"Wave Mill" Series
WEZ 17000 E
New
Radial Axial
Rake Angle
90°
DMM
LS LF
LH
LF
LS
Body - WEZ (Shank Type) Cat. No.
mm
DC
DC
LH
WEZ 17025E02 17025E02-20 17028E02 17030E03 17032E02 17032E03 17032E03-25 17035E03 17040E03 17040E04 17050E03 17050E03-42 17050E05 17050E05-42 17063E04 17063E04-42 17063E06 17063E06-42 17080E07
15
Fig. 2
DMM
Fig. 1
-6° – -12° 6° – 15°
Dimensions (mm)
Stock
DC
DMM
LH
LS
LF
No. of Teeth
Weight (kg)
Fig.
l l l l l l l l l l l l l l l l l l l
25 25 28 30 32 32 32 35 40 40 50 50 50 50 63 63 63 63 63
25 20 25 25 32 32 25 32 32 32 32 42 32 42 32 42 32 42 32
35 35 35 40 40 40 40 40 30 30 30 30 30 30 30 30 30 30 30
85 85 85 90 90 90 90 90 105 105 105 105 105 105 105 105 105 105 105
120 120 120 130 130 130 130 130 135 135 135 135 135 135 135 135 135 135 135
2 2 2 3 2 3 3 3 3 4 3 3 5 5 4 4 6 6 7
0,38 0,25 0,40 0,43 0,71 0,69 0,44 0,72 0,81 0,79 0,93 1,41 0,89 1,37 1,10 1,58 1,08 1,56 1,39
1 2 2 2 1 1 2 2 2 2 2 2 2 2 2 2 2 2 2
Indexable Endmills
Inserts are sold separately.
Spare Parts
Identification Details Insert Screw
Wrench
Applicable Cutters WEZ 17025E02(-20) 17028E02 BFTX0407IP 17030E03 17032E02 17032E03(-25) 17035E03 17040E03 3,0 17040E04 BFTX0409IP 17050E03(-42) 17050E05(-42) 17063E04(-42) 17063E06(-42) 17080E07
H28
l = Euro stock m = Japan stock
WEZ
17
032
E
Cutter Series
Insert Size
Cutter Diameter
Round Shank
02 - 30 Number of Teeth
Shank Diameter
Recommended Cutting Conditions
H22 TRDR15IP
Recommended Tightening Torque (N·m)
