ADVANTAGES OF HIGH REACH EXCAVATORS ON DEMO PROJECTS

Corporate Office 5000 Vasquez Blvd., Denver, CO 80216 303-355-5900 2340 I-70 Frontage Road Grand Junction, CO 970-241-1550 Colorado Springs Parts/Sales 2250 Reliable Circle Colorado Springs, CO 719-576-5541 Colorado Springs Service 2239 Commercial Blvd. Colorado Springs, CO 719-576-5541 2600 Center Drive Milliken, CO 970-587-1188 7854 Hutchins Drive Cheyenne, WY 307-634-5149 39 Kay Cee Lane Durango, CO 970-259-0455 1181 Burgundy Dr El Paso, TX 915-872-1001 25015 S McQueen Rd Chandler, AZ 602-9863003 4428 East Trent Ave. Spokane, WA 99212 800-541-0754 22431 83rd Ave. S. Kent, WA 98032 800-669-2425 19444 Ivan Street SW Rochester, WA 98579 800-304-4421 5241 NE 82nd Ave. Portland, OR 97220 800-950-7779 3155 Highway 93 S. Kalispell, MT 59901 800-434-4190 1257 West Amity Boise, ID 83705 800-221-5211

TREES, BRANCHES, LIMBS, AND STUMPS ARE NO MATCH FOR A BANDIT®

From roadways to right-of-ways, lot clearing to road clearing, get your work done faster and more efficiently than ever before with Bandit® machinery! Choose from different styles and sizes to suit your needs. Call today to reserve yours or to request a demonstration. SMALL EQUIPMENT DEALERS

(Brush Chippers, Stump Grinders, Skid Steer Attachments)

bobcatofnorthtexas.com

High reach excavators use shears and demolition processors to make exact cuts when demolishing structures.

In a world where safety and precision reign supreme, cranes and wrecking balls are things of the past. High reach excavators have taken up the mantle as the go-to machine for demolition projects due to three unique advantages.

Fast Assembly

A converted high reach excavator engineered by C.W. Machine Worx can be assembled in two hours without assistance from additional equipment. These converted high reach excavators also only require one operator to attach their fronts. The operator can align the converted excavator’s stub front with the high reach front directly from the shipping truck. Once aligned, hydraulic pins from the modular joint attach the stub front to the high reach front and the machine is ready to operate.

“We refer to our converted high reach excavators as ‘self-erecting machines’ because they put themselves together,” Company Wrench Fleet Product Support Trainer Ben Dowdy said.

“They use custom counterweights that can be both removed and placed on the carrier by the excavator itself. Other pieces of equipment are usually required to assemble machines of this size, but not with our converted high reach excavators.”

Precision

High reach excavators use shears and demolition processors to make exact cuts when demolishing structures. These materials fall from the structure in a contained area, making high reach excavators the ideal machine for highly populated, dense areas, according to the manufacturer.

This level of control becomes even greater when operators use a telescopic boom instead of a two or three-piece boom. With the simple press of a button, operators can raise or lower the telescopic boom to make precise cuts across multiple working ranges. Two and three-piece booms require operators to add or remove sections of the boom to change working ranges.

“The learning curve for an operator is much easier with a telescopic boom,” Dowdy said. “When using a telescopic boom, you only have to worry about your boom and stick functions, like with a standard excavator. Three-piece booms feature a jib or mid-link function that allows the stick to bend up or down. This function is independent of the boom and stick functions so it adds another element to consider for operators. Ultimately, the decision between a telescopic boom and three-piece boom comes down to preference and working ranges.”

Industry Specific Features

The following high reach excavator designs can be installed to make the life of a demolition contractor easier: • Tilted Cab — The cab tilts up to 45 degrees for increased operator visibility and comfort. • Cab Interference Systems — This keeps the attachment from contacting the machine by slowing hydraulics when the operator reaches an unsafe working angle. • Interchangeable Fronts — Converted high reach excavators are capable of using high reach fronts, long reach fronts, and standard fronts. This allows a single excavator to perform projects that normally require multiple machines.

Company Wrench offers factory-built high reach excavators from Kobelco and converted high reach excavators from C.W. Machine Worx.

For more information, call 866/262-4181 or visit www.companywrench.com. 

p qpwww.compassequip.com

3-

t4688 Pacific HeightssRd • Oroville, CA 530-53 -7 7284 • 530-533-8610

pwww.empire-cat.com

1772 25 S Country Club Dr • M 7480-476 6-6004 esa, AZ

www.icmsolutions.com 800-779-4450 0 8007794450

4899 West 2100 South Salt Lake City, UT

348 South 5300 West Hurricane, UT 5040 S Apple St

Boise, ID

www.pacwestmachinery.com p y

A WAttleaSe W , W WA WAaneSpok , W WA WAoasP , Wc 800-935-5933 800-938-5933 800-929-5933

ernon, WMtVVe WA A 360-588-3083 Portland, OR 9800-9229-5933 Eugene, OR 866-920-5933

www.quinncompany.com

Bakersfield, CA 661-393-5800 f IndustryCity o y, , CA 256 -46 63 3-4000

S lmar

Foothill Ranch, C 9-794 -776 68-1777 erLancast r,, CA 661-942-1177 Sy y r CAr,, CA 677- -818-7767--77171 er

A Oxnard, CA 5-805-48 -2 2171 Riv rsside, CA 9 95 51-686-4560

www.wagnerequipment.comwww.westate.com

18000 Smith Rd • Aurora, CO • 3 3-0 -7 739-3000MT3809 Hwy 312 • Billings, MT • 7999-66800- 6776 6

Burlington, CO 346-719- -7 7880 Colorado Springs, CO 90-719-3 -7 7316

DurangoCO Hayden, CO 7970-2 276 6-3781 Pueblo, CO 719-544-4433 Y CO 50

Durango, CO 0-97 -2 259-2001 8Grand Junction, CO 2-0-97 -2 24 -22834 Yuma, CO 970-84 -22911 Albuquerque, NM 055-345-8411 57 3-

Farmington, NM 2750055-3 7-5331 Hobbs, NM 75 5-39 -22148 ElP T TX X 0- 17

or

El , TPaso 6721-915-8 -77665 51 Winds r,, CO 97 -2278- 7550

www.westate.com

M 0T2LTactro koec Ltoo Outste ok k®L 0 X™HP acityape c30% mor e-swith pr eencr

X PXT2LTactrookL k L 00HP eturaef one crusher00™ c® HP2gdberec Nortoo OutstMet fficiens an e -dewith a 2s equipped and i . y.apor 30% higher cwing fowcre-sk prc een, allo acity dutyyHeavy s oryevonwide cs and hassic ev-belt crusher drivect , and diroughpute high thrtaacilitf . fficiencys high fuel eeensur yase made etion araansporte and trServic eervice svensixtwith e orn fwold dot forms thatfpla k. bed trucw owansporting in one piec tr e on a lo

hT X PXT2LThe L 00HP therwith otion ombina crusher in certiary or tondaryecas a sed t usss bei oduction.s pretega aggracityapor high ceens fcrnd soL s ak mobile crusheractrok

om orc.oup.mogrevt lioom arwvirtual shosit our vior or tributsc diC etoo OutstMeour yact ton k.actro ko/lokle om/c.oupt mogre aarn mor

AUTHORIZED DOOSAN DEALERS

CALIFORNIA

BERCHTOLD EQUIPMENT COMPANY

661-323-7817 doosandealers.com/Bakersfield

805-922-7905 doosandealers.com/Santa-Maria

MEGA MACHINERY CO.

619-561-7832 doosandealers.com/Lakeside

RGW EQUIPMENT

925-606-2450 doosandealers.com/Anderson-CA

925-606-2451 doosandealers.com/Lathrop

925-606-2450 doosandealers.com/Livermore

SCOTT EQUIPMENT

909-822-2200 doosandealers.com/Fontana

562-777-0775 doosandealers.com/Santa-Fe-Springs

951-355-3085 doosandealers.com/Temecula

ALASKA

BOBCAT OF JUNEAU

907-523-7920 doosandealers.com/Juneau

BOBCAT OF KETCHIKAN

907-225-7921 doosandealers.com/Ketchikan

CRAIG TAYLOR EQUIPMENT

907-276-5050 doosandealers.com/Anchorage

907-452-1192 doosandealers.com/Fairbanks

907-262-5977 doosandealers.com/Soldotna

907-376-3838 doosandealers.com/Wasilla

IDAHO

CASCADE TRADER

208-762-5575 doosandealers.com/Hayden

OKLAHOMA

CENTRAL POWER SYSTEMS & SERVICES

816-781-8070 doosandealers.com/Tulsa

580-256-6014 doosandealers.com/Woodward

405-324-2330 doosandealers.com/Yukon

OREGON

FEENAUGHTY MACHINERY COMPANY

541-636-3660 doosandealers.com/Eugene

503-282-2566 doosandealers.com/Portland

WILSON EQUIPMENT

541-830-3966 doosandealers.com/Central-Point

COLORADO

EQUIPMENTSHARE

720-414-2044 doosandealers.com/Denver

MONTANA

NORTHWEST PARTS AND RIGGING CO.

406-892-1778 doosandealers.com/Columbia-Falls

UTAH

EQUIPMENTSHARE

801-893-6388 doosandealers.com/Salt-Lake-City

WASHINGTON

CASCADE TRADER

360-748-1182 doosandealers.com/Chehalis

WYOMING

BOBCAT OF CASPER

307-235-6685 doosandealers.com/Casper

BOBCAT OF GILLETTE

307-686-4890 doosandealers.com/Gillette

TEXAS

EQUIPMENT INCORPORATED

903-838-4508 doosandealers.com/Texarkana

H & V EQUIPMENT SERVICES

361-241-1000 doosandealers.com/Corpus-Christi

956-565-3788 doosandealers.com/Progreso

210-648-5885 doosandealers.com/San-Antonio

R.B. EVERETT & CO.

817-299-0010 doosandealers.com/Haltom-City

281-991-8161 doosandealers.com/Pasadena

TEXAS TIMBERJACK

409-384-4611 doosandealers.com/Jasper

936-634-3365 doosandealers.com/Lufkin

The new Doosan® dozer delivers more horsepower, better visibility and easier operation to help you push through your biggest challenges.

Contact your local Doosandealer for details.

©2022 Hyundai Doosan Infracore. All rights reserved. Hyundai Doosan Infracore is an affiliate of Hyundai Heavy Industries Group. The Doosan trademark, , is used under license from Doosan Corporation.

TRENCHING from page 1

OSHA called on all employers engaged in trenching and excavation activities to act immediately “to ensure that required protections are fully in place every single time their employees step down into or work near a trench.”

Doug Parker, assistant secretary for occupational safety and health, said in a matter of seconds workers can be buried under thousands of pounds of soil and rocks in an unsafe trench.

He wants to see the increase in the number of workers needlessly dying and suffering serious injuries in trenching incidents stopped.

“Every one of these tragedies could have been prevented had employers complied with OSHA standards,” said Parker. “There simply is no excuse for ignoring safety requirements to prevent trench collapses and cave-ins.”

The agency reported that 22 deaths in the first half of 2022 surpasses the total of 15 in 2021.

In June, two workers aged 20 and 39 died in Jarrell, Texas, when the unprotected trench more than 20 ft. deep collapsed upon them as they worked.

OSHA noted that trench shields sat unused beside the excavation. This incident prompted the agency to announce the enhancements.

To stress the dangers of disregarding federal workplace safety requirements, OSHA enforcement staff will consider every available tool at the agency’s disposal, said the agency.

“These actions will place additional emphasis on how agency officials evaluate penalties, including criminal referrals for federal or state prosecution to hold employers and others accountable.”

OSHA compliance officers will perform trench inspections nationwide and may stop by and inspect any excavation site during their daily duties.

Industry Gives Its Blessing

The National Utility Contractors Association (NUCA) marked this year’s Trench Safety Stand Down by reinforcing the idea that safety training is key to an employee’s daily activity.

The association believes safety training also is critical to a wellfunctioning utility construction job site.

“Time and time again, evidence shows that the key to significantly reducing the risks associated with our industry is employee training and reinforcement,” said Mike Flowers, NUCA’s director for safety, training and education.

This year, according to the association, 23,000 workers employed by 345 companies on 1,978 job sites participated in a stand down training event the week of June 20 to 24.

The goal of the event is to provide those who work in and around trenches and excavations with information about current excavation requirements and safety procedures.

OSHA and the North American Excavation Shoring Association (NAXSA) joined forces to host the Colorado Trench Safety Summit in early October.

The free event included classroom training, roundtable discussions and live demonstrations.

A similar event took place in Southlake, Texas, with the North Texas NUCA chapter in September.

Early this year, ANSI announced approval of the updated A10.12 excavation safety standard, Safety Requirements for Excavation.

The standard details how to design an excavation plan, including responsibilities, training and duties, assessing underground utilities, water accumulation and stability of adjacent structures and protecting workers from falls, cave-ins and confined spaces.

It applies to all open excavations, including trenches, made in the earth’s surface that require worker and/or property protection.

Defining Trench Safety

NUCA reported that OSHA’s standard 1926.650, Subpart P on trenching and excavation requires protective systems for trenches that are 5 ft. or deeper.

The federal agency warns that trench collapses are rarely survivable because a cubic yard of soil can weigh as much as 3,000 lbs.

“Trench hazards are wellknown,” said OSHA, “yet far too many workers continue to be injured or killed during excavation work.”

The agency believes trench collapses, or cave-ins, are more likely than other excavation-related incidents to result in worker fatalities.

“It only takes seconds to become buried in thousands of pounds of soil.”

But trench hazards can be controlled when employers act responsibly, train employees and follow federal standards.

OSHA lists steps contractors can take to keep excavation work safe: • Ensure there is a safe way to enter and exit the trench; • Trenches must have cave-in protection — remember to Slope, Shore, Shield; • Keep materials away from the edge of the trench; • Look for standing water or other environmental hazards; and • Never enter a trench unless it is properly inspected

The National Institute of Occupational Safety and Health (NIOSH) warns that working in an unprotected trench is dangerous.

The walls can collapse suddenly and without warning. When this happens, workers do not have time to move out of the way.

“A small amount of dirt may not seem dangerous, but can weigh more than 3,000 pounds — the weight of a compact car,” said the organization. “This small amount of dirt is enough to fatally crush and suffocate workers.”

Like OSHA, safety experts at NIOSH warn that “workers should never enter a trench that does not have a protective system in place.”

The protective system should be designed and installed by a competent person, someone who can identify hazards and is authorized to correct them.

Competent person training is available from many sources, noted NIOSH, including insurance companies, trade associations, labor unions and equipment manufacturers.

The best way to prevent trench collapse and trenching fatalities is to use other methods, when possible, said NIOSH.

Some options include directional boring, relining the pipe, pipe ramming and utility tunneling and pipe jacking.

Robots can be used on construction sites to transport, line and join large pipes to protect workers from serious injuries.

Additional Advice

Caterpillar dealer Blanchard Machinery warns that the fatality rate for excavating is 112 percent higher than general construction.

“Trenching is a dangerous job,” said the West Columbia, S.C.based, company. “But you can protect yourself and your team from injury with the right precautions. Anticipate the risks before they become hazards and be proactive with these trench safety tips.” • Understand proper trenching practices

Blanchard reiterates that the site manager should implement trenching techniques based on soil, trench dimensions and other sitespecific factors.

“Never work in a trench without supporting the sides with a trench box, shoring, or combination of sloping and benching methods,” said Blanchard. • Follow site-specific trenching safety guidelines

Every work site is different, noted the company.

“Account for environmental and atmospheric conditions, soil type, trench dimensions and the work you’re doing in creating site-specific safety guidelines.”

According to Blanchard, these rules should be safety standards across all trench settings. Never enter a trench with standing water or accumulating water without taking proper precautions to drain and prevent more flow. • Test and inspect trenches regularly

Trenches must be inspected before work begins each day to check for hazardous fumes, oxygen levels, water accumulation and environmental changes.

The inspector should reinspect trenches after environmental changes and natural events, like nearby blasting work or heavy rain. • Know the soil, environment

Soil type and quality are some of the most significant factors to consider when designing a trench.

Always conduct utility line tests before trenching. Mark gas, electrical, water and other lines with correct signage and barriers before operating any equipment.

“Failure to do so could result in injury and costly damage or fees,” warns Blanchard. • Use a trench box — but don’t rely on it

Trench boxes are in place to protect workers in the event of a cavein and cannot always prevent the cave-in itself.

Proper barrier placement should include shoring and worker barriers with enough force to be greater than the force coming from the trench walls.

Avoid using trench boxes for greater depths than the manufacturer has rated them for and never work inside a damaged barrier. 

CEG
