ZR704
- Excellent machinability with cutting edge considered the characteristics of high hardness workpiece R
- Extend customer choice with various corner R size and effective length
D
D2
13°
L1
L3
L2
R D
D2
13°
L1
L3
L2 ■
ULTRA FINE
30
TOLERANCE
DATA 0.01
HELIX
~ D6 D8 ~ 12
0.015
Φ6 OR UNDER ABOVE Φ6
D
SHANK DIA. 0 ~ -0.012mm 0 ~ -0.015mm
h5
p.458
EDP No
D
R
L1
L3
L2
D2
EDP No
D
R
L1
L3
L2
D2
ZR704 010 01 03 S4 ZR704 010 01 04 S4 ZR704 010 01 06 S4 ZR704 010 02 03 S4 ZR704 010 02 04 S4 ZR704 010 02 06 S4 ZR704 010 03 03 S4 ZR704 010 03 04 S4 ZR704 010 03 06 S4 ZR704 015 01 04 S4 ZR704 015 01 06 S4 ZR704 015 02 04 S4 ZR704 015 02 06 S4 ZR704 015 03 04 S4 ZR704 015 03 06 S4 ZR704 020 01 06 S4 ZR704 020 01 08 S4 ZR704 020 02 06 S4 ZR704 020 02 08 S4 ZR704 020 03 06 S4 ZR704 020 03 08 S4 ZR704 020 05 06 S4 ZR704 020 05 08 S4 ZR704 020 02 08 ZR704 020 02 10 ZR704 020 02 12 ZR704 025 01 06 S4 ZR704 030 01 08 ZR704 030 01 10 ZR704 030 01 12 ZR704 030 01 16 ZR704 030 01 20 ZR704 030 02 08 ZR704 030 02 10 ZR704 030 02 12 ZR704 030 02 16 ZR704 030 02 20 ZR704 030 03 08
1 1 1 1 1 1 1 1 1 1.5 1.5 1.5 1.5 1.5 1.5 2 2 2 2 2 2 2 2 2 2 2 2.5 3 3 3 3 3 3 3 3 3 3 3
0.1 0.1 0.1 0.2 0.2 0.2 0.3 0.3 0.3 0.1 0.1 0.2 0.2 0.3 0.3 0.1 0.1 0.2 0.2 0.3 0.3 0.5 0.5 0.2 0.2 0.2 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.2 0.2 0.2 0.3
2 2 2 2 2 2 2 2 2 2.5 2.5 2.5 2.5 2.5 2.5 3 3 3 3 3 3 3 3 3 3 3 3.5 4 4 4 4 4 4 4 4 4 4 4
3 4 6 3 4 6 3 4 6 4 6 4 6 4 6 6 8 6 8 6 8 6 8 8 10 12 6 8 10 12 16 20 8 10 12 16 20 8
50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 50 55 55 55 55 60 55 55 55 55 60 55
4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 6 6 6 4 6 6 6 6 6 6 6 6 6 6 6
ZR704 030 03 09 ZR704 030 03 10 ZR704 030 03 12 ZR704 030 03 16 ZR704 030 03 20 ZR704 030 05 08 ZR704 030 05 09 ZR704 030 05 10 ZR704 030 05 12 ZR704 030 05 16 ZR704 030 05 20 ZR704 030 10 08 ZR704 030 10 10 ZR704 030 10 12 ZR704 030 10 16 ZR704 030 10 20 ZR704 040 01 10 ZR704 040 01 12 ZR704 040 01 16 ZR704 040 01 20 ZR704 040 01 25 ZR704 040 02 10 ZR704 040 02 12 ZR704 040 02 16 ZR704 040 02 20 ZR704 040 02 25 ZR704 040 03 10 ZR704 040 03 12 ZR704 040 03 16 ZR704 040 03 20 ZR704 040 03 25 ZR704 040 05 10 ZR704 040 05 12 ZR704 040 05 16 ZR704 040 05 20 ZR704 040 05 25 ZR704 040 10 10 ZR704 040 10 12
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
0.3 0.3 0.3 0.3 0.3 0.5 0.5 0.5 0.5 0.5 0.5 1 1 1 1 1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.3 0.3 0.3 0.5 0.5 0.5 0.5 0.5 1 1
4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
9 10 12 16 20 8 9 10 12 16 20 8 10 12 16 20 10 12 16 20 25 10 12 16 20 25 10 12 16 20 25 10 12 16 20 25 10 12
55 55 55 55 60 55 55 55 55 55 60 55 55 55 55 60 55 55 55 60 60 55 55 55 60 60 55 55 55 60 55 55 55 60 60 60 55 55
6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
42
ZR704
4 FLUTES NECK TYPE RADIUS ENDMILL EDP No
D
R
L1
L3
L2
D2
ZR704 040 10 16 ZR704 040 10 20 ZR704 040 10 25 ZR704 060 02 20 ZR704 060 03 20 ZR704 060 05 20 ZR704 060 10 20 ZR704 060 15 20 ZR704 060 20 20 ZR704 080 02 25 ZR704 080 03 25 ZR704 080 05 25 ZR704 080 10 25 ZR704 080 15 25 ZR704 080 20 25 ZR704 100 02 32 ZR704 100 03 32 ZR704 100 05 32 ZR704 100 10 32 ZR704 100 15 32 ZR704 100 20 32 ZR704 120 03 38 ZR704 120 05 38 ZR704 120 10 38 ZR704 120 15 38 ZR704 120 20 38
4 4 4 6 6 6 6 6 6 8 8 8 8 8 8 10 10 10 10 10 10 12 12 12 12 12
1 1 1 0.2 0.3 0.5 1 1.5 2 0.2 0.3 0.5 1 1.5 2 0.2 0.3 0.5 1 1.5 2 0.3 0.5 1 1.5 2
6 6 6 9 9 9 9 9 9 12 12 12 12 12 12 15 15 15 15 15 15 18 18 18 18 18
16 20 25 20 20 20 20 20 20 25 25 25 25 25 25 32 32 32 32 32 32 38 38 38 38 38
55 60 60 60 60 60 60 60 60 60 60 60 60 60 60 70 70 70 70 70 70 80 80 80 80 80
6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 10 10 10 10 10 10 12 12 12 12 12
EDP No
D
R
L1
L3
L2
D2
※The above specifications are subject to change without prior notice for product quality improvement.
■Applicable Working Material Carbon Steel ~ HB225
Alloy Steel HB225~325
Prehardened Steel HRc30~50
○
○
Hardened Steel SKD61 SKD11 ~HRc55 ~HRc55 ◎ ◎
Copper
Graphite
Cast Iron Stainless Aluminum ~FCD500 Steel
○ ○ : GOOD ◎ : EXCELLENT
43
STAR
STAR
4 FLUTES NECK TYPE RADIUS ENDMILL
