WELDING & GAS Cable Connectors
ARC WELDING CABLES & HOLDERS
Electrode Holder – Twistlock
• Suitable for 2.0 – 5.0mm diameter electrodes • Fully insulated to ensure operator protection • Copper shim provided for improved conductivity • Enhanced operator appeal due to twist lock design • Suitable for welding, fabrication and maintenance applications Mfr No. FTH18-04
Description Twist lock holder to 5.0mm diameter
Amperage 400
Part Number 0317 2616
Welding Work Clamps
• Spring loaded work clamp to maximise earthing potential • High clamping pressure • Copper braiding for improved conductivity • Sturdy carbon steel construction • Suitable for welding, fabrication and maintenance applications
Type Spring loaded Spring loaded
Mfr No. MQ7090-20 MQ7090-21 MQ7797-30 MQ7797-31 MQ7512-40 MQ7512-41
Description Dinse female Dinse male Dinse female Dinse male Dinse female Dinse male
Size mm² 25 25 50 50 70 70
Part Number 0317 2463 0317 2480 0317 2497 0317 2514 0317 2531 0317 2548
500A Cable Connector – Twist Lock
SFC25-03 Mfr No. SFC25-03 SFC26-05
• High quality brass construction • Rubber boot provided for insulation purposes • Copper shim provided for improved conductivity • Easy replacement within the field • Suitable for welding, fabrication and maintenance applications
Amperage 300 500
Part Number 0317 2429 0317 2446
Arc Welding Lead Sets
• Male/Female connector designed to extend cable length in the field • High quality brass construction • Rubber boot provided for insulation purposes • Copper shim provided for improved conductivity • 500Amp rating • Suitable for welding, fabrication and maintenance applications Mfr No. FCC78-05
Description Twist lock
Size mm² 50 – 90
Part Number 0317 2565
• Electrode holder suitable for 1.6 – 6mm diameter electrodes • Earth clamp designed to maximise earthing potential on plate • Double insulated welding cable
Mfr No. WS42525 WS42550 WS85050
Plug 25mm 50mm 50mm
RELATED MIG WELDINGPRODUCT MACHINES Welding (Chipping) Hammers
Cable 4m x 25mm² 4m x 25mm² 8m x 50mm²
Amperage 250 250 400
Part Number 0861 7239 0861 7256 0861 7307
• Hardened head with chisel and point • Spring handled hammer in red for increased visibility • May reduce vibration for user Search for part 0806 3007 at blackwoods.com.au
WELDING & GAS
Multi-Process MIG Series
• 3 in 1 Multi-process machines, capable of Synergic MIG, DC TIG and MMA (VRD) • Inverter technology with full digital control functions • Synergic programs for carbon steel, stainless steel, aluminium and silicon bronze and flux-cored • Machine package includes MIG torch, arc leads and regulator • Limited three year warranty ASIM200-5 • Available in compact • Suitable for maintenance workshop and panel repairs • Complies with AS 60974.1:2006 and AS 1674.2:2007 ASIM250C • Available in compact or with separate wirefeeder (10m lead kit) • Suitable for maintenance workshop and medium to heavy industrial applications • Complies with AS 60974.1:2006 Mfr No. Description ASIM200-5 Compact 5kg spool ASIM250C Compact 15kg spool *Water cooler not included in package
Supply Voltage 240 240
Supply Amperage 15 15
ASIM200-5
Output Range Amperage 30 – 200 30 – 250
Duty Cycle 200A@15% 250A@15%
ASIM250C
Part Number 0328 2079 0328 2096
blackwoods.com.au | 13 37 79
227
