Turnbuckles TBO for use with LB-10 lashing bars The MacGregor TBO family of turnbuckles is a classic hook-eye type of securing system. The hook-eye turnbuckle is used together with the LB10 type of lashing bars and is commonly used on board older container vessels. The TBO turnbuckle length is adjusted by the double-sided threads in the turnbuckle body. The lashing bars are of a fixed length with a closed eye-loop connecting to the turnbuckle.
TBO Order number
1018030
1065373
1065374
1130238
68
Product
TBO-1G/2
TBO-1G/N
TBO-1G/N
TBO-1H/N
Weight kg
19.5
12.6
13.5
12.8
Jaw Width, mm
42
46
46
46
Length min - max, mm
1058 - 1660
900 - 1460
900 - 1470
865 - 1439
Material High tensile steel High tensile steel High tensile steel High tensile steel
Treatment Hot-dip galvanised, spindle greased Hot-dip galvanised, spindle greased Hot-dip galvanised, spindle greased Hot-dip galvanised, spindle greased
Safe Working Load Tension, kN
Details
Counter part
Design
245
Flat bar body, jaw-hook, with counter nut
ZP lashing plate, ZA-3 lashing eye, ZA-7 slewing eye, LB-10/4T/4 lashing bar
MacGregor
245
Round bar body, jaw-hook
ZP lashing plate, ZA-3 lashing eye, ZA-7 slewing eye, LB-10/4T/4 lashing bar
MacGregor
245
Round bar body, jaw-hook, with counter nut
ZP lashing plate, ZA-3 lashing eye, ZA-7 slewing eye, LB-10/4T/4 lashing bar
MacGregor
Round bar body, jaw-jaw
ZP lashing plate, ZA-3 lashing eye, ZA-7 slewing eye, LB-10/4T/4 lashing bar
MacGregor
245
