Recommended Marine Shop Electrical Test Equipment and Tools Part Number
6
Description
Remarks/Use
511-0300
Infrared Temperature Meter
Used to read engine, spark plug, lower unit, and hull temperature. Ideal for quickly measuring engine temperature.
511-4017
Optical Sensor Tester 4 & 6 Cylinder
Used to set timing on a 4 or 6 Cyl engine or test optical sensors on the bench and on the engine. Unique buzzer allows you to set timing without having to see the LED.
511-4019
Optical Sensor Tester 3 Cylinder
Unique tester is used to test 3 Cyl optical sensors on the bench and on the engine.
511-4127
6 Cyl Optical Test Harness
Test Harness allows you to check the DVA voltages of the stator while connected to the power pack.
511-5207A 1
CDM Test Harness
Test the CDM Module DVA on the engine and isolate the kill circuit.
511-6996
Remote Starter
Controls most Johnson/Evinrude engines from 1969 thru 2017(DOES NOT WORK WITH DIGITAL THROTTLE AND SHIFT ENGINES).
511-7270
4 Cyl Optical Test Harness
Test Harness allows you to check the DVA voltages of the stator while connected to the power pack.
511-7800
Remote Starter
Controls most Mercury engines from 1970 thru 1978.
511-7900
Remote Starter
Controls most Mercury engines from 1979 thru 2005. 8 to 14 pin adapter required for 2006 and newer engines.
511-9764
Neon Spark Tester
Sealed single cylinder tester can be used to engine ground with the removable ground clip or in-line to the spark plug for engine running tests.
511-9766
Sealed Spark Gap Tester
Allows you to test up to 8 cylinders for cranking speed tests. Sealed design reduces the chances of injury and fire.
511-9770
Piercing Probes (Highly Recommended)
Allows access to wires for testing without removing the connector. Tiny hole usually reseals itself when wire heats.
511-9772
Ammeter Adapter
Used with most Digital multimeters to measure amperage output of the charging system or starter draw amperage.
511-9773NL
DVA (Peak Voltage) Adapter
Unit automatically compensates for polarity. Can be used with most quality multimeters.
511-9775
Pack Load Resistor
To load the output of ignition modules when testing ignition coils. Can be used on most outboards.
511-60A
CDI Electronics Meter
Most cost effective meter for marine use. Has voltage, temperature, amperage, ohms, and DVA readings (includes the 511-9773NL DVA Adapter).
511-9778
Compression Test Kit
Compression Test Kit includes both 12mm and 14mm Adapters.
