PSE SCREW FIT
D2
Da
D
Dg
Milling | Indexables
l2
90° shoulder cutter 2 corners inserts with bottom notch Screw fit type 16 - 40 mm
90° C.839
C.845
Designation
Z
D
Dg
l2
D2
Wrench size
ap max
Applicable inserts type
Da
7801600 7801601 7801602 7801603 7801604 7801605 7801606 7801607 7801608 7801609 7801610 7801611
PSE11R016SF8-2 PSE11R020SF10-3 PSE11R025SF12-4 PSE11R028SF12-4 PSE11R032SF16-5 PSE11R035SF16-5 PSE11R040SF16-6 PSE15R025SF12-2 PSE15R028SF12-2 PSE15R032SF16-3 PSE15R035SF16-3 PSE15R040SF16-4
2 3 4 4 5 5 6 2 2 3 3 4
16 20 25 28 32 35 40 25 28 32 35 40
8 10 12 12 16 16 16 12 12 16 16 16
27 33 35 35 40 40 40 35 35 40 40 40
14,5 18 23 23 28 28 28 23 23 28 28 28
10 14 17 17 22 22 22 17 17 22 22 22
10 10 10 10 10 10 10 14 14 14 14 14
ZD…T11… ZD…T11… ZD…T11… ZD…T11… ZD…T11… ZD…T11… ZD…T11… ZD…T15… ZD…T15… ZD…T15… ZD…T15… ZD…T15…
8,5 10,5 12,5 12,5 17 17 17 12,5 12,5 17 17 17
90 degrees
Milling | Indexables
EDP
Accessories & spare parts
Applicable cutter
C 820
C.972
Clamping screw
Wrench
ZD-T11 Ø 16 ~ 40
7808107
FS25656P (Torx 8IP)
7808225
8P-D (Torx 8IP)
ZDKT15 Ø 25 ~ 63
7808115
FS35686P (Torx 15IP)
7808228
15IP-D (Torx 15IP)
