ACQUISITION
IP-Enhanced Camera-Back Fibre Transport MULTIDYNE FIBER OPTIC SOLUTIONS’ SilverBack V is a 12G- and 4K-capable camera-back system incorporating an IP output. The SilverBack V enables the convergence of fibre and IP-based production workflows while building on the flexibility of the SilverBack family. MultiDyne will demonstrate the SilverBack V at IBC2018 at stand 11.D40. In addition to its future-friendly IP capabilities, SilverBack V also brings new features and benefits to fibre users in markets ranging from electronic newsgathering (ENG) and live sports coverage to motion picture productions and other remote contribution applications. SilverBack V supports both singlelink 12G and quad-link 3G SDI connectivity, maximising 4K Ultra HD signal interface flexibility. The SilverBack V base station supports two camera heads simultaneously, enabling exceptional cost-effectiveness and space savings. A built-in multiviewer provides live monitoring of both camera feeds, with audio monitoring available as an option. The space-efficiency of the dual-camera base station is paralleled by the reduced width of the SilverBack V camera-back unit, which makes it the most compact unit in the SilverBack family to date. The significantly narrower design enables a much lighter camera-back load and eases operator mobility while still ensuring proper overall weight balance between the camera-
back, body and lens. MultiDyne is also working closely with camera vendors including Sony, Panasonic, Canon, JVC and more to develop specific SilverBack V designs tailored to the connection points, colour, texture and ergonomics of each camera. In addition to supporting 12Gbp/s and 3Gbp/s connections, SilverBack V also combines 1.5Gb/s video, audio, intercom, camera control, tally, data and power onto a single tactical cable, SMPTE hybrid fibre cable, and/or IP network connection. Integrated expansion slots support a variety of interchangeable I/O connectivity modules for frictionless interoperability with other MultiDyne fiber transport systems and third-party products. Visit www.multidyne.com
OConnor Camera Assistant Bag OCONNOR HAS INTRODUCED its all-new Camera Assistant bag, which will making its official European debut at IBC2018 on The Vitec Group’s Stand, 12.E65. Featuring a water- and dust-resistant liner with stuff pocket, the bag is designed without any internal seams and features a hinged lid that can be left open on set without putting sensitive equipment at risk. The Camera Assistant bag is constructed of highquality, water-resistant materials and features a tough, wipeable outer fabric and a double-skin lining. For heavier loads D-ring fixing points on the front and back enable users to carry the bag Sherpa-style using the leather strap provided, which spreads the weight of the bag
over the carrier’s back rather than concentrating it on the shoulders. The Camera Assistant bag fits into a standard Pelicase 1620 travel case. On the inside, the Camera Assistant bag includes seven heavyduty dividers with double-sided fastening strips, designed to secure all OConnor heads and accessories. Additional fixing points hold accessories such as pan bars and camera plates, and durable clear-mesh pockets offer storage for additional gear. The Camera Assistant bag also includes an extra pouch that can be carried on the user’s belt or fixed externally to the main bag. Visit www.ocon.com
UHD and 4K Cameras from Marshall Electronics
The CV380-CS is designed for any point-of-view (POV) camera application where a small, miniature camera can fit into unique locations for compelling angles and viewpoints. The CV380-CS has a varifocal or fixed CS/C lens mount with DC Auto-Iris capability and can accept a range of interchangeable lenses for enhanced customisation. The CV380-CS is among the first additions to Marshall’s latest generation of compact and miniature cameras utilising a fully redesigned body style and form factor. Special attention has been given to enhance durability in the field with the addition of new structural ‘wings’, designed to give greater protection to rear connectors during use. The CV380-CS offers three resolution modes with the following frame rate settings:
The Marshall CV420-CS has outputs of 12G/6G/3G/ HD-SDI and HDMI 2.0, and it has a Varifocal or Fixed CS/C lens mount capability with DC Auto-Iris plug-in for custom lens adaptions.
Marshall Electronics’ CV380-CS UHD compact camera.
The CV420-CS offers the following resolution modes and frame rate settings (industry standard for U.S. broadcast, PAL, NTSC and cinematic 24 fps): • True 4K (4096x2160p) at 50, 59.94, 60, 25, 29.97, 30, and 24 fps. • UHD (3840x2160p) at 50, 59.94, 60, 25, 29.97, 30, and 24 fps.
• UHD (3840x2160p) at 25, 29.97, and 24 fps.
• Interlaced HD (1920x1080i) at 50, 59.94, and 60 fps.
• Progressive HD (1080p and 720p) at 50, 59.94, 25, 29.97, and 24 fps.
• Progressive HD (1080p and 720p) at 50, 59.94, 25, 29.97, and 24 fps.
• Interlaced HD (1080i) at 50, 59.94, and 60 fps.
Remote control for the CV420-CS is operated by RS485 (Visca) or OSD menu joystick, and a wide range of picture adjustment settings are available such as Paint (Red/Blue), White Balance, Gain, Pedestal (blacks), Gamma, Shutter and more. The CV420-CS can capture detailed shots while maintaining a discrete presence and can be used as a fixed ‘e-PTZ’ camera, where select windows of the image can be zoomed and panned within the frame.
The CV380-CS features professional picture settings including white balance, gamma, gain, pedestal and digital zoom, and can be remotely matched and adjusted using RS485 (Visca). The CV380-CS is targeted for use in broadcast, live sports, reality television, as well as Pro AV applications including education, corporate communications, presentations and more. Also new, the Marshall CV420-CS, built around a 12.4-Megapixel, 1/1.7inch sensor, delivers crisp, clear 4096x2160p video with vibrant colours and fast frame rates.
Visit www.marshall-usa.com
ACQUISITION
MARSHALL ELECTRONICS IS ADDING to its miniature and compact camera offerings with its new ultra-high-definition (UHD) compact camera, the Marshall CV380-CS, which will premiere at IBC2018 (booth 12.D20). The CV380-CS uses an 8.5-Megapixel, 1/2.5-inch sensor, to capture detailed video images, and outputs in 6G/3G/HD-SDI and HDMI 1.4.
