General H-Form Stick Rack Assembly Instructions
NOTE: This Stick Rack requires 1 person to assemble.
General H-Form Stick Rack Assembly Instructions
Tools Required
Screwdriver Allen Key
Components
A End Frames (2x) B Crossmembers (varies depending on length of gondola ordered)
C Centre Post (varies depending on length of gondola ordered)
D Back Panel (varies depending on length of gondola ordered)
G Graphic Frames (4x)
E In-Line accessories (varies)
F End Cap accessories (varies)
K Socket Screws (varies)
H Printed Fabric (4x)
I Top Cap (2x)
J End Panel (2x)
General H-Form Stick Rack Assembly Instructions
1 . Begin with taking one of the End FramesInstall Levellers
3. Tighten with supplied hardware
A
2 . Insert Top and Bottom Connectors. K
4. Insert first Back Panel
B
D
General H-Form Stick Rack Assembly Instructions
5. Attach Centre Post . Install Levellers.
Tighten with supplied hardware
7. Repeat until ordered length of gondola is finished (4ft, 6ft, 8ft, etc.)
Use Connectors and back panels
B D C
K 6.
General H-Form Stick Rack Assembly Instructions
9. K 8.
J I
Tighten with supplied hardware
Install End Panels and Top Caps
General H-Form Stick Rack Assembly Instructions
Install In-Line StickTrays and accessories E 10.
11.
F.
Install End Cap Accessories
General H-Form Stick Rack Assembly Instructions
12. Install Graphic Frames
Making sure bump out goes on bottom. Lastly, install Printed fabric panels as indicated in separate instructions.
G.
