Abrasive Spiral Bands Rubber Drum Holders Rubber drum holders marked “H” are the harder type and permit grinding at higher contact pressures. Due to their reduced elasticity they are more suitable for edge grinding.
Rubber drum holders, cylindrical
T
S
D
Cylindrical type GK 0410/3 GK 0410/6 GK 0610/3 GK 0610/6 GK 0810/3 GK 0810/6 GK 1010/6 GK 1020/6 GK 1310/6 GK 1325/6 GK 1510/6 GK 1530/6 GK 1925/6 GK 2220/6 GK 2220/6 H GK 2525/6 GK 3020/6 GK 3030/6 GK 3030/6 H GK 3825/6 GK 4530/6 GK 4530/6 H GK 5125/6 GK 6030/6 GK 6030/8 GK 7530/8 GK 10040/8 Conical type GK 201463/6 GK 292230/6 GK 362260/6
48 I 204
T
Rubber drum holders - standard type = Hardness approx. 65 Shore A
L
Order No.
Rubber drum holders, conical
Rubber drum holders - special type “H” = Hardness approx. 80 Shore A
D
J
Recommendation for use: The minimum speeds stated here are not valid if diamond abrasive sleeves are being used.
EAN 4007220
DxJxT [mm]
SxL [mm]
Acc. to ISO standards
Max. speed [RPM]
Minimum speed [RPM]
146729 146712 146743 146736 146767 146750 146774 146781 146798 146804 146811 146828 146835 146842 146859 146866 146873 146880 146897 146903 146927 146934 146941 146958 146965 146972 146989
4 x 10 4 x 10 6 x 10 6 x 10 8 x 10 8 x 10 10 x 10 10 x 20 13 x 10 13 x 25 15 x 10 15 x 30 19 x 25 22 x 20 22 x 20 25 x 25 30 x 20 30 x 30 30 x 30 38 x 25 45 x 30 45 x 30 51 x 25 60 x 30 60 x 30 75 x 30 100 x 40
3 x 40 6 x 40 3 x 40 6 x 40 3 x 40 6 x 40 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 6 x 35 8 x 35 8 x 35 8 x 35
15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1 15637-1
55.000 55.000 55.000 55.000 55.000 55.000 44.000 44.000 44.000 44.000 36.000 36.000 30.000 26.000 26.000 22.900 19.100 19.100 19.100 15.900 12.700 12.700 11.200 9.500 9.500 7.600 5.700
30.000 30.000 30.000 30.000 30.000 30.000 30.000 30.000 30.000 30.000 26.000 26.000 20.000 18.000 18.000 16.000 13.000 13.000 13.000 10.000 8.500 8.500 7.500 6.500 6.500 5.000 4.000
5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
44 89 48 93 50 95 50 60 54 80 60 100 104 102 102 130 138 187 187 248 445 445 470 670 770 1.025 2.250
147078 147085 147092
20 x 14 x 63 29 x 22 x 30 36 x 22 x 60
6 x 37 6 x 40 6 x 40
-
26.000 19.100 15.900
19.000 13.000 10.000
5 5 5
190 167 370
