swivel inlet with (2) 11/2" male outlets. Operates easily under high pressure. Red body with chrome trim or polished brass. Rugged die-cast handles. NST threads. Ship. wt. 10 lbs.
Lightweight cast and extruded aluminum construction. Features 21/2" female swivel inlet and 21/2" male rigid outlet. The body and both inlet and outlet fittings are hard anodized.The internal, non-rising brass actuator stem requires approximately 10 turns to open or close. Precision-machined surfaces provide a good metal to metal seal. NST threads. Ship. wt. 12 lbs.
1
Two way Quarter turn Full flow AR119
Open pressurized gates slowly
Gated Ball Valve, Polished Brass
BE097 Hydrant Gate Valve
ADAPTERS & FITTINGS
Lightweight Gated Valve No more heavy brass valves to carry around. Our lightweight line wyes with aluminum construction cut the overall weight by more than 30% when compared to traditional brass valves. Ship. wt. 8 lbs.
Single Gate Valve These gate valves are made with a full size waterway. They are used next to the hydrant, so that one stream may be stopped without interfering with the other. Withstands 400 lbs. of pressure. Ship. wt. 12 lbs.
BE315
BE257 BE315
21/2" NSTF Inlet x (2) 11/2" NSTM Outlet Valve 21/2" NSTF Inlet x (2) 21/2" NSTM Outlet Valve
2-Way Wye These wyes are made of aluminum alloy that has been heat-treated. The other major components are made of stainless steel and galvanized brass. This lightweight and smaller design minimizes the friction loss by up to three times. Ship. wt. 12 lbs.
AW064 AW065 AW066
B73901 21/2" Brass, Rocker Lug Valve B73902 21/2" Chrome Pin Lug Valve
Darley Hydrant Valve This is the same Darley Ball valve used on our midship pumps. It features a 21/2" swivel female inlet x 21/2" male outlet. Suitable for controlling hydrant flows. Body is red with chrome trim and featured at a price you can’t beat. Ship. wt. 14 lbs.
11/2"F Inlet x (2) 11/2"M Outlet Wye 21/2"F Inlet x (2) 11/2"M Outlet Wye 21/2"F Inlet x (2) 21/2"M Outlet Wye
/4 turn valve
1
M988
2 1/2" Gated Wye TFT’s new 2 1/ 2" Gated Wye is designed for the rugged fire ground environment, yet is the lightest most flow efficient ever created. Lightweight, only 10 lbs. Less than 10 psi loss at 1000 gpm Exclusive color-coded folding handles store out of the way even in the tightest compartments The ONLY valve to offer an automatic valve lock even up to 250 psi operating pressure BG525
198
21/2"F Inlet x (2) 21/2"M Outlet Gated Wye
1.800.323.0244 | www.edarley.com/adapters
21/2" NST Hydrant Valve
Multi-Use Adapter The latest multi-use adapter. Perfect for hazmat decontamination. Other uses include forestry units, portable water, and portable drinking water. You will also find it useful for vehicle wash down. Available in 11/2" or 21/2" NST. Ship. wt. 3 lbs.
AJ09901 AJ09902
Hazmat Adapter 11/2"F x (2) GHT M Hazmat Adapter 21/2"F x (2) GHT M
