HydrantPro Diffuser
Hydrant Diffuser Protect Property and Vehicles From Possible Water Force Damage
WATER SUPPLIES
New design - Lightweight with quality aluminum swivel adapter Estimates gallons flushed Available in 100psi/1680gpm or 160psi/2120gpm high quality liquid filled gauge Diffuses flow to reduce damage while flushing hydrant Swivels to Aim Flow - Point the flow where you want to flush Ruggedly constructed to provide years of dependable service Replaceable pressure tube assembly and ball-bearing swivel hydrant adapter
BK126 BK127 AM163 BK128 AF331
21/2"NST HydrantPro Diffuser (100psi/1680gpm) 21/2"NST HydrantPro Diffuser (160psi/2120gpm) Inner Tube for 21/2" Diffuser Carrying Case for 21/2" Diffuser (BK126 & BK127) 41/2" NST Swivel Piezo Diffuser
Created to overcome the constant problem of traffic disruption and water force damage to property and vegetation in the testing area. Discharge stream velocity is slowed and redirected while flowing through a series of steel grids. The pattern diverter, on outer edge of discharge cone, directs diffused stream to side or down, depending on adjustable settings. Slots in the case inlet adapter permit a firm hold of pitot gauge against the full water force before diffusion, assuring a more accurate pitot reading. The pipe-like projection at the right serves as a handle for easy threading during hydrant attachment. Even high pressure hydrants delivering 1125 gpm are now limited to a discharge distance of 5'. Fully in accord with “Special Interest Bulletins” of the American Insurance Association. 21/2" NST threads. 17"H x 17"W x 29"L. Ship. wt. 22 lbs. S672
Hydrant Diffuser
Fire Hose Tester with Pressure Washer and Tool Tray The Fire Hose Tester is easy-to-use and comes standard with four outlets, stainless steel balls valves, 11/2 NST male discharges and a 11/2 NST male inlet, 3 gallons a minute at 600 psi. It is capable of testing up to 6" diameter hose, and 300' per discharge. The Fire Hose Tester comes standard with an easy-to-use wheeled cart that fits Non-marking hose, heavy-duty through standard 36" doorways. Also included wand and handle is a built-in pressure washer with 25' of 3/8" non-marking hose, a quick-release, heavy-duty wand and handle, a stainless steel nozzle with stream straightener and a quick-connect injector and metering valve for adding cleaning agents to the water supply. BG535
Fire Hose Tester w/Pressure Washer and Tool Tray
Dechlorinating Diffuser The Dechlorinating Diffuser uses either LPD-Chlor™ Tablets (contains Sodium Sulfite 81.3%) or Vita-D-Chlor™ Tablets (Ascorbic Acid-Vitamin C) that neutralize the chlorine/ chloramines in the water you are flushing. When using the LPD-CHLOR tablets, the Dechlorinating Diffuser consumes about 1 tablet per 2,500 gallons - the feed tube should be topped off with additional tablets after each increment about 10,000 gallons of flow. Weighing 33 lbs., the Dechlorinating Diffuser is heavy enough to take the day-to-day abuse of flushing. You can flush straight off a hydrant or attach a hose to point the flow where you want it to go. Handle flows from 200 - 1,250 gpm and hydrant pressures up to 200 psi. Neutralizes chlorine and chloramine in potable water Connects to hydrant or fire hose BH154 BH155 BH156 BH157 BH158
186
Adaptable for low and high volume flow Flow measurement pitot Pitots sold separately
Dechloronating Diffuser (Color: Orange) Aluminum Dechloronating Diffuser (Color: Yellow) LPD Pitot Kit LPD Hitch Mount Bracket LPD-Chlor Tablets
1.800.323.0244 | www.edarley.com/water
BH154
