Undercarriage equipment

Track shoe

Many different track shoe options are available according to the job site requirements.

* XX: The number of shoe plate

Heavy duty full track guard

Heavy duty full track guard for the undercarriage of EC210B, EC240B, EC290B, EC360B and EC460B are available for hard conditions.

Foot step for lower frame For easy access and safety, foot steps are recommended according to the shoe widths.

Skid rail

Depending on the job site conditions, the top rollers can be replaced with a skid rail. Skid rails are available on the EC140B, EC210B, EC240B and EC290B.

*Available as option kit only

Retractable track gauge

For EC460B, the retractable track gauge is available for easy transportation. Special tool for high torque tightening and loosening the bolts is included in this kit.

Track gauge, retracted (for transportation): 2 390 mm

Track gauge, extracted (for working): 2 890 mm

* Available as factory installation.

Dozer blade (LC only)

Front dozer blade is available for EC140B LC to increase versatility in jobs such as dozing, backfilling trenches and speedy site clean-up.

Blade width: 2 590 mm

Blade height: 600 mm

* Available as factory installation.
