ABRASIVES REINFORCED ABRASIVES – METAL GRINDING WHEELS – DEPRESSED CENTRE
REINFORCED ABRASIVES – METAL GRINDING WHEELS – DEPRESSED CENTRE – STAINLESS & MILD STEEL
Depressed Centre Grinding Wheels – Steel
• Best results achieved when wheel is run as close as possible to the recommended rpm without exceeding it • All wheels are labelled clearly with applications, standards, fitting instructions, dimensions of wheel and maximum rpm • Suitable for use on many mild steel applications • Complies with AS 1788.1:1987 and EN 12413 Dimensions mm 100 x 6.0 x 16 115 x 6.0 x 22 125 x 6.0 x 22 180 x 6.0 x 22 230 x 6.0 x 22
Specification A24R-BF27 A24R-BF27 A24R-BF27 A24R-BF27 A24R-BF27
Std Pack 25 25 25 50 50
• Excellent grinding performance with high metal removal parts • Extremely comfortable and efficient grinding solution • Consistent high stock removal • Maximises product throughout • For best results, high frequency grinders are recommended • Suitable for grinding carbon steel, tool and cast irons • Complies with AS 1788.1:1987
Part Number 0676 2029 0676 2046 0676 2063 0676 2080 0676 2097
Dimensions mm 115 x 7.0 x 22 125 x 7.0 x 22 180 x 7.0 x 22 230 x 7.0 x 22
Depressed Centre Grinding Wheels – Steel
• Suitable for grinding ferrous metal welds and structural steels • Complies with AS 1788.1:1987 A30S-BF27 • Suitable for general purpose grinding A24/30T-BF27 • Long life • Suitable for general purpose rough grinding
A30S-BF27
ABRASIVES
Dimensions mm 100 x 6.0 x 16 115 x 6.0 x 22 125 x 6.8 x 22 180 x 6.8 x 22 230 x 6.8 x 22
Specification A30S-BF27 A30S-BF27 A24/30T-BF27 A24/30T-BF27 A24/30T-BF27
Depressed Centre Grinding Wheels – Maxx
Specification ZA24Q – Zirconia ZA24Q – Zirconia ZA24Q – Zirconia ZA24Q – Zirconia
Std Pack 10 10 10 10
Part Number 0294 6159 0294 6176 0294 6193 0294 6210
REINFORCED ABRASIVES – METAL GRINDING WHEELS – DEPRESSED CENTRE – FLEXIBLE DISCS
3M Cubitron II Flexible Grinding Wheels ™
™
• Made with 3M™ revolutionary Precision Shaped Grain (PSG) • Faster cut – lets you produce more parts per hour • Longer life – for a lower cost per grind • Requires less pressure – allows the abrasive to do more of the hard work • Less vibration – easier to use, smooth running • Suitable for use with a backing plate • Ideal for grinding, blending, bevelling and deburring
A24/30T-BF27 Std Pack 50 50 50 25 10
Part Number 0020 5601 0022 5908 0292 1019 0112 1807 0112 1904
Dimensions mm 125 x 3 x 22 125 x 3 x 22 125 x 3 x 22
Grit 36 60 80
Std Pack 20 20 20
Part Number 0407 6217 0407 6234 0407 6251
TECHNICAL TIP Precision Shaped Grain (PSG) Imagine an abrasive technology that rewrites the rules of grinding. Generating less heat, faster processing time, fewer stress failures and less burnishing. In their spirit of Innovation, 3M™ have pioneered a new technology known as Precision Shaped Grain (PSG) where ceramic minerals have been precisely shaped into repeatable triangle shaped grains. 3M™’s patented, precision-shaped ceramic abrasive grain continuously self-sharpens during use as points break off in a manner to maintain the pyramid’s precision shape. Each mineral grain acts like an individual cutting tool, slicing through metal like a knife. This results in the abrasive products with PSG cutting faster, lasting longer and running cooler. As the abrasive mineral wears down under pressure, the resultant surface finish is consistent due to the material’s common density and wear characteristics. As a result of its uniquely designed properties no other abrasive looks or performs in the same way.
220
blackwoods.com.au | 13 37 79
