J225 Solid Carbide Thread Mill with Through Coolant, Metric Fine
Universal high performance tool to machine same or bigger diameters than the TDZ with the same pitch. Left or right-hand, through or blind holes almost down to the bottom. With Alcrona Pro coated for the best machining result and through coolant for better chip evacuation.
l 10°
R
Alcrona Pro
Workpiece material group suitability, starting values for cutting speed (m/min) and Alpha Code. Tables with feed per tooth and correction factors can be found starting from page 234.
P1.1
P1.2
P1.3
P2.1
P2.2
P2.3
P3.1
P3.2
P3.3
P4.1
P4.2
P4.3
M1.1
M1.2
M2.1
M2.2
M2.3
M3.1
M3.2
M3.3
M4.1
M4.2
K1.1
K1.2
K1.3
K2.1
K2.2
K2.3
K3.1
K3.2
K3.3
K4.1
K4.2
K4.3
K4.4
K4.5
K5.1
K5.2
K5.3
N1.1
N1.2
N1.3
N2.1
N2.2
N2.3
N3.1
N3.2
N3.3
N4.1
N4.2
N4.3
S1.1
S1.2
S1.3
S2.1
S2.2
S3.1
S3.2
S4.1
S4.2
H1.1
H3.1
190 E 61 E
120 E 288 F 28 D
212 E 50 E 91 E
259 F 23 D
242 E 42 E 74 E
187 F 22 D
163 E 52 D
111 D 671 F 18 D
143 E 44 D 84 D
396 F 66 D
127 E 40 D 62 D
198 F
146 E 33 D 53 D
319 F
118 E
99 E
29 D
143 E
44 D
126 E
160 F
72 F
87 E
106 E 95 E
44 D
74 E 80 E 73 E
44 D
61 E
136 E 440 F 33 D
69 E
58 E
110 E
88 E
330 F
220 F
36 D
28 D
48 D
Internal Thread.
Product J2258.0X1.0 J22510.0X1.0 J22510.0X1.5 J22512.0X1.0 J22512.0X1.5 J22514.0X1.0 J22514.0X1.5 J22516.0X1.5
TDZ
TP
DC
APMX
OAL
DCON MS
[mm]
[mm]
[mm]
[mm]
[mm]
M10 M12 M12 M14 M14 M16 M16 M18
1.00 1.00 1.50 1.00 1.50 1.00 1.50 1.50
8.00 10.00 10.00 12.00 12.00 14.00 14.00 16.00
16.00 20.00 20.00 22.00 22.00 26.00 26.00 30.00
63.0 72.0 72.0 83.0 83.0 83.0 83.0 92.0
8.00 10.00 10.00 12.00 12.00 14.00 14.00 16.00
NOF
4 4 4 4 4 5 5 5
