Boring Bars
For Positive CC _ _- Inserts ( a = 7°)
B/D/S…SCLC Type B Type
B/D-SCLC
D Type
(Fig.1)
Insert (ex.)
(Fig.2)
Min. Bore Dia.
Bottom facing
Oil hole
Spare Parts Holders Steel shank
B08H - SCLC R/L 0602-10 B10K - SCLC R/L 0602-12 D12M - SCLC R/L 0602-14 D16R - SCLC R/L 09T3-18 D20S - SCLC R/L 09T3-22 D25T - SCLC R/L 1204-32 D32T - SCLC R/L 1204-40
Anti-vibration B type
Boring Bars for pos. Insert
Stock øDmin R L l l 10 l l 12 l l 14 l l 18 l l 22 l l 32 l l 40
Cat. No.
Anti-vibration D type with oil hole
ød
8 10 12 16 20 25 32
Dimensions (mm)
h
l1
f
7 100 5,5 9 125 6 11 150 7 15 200 11 18 250 13 23 300 17 30 300 20
g
l2
19 -13° 21 -12° 25 -10° 30 -8° 30 -7° 38 -6° 53 -6°
Fig. 1.
Screw
Insert (ex.)
BFTX02505N 1,1
CC T 0602
Wrench TRX08
BFTX02506N
2.
BFTX0407N
CC T 09T3
BFTX0409N BFTX0511N 5,0
CC T 1204
TRX15 TRX20
All figures show right hand tools. Remarks: Right handed tool holders are applicable with left handed or neutral inserts. Left handed tool holders are applicable with right handed or neutral inserts.
Holders Tool holders (S type) with screw-lock system
Cat. No.
Dimensions (mm)
R L øDmin d h l 1
S - SCLC R/L
Stock
l 2
f
g
S10K - SCLC R/L 06 S12M - SCLC R/L 06 S16R - SCLC R/L 06
s s 13 10 9 125 9 7 -12°
S16R - SCLC R/L 09 S20S - SCLC R/L 09
s s
S25T - SCLC R/L 12 S32U - SCLC R/L 12 S40V - SCLC R/L 12
s s 16 12 11 150 11 9 -10° l l
s s s
l l
l
20 16 15 200 15 11 -8° 20 16 15 200 15 11 -8° 25 20 18 250 20 13 -7° 32 25 23 300 20 17 -6° 40 32 30 350 25 22 -10° 50 40 37 400 25 27 -8°
CC_ _ 0602_ _
CC_ _ 09T3_
_
CC_ _ 1204_ _
All figures show right hand tools.
Applicable Inserts Holder
Spare Parts
Carbides, Cermets
Screw
Wrench
S - SCLC R/L
S.....06
CCMT 0602_ _ NFP
CCGW 0602_ _
-
BFTX02505N
1,1
TRX08
S16R.....09
CCMT 09T3_ _ NFP
CCGW 09T3_ _
-
BFTX0407N
3,0
TRX15
S20S.....09
CCMT 09T3_ _ NFP
CCGW 09T3_ _
-
BFTX0409N
3,4
TRX15
S.....12
CCMT 1204_ _ NFP
CCGW 1204_ _
-
BFTX0511N
5,0
TRX20
E14
l = Euro stock
q = Delivery p=
on request To be replaced by new item
Recommended Tightening Torque (N·m)
