29 minute read
of wheel clamping
from Modern Tire Dealer - Performance Handbook 2015
by EndeavorBusinessMedia-VehicleRepairGroup
The Porsche Carerra GT’s center nuts are color coded (red for the left side and blue for the right side).
If you look closely, this red nut (on the driver side of the car) is labeled with an arrow for direction to loosen. Each nut is so-marked to avoid confusion between thread directions. This red nut features right-hand threads, requiring counterclockwise rotation to loosen.
are hard plastic and are available to cover both inch and metric sizes) and two thread pitch gauges (one inch and one metric). That’s all you need to quickly and accurately read any wheel bolt or nut without any guesswork.
Common wheel fastener thread sizes: 7/16-20 1-20 9/16-18
M12 X 1.25
M12 X 1.5
M12 X 1.75
M14 X 1.5
M14 X 2.0
Head/drive styles
The “head” of a wheel bolt or nut features a specific drive design and appearance approach. The most conventional drive style involves a hex (six-sided) that requires the use of a six-point wrench. However, other styles do exist, although not encountered as often. These include female hex drive “tuner” nuts which feature a relatively small and smooth outer body diameter (to ft into small-diameter fastener recesses in some wheels), and a female hex drive hole, requiring a male hex bit for service. Yet another drive style is the spline-drive head which features a symmetric pattern of straight-cut external splines instead of hex walls. Splined fasteners require a dedicated female spline socket, available from the maker of the splined fasteners.
In terms of appearance, nuts may be either open (the threaded hole runs all the way through the nut) or closed (threads terminate inside the nut). Closed head styles are varied, and include fush tops, raised conical domes, raised fattop domes, extended hex walls (for easier reach and handling and greater wrench contact area) and radiused domes.
Body and thread length
All of the wheel nut and wheel bolt styles that we’ve mentioned are available in a wide variety of lengths, in terms of drive area or thread engagement area. Drive
is too long, this will prevent full seating at the wheel.
Wheel fastener tightening
Never use an impact gun to remove or install threaded fasteners when dealing with custom alloy wheels.
The reason to avoid using an impact gun during removal is simply to avoid scratching the fastener pockets of the wheel. If you insist on removal with a gun, use only a clean thinwall socket and run the gun at a slower speed.
Here is Porsche’s specialty tool kit for removing and installing the center nuts on the Carerra GT. Included is the nut wrench (on the left), the torque multiplier (in the center) and the stop-arm that rests against a wheel spoke.
The Porsche tool engaged onto the wheel nut. The torque multiplier tool is driven by a 1/2-inch drive torque wrench. By pulling a mere 128 ft.-lbs. on the torque wrench, the torque multiplier achieves a fnal at-the-nut torque value of 407 ft.-lbs. area height may be dictated by the thickness of the wheel’s center hub, or by the design of the wheel (maybe the nut or bolt head needs to project out farther for easier wrench access). The necessary thread engagement area will affect length as well, involving either inboard thread reach or outboard projection based on stud length. Thread length/depth is extremely critical. The nut-to-stud or bolt-to-female thread engagement area must be suffcient to properly secure the wheel.
At bare minimum, thread engagement depth must be greater than the diameter of the thread (for example, if the thread is 12 mm, thread engagement depth must be greater than 12 mm). Pay particular attention with closeddesign nuts. Make sure that the stud does not bottom-out inside the nut. This will prevent the fastener from seating onto the wheel. By the same token, if a wheel bolt’s shank length
Splined wheel nuts offer a slender, more accessible reach, especially for wheel applications where the nut is recessed in the wheel. Note that the splined interface offers a durable grip surface for the lock key socket. The UHC open nut provides a lowprofle ft for those who prefer a less-obtrusive appearance.
It’s easy to scratch the pockets with the socket or the exiting nut or bolt, even while trying to maintain control gun control.
Whether we’re dealing with a bargain-basement, impurityriddled aluminum casting or the fnest and strongest billet, forged or investment-cast alloy wheel, proper clamping force is critical for both wheel care and performance.
For one thing, over-tightening can gall or deform the wheel’s fastener pocket seats. Excessive over or unequal tightening can distort both the wheel center section as well as today’s commonly thin-wall hubs. This can result in a distorted brake rotor, leading to brake pedal pulsation. Considering the lightweight rotor hats featured on many of today’s vehicles, that’s an open invitation to disc brake warping and brake pedal bounce, which will surely result in a comeback complaint.
When taper or round seat wheel fasteners are tightened, an interference fit is experienced. The male seat of the fastener contacts the female seat of the wheel and creates a small wedge contact when tightened, creating a pressure point that helps to lock the fastener in place. If either type of fastener is under-tightened, they can loosen during operation. If over-tightened, the fastener can become fatigued
One option for open-nut applications is McGard’s UHC model that features a female key slot. The lock socket features a surround that captures the nut for a more secure removal and installation.
and can deform the material in the wheel’s female seat pocket, which can result in fastener loosening. The shape of the radiused seat reduces the effect of over-tightening since contact pressure is more evenly distributed than with a taper seat style.
Flat seat style is used almost exclusively with alloy wheels, since in the early days of alloy aftermarket wheels, the alloy material may not have been strong enough to handle the frictional forces created by tapered or radiused seats.
Over-tighening a fat seat nut can deform the wheel, causing the aluminum under the washer to extrude, which displaces the aluminum, causing the nut to loosen.
Over-tightening can also stretch the wheel studs or wheel bolt shanks beyond their elastic range. All bolts or studs are designed to stretch a miniscule amount when optimal clamping load is achieved. This elasticity of the stud or bolt is what helps to secure the wheel on the hub. When torqued to specifcation, this is referred to as achieving the proper “clamping load.” If the stud or bolt is excessively over-tightened, it’s possible that it will stretch beyond its yield point, losing its “rubber band” effect. If stretched beyond the yield point, the stud or bolt becomes so weak that it cannot provide the clamping load needed. The result: the fastener loosens or the stud or bolt shank breaks.
Always follow the torque specifcations listed by either the vehicle manufacturer or by the wheel maker. Don’t guess. Actually take the time to pick up a calibrated torque wrench and tighten all of the wheel’s fasteners, in the proper sequence, in several steps to achieve fnal (and equal) torque values.
While the use of torquelimiting “sticks” is common, when dealing with alloy wheels, the preferred method involves using a calibrated torque wrench. Note that in addition to dial or micrometer “click” style torque wrenches, today’s tool market includes high-precision digital torque wrenches that prove quite handy. With the press of a button, you set the desired torque value. Once that value is achieved, the tool “beeps,” vibrates and illuminates a LED light, features that are well appreciated in a noisy shop.
Never tighten wheel fasteners in a progressive adjacent pattern. Tighten in a “crisscross” pattern in order to evenly spread the clamping load to avoid warping the wheel or hub face.
Retorque
Specifically when dealing with alloy wheels, it’s highly
advisable to re-check the value of each fastener after about the frst 50 to 100 miles of operation. Due to metal compression/elongation and thermal stresses, the clamping loads may change during initial use. When rechecking torque value, wait for the wheels to cool to ambient temperature (never torque a hot wheel). Loosen and retighten, to value, in sequence. Again, some will argue that this step is not necessary, but it’s better to be safe than sorry, and it’s better to catch a loose nut early as opposed to too late.
Wheel fastener (nut or bolt) torque values
While you should always refer to the vehicle manufacturer’s recommendations for proper wheel fastener torque values, following is a generic guideline. Don’t guess. Adhere to the vehicle maker’s specs. 12 mm 14 mm 7/16 in. 1 in. 9/16 in. Torque (ft.-lbs.) 75-85 85-100 70-80 75-85 135-145
Wheel locks
As a deterrent to would-be wheel thieves, “wheel locks” have been popular additions to vehicles equipped with expensive alloy wheels and high-dollar tires. Contrary to the term “locks,” these fasteners do not actually “lock.” Rather, they feature a drive design that requires a special wrench that matches the specifc design of the fastener’s drive. Commonly, “locking” lug nuts or wheel bolts may feature an irregular female keyway machined into the fastener head, requiring a drive tool with a matching male shape. Another common approach features a splined design, requiring a matching female-splined tool. If a lock tool is missing, removal of the locking fastener may require either welding a bolt or nut to the locking fastener, a specialty gripping tool (similar to a female “easy-out” tool) or a call to the wheel lock manufacturer to order a replacement lock key.
The Cobra features a right-hand thread on the right side of the car, and a left-hand thread on the left side. Remember, threads should be lightly lubed with moly before servicing to avoid galling the aluminum knock-off spinner nut.
Knock-off/pindrive system
Many race cars (as well as a few vintage street cars such as some old Corvettes, Ferarris, AC Cobras, etc.; and some latemodel exotic cars, such as Porsche’s C a r e r r a G T ) feature a wheel fastening system that involves a
The knock-off spinner nut is made of aluminum. In order to tighten or loosen the spinner nut, a heavy lead hammer is used to beat the spinner wings. The lead deforms easily, but that’s intentional. The lead (softer than the aluminum wings) is sacrifced, to prevent damage to the aluminum wings.
single large center nut instead of a series of individual fasteners. C o m m o n l y called “knockoff” or “pin-drive” wheels, this features a large center hole in the wheel that slides over an extended male threaded spindle. A large center nut (sometimes hex sided, sometimes featuring two or three
large “wings”) secures the wheel to the hub. This system is often called a “knock-off” because (in the case of winged center nuts) a large lead hammer is sometimes used to loosen or tighten the center nut (where the nut is winged). Even if the nut is hexed, a large special wrench may feature extended leverage arms that allow the use of a lead hammer to “knock” the nut. The term “pin-drive” refers to the series of short stubby dowel pins located on the hub face that engage into holes on the rear of the wheel center. Locating the wheel onto these pins prevents the wheel from rotating in relation to the hub. Basically, the term knock-off and pin-drive are synonymous.
It’s important to be aware that a knock-off wheel system may feature left-hand threads and right-hand threads on opposite sides of the vehicle. It’s critical to recognize this before attempting to loosen a left-hand thread nut by trying to rotate it counterclockwise. Some pindrive systems feature right-hand threads on the right side of the car and left-hand threads on the left side; while some cars may feature the opposite (lefthand threads on the right side and right-hand threads on the left side).
As an example, of a latermodel exotic application, the center nuts on the 2005 Porsche Carrera GT feature a spline-type engagement, requiring a special dedicated Porsche tool for service. This socket tool is part of a “torque-multiplier” Porsche tool kit. The socket engages the nut, while a special torque multiplier gearbox attaches to the socket. The Porsche torque specifcation for these nuts is 407 ft.-lbs. Initially that sounds like an impossibility (after all, how many folks have a 400+ ft.-lbs. torque wrench lying in their toolbox?). However, that’s where the torque multiplier comes in. Simply adjust your torque wrench to 128 ft.-lbs. and attach it to the multiplier tool. As you pull to a mere 128 ft.-lbs., the multiplier gearbox converts this amount of force into an effective 407 ft.-lbs. The tool isn’t cheap (around a cool $2,000 at your local Porsche dealer), but it makes the job easy and precise.
Naturally, since only a single large nut secures the wheel in place, you want to make certain that the nut won’t accidentally loosen. In addition to achieving the specifed torque value when tightening the nut, a back-up system is often employed to maintain the nut’s position. If the nut is the wing-nut style, stainless steel safety wire can be used to insure against loosening (wire is run through a small hole in one of the wings to a small hole in a wheel spoke). In the case of the Porsche Carrera GT, the alloy nuts feature a spring-loaded tab that engages in a spindle slot.
Yet another potential example of a shop encountering pindrive wheels is the customer who owns an AC Cobra replica. While the majority of these cars (commonly referred to as “kit” car Cobras) will feature common fve-bolt hubs along with traditional wheel nuts, some examples may feature the original style pin-drive hub system, wherein the center spindle nut threads onto the spindle with a three-wing-style nut that must be loosened or tightened using a lead hammer. This vintage style then requires a means to prevent the nut from loosening. This involves installing a length of stainless steel safety wire that connects one of the nut’s “wings” to the wheel (small wire holes should exist on both the wings and the wheel.) Granted, it’s rare that you’ll encounter this, but it’s good to know the procedure if the circumstance arises.
