Biology
The light microscope Learning objectives: • observe plant and animal cells with a light microscope • understand the limitations of light microscopy.
Key words magnification micrographs resolving power
The type of light microscope you have used in the school laboratory is called a compound microscope. Microscopes magnify the specimen you are looking at, making them look bigger than they are.
Some early microscopes had just a single lens. The compound microscope has two. As lens-making techniques improved, microscopes were developed with higher magnifications and resolutions. Figure 1.4 A compound microscope
Magnification The magnified image is produced by two lenses, an eyepiece and an objective lens. There is usually a choice of objective lenses. Total magnification = magnification of eyepiece × magnification of objective lens For instance, if the eyepiece has a magnification of 10, which is written × 10, and the objective lens has a magnification of × 40, the total magnification is × 400.
16
1
Calculate the total magnification with an eyepiece magnification of × 15 and an objective lens magnification of × 40.
2
What magnification would the objective lens need to be to give a total magnification of × 300 with an eyepiece of × 15?
Did you know? British scientist Robert Hooke first used the term ‘cell’. He recorded the first drawings of cells using a compound microscope in his book Micrographia, which was 350 years old in 2015. You may also have heard of Hooke for his law of elasticity, Hooke’s law, in physics.
