J200 Solid Carbide Thread Mill with Countersink, Metric
DCON MS
Universal high performance tool to machine same or bigger diameters than the TDZ with the same pitch. Left or right-hand, through or blind holes almost down to the bottom. With 60° countersink for chamfering in a single machining cycle. Alcrona Pro coated for the best machining result in a wide range of materials.
DC
60°
APMX LU OAL
l 10°
R
Alcrona Pro
DIN 6535HA
Workpiece material group suitability, starting values for cutting speed (m/min) and Alpha Code. Tables with feed per tooth and correction factors can be found starting from page 234.
P1.1
P1.2
P1.3
P2.1
P2.2
P2.3
P3.1
P3.2
P3.3
P4.1
P4.2
P4.3
M1.1
M1.2
M2.1
M2.2
M2.3
M3.1
M3.2
M3.3
M4.1
M4.2
K1.1
K1.2
K1.3
K2.1
K2.2
K2.3
K3.1
K3.2
K3.3
K4.1
K4.2
K4.3
K4.4
K4.5
K5.1
K5.2
K5.3
N1.1
N1.2
N1.3
N2.1
N2.2
N2.3
N3.1
N3.2
N3.3
N4.1
N4.2
N4.3
S1.1
S1.2
S1.3
S2.1
S2.2
S3.1
S3.2
S4.1
S4.2
H1.1
172 B 55 B
109 B 262 C 25 A
193 B 45 B 83 B
235 C 21 A
200 B 38 B 67 B
170 C 20 A
148 B 47 A
101 A 610 C 16 A
130 B 40 A 76 A
360 C
115 B 36 A 56 A
180 C
133 B 30 A 48 A
290 C
107 B 26 A 40 A
145 C
90 B
130 B 114 B 65 C
79 B 96 B 86 B
40 A
67 B 72 B 66 B
40 A
55 B
123 B 400 C 30 A
62 B
100 B 300 C 33 A
52 B 80 B
200 C 25 A
60 A
Internal Thread.
Product J2003.2X.7 J2004.1X.8 J2004.8X1.0 J2006.5X1.25 J2008.2X1.5 J2009.9X1.75 J20011.6X2.0 J20013.6X2.0
224
TDZ
TP
DC
APMX
OAL
DCON MS
[mm]
[mm]
[mm]
[mm]
[mm]
M4 M5 M6 M8 M10 M12 M14 M16
0.70 0.80 1.00 1.25 1.50 1.75 2.00 2.00
3.20 4.10 4.80 6.50 8.20 9.90 11.60 13.60
8.40 11.20 13.00 17.50 21.00 26.25 30.00 34.00
57.0 57.0 63.0 72.0 83.0 83.0 92.0 92.0
6.00 6.00 8.00 10.00 12.00 14.00 16.00 18.00
NOF
LU
3 3 3 3 3 4 4 4
9.50 12.10 14.40 19.10 22.80 28.20 32.20 36.20
[mm]
