MAIN COMPONENTS CONSTRUCTION DETAILS AND OPTIONS
by AFDJ
Next Article
Pump Casing Cast Iron
304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Pump Shroud Cast Iron 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Bearing Housing Cast Iron 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Shaft 304 Stainless Steel 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel, 4110 High Tensile Steel
Impeller Brass Cast Iron, 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Impeller Nut Brass Cast Iron, 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Seal Cover Cast Iron 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Bearing End Caps Cast Iron 304 & 316 Stainless Steel, Duplex Stainless Steel & Super Duplex Stainless Steel
Other Construction Details
Our casting quality is completed to a high standard and quality checked, any components with risk of corrosion are painted in Marine Grade Paint for maximum corrosion protection.
Impeller and Nut is constructed in Brass for proven longevity and has superior wear and corrosion resistance.
Bearings are NSK Brand Single Row Radial Ball Bearings.
Shaft Seal is a Silicon Carbide / Viton / Carbon / 316 Stainless Steel Seal.
Pump Flanges cast with Extra Thickness added for better strength and come standard universally drilled in both Chinese Bolt Pattern (Table H) and AUS Standard Bolt Pattern (Table D) providing better flexibility whether you are installing a new system or replacing an old system, removing the need to modify existing pipework to suit either bolt pattern.
Sealing Method
Our Sealing Method is a Silicon Carbide / Viton / Carbon / Stainless Steel mechanical seal which runs in its own enclosed sealed chamber which is lubricated by food grade white oil, this sealing method protects the pump in instances where it may run for extended durations of time without water “ran dry” without risking damage to the pump or seal. This innovative new sealing method is a superior sealing method due to the reliability and the little maintenance required, mechanical seals provide a 100% seal rather than the outdated gland packing method which constantly leaks or sucks air, mechanical seals are proven to increase longevity of the pump mainly by protecting the bearings from residual moisture which is a proven factor in premature bearing failure.
Model Number Format
EXAMPLE MODEL NO: 300HWG-8A
Operating Limits
Ambient Temperature: 50˚ C
Liquid Maximum Temerature : 50˚ C
![](https://assets.isu.pub/document-structure/230516052811-51a83dba66672fffe5bf880063e631ac/v1/5dfffedbb65f81a05784f9f8cfcf562d.jpeg)
Maximum Suction Lift: 6 Meters (Vertical)
Other Specifications
Can be direct coupled
Direction of Rotation: Anti-Clockwise
Designed Tolerance Between Suction Shroud and Impeller Face: 3mm ± 2mm
Flange Bolt Pattern: Universal China (Table H) + Table D Drilled Flanges
Mechanical Seal Oil Bath: STELLA White Oil (ISO 15, 22, 32, 46 & 68)
Older Pump Model Numbers And Equivalents
Part Number Identification
![](https://assets.isu.pub/document-structure/230516052811-51a83dba66672fffe5bf880063e631ac/v1/e11daa8a6c78ed57c023398a5f7cd10a.jpeg)
PART NUMBER FORMAT:
(Pump Model)-(Series Number)P(Part Identification Number)(Material Code S = Standard Material)(Trim Impellers Only)
Example 1: 200HWG-8-P3-S Standard 304 Stainless Steel Shaft for a 200HWG-8 Mixed Flow Pump
Example 2: 300HWG-5-P13-304SS-A 304 Stainless Steel Impeller for a 300HWG-5 Mixed Flow Pump with A Level Trim (if ordering without Trim it would just be 300HWG-5-P13-304SS)
MATERIAL CODES: CI Cast Iron B Brass 304SS 304 Grade Stainless Steel 316SS 316 grade Stainless Steel
2205DSS 2205 Duplex Stainless Steel
