Recommended Cutting Condition [ WAE30(2)3, WAR303 series ] WORKPIECE
Technical Data [ WAR302 series ]
► Side cutting , General Cutting ALUMINIUM, NONFERROUS METALS
WORKPIECE
DIAMETER(mm)
RPM
FEED
3 4 5 6 8 10 12 14 16 18 20
7,000
455
7,000
546
7,000
651
7,000
756
5,600
861
5,600
1,050
5,600
882
4,200
1106
4,200
1,211
2,800 2,800
910 956
DIAMETER(mm)
4 6 8 10 12 14 16 18 20
► Side cutting , General Cutting
ALUMINIUM ALLOY (＜Si 4%)
ALUMINIUM ALLOY (＜Si 8%)
ALUMINIUM ALLOY (DIE CASTING)
ALUMINIUM ALLOY (Cu)
RPM
FEED
RPM
FEED
RPM
FEED
RPM
FEED
24,000
4,800
19,900
3,980
16,000
3,200
12,000
2,400
16,000
3,840
13,200
3,160
10,600
2,544
8,000
1,920
12,000
3,600
9,900
2,970
8,000
2,400
6,000
1,800
9,500
3,420
8,000
2,880
6,300
2,260
4,800
1,720
8,000
3,200
6,600
2,640
5,300
2,120
4,000
1,600
6,800
2,990
5,600
2,460
4,500
1,980
3,400
1,490
6,000
3,000
5,000
2,500
4,000
2,000
3,000
1,500
5,300 4,800
2,600 2,400
4,400 4,000
2,200 2,000
3,500 3,200
1,750 1,600
2,600 2,400
1,300 1,200
RPM = rev. / min. FEED = mm / min.
RPM = rev. / min. FEED = mm / min.
2.5D 0.15D
[ WAR302 series ]
※ Please reduce cutting speed around 20~30% from the above table or AE323 series.
[ WAE30(2)3, WAR303 series ] WORKPIECE
WORKPIECE
► Slotting, General Cutting ALUMINIUM, NONFERROUS METALS
DIAMETER(mm)
RPM
FEED
3 4 5 6 8 10 12 14 16 18 20
7,000
350
7,000
441
7,000
504
7,000
606
5,600
700
5,600
854
5,600
1,050
4,200
903
4,200
945
2,800 2,800
700 805
RPM = rev. / min. FEED = mm / min.
► Slotting, General Cutting
ALUMINIUM ALLOY (＜Si 4%)
ALUMINIUM ALLOY (＜Si 8%)
ALUMINIUM ALLOY (DIE CASTING)
ALUMINIUM ALLOY (Cu)
DIAMETER(mm)
RPM
FEED
RPM
FEED
RPM
FEED
RPM
FEED
4 6 8 10 12 14 16 18 20
24,000
3,840
19,900
2,980
16,000
2,240
12,000
1,440
16,000
3,072
13,200
2,370
10,600
1,780
8,000
1,150
12,000
2,880
9,900
2,230
8,000
1,680
6,000
1,080
9,500
2,730
8,000
2,160
6,300
1,580
4,800
1,030
8,000
2,560
6,600
1,980
5,300
1,480
4,000
960
6,800
2,390
5,600
1,845
4,500
1,380
3,400
890
6,000
2,400
5,000
1,870
4,000
1,400
3,000
900
5,300 4,800
2,080 1,920
4,400 4,000
1,650 1,500
3,500 3,200
1,220 1,260
2,600 2,400
780 720
RPM = rev. / min. FEED = mm / min.
1.0D 1.0D
1.0D 1.5D
