CONSTRUCTOR
COVERING GENERAL BUILDING & GENERAL ENGINEERING CONSTRUCTION THE MAGAZINE OF THE ASSOCIATED GENERAL CONTRACTORS OF AMERICA, SPECIAL EDITION THE MAGAZINE OF THE ASSOCIATED GENERAL CONTRACTORS OF agcsd.org SAN DIEGO CHAPTER, INC. AMERICA, SAN DIEGO CHAPTER, INC.
AGC BUILD SAN DIEGO AWARDS
agcsd.org
RECOGNIZING EXCELLENCE IN CONSTRUCTION
2
AGC BUILD SAN DIEGO AWARDS - 2019
THIS WAS HAZARD CONSTRUCTION’S
CHALLENGE SOLUTION
Overcome deep excavation, steep slopes, tight radius & vertical clearances to safely shore major pipe installation.
THIS WAS OUR
The Florida Canyon Emergency Pipeline Project in San Diego challenged contractor Hazard Construction. The “emergency” required immediate replacement of 550’ of rusted metal storm drainage pipe with 10’-diameter cement pipe. Excavation depth ranged from 15’ wide/15’ deep to 26’ deep to protect steep slopes and allow for pipe size and required vertical clearance. Tight work space radius was both a safety and functional concern. With confined trench space and heavy piping materials, expert shoring was critical to the project’s success. A Trench Shoring Company (TSC) Operations Manager and Slide Rail Specialist were involved from project scope through excavation phases. Multiple inventory locations allowed TSC to provide 100’ of its SBH® Slide Rail Shoring from local stock. Leap-frogging the slide rails ahead 5-1/2 times as each pipe section was laid resulted in better control of shoring used, project cost and time savings. We offer the largest inventory of Slide Rail Systems with panel sizes from 6’-28’, so we’ll be there for your challenging project too! © 2019 Trench Shoring Company
RECOGNIZING EXCELLENCE IN CONSTRUCTION
We offer same day service from our 10 locations to Southern California, Bakersfield, Fresno, the CA Central Coast and the Las Vegas, Nevada areas.
San Diego
858-530-2500 TrenchShoring.com
3
AGC CONTENTS
SAN DIEGO
The Associated General Contractors, San Diego Chapter, Inc.
6 Welcome 7 Program 8 Judges
6212 Ferris Square San Diego, CA 92121
10 Sponsor Bios
Phone (858) 558-7444 Fax (858) 558-8444
AWARD ENTRIES
www.agcsd.org
14 Building Construction - Public Work 20 Building Construction - Private Work 24 Underground / Utilities Construction
ABOUT THE AWARDS
26 Heavy / Highway Construction 30 Unique Small Project - Public Work
Biennially, AGC San Diego presents the Build San Diego Awards to AGC member firms for their outstanding projects based upon the following criteria: Excellence in Project Management; Innovation in Construction Techniques or Materials; Excellence in Client Services; Contractor’s Contribution to the community; Meeting the Challenges.
32 Unique Small Project - Private Work 34 Sustainable Project 36 Unique Special Project
November 5, 2019 @ Hilton San Diego Bayfront
JOIN THE CONVERSATION @agcsandiego #buildsandiego
4
AGC BUILD SAN DIEGO AWARDS AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
5
WELCOME
from AGC San Diego Chapter President Steve Friar Honoring the hard work and dedication of our industry is why the Build San Diego Awards were created and the Associated General Contractors of America, San Diego Chapter, Inc. is proud to honor the 2019 finalists. Every two years, we award the contractors that build the outstanding buildings and supporting infrastructure that help make San Diego America’s Finest City. Our record number of award entries showcase the diversity of projects from a new downtown hotel to the neighborhood fire station. A range of jobs are represented as you review the 2019 award projects: hospitality, education, recreation, health services, military, energy, tourism, bridge and road work, faith-based, and institutional work. These projects, public or private, are an integral part of the region’s economy, and they represent the hard work of architects, engineers, and construction firms. Communities around our region will benefit from these projects for years to come as they provide infrastructure to our growing region, as well as provide services to the residents and visitors. Projects this year include transformations to iconic locations along with new structures to our city landscape. Each company should take great pride in what they have built for our city. This year, for the first time, AGC San Diego is also recognizing a top Public Agency who contractors have highlighted as an owner of choice for their commitment to partnering with the construction industry to deliver world class infrastructure. The San Diego construction industry is one of the largest employers in the region. These Build San Diego projects represent the skill and dedication of all those that work within this exciting and challenging industry. Congratulations to the 2019 Build San Diego Award winners!
Steve Friar, Hensel Phelps 2019 President AGC San Diego Chapter, Inc.
PROGRAM PLEDGE OF ALLEGIANCE PRESIDENT’S WELCOME RECOGNITION OF GUESTS
Past Presidents & Board Members
RECOGNITION OF JUDGES see page 8 for list of Judges
LUNCH INTRODUCTION OF SPECIAL GUEST SPEAKER The Honorable Steve Vaus, Mayor of Poway
INTRODUCTION OF SPONSORS
INTRODUCTION OF MASTER OF CEREMONIES Matt Pound General Manager, Escondido Materials
PRESENTATION OF 2019 BUILD SAN DIEGO AWARDS
JOIN THE CONVERSATION @agcsandiego #buildsandiego
AGC BUILD SAN DIEGO AWARDS
JUDGES JOHN ADDLEMAN
San Diego History Center
San Diego History Center
AGC extends its sincere appreciation to the 2019 Build San Diego judges
Risk... Needs to be Managed.
Executive Director of Planning Services, San Dieguito Union High School District The old tower at Santa Fe depot comes down, circa 1915
JIM CLEATON
Managing Risk and Negotiating Insurance
BILL MORGAN
Commercial Insurance | Surety Bonds | Employee Benefits | Risk Control | Personal Lines
Director of Construction, San Diego State University
Deputy Director – Engineering Services Division, County of San Diego Department of Public Works
450 B St. Suite 1800 | San Diego, CA 92101 | 619 234 6848 | www.cavignac.com
AGC Constructor2018 3.75 x 4.75 - Santa Fe Depot Tower.indd 1
MICHAEL TILLEY
Sr. Program Manager/Airport Design & Construction, San Diego County Regional Airport Authority
AGC BUILD SAN DIEGO AWARDS
8
AGC BUILD SAN DIEGO AWARDS - 2019
1/16/2018 3:48:22 PM
THE HAWTHORNE
BUILDING BETTER COMMUNITIES
PROUD TO BE PART OF BUILDING
San Diego
We Help Our Customers Build Better Communities Whether you live in San Diego, the Hawaiian Islands or the Pacific Region, you can count on Hawthorne Cat to be there to help you get the answers you need when you need them. We’re here to assist you with solutions for your business.
800.437.4228 www.hawthornecat.com RECOGNIZING EXCELLENCE IN CONSTRUCTION
9
SPONSORS The AGC San Diego Board of Directors would like to thank Dave Ness of Hawthorne CAT and John Maguire of Torrey Pines Bank for their generous assistance in underwriting this program.
Hawthorne Cat is the authorized dealer for Cat construction and power equipment in San Diego County, the Hawaiian Islands and the Pacific Region. Since 1956, Hawthorne Cat has served various industries including general and heavy construction, quarry and aggregate, landscaping, marine, paving, waste management, backup power and power generation. Like our products, the list of support services we offer is continually being improved, expanded and redesigned around our commitment to customer satisfaction. Hawthorne Cat is committed to partnering with our customers and exceeding their expectations with exceptional products and services through our empowered team that demonstrates strong work ethic, integrity and teamwork. Your complete satisfaction as a partner with Caterpillar and Hawthorne Cat will always be our highest priority. To learn more about Hawthorne Cat, please visit www.hawthornecat.com
Founded by local business and banking experts, Torrey Pines Bank offers a highly personalized banking experience with a focus on exceptional service, a broad range of solutions, a commitment to building relationships, and ready access to decision-makers. As a division of Western Alliance Bank, this is all backed by the national strength of Western Alliance Bancorporation, one of the fastest-growing bank holding companies in the U.S. From the ground up, Torrey Pines Bank delivers real estate developers and investors financing expertise to help a wide range of property type businesses. Our work with the development community is longstanding and extensive. Our highly experienced bankers bring deep industry knowledge and an entrepreneurial way of thinking to move projects forward. Every real estate deal and construction project is unique, and we will work with you to develop smart banking and financing solutions to meet your needs. Torrey Pines Bank is a division of Western Alliance Bank. Member FDIC. To learn more, visit www.TorreyPinesBank.com
AGC BUILD SAN DIEGO AWARDS
10
AGC BUILD SAN DIEGO AWARDS - 2019
Your business doesn’t stop working at night. At Torrey Pines Bank, we don’t clock out until you do. We do what it takes to give our clients peace of mind, and that includes making ourselves available when it’s convenient for you.
Bank on Accountability
torreypinesbank.com
Top 10 - Forbes Best Banks
Torrey Pines Bank, a division of Western Alliance Bank. Member FDIC. Western Alliance ranks top ten on Forbes’ Best Banks in America list, four years in a row.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
11
AWARD ENTRIES BUILDING CONSTRUCTION - PUBLIC WORK
Balfour Beatty - Southwestern College Wellness & Aquatic Complex Barnhart-Reese Construction - Bayside Fire Station No. 2 _ Clark Construction - Huaxyacac Hall, San Diego State University EC Constructors, Inc. - Pine Valley Fire Station #44 Erickson-Hall Construction Co. - Sage Creek High School Performing Arts Center Lusardi Construction Co. - Alvin Dunn / La Mirada Academy McCarthy Building Companies, Inc. - SDUHSD Torrey Pines High School, Performing Arts Center Swinerton - San Diego Airport Terminal 2 Parking Plaza
BUILDING CONSTRUCTION - PRIVATE WORK
Erickson-Hall Construction Co. - Emmanuel Faith Community Church Children’s Ministry Building Hensel Phelps - Intercontinental San Diego Swinerton - Sycuan Casino Resort
UNDERGROUND / UTILITIES CONSTRUCTION
Orion Construction Corporation - Hale Ave. Emergency Sewer Replacement
HEAVY / HIGHWAY CONSTRUCTION
Flatiron West, Inc. - Willow Street Bridge Replacement Project Mid-Coast Transit Constructors - Gilman Drive Bridge Pulice Construction, Inc. - South Bay BRT Segment 3 R.E. Staite Engineering, Inc. - General Dynamics NASSCO Graving Dock Cofferdam Skanska - I-805 North HOV/BRT Design Build Project
UNIQUE SMALL PROJECT - PUBLIC WORK
EC Constructors, Inc. - South Mission Beach Lifeguard Station KTA Construction, Inc. - Avenida De La Playa Storm Drain Reconstruction – Phase 2 Orion Construction Corporation - Ladera Street Bluff Stabilization Project Swinerton - San Diego Zoo Rex’s Roar
UNIQUE SMALL PROJECT - PRIVATE WORK Bergelectric Corp. - Camino De La Reina TC Construction Co., Inc. - Sycamore Ranch
SUSTAINABLE PROJECT
Hensel Phelps - UC San Diego Mesa Nueva Balfour Beatty - North Coastal Live Well Health Center
UNIQUE SPECIAL PROJECT
Cass Arrieta - Desert View Drive Slope Repair and Restoration Dynalectric Company - University of California, San Diego Satellite Utility Plant EC Constructors, Inc. - Pine Valley Fire Station #44 Hensel Phelps - Sharp Chula Vista Ocean View Tower Lusardi Construction Company - The Plunge Mid-Coast Transit Constructors - Gilman Drive Bridge Orion Construction Corporation - Catalina 12” Water Main and Sewer Main replacements Pacific Building Group - San Diego Zoo Safari Park – Walkabout Australia R.E. Staite Engineering, Inc. - General Dynamics NASSCO Graving Dock Cofferdam
12
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
13
PUBLIC WORK
BUILDING CONSTRUCTION PROJECT: Southwestern College Wellness & Aquatic Complex CONTRACTOR: Balfour Beatty OWNER: Southwestern College ARCHITECT: Gensler PROJECT DESCRIPTION: The new $54 million complex replaces the college’s former gymnasium
and aquatic facilities. It houses a three-court gymnasium with team locker rooms, cardio and weight training space, multi-purpose instructional space, staff offices, and a community room. The aquatic area consists of three pools; a 50 meter “Fast Pool” to support competitive swim and water polo events; a 5 meter “Flex Pool” with variable depths to support diving, physical education programs, recreational swimming, water safety programs; and a 25 yard “Adaptive Therapy Pool.” The facility serves as both the home for several school athletic teams as well as the wellness and recreation epicenter of the campus and community.
PUBLIC WORK
BUILDING CONSTRUCTION
14
PROJECT: Bayside Fire Station No. 2 CONTRACTOR: Barnhart-Reese Construction, Inc. OWNER: Civic San Diego ARCHITECT: Rob Wellington Quigley, FAIA PROJECT DESCRIPTION: Located in San Diego’s Little Italy neighborhood, the fire station solves a
longstanding problem for the local Fire Department – meeting response times for the waterfront areas of downtown, west of the busy railroad and trolley lines. The building includes a single-story of below-grade parking, an apparatus bay and lobby at ground level, and living spaces on the second and third floors – all connected by both a slide and fire pole. Challenges included the station’s location along the busy Pacific Highway/Cedar Street corridor, both of which are major arteries entering and exiting Downtown San Diego. Great care was taken to coordinate daily with the City of San Diego Traffic Department, and two other large construction projects to ensure both pedestrian and vehicle traffic were not impacted with road closures.
AGC BUILD SAN DIEGO AWARDS - 2019
_ PROJECT: Huaxyacac Hall, San Diego State University CONTRACTOR: Clark Construction Group – California, LP OWNER: San Diego State University ARCHITECT: AC Martin PROJECT DESCRIPTION: This new housing facility blends seamlessly with the campus’ historic Mission-Revival core and supports the University’s mission of providing an environment that fosters _
success and bolsters recruitment, retention, and graduation rates. Huaxyacac Hall provides a focused freshman experience and a “place to call home.” The 200,000 square foot project includes faculty offices, kitchen, market, café, outdoor courtyard spaces, and can accommodate up to 1,200 residents. The team had to create the site area by building a large 53 feet high by 220 feet long retaining wall on a canyon. Despite this, Clark stayed on schedule and on budget to allow students to move in as committed.
PUBLIC WORK
BUILDING CONSTRUCTION
PROJECT: Pine Valley Fire Station #44 CONTRACTOR: EC Constructors, Inc. OWNER: County of San Diego ARCHITECT: Jeff Katz Architecture PROJECT DESCRIPTION: Work on this project involved the demolition of an existing 6,900 square
foot building and the construction of a new 13,000 square foot fire station. This LEED Silver building was completed utilizing a Design Build delivery method, enabling the project to be designed and constructed in 18 months, from award of contract to grand opening. The true measure of design excellence is the building’s ability to hold up over time to the heavy use these types of facilities encounter. With this in mind, the walls in the apparatus bay and support spaces were constructed with CMU and integral colored board formed cast-in-place concrete.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
PUBLIC WORK
BUILDING CONSTRUCTION
15
PUBLIC WORK
BUILDING CONSTRUCTION PROJECT: Sage Creek High School Performing Arts Center CONTRACTOR: Erickson-Hall Construction Co. OWNER: Carlsbad Unified School District ARCHITECT: Rachlin Partners PROJECT DESCRIPTION: This 17,272-square-foot project features a two-story lobby, 345-seat
auditorium, and a back-of-house Black Box/Multi-purpose Room separated from the auditorium by a double wall and corridor to reduce noise and open flexibility for indoor/outdoor use. Consideration was given to sight lines and acoustics that deliver a more intimate experience and improve student attentiveness. Perforated metal panels on the entry facade are suspended in front of a structural glazed curtain wall to control the amount of sunlight cascading into the building. Construction activities were executed on the active high school campus without disruption to the learning environment, while ensuring the constant safety of students, faculty, staff and campus visitors.
PUBLIC WORK
BUILDING CONSTRUCTION
16
PROJECT: Alvin Dunn / La Mirada Academy CONTRACTOR: Lusardi Construction Company OWNER: San Marcos Unified School District ARCHITECT: PJHM PROJECT DESCRIPTION: This project replaced the Alvin Dunn School, which was constructed by
Lusardi Construction in 1960. It consisted of three new buildings totaling 120,000 square feet with 51 classrooms, library, innovation lab, kiln room, theatre, full-service kitchen, band room, multipurpose gymnasium, and administration spaces. The newly constructed school was built on an active school site over a two-year phased construction schedule with zero class interruptions or interim campus being needed. Lusardi Construction donated several building material samples that are being housed in the new multipurpose building display case. These samples give a snapshot of what products were used to create their new school.
AGC BUILD SAN DIEGO AWARDS - 2019
PROJECT: SDUHSD Torrey Pines High School, Performing Arts Center CONTRACTOR: McCarthy Building Companies, Inc. OWNER: San Dieguito Union High School District ARCHITECT: Roesling, Nakamura, Terada Architects PROJECT DESCRIPTION: This $24 million project includes a Black Box Theater, 350-seat proscenium theater, state-of-the-art lighting, audio/visual soundboards, acoustical panels, scene shop, green room, dressing rooms, a new dance room, music building, and outdoor amphitheater. Innovative construction techniques were used in this Construction Manager – Multi Prime project, including a posttensioned architectural cast-in-place concrete bridge, tension grids, and the integration of the heather systems into the BIM coordination process. Delays due to steel detailing and procurement were mitigated by tightening of the CMU activities and coordination amongst finish trades.
PUBLIC WORK
BUILDING CONSTRUCTION
PROJECT: San Diego International Airport Terminal 2 Parking Plaza CONTRACTOR: Swinerton OWNER: San Diego County Regional Airport Authority ARCHITECT: Watry Design and Gensler PROJECT DESCRIPTION: This Progressive Design-Build project serves as one of the gateways to
the airport, and provides a seamless transition from the travelers’ vehicles to the terminal. The site is over 9 acres, and the parking plaza is over 1 million square feet in total parking structure area, containing over 3,000 parking spaces. Off-site improvements consisted of parking lot reconfigurations, utility relocations, and connection into the existing campus. The most innovative sustainability component was the onsite rainwater harvesting system that holds 112,500 gallons. It reuses otherwise wasted water and eliminates the need to install a huge underground tank with fresh water. This reduces the amount of domestic water the Airport needs to operate its Central Plant when naturally occurring rain water is available.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
PUBLIC WORK
BUILDING CONSTRUCTION
17
18
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
19
PRIVATE WORK
BUILDING CONSTRUCTION PROJECT: Emmanuel Faith Community Church Children’s Ministry Building CONTRACTOR: Erickson-Hall Construction Co. OWNER: Emmanuel Faith Community Church ARCHITECT: BGW (Building God’s Way) PROJECT DESCRIPTION: This 45,000-square-foot, two-story building features large multipurpose
rooms with interactive play areas and big classic toys used as props and play apparatus. Building systems include state-of-the-art audio/visual technology and LED lighting. Site improvements included installation of a new traffic signal at a nearby intersection. A unique challenge was creating a facility that was colorful and fun for kids, with a color theme to match the church’s current logo using six primary and secondary colors. Three innovative materials and construction techniques that were used on the project were the 3Form art piece, a rooftop patio, and an underground storm structure.
PRIVATE WORK
BUILDING CONSTRUCTION
20
PROJECT: Intercontinental San Diego CONTRACTOR: Hensel Phelps OWNER: LFS Development, LLC ARCHITECT: John Portman & Associates PROJECT DESCRIPTION: This project is located where the Pacific Coast League Padres played
from 1936 to 1957. The luxury, 400-room hotel showcases a 210-foot-tall building that includes 24 suites with floor to ceiling windows. Features include three levels of subterranean parking for 686 cars; 35,000 square feet of multipurpose indoor spaces; and 60,000 square feet of outdoor space. There is also a rooftop bar, a pool bar, and a café on the 19th floor. Hensel Phelps self-performed the concrete and placed 8,500 yards of concrete for the Mat foundation in a single 24 hour pour. Multi-agency oversight created challenges; however, the “give and take” became the motto and theme as all issues were skillfully resolved.
AGC BUILD SAN DIEGO AWARDS - 2019
PROJECT: Sycuan Casino Resort CONTRACTOR: Swinerton OWNER: Sycuan Band of Kumeyaay Nation ARCHITECT: Hnedak Bobo Group PROJECT DESCRIPTION: This project included over 500,000 square feet of expansion and remodel
to the existing casino, including a new ground-up, 4 diamond, 12-story, 302 key hotel, swimming pools, spas, and a lazy river. This project also included 25,000 square feet of a new conference and events center. Architectural features include a cantilevered edge bar at level one of the casino, pitched roof with an eight-foot overhang at both sides of the hotel tower, and 12 floors of adhered stone on both stair towers. BIM coordination ensured all prefabrication was maximized and field efficiencies were achieved. The project was initially over budget by $25 million, but the Swinerton team used value engineering to reduce cost yet maintain the intent of the overall project.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
PRIVATE WORK
BUILDING CONSTRUCTION
21
22
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
23
CONSTRUCTION
UNDERGROUND/UTILITIES
24
PROJECT: Hale Ave. Emergency Sewer Replacement CONTRACTOR: Orion Construction Corporation OWNER: City of Escondido ENGINEER: Orion Construction Corporation PROJECT DESCRIPTION: The City of Escondido faced an immediate emergency after the
inspection of a deteriorated sewer trunk main feeding into the Hale Avenue Resource Recovery Facility sewage treatment plant. In April 2018, the City approached Orion Construction, which had crews and equipment working onsite by the end of the month. 1580 linear feet of 36” sewer main and 580 linear feet of 30” sewer main was replaced, a sewer bypass was installed, 11 sewer manholes were replaced, and 36 feet of abandoned lines were 100% filled with grout. Work was completed in August 2018, and it was an extremely fast-paced emergency public project in heavily trafficked areas on numerous private properties.
AGC BUILD SAN DIEGO AWARDS - 2019
toolshedrentals.com
AGC Member
OPEN AT 6:00AM - OPEN SATURDAYS
Like us Follow us Follow us on Facebook on Instagram on Twitter
FAST DELIVERY EVERYWHERE
WE HAVE THE EQUIPMENT!
Chris Dalsimer 760-644-1078
Mark Martini 760-274-3250
Charlie Rodriguez 760-960-3573
Hal Dahlstrom 951-230-7402
WE THINK IT’S REALLY ABOUT THE PEOPLE! SERVING ALL OF SOUTHERN CALIFORNIA 156 W. MISSION AVENUE• ESCONDIDO • CA • 92025 • (760) 743-6700 RECOGNIZING EXCELLENCE IN CONSTRUCTION
25
CONSTRUCTION
HEAVY/HIGHWAY PROJECT: Willow Street Bridge Replacement Project CONTRACTOR: Flatiron West, Inc. OWNER: City of Chula Vista ARCHITECT: T.Y. Lin International PROJECT DESCRIPTION: This project required the removal and replacement of the existing Willow
Street Bridge. To maintain access across the Sweetwater River during construction, the new bridge was constructed in two phases. The 620-foot post tensioned Box Girder Bridge was built on 32 cast-in-drilled-hold piles, which varied in size from 30 to 96 inches. To convey local storm runoff from the project site, the contract required significant improvements to the area’s drainage. One of the more complex operations was the construction of a 600-foot long double box culvert. The 15-foot-wide by 5-foot-deep culvert ran down Willow Street and crossed the busy intersection at Bonita Road.
CONSTRUCTION
HEAVY/HIGHWAY
26
PROJECT: Gilman Drive Bridge CONTRACTOR: Mid-Coast Transit Constructors OWNER: San Diego Association of Governments (SANDAG) ARCHITECT: Safdie Rabines Architects, KTU+A Planning + Landscape Architecture PROJECT DESCRIPTION: This was a distinct project within the Mid-Coast Corridor Projects’
umbrella. The Gilman Drive Bridge is a 406-foot concrete arch bridge with three spans and a multicell post-tensioned box section covering eight lanes of Interstate 5. The superstructure, including the arch legs, consists of over nine million pounds of concrete. The bridge was pre-stressed using 25 miles of high-strength steel strands pulled with enough force to create over 14 million pounds of compression. The complex design, coupled with the challenges of working over an active freeway, required innovative construction techniques to safely construct the bridge. These challenges were addressed through extra planning, communication, and collaboration among management, craft workers, and subcontractors.
AGC BUILD SAN DIEGO AWARDS - 2019
PROJECT: South Bay Bus Rapid Transit Segment 3 CONTRACTOR: Pulice Construction, Inc. OWNER: San Diego Association of Governments (SANDAG) ARCHITECT: Kimley Horn & Associates PROJECT DESCRIPTION: This project included the construction of the Otay Mesa Transit Center,
which improves traffic flow and the movement of commodities and people between the United States and Mexico. It was broken up into ten phases to minimize public disruption. Work included clearing and grubbing, tree removals, excavation, grading, curb & gutter, HMA, PCC pavement, signage, striping, storm drain infrastructure, new irrigation services, street lights, traffic signal improvements and communication, and BRT station amenities. Best management practices were used to protect against excessive amounts of dirt, silica, and constant maintenance.
CONSTRUCTION
HEAVY/HIGHWAY
PROJECT: General Dynamics NASSCO Graving Dock Cofferdam CONTRACTOR: R.E. Staite Engineering, Inc. OWNER: General Dynamics NASSCO ARCHITECT: Triton Engineers, Inc. PROJECT DESCRIPTION: This massive project was designed and constructed utilizing approximately
750 tons of heavy custom-fabricated steel components. It consisted of H-Pile, a steel waler system and sheet pile, each averaging 120 feet long, and driven up to 90 feet deep into the underlying mudline beneath San Diego Bay in an average depth of 30 feet of tidal bay saltwater. Dewatering the entire Graving Deck involved the around-the-clock pumping of 25 million gallons of water through NASSCO’s water filtration system, and R.E. Staite continues to monitor the system 24 hours a day, seven days a week. One of the biggest challenges is that the cofferdam had to be watertight and maintained within 6 feet of elevation in order to functional.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
CONSTRUCTION
HEAVY/HIGHWAY
27
CONSTRUCTION
HEAVY/HIGHWAY
28
PROJECT: I-805 North HOV/BRT Design Build Project CONTRACTOR: Skanska OWNER: Caltrans ARCHITECT: AECOM PROJECT DESCRIPTION: This project added one high-occupancy vehicle (HOV) / bus rapid
transit (BRT) lane in each direction of the I-805 freeway for approximately 4 miles from SR-52 to Mira Mesa Boulevard and the south-facing direct access ramps (DAR) at Carroll Canyon Road. The 2,280 foot DAR included a new 480 foot bridge and two 1,800 foot soil nail / tie-back walls with a maximum height of 45 feet. The new lanes, joined with the existing HOV/BRT lanes, now provide continuous HOV access to SR-52. An Integrated Project Office, formal facilitated partnering, over the shoulder design review meetings ensured that project schedule, budget, and performance objectives were met. Together, Skanska and Caltrans delivered the project with zero recordable injuries.
AGC BUILD SAN DIEGO AWARDS - 2019
Technology solutions and support:
RDO does that.
RDO Equipment Co. is committed to being an industry leader in technology and SmartGradeTM is no exception. We train and equip our team to ensure customers have the knowledge and support they need to keep equipment productive, and maximize opportunities that come with new innovations. We make sure technology works for our customers―and their bottom lines. Call RDO Equipment Co. to see what we can do for you. ARIZONA
Chandler Flagstaff Phoenix Prescott Tucson Yuma
602-845-1800 928-526-0639 602-415-4700 928-776-8300 520-294-5262 928-341-7100
CALIFORNIA Imperial Indio Lakeside Riverside
760-355-7800 760-342-8900 619-270-4300 951-778-3700
RECOGNIZING EXCELLENCE IN CONSTRUCTION
29
PUBLIC WORK
UNIQUE SMALL PROJECT PROJECT: South Mission Beach Lifeguard Station CONTRACTOR: EC Constructors, Inc. OWNER: City of San Diego ARCHITECT: Ruhnau Clarke PROJECT DESCRIPTION: This project included demolition of an existing 897 square foot, three-story
lifeguard tower, built in 1974, and construction of a new 3,676 square foot, three-story lifeguard station. The new lifeguard station was built side by side the existing station to maintain lifeguard service in the area during construction. Work also included erosion control barrier; extension of a six-foot wide sidewalk; re-striping of accessible parking stalls; and landscaping repair. The project duration included a two-year delay due to a lawsuit filed against the City of San Diego by the Citizens for Beach Rights, and a three-month absence of work due to beach moratorium periods from late May to early September.
PUBLIC WORK
UNIQUE SMALL PROJECT
30
PROJECT: Avenida De La Playa Storm Drain Reconstruction – Phase 2 CONTRACTOR: KTA Construction, Inc. OWNER: City of San Diego ENGINEER: Rick Engineering PROJECT DESCRIPTION: This project involved the removal of an existing, failed, pre-cast concrete
drainage structure and replacement with a new cast-in-place concrete structure. Each structure was approximately 650 linear feet in length and included curbs, streets, cross gutters, hardscape & landscape. Challenges included working in a limited construction area; a short construction schedule; continuous dewatering due to rainfall and tidal influence; as well as beach and property access issues for the residents, merchants, and public. Even with the adverse working conditions, the project was completed on time and on budget thanks to innovative construction methods, such as a well point dewatering system, shoring system, and effective stabilization of the trench walls.
AGC BUILD SAN DIEGO AWARDS - 2019
PROJECT: Ladera Street (Sunset Cliffs) Emergency Bluff Stabilization CONTRACTOR: Orion Construction Corporation OWNER: City of San Diego ENGINEER: WSP PROJECT DESCRIPTION: A portion of the bluff near the historic surfer access staircase had collapsed
and fallen into the ocean. The City of San Diego was concerned for the bluff’s stability because it posed a serious threat to life and safety of the beach goers. The city, however, wanted to maintain access to the popular surf spot during construction. Orion Construction and WSP were engaged as emergency contractors, and promptly completed a stability assessment and presented several options for bluff stabilization. After the preferred option was selected, Orion rapidly completed planning and execution of design and construction work to restore safe access for surfers to the base of the bluff on an expedited time frame.
PUBLIC WORK
UNIQUE SMALL PROJECT
PROJECT: San Diego Zoo Rex’s Roar CONTRACTOR: Swinerton OWNER: San Diego Zoo Global ARCHITECT: FPBA PROJECT DESCRIPTION: This 5,000-square foot site renovation, located at the front entrance of
the San Diego Zoo, is a 10-ton, 27-foot tall bronze sculpture of Rex the Lion landing on one paw at a 30-degree angle. This cantilevered structure is made possible by the large 50-ton footing on which Rex rests his paw, and by the stainless-steel skeletal frame which supports the 200 bronze pieces that make up his body. 3D printing was used to scale the sculpture from a 12-inch model to a 7-foot, and a preconstruction 3D site logistics plan helped with the 14-hour installation window in time for a surprise unveiling. There were safety challenges, but barricades allowed construction works to get in and out of the site with minimal disruption to the Zoo’s daily operations.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
PUBLIC WORK
UNIQUE SMALL PROJECT
31
PRIVATE WORK
UNIQUE SMALL PROJECT PROJECT: Camino De La Reina CONTRACTOR: Bergelectric Corp. OWNER: Casey Brown Company ARCHITECT: Andrew Mangan, Walcott AI ELECTRICAL ENGINEER: Michael Wall Engineering PROJECT DESCRIPTION: This project included the complete transformation of the historic San
Diego Union Tribune Newspaper buildings to a state-of-the-art creative office facility. Both buildings were gutted down to the concrete walls and ceilings. Bergelectric was responsible for all aspects of the electrical installation, which included re-routing the 12kV distribution, and the demolition and re-routing of a co-generation system. The existing concrete structures made for a difficult electrical installation, and the power requirements for the old newspaper machines created challenges.
PRIVATE WORK
UNIQUE SMALL PROJECT
32
PROJECT: Sycamore Ranch CONTRACTOR: TC Construction Co., Inc. OWNER: William Lyons Home ENGINEER: Fuscoe Engineering PROJECT DESCRIPTION: This roadway project consisted of clearing and grubbing,
grading, creek diversion, storm drains, keystone retaining walls, sidewalks, curb and gutter, asphalt paving, crash cushions, lodge pole fencing, landscaping, and the installation of an enviro-flex erosion system. The cast in place concrete hydro arch culvert, which serves as a roadway bridge, had to be installed quickly, since there is only one excavator grappling attachment in the United States. The presence of ground water created challenges, but dewatering pumps and a highline allowed for the delivery of free water to a nearby golf course. It took 25 years for the project to be approved, but the constructed roadway now unites two communities.
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
33
SUSTAINABLE PROJECT PROJECT: County of San Diego North Coastal Live Well Health Center CONTRACTOR: Balfour Beatty OWNER: County of San Diego ARCHITECT: HMC Architects PROJECT DESCRIPTION: Inspired by the environment that surrounds it, this project is a beacon of
hope and a shining example of sustainability. The three-story, 36,000 square foot facility houses the County’s Aging and Independence Services, a Military and Veterans Resource Center, Community Health Promotions, Regional Administration, Public Health Services, and Behavioral Health Services. Lean construction was incorporated into this Design-Bid-Build project, as integrated project delivery was utilized, as was A3 problem solving, and a Start-Stop-Keep process. Given a tight budget and short timeline, the team embraced the County of San Diego’s vision and delivered the first Zero Net Energy Facility in California and a LEED Platinum certified project.
SUSTAINABLE PROJECT PROJECT: UC San Diego Mesa Nueva Graduate and Professional Student Housing CONTRACTOR: Hensel Phelps OWNER: The Regents of the University of California ARCHITECT: Mithun, Inc. and RJC Architects PROJECT DESCRIPTION: This project is the first of a three-phase program and one of the most student-friendly, energy-efficient, a nd technologically a dvanced s tudent h ousing c enters in the United States. The new $188 million mixed-use project includes 618,076 square feet of five residential buildings with 1,355 beds, as well as a 5-story, 904 stall parking structure. The state-ofthe-art campus housing has 11,000 square-feet of common amenity and administration space serving as a collaboration area for students, faculty, and residents. Through teamwork and a proactive approach, the team overcame a faucet manufacturing defect that partially flooded one of the buildings. The project was designed for sustainability and efficiency and received LEED Gold Certification.
34
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
35
UNIQUE SPECIAL PROJECT PROJECT: Desert View Drive Slope Repair and Restoration CONTRACTOR: Cass Arrieta OWNER: City of San Diego ENGINEER: City of San Diego PROJECT DESCRIPTION: This project was completed in a timely manner with the coordinated efforts
of civil, environmental, legal, geotechnical, and construction professionals. Due to the proximity to homes and a major highway, Homeland Security was consulted to create a landside disaster plan, and I-5 had to be shut down at night to bring in materials. The slope repair was designed to improve the eroded slot canyon beyond the original condition and stabilize the landslide potential. The storm drain was realigned and extended downhill to a safe point of discharge. Slope repair was complicated by limited access, coordination with multiple stakeholders, elevated safety concerns, access from I-5, construction extending into the rainy season, and permitting through multiple agencies.
UNIQUE SPECIAL PROJECT PROJECT: University of California, San Diego Satellite Utility Plant CONTRACTOR: Dynalectric Company OWNER: The Regents of the University of California ELECTRICAL ENGINEER: P2S Engineering, Inc. ARCHITECT: Hanna Gabriel Wells PROJECT DESCRIPTION: This new 7,000 square foot utility plant is the only integrated emergency
power control system on campus that serves a multi-building complex. It allows for offsite utility distribution, which eliminates generators in buildings and offers additional power reliability. Housing the entire system in one location offers cost savings to the university through ease of maintenance. In addition, the complex manhole systems allow for accessible maintenance and isolation. Another distinctive aspect is the architectural and structural excellence in the striated concrete building. The aesthetics were created through a process of mock-ups to ensure the layers of concrete reproduced an appearance that is cohesive with the existing campus.
36
AGC BUILD SAN DIEGO AWARDS - 2019
UNIQUE SPECIAL PROJECT PROJECT: Pine Valley Fire Station #44 CONTRACTOR: EC Constructors, Inc. OWNER: County of San Diego ARCHITECT: Jeff Katz Architecture PROJECT DESCRIPTION: This 13,000-square-foot two-story fire station includes three deep bays for
parking fire apparatus and a half bay for an ambulance or battalion chief vehicle, support spaces, an administrative/training area, and living accommodations. The living spaces include a fitness room, kitchen, dining, day room, individual bunk rooms and restroom facilities, and administrate office space. The walls in the apparatus bay and support spaces were constructed with CMU and integral colored board formed cast-in-place concrete. The combination of concrete and CMU provide the durability, sustainability, and cleanability a fire station requires. Additionally, the rich texture and colors of the CMU complement the aesthetics and architectural character of this rural neighborhood.
UNIQUE SPECIAL PROJECT PROJECT: Sharp Healthcare Chula Vista Ocean View Tower CONTRACTOR: Hensel Phelps OWNER: Sharp Healthcare ARCHITECT: SmithGroup PROJECT DESCRIPTION: This $190 million, 197,696-square-foot, seven-story tower connects to the
existing hospital on the medical campus, and features a large double-height lobby with a lightfilled space, and 106 spacious and private patient rooms. The new hospital includes six high-tech operating rooms, ten ICU suites, medical-surgical patient rooms, central nurse stations, family waiting areas, rooftop cafĂŠ, and indoor/outdoor dining with 270-degree panoramic ocean views. With two weeks until the deadline for the compressed collaborative structural review with OSHPD, the team came up with a solution regarding the mat foundation questions and preserved the schedule.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
37
UNIQUE SPECIAL PROJECT PROJECT: The Plunge CONTRACTOR: Lusardi Construction Company OWNER: Pacifica Enterprises ARCHITECT: James Gates Architect PROJECT DESCRIPTION: Southern California’s oldest and largest swimming pool opened in 1925
as a Natatorium in Belmont Park, fed by ocean saltwater. This new state-of-the-art facility, designed for two separate climate conditions, features a glass retractable roof and mechanical system that brings fresh air and maintains a set temperature. Due to the harsh environment (just 100 yards from the ocean) all construction and finishes were designed to be anticorrosive. The mosaic tile within the pool is an exact replica of the tile that was used in 1925, and the arches are replicas of original precast arches that not only tie The Plunge back to its origin but also a majority of historic San Diego. Taking over the design of the pool’s equipment and filtration system was a challenge, but countless in-person design meetings allowed the team to pass inspection.
UNIQUE SPECIAL PROJECT PROJECT: Gilman Drive Bridge CONTRACTOR: Mid-Coast Transit Constructors OWNER: San Diego Association of Governments (SANDAG) ARCHITECT: Safdie Rabines Architects, KTU+A Planning + Landscape Architecture PROJECT DESCRIPTION: This was the first Construction-Manager / General Contractor (CM / GC)
project delivered by SANDAG. The 406-foot concrete arch bridge with three spans and a multicell post-tensioned box section covers eight lanes of Interstate 5. The complex geometry required unique falsework and form designs. The superstructure, including the arch legs, consists of over nine million pounds of concrete. The bridge was pre-stressed using 25 miles of high-strength steel strands pulled with enough force to create over 14 million pounds of compression. The complex design, coupled with the challenges of working over an active freeway, required innovative construction techniques to safely construct the bridge.
38
AGC BUILD SAN DIEGO AWARDS - 2019
UNIQUE SPECIAL PROJECT PROJECT: Catalina 12” Cast Iron Water Main and Catalina Sewer Main Improvement Project CONTRACTOR: Orion Construction Corporation OWNER: City of San Diego ENGINEER: Harris & Associates PROJECT DESCRIPTION: This was a $19 million Design Build project where the City of San Diego
elected to perform a “Full Utility Corridor Upgrade” due to the potential of major traffic and community impacts. Catalina Boulevard is the main access point for Naval Base Point Loma, Point Loma Nazarene University, Cabrillo National Monument, Fort Rosecrans National Cemetery, and many other small businesses and local residents. Upgrades and replacements included six different parallel pipelines, 24” Steel Watermain, 16” PVC Watermain, 12” Sewer Main, 54 Private Property Sewer Lateral Replumbs, 18” RCP Storm Drain, and a new Fiber Optic Cable.
UNIQUE SPECIAL PROJECT PROJECT: Walkabout Australia at the San Diego Zoo Safari Park CONTRACTOR: Pacific Building Group OWNER: San Diego Zoo Global ARCHITECT: Hubbell & Hubbell SAN DIEGO ZOO SAFARI PARK ARCHITECT: Robyn Badger PROJECT DESCRIPTION: This $14 million, 3.5-acre project, includes a new 8 foot wide visitor path
that winds along several exhibit yards, an airlock house at the entry of the kangaroo exhibit, and three new barns that provide animal holding areas. Designed to look like an antique Australian Woolshed with reclaimed wood and metal, the largest barn also has an event space on the second floor. Small ponds and water features, including a donated water tank from a local farm, were added to the animal yards, while artists’ concrete formations, elevated decks and a rebuilt windmill added dimension to the exhibit. Pacific Building Group overcame challenges by working closely with animal keepers and the Zoo’s horticulture department to maintain the safety of animals, plants, and people at all times.
RECOGNIZING EXCELLENCE IN CONSTRUCTION
39
UNIQUE SPECIAL PROJECT PROJECT: General Dynamics NASSCO Graving Dock Cofferdam CONTRACTOR: R.E. Staite Engineering, Inc. OWNER: General Dynamics NASSCO ENGINEER: Triton Engineers, Inc. PROJECT DESCRIPTION: This project is a one-of-a-kind custom cofferdam designed and
constructed utilizing approximately 750 tons of heavy custom-fabricated steel components. It consisted of H-Pile, a steel waler system and sheet pile, each averaging 120 feet long, and driven up to 90 feet deep into the underlying mudline beneath San Diego Bay, in an average depth of 30 feet of tidal bay saltwater. One aspect of this Design-Build project’s uniqueness was the fasttrack design and construction engineering feat. The biggest challenge faced was working in an active shipyard under intense schedule completion constraints, while concurrently maintaining the owner’s active schedule and operational continuity.
40
AGC BUILD SAN DIEGO AWARDS - 2019
RECOGNIZING EXCELLENCE IN CONSTRUCTION
41
It's Good Business to do Business with an AGC Member
Skill • Integrity • Responsibility
Building Your Quality of Life
First in service since 1979
tprco.com
Beam
and
Plate
HigH CleaRanCe SHoRe
Steel tRenCH Box
QuadRa BRaCe
Slide Rail SyStem
manHole Box
aluminum Quik-Box
Southern California locations Los Angeles, CA North Los Angeles Ventura / Santa Barbara
800-821-4478 877-246-4087 855-834-9058
Orange County Inland Empire San Diego
â—? 34 locations across the U.S.
800-772-8004 877-246-4085 800-350-7528
PRSRT STD US POSTAGE
PAID
SAN DIEGO, CA PERMIT # 2686
