Polishing Tools Cloth Rings ■■High-gloss polishing of all metals, cloth rings TW or FL with polishing paste PP 4 HGP ■■High-gloss polishing of plastics, cloth rings TW or FL with polishing paste PP 5 HGP K
Cloth rings are used with polishing pastes for preliminary and high-gloss polishing.
Cloth rings
For very smooth finishes it may be recommended to use several, or even all, types in succession.
Recommended cutting speed: TW and FL 5 - 15 m/s ST and TH 10-15 m/s
These tools are available in four types: ST sisal fabric = pre-polishing TH hard cloth = pre-polishing TW soft cloth = high-gloss polishing FL flannel = high-gloss polishing
Ordering note: Please order arbors separately. TR 12510, version ST (sisal cloth): 10 mm centre hole dia. (25,4/hexagonal, arbor FR/ VR 12/25,4)
Recommendation for use: ■■Pre-polishing of steel or stainless steel, cloth ring ST or TH with polishing paste PP 1 VP Fe ■■Pre-polishing of aluminium or brass, cloth ring ST or TH with polishing paste PP 2 VP MS ■■Pre-polishing of non-ferrous metals, cloth ring ST or TH with polishing paste PP 3 VP NE
Order No.
Type FL Flannel
ST Sisal fabric
TH Hard cloth
TW Soft cloth
Ordering example: EAN 4007220294185 TR 12510-20 TW How to order: TR = Cloth ring 12510 = Dia. x in use width [mm] 20 = Centre hole dia. H [mm] TW = Soft cloth Please state required design.
Dia. D [mm]
H [mm]
Useful width [mm]
Recom. speed [RPM]
Max. speed [RPM]
12.000 7.500 6.100
Suitable matching arbors
EAN 4007220 TR 5010-6 TR 8010-10 TR 10010-10
804339 294116 294154
294086 294123
804315 294093 294130
804322 294109 294147
50 80 100
6 10 10
10 10 10
3.800 2.500 1.900
TR 12510-20
294192
294161
294178
294185
125
20
10
1.300
TR 15010-20
294239
294208
294215
294222
150
20
10
1.250
TR 20010-20
294277
294246
294253
294260
200
20
10
950
BO 6/6 3-10 BO 8/10 6-20 BO 8/10 6-20 BO 12/20 10-50, 4.900 BO MK 1/20 10-50 BO 12/20 10-50, 4.000 BO MK 1/20 10-50 BO 12/20 10-50, 3.000 BO MK 1/20 10-50
5 5 5
230 285 485
5
694
5
1.070
5
1.810
Arbors Re-usable arbor for cloth rings.
Arbors
These arbors reduce set-up times significantly. Tools can be changed without removing the arbor from the machine spindle.
BO 6/6 3-10 BO 8/10 6-20
Explanation of the code system: S = Shank diameter [mm] L = Shank length [mm]
BO 12/20 10-50
BO MK 1/20 10-50
Order No.
BO 6/6 3-10 BO 8/10 6-20 BO 12/20 10-50 BO MK 1/20 10-50
108 I 204
EAN 4007220
Suitable for centre hole [mm]
SxL [mm]
Clamping width [mm]
297650 297667 297674 297681
6 10 20 20
6 x 25 8 x 30 12 x 35 -
3-10 6-20 10-50 10-50
1 1 1 1
38 88 360 370
