Coated SUMIBORON
H Hardened Steel
Characteristics
New Coated SUMIBORON Series achieving - higher speed - higher efficiency and - higher precision -
BNC2010
BNC2020
General Features Using a high heat resistant and tough CBN substrate coupled with a special ceramic coating, this series caters to a wide variety of applications with improved precision and longer tool life as compared to conventional CBN. There is a comprehensive lineup of economical and easy-touse insert selection, such as the cost effective double-sided, multi-cornered, one-use type inserts. BNC2010 and BNC2020 are the latest additions to the Coated SUMIBORON series, to provide even better stability and longer tool life for hardened steel machining.
BNC100
BNC160
BNC200
BNC300
BNC500
Characteristics
-
Easy Edge Management
Strong Brazing
Numbering of cutting edges.
Utilizing a new brazing method with improved strength.
Double sided, Multi-cornered One-use Insert More cost effective than conventional one-use inserts.
Special Ceramic Coating and Newly Developed CBN Substrate Provides longer tool life.
Cutting Performance
-
Application
Conditions
-
Recommended Cutting Speed (m/min)
Cutting Edge Management Before usage
General Purpos
Finishing
Hardened Steel
SUMI BORON
(Continuous to Light interrupted Rz = above 3,2)
Heavy Interrupted High Precision (Rz = 1,6 to 3,2)
High Efficiency
Cast Iron
(Carburized layer removal)
L10
After usage
Ductile Cast Iron
The edge numbers are still visible after machining, which makes the management of used cutting edges easy. BNC2010 and BNC2020 are coated in gold, which makes it easy to distinguish used edges.
