WXL-EBD
R
d
Milling | Solid carbide
l L
Carbide end mill with WXL coating For high speed milling in steels, stainless and cast iron 2 flutes, ball nose
○ ◉
~45 HRC
CARBIDE
P
○ ◉
M
◉
K
◉
~55 HRC
~35 HRC
~350 HB
WXL
30˚
FIT
SHRINK
N
○
S
○
H
○
~60 HRC
R
± 0.005 3>R
R
R
0.003~-0.007 3≤R≤6
± 0.01 6<R
C.897
EDP
Z
D
R
L
l
d
3106350 3106400 3105400 3106401 3106860 3106500 3106501 3106502 3106870 3106600 3106601 3106880 3106610 3106890 3106620 3106621 3106900 3106630 3106910 3106640 3106641 3106650 3106660 3106661 3106920 3106670 3106930 3106680 3106690 3106700
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
3,5 4 4 4 4,5 5 5 5 5,5 6 6 6,5 7 7,5 8 8 8,5 9 9,5 10 10 11 12 12 13 14 15 16 18 20
1,75 2 2 2 2,25 2,5 2,5 2,5 2,75 3 3 3,25 3,5 3,75 4 4 4,25 4,5 4,75 5 5 5,5 6 6 6,5 7 7,5 8 9 10
70 70 60 70 80 80 80 80 80 90 90 90 90 90 100 100 100 100 100 100 100 100 110 110 110 110 110 140 140 160
8 6 8 8 8 8 10 12 10 10 12 13 14 14 12 14 16 18 18 15 18 22 18 22 24 26 28 30 34 38
6 6 4 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 10 10 10 12 12 12 12 12 16 16 20
Milling | Solid carbide
P
C 661
