In general, you will hear meteorologists report sustained wind speeds when covering an approaching hurricane. They might also mix in some peak gusts, but for the most part they focus on sustained wind speeds. Sustained wind speeds for tropical cyclones use a 60-second averaging time. Sustained wind speed is also used by the Saffir-Simpson scale to roughly quantify the likely damage that the wind from a storm might cause typical buildings and other structures. There are criticisms of the accuracy of the Saffir-Simpson scale method, but it is widely used by the public to generalize about the severity of tropical cyclones; therefore, it is likely that the public might and commonly does attempt to compare reported sustained wind speeds to building-code-specified three-second-gust wind speeds to determine if their house or structure will withstand the storm. There is danger in making that comparison.
We need to be careful when comparing the reported sustained wind speed for a storm with the threesecond-gust design wind speeds referenced in building codes and design standards. They are not the same and need to be converted before they can be compared for equivalence. After seeing the following example, one could easily see the possibility of the public or a public official comparing the sustained wind speeds reported by the weatherman to the wind speeds used by building codes and design standards and drawing conclusions that may underestimate the force and effect of the storm.
Let’s take a hypothetical situation where a building jurisdiction has adopted a wind speed of 130 mph three-second-gust design wind speed for structures built in that jurisdiction. There are various methods to convert wind speeds between different averaging times, and many factors that may need to be considered when doing that. One method for converting is the Durst method referenced in ASCE 7. Another more recent method recommended by the World Meteorological Organization provides a pretty straightforward conversion between sustained wind speed and three-second-gust wind speeds for near-surface applications. So for the sake of simplicity, we will use it for this example. If we convert a reported sustained wind speed of 130 mph to a three-second-gust average wind speed using this method, it equates to a three-second-gust wind speed for Off-Sea of 160 mph (Off-Sea is appropriate for an approaching hurricane). The adopted130 mph three-second-gust wind speed converts to 105 mph sustained wind speed. This difference could lead individuals in the path of the storm to underestimate its severity if they are not aware of the difference between averaging intervals for wind speeds. They could see the sustained wind speed of 130 mph being reported by the weather service when the storm is over open water and assume that their structure, or structures in their jurisdiction, will stand up fairly well. This would be a serious underestimate, since those structures would need to be designed to resist a 160 mph three-second-gust wind speed using ASCE 7 in order for that to be true. To say that a different way, one might think that their structure was designed for a Category 4 storm (130 mph sustained), when in fact it was actually designed for a Category 2 storm (105 mph sustained) using the Saffir-Simpson scale. Hurricane Irma at its maximum sustained wind speed of 185 mph would equate to a 227 mph three-second-gust wind speed using this conversion method. From a roof anchorage, lateral design and load path design perspective, the difference between 130 mph and 160 mph can be substantial, especially when the building is located on flat open terrain where Exposure C or Exposure D are appropriate assumptions for the design.
