MAIN SPEAKER SYSTEM 87 x L-Acoustics Kudo in 18 arrays 36 x EAW BH760 in 18 arrays 36 x Lab Gruppen PLM 10000Q 4-channel digital amplifiers 24 x Lab Gruppen fp6400 dual-channel amplifiers 7 x Lab Gruppen 10000Q 4-channel amplifiers 2 x Digico SD8 digital mixing consoles 14 x nodes of Optocore Optic Fibre signal distribution supported by XTA DS800 analogue back-up 8 x Sennheiser SR300 G2 IEM Transmitters with 16 EK300 receivers 8 x Shure UR4D radio microphone systems with a combination of handheld and beltpack transmitters 2 x Rode speech/presentation microphone systems
AKG
DMS 700
The new DMS 700 is a revolutionary digital wireless solution designed for the future:
2 x Pyramix 48-channel digital replay systems FOP cast monitors were a selection of RCF 322I and Turbosound Impact 50 passive speaker cabinets 16 x Alpermann & Velte timecode readers 16 x Yamaha MSP3 powered program monitors Dolby lake DLP4/12 signal processors
The First Professional Digital Wireless System
Lake Audio MESA EQ processors
CREW LIST Scott Willsallen – Audio Designer, Auditoria Ian Baldwin – Technical Manager, David Atkins Enterprises Andrew Rodd - Norwest Project Manager Justin Arthur – Systems Engineer Steve Caldwell – RF / Spectrum Manager Lisa Fahrenberger – IEM manager Trevor Beck – Replay Engineer Ian Shapcott – Audio Operator Oliver Hutchison – FOP Audio Tech Ryan Parker – FOP Audio Tech Dane Cook – FOP Audio Tech Paddy Moran – FOP Audio Tech Lee McClymont – FOP Audio Tech
singing of the anthems etc. CH: Sounds like you needed to fashion some trolleys. SWA: Right. These are five-element Kudo arrays – 18 positions in all – which are quite tall. And to manufacture a trolley to get them onto the field and then on the floor was quite expensive – and I thought spending 30 or 40 thousand dollars in a pretty limited budget to get the PA off the field in a hurry wasn’t good value. There must be a better way. The ‘better way’ was to use typical courier-style hand trolleys for the subs. And then a lot of time went into coming up with a set of rails that bolted onto the back of each Kudo array. And that enabled the array to be rolled onto a trailer and three or four of these trailers to be hitched up in a line and then taken off with a Gator.
• Up to 150MHz tuning range • 256 bit RC4 signal encryption for secure audio transmission • 2-channel digital true-diversity receiver • No Compander (used in analogue systems): higher sound quality • On-board DSP per channel (Compressor, EQ, Limiter) • Quick setup via infrared data link to the transmitter • Graphical spectrum analyser helps find clear channels • Remote monitoring and control via PC
CH: Like collecting shopping trollies. SW: Yeah, that’s right. Shopping trollies that weigh half a tonne each! But it worked really well. I mean, they cleared in nine minutes!
