Wheel Brushes Wheel Brushes with Arbor Hole, Individual Filament Type Excellent for medium-duty brushing (handheld or stationary) of large surface areas.
RBU = Wheel brushes, individual filament type, extra wide
Packaging unit: 1 piece
l2
Recommendation for use: Tool contact pressure should be kept low. Ensure that workpiece contact is made by wire ends only.
d2 d1
Ordering example: EAN 4007220658710 RBU 10020/14,0 ST 0,30 SG
b
Steel wire, performance line SG Order No.
RBU 10020/14,0 ST 0,30 SG RBU 10028/14,0 ST 0,30 SG RBU 12520/14,0 ST 0,30 SG RBU 12528/14,0 ST 0,30 SG RBU 15025/AK32-2 ST 0,30 SG RBU 15038/AK32-2 ST 0,30 SG RBU 18025/AK32-2 ST 0,30 SG RBU 20025/AK32-2 ST 0,30 SG RBU 20038/AK32-2 ST 0,30 SG RBU 25030/AK32-2 ST 0,30 SG RBU 25048/AK32-2 ST 0,30 SG RBU 30040/50,8 ST 0,30 SG
EAN 4007220
Wire dia. d6 [mm]
Brush dia. d1 [mm]
Trim width b [mm]
Trim length l2 [mm]
Arbor hole dia d2 [mm]
Basic hole dia. [mm]
Recom. speed [RPM]
Max. speed [RPM]
658710 153604 806852 806869 658727 153628 658741 658765 153635 658772 220924 616086
0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30
100 100 125 125 150 150 180 200 200 250 250 300
20 28 20 28 25 38 25 25 38 30 48 40
24 24 30 30 25 25 40 38 38 50 50 40
14,0 14,0 14,0 14,0 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2 50,8
25,4 25,4 25,4 25,4 50,8 50,8 50,8 85,4 85,4 117,5 117,5 117,5
4.000 - 6.000 4.000 - 6.000 4.000 - 6.000 4.000 - 6.000 3.000 - 4.500 3.000 - 4.500 3.000 - 4.500 2.300 - 3.400 2.300 - 3.400 1.800 - 2.700 1.800 - 2.700 1.500 - 2.500
8.000 8.000 8.000 8.000 6.000 6.000 6.000 4.500 4.500 3.600 3.600 3.000
0,334 0,553 0,377 0,600 0,833 1,486 0,928 1,373 1,928 2,260 3,300 3,914
Stainless steel (INOX) wire, performance line SG All stainless steel (INOX) brushes are degreased. Order No.
Wire dia. d6 [mm]
Brush dia. d1 [mm]
Trim width b [mm]
Trim length l2 [mm]
Arbor hole dia d2 [mm]
Basic hole dia. [mm]
Recom. speed [RPM]
Max. speed [RPM]
806876 806883 658789 220887 658871 658895 220900 658901 220931
0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30 0,30
125 125 150 150 180 200 200 250 250
20 28 25 38 25 25 38 30 48
30 30 25 25 40 38 38 50 50
14,0 14,0 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2 AK32-2
25,4 25,4 50,8 50,8 50,8 85,4 85,4 117,5 117,5
3.200 - 5.200 3.200 - 5.200 2.400 - 3.900 2.400 - 3.900 2.400 - 3.900 1.800 - 2.900 1.800 - 2.900 1.400 - 2.300 1.400 - 2.300
8.000 8.000 6.000 6.000 6.000 4.500 4.500 3.600 3.600
0,377 0,600 0,833 1,486 0,928 1,373 1,928 2,260 3,300
208
RBU 12520/14,0 INOX 0,30 SG RBU 12528/14,0 INOX 0,30 SG RBU 15025/AK32-2 INOX 0,30 SG RBU 15038/AK32-2 INOX 0,30 SG RBU 18025/AK32-2 INOX 0,30 SG RBU 20025/AK32-2 INOX 0,30 SG RBU 20038/AK32-2 INOX 0,30 SG RBU 25030/AK32-2 INOX 0,30 SG RBU 25048/AK32-2 INOX 0,30 SG
EAN 4007220
An adapter set AK 32-2 is included with each brush order. Arbor holes contained in set in mm (inches): 31,75/20/18/14/12/25,4 (1)/ 22,2 (7/8)/19,2 (.750)/ 16 (5/8), 12,7 (1/2). Adapter set AM 51 can also be used on applications with high heat development and applications of force.
Exception: Brushes with dia. 100 and 125 mm are supplied with variable arbor holes 22,2/18 and 14 mm. It is not possible to use the adapter set AM 51. RBU 30040 is supplied with arbor hole 50,8 mm. The arbor hole can be reduced to the required dimension using the adapter set AM 51. Please refer to pages 43-44 for detailed information and ordering data regarding appropriate adapter systems and accessory parts on pages 43-44.
BO 8/12-22,2 5-18 (EAN 4007220751923) is suitable for RBU 10020 and 12520, BO 8/22,2 5-10 (EAN 4007220751930) for RBU 10028 and 12528 and BO 12/22,2 10-30 (EAN 4007220561317) for RBU 15025 and 15038. For safety reasons, the use of arbors is limited for brushes with max. dia. 150 mm.
208 I 11
