| ATMOS treatment units | Monitor arms
Monitor arms Monitor arm for shelf adapter or system frame For direct mounting to the ATMOS S 61 Servant. Monitor connection dimensions: VESA 75 and 100
REF
❁ 534.3095.0
Included in delivery: Monitor support with rod for insertion in the system frame/ shelf adapter. Monitor is not included in delivery!
Monitor arm ATMOS S 61 ENT professional For ergonomic integration any examination monitors in the treatment environment Characteristics: The monitor arm enabled an easy position of the monitor as well as beside the patient chair during examination ▪ in front of the microscope column for demonstration purposes
❁ 534.3020.0
Included in delivery: Monitor arm with attachment screws for system frame, High quality SVHS-video cable, length 5m (REF 008.0882.0), for connection of ENT cameras on monitor Monitor is no include in delivery! System requirements: System frame REF 534.1005.0, REF 534.1010.0 or REF 534.1020.0 is required for adaptation.
Monitor Medical TFT-Monitor 17" Monitor for medical applications Characteristics: 17" TFT-Monitor with medical-power supply for use near the patient with video and computer connection Technical data: Video input Y/C-SVHS and FBAS, release 1280 x 1024, 300 cd/m² 100-240 V Include in delivery: TFT-Monitor, medical-power supply, operating instruction
Medical 19" LCD monitor Sony LMD-1950MD Monitor for medical applications Characteristics: Top quality SXGA panel (1280x1024) with digital 10-bit signal processing; optimised for endoscopic examinations. Top quality with regard to image brightness, first-class contrast and colour depth, max. angle of vision (89°), 5:4 display with anti reflection coating Technical data: Performance: 66 W, weight: 9.7 kg, voltage range: 100-240 V~
❁ 534.3015.0
Medical 15" video / PC monitor Medical monitor for connection to ATMOS Scope and ATMOS Cam (video outlet) Characteristics: 15" (38 cm) LCD/TFT monitor, 1024 x 768, XGA, NeoV optical glass, 4 ms, white, sturdy metal housing, quick reaction time of 4 ms, high contrast ratio (3000:1), high brightness (350 cd/m2), DVI compatible for high quality display, shortcut key for the preferred video mode, automatic adaptation for perfect adjustment, Kensington safety equipment, VESA standard wall support Technical data: Performance: 36 W, weight: 4.8 kg, voltage range: 100-240 V~
❁ 534.3005.0
Included in delivery: Monitor, VESA-fitting, DVI cable, medical-power supply, operating instructions
Included in delivery: Monitor, Medical power supply, 15-Pin D-Sub cable, 24-Pin DVI-D cable, S-Video cable, CVBS cable, operating instructions, CD ROM Please note: The monitor can be connected via the CVBS interface to the ATMOS Cam 21/31. The DVI and VGA inputs are not compatible with the ATMOS Cam 21/31.
Please contact us via: ENT@atmosmed.com | Phone: +49 7653 689-374 | Fax: +49 7653 68986-374 54
❁ 534.3010.0
