Boring Bars
For Positive DC _ _- Inserts ( a = 7°)
B/D/S…SDUC Type B Type
B/D-SDUC
D Type
(Fig.1)
Insert (ex.)
(Fig.2)
Min. Bore Dia.
Copying
D
D
Oil hole
Spare Parts Holders Steel shank
Cat. No.
Boring Bars for pos. Insert
Anti-vibration B type Anti-vibration D type with oil hole
Stock Dimensions (mm) øDmin R L ød h l 1 f e
g
B10M - SDUC R/L 0702-13
l
l 13 10
9 150 7 2,5 -8°
D12M - SDUC R/L 0702-16 D16R - SDUC R/L 0702-20 D20S - SDUC R/L 11T3-25 D25S - SDUC R/L 11T3-32 D32T - SDUC R/L 11T3-40
l
l 16 12 11 150 9 3,5 -8°
l
l 20 16 15 200 11 4,0 -6°
l
l 25 20 18 250 13 4,5 -6°
l
l 32 25 22 250 17 7,0 -6°
l
l 40 32 30 300 22 8,0 -6°
Screw
Wrench
DC T 0702
BFTX02506N 1,5
TRX08
DC T 11T3
BFTX0409N 3,4
TRX15
Fig.
Insert (ex.)
1.
2.
All figures show right hand tools. Remarks: Right handed tool holders are applicable with left handed or neutral inserts. Left handed tool holders are applicable with right handed or neutral inserts.
Holders Tool holders (S type) with screw-lock system
Cat. No.
Dimensions (mm)
R L øDmin d h l 1
S - SDUC R/L
Stock
S10K - SDUC R/L 07 S12M - SDUC R/L 07 S16R - SDUC R/L 07
l l
S20S - SDUC R/L 11 S25T - SDUC R/L 11 S32U - SDUC R/L 11
l l
l l l l
l l l l
f e
g
13 10 9 125 7 2,5 -8° 16 12 11 150 9 3,5 -8° 20 16 15 200 11 4 -6° 25 20 18 250 13 4,5 -6° 32 25 22 300 17 7,5 -6° 40 32 30 350 22 11 -6°
DC_ _ 0702_ _
DC_ _ 11T3_ _
All figures show right hand tools.
Applicable Inserts Holder
Spare Parts
Carbides, Cermets
CBN, PCD
Screw
Wrench
S - SDUC R/L S - SDQC R/L
S10K.....07
DCMT 0702_ _ NFP
DCMT 0702_ _ NSK
DCGW 0702_ _
BFTX02506N
1,5
TRX08
S12M.....07
DCMT 0702_ _ NFP
DCMT 0702_ _ NSK
DCGW 0702_ _
BFTX02506N
1,5
TRX08
S16R.....07
DCMT 0702_ _ NFP
DCMT 0702_ _ NSK
DCGW 0702_ _
BFTX02506N
1,5
TRX08
S.....11
DCMT 11T3_ _ NFP
DCMT 11T3_ _ NSK
DCGW 11T3_ _
BFTX0409N
3,4
TRX15
E16
l = Euro stock
Recommended Tightening Torque (N·m)
