XR504
- Excellent chip emission and smooth workpiece surface finish by applying Unequal Index flutes
D2
D2
D
X-Star
X-Star
D
D
D2
13°
L1
L2 ■
M 0.01
TOLERANCE
DATA
D1 ~ 12 D13 ~ 25
0.02
HELIX
ALL SIZES
■
D
SHANK DIA. 0 ~ -0.02mm 0 ~ -0.03mm
h6
ULTRA FINE
M
5
0.01
TOLERANCE
DATA
D1 ~ 8 D10 ~ 25
0.02
HELIX
p.517-519
ALL SIZES
D
SHANK DIA. 0 ~ -0.02mm 0 ~ -0.03mm
h6
p.517-519
EDP No
D
R
L1
L2
D2
EDP No
D
R
L1
L2
D2
XR504 020 XR504 030 XR504 040 XR504 050 XR504 060 XR504 070 XR504 080 XR504 090 XR504 100 XR504 110 XR504 120 XR504 130 XR504 140 XR504 160 XR504 180 XR504 200 XR504 250
2 3 4 5 6 7 8 9 10 11 12 13 14 16 18 20 25
0.1 0.1 0.2 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
5 8 11 13 13 16 19 19 22 22 26 26 26 32 32 38 45
45 50 50 50 50 60 60 70 70 75 75 80 80 90 100 100 120
4 6 6 6 6 8 8 10 10 12 12 12 14 16 18 20 25
XR505 06 050 XR505 08 050 XR505 10 050 XR505 12 075 XR505 14 075 XR505 14 075 S16 XR505 16 100 XR505 18 100 XR505 18 100 S20 XR505 20 100 XR505 25 100
6 8 10 12 14 14 16 18 18 20 25
0.5 0.5 0.5 0.75 0.75 0.75 1 1 1 1 1
13 19 22 26 26 26 32 32 32 38 38
57 63 72 83 83 92 92 92 104 104 104
6 8 10 12 14 16 16 18 20 20 25
※The above specifications are subject to change without prior notice for product quality improvement.
※The above specifications are subject to change without prior notice for product quality improvement.
※ Flat shank is available upon request ex) XR504100F : Flat shank
■Applicable Working Material Carbon Steel ~ HB225 ◎
■Applicable Working Material
Prehardened Alloy Steel Steel HB225~325 HRc30~50 ◎
○
Hardened Steel SKD61 SKD11 ~HRc55 ~HRc55
Copper ○
Graphite
Cast Iron Stainless Aluminum ~FCD500 Steel ◎ ○ : GOOD ◎ : EXCELLENT
230
- Excellent machining surface with proper design of rake angle considered the characteristics of workpiece.
L2
L2
R
- Excellent wear resistance with high hardness cutting edge
R
L1
L1
ULTRA FINE
- Excellent chip emission and smooth workpiece surface finish by applying Unequal Index flutes
- Excellent wear resistance with high hardness cutting edge
R
XR505
5 FLUTES VARIABLE HELIX RADIUS ENDMILL
4 FLUTES VARIABLE HELIX RADIUS ENDMILL
Carbon Steel ~ HB225
Alloy Steel HB225~325
Prehardened Steel HRc30~50
◎
◎
○
Hardened Steel SKD61 SKD11 ~HRc55 ~HRc55
Copper ○
Graphite
Cast Iron Stainless Aluminum ~FCD500 Steel ◎ ○ : GOOD ◎ : EXCELLENT
