XXB504
- Excellent chip emission and smooth workpiece surface finish by applying Unequal Index flutes C
- Anti-bending strength with double core type L1
L2
L2
D
D2
C
X-Star
■
M 0.01
SH
0.01
HELIX
ALL SIZES
X-Star
L1
ULTRA FINE
- Applying chamfer type on end face to reduce cutting edge chipping
D2
- Suitable for semi-finishing and finishing by 4 flutes cutting
D2
D L1
- Excellent chip emission and smooth workpiece surface finish by applying Unequal Index flutes
D
R
XCC503
3 FLUTES DOUBLE CORE CHAMFER ENDMILL
4 FLUTES VARIABLE HELIX BALL NOSE ENDMILL
L2
TOLERANCE
■
D
DATA
ALL SIZES
SHANK DIA. 0 ~ -0.02mm
h6
M
ULTRA FINE
HELIX
TOLERANCE D
DATA
C
ALL SIZES
SHANK DIA. 0 ~ -0.02mm
h6
p.517-519
p.517-519
EDP No
D
R
L1
L2
D2
EDP No
D
C
L1
L2
D2
XXB504 040 XXB504 060 XXB504 080 XXB504 100 XXB504 120
4 6 8 10 12
2 3 4 5 6
8 12 15 20 25
70 90 100 100 110
4 6 8 10 12
XCC503 020 XCC503 025 XCC503 030 XCC503 035 XCC503 040 XCC503 045 XCC503 050 XCC503 055 XCC503 060 XCC503 080 XCC503 100 XCC503 120 XCC503 160 XCC503 200 XCC503 250
2 2.5 3 3.5 4 4.5 5 5.5 6 8 10 12 16 20 25
0.025 0.025 0.035 0.035 0.045 0.045 0.055 0.055 0.075 0.1 0.125 0.15 0.2 0.25 0.3
6 8 10 10 12 14 15 15 15 20 25 30 40 45 50
50 50 50 50 50 50 50 50 50 60 70 75 90 100 120
6 6 6 6 6 6 6 6 6 8 10 12 16 20 25
※The above specifications are subject to change without prior notice for product quality improvement.
※ Flat shank is available upon request ex) XXB504100F : Flat shank
※The above specifications are subject to change without prior notice for product quality improvement.
※ Flat shank is available upon request ex) XXC503100F : Flat shank
■Applicable Working Material Carbon Steel ~ HB225 ◎
■Applicable Working Material
Prehardened Alloy Steel Steel HB225~325 HRc30~50 ◎
○
Hardened Steel SKD61 SKD11 ~HRc55 ~HRc55
Copper ○
Graphite
Cast Iron Stainless Aluminum ~FCD500 Steel ◎ ○ : GOOD ◎ : EXCELLENT
218
Carbon Steel ~ HB225
Alloy Steel HB225~325
Prehardened Steel HRc30~50
◎
◎
○
Hardened Steel SKD61 SKD11 ~HRc55 ~HRc55
Copper ○
Graphite
Cast Iron Stainless Aluminum ~FCD500 Steel ◎ ○ : GOOD ◎ : EXCELLENT
