DRAG / MUSCLE / STREET / HIGH PERFORMANCE
‘99 - ‘04 F-150 LIGHTNING/HARLEY HEAT EXCHANGERS The 80245N offers huge gains over the factory model by offering more surface area, volume, and superior core construction. It is a single pass system and can be installed in less than 30 minutes. There is no drilling, cutting, or fabrication required. Detailed instructions included. The 80249N offers even more cooling capacity by adding a double pass design (uses a baffle to pass the coolant through the core twice). The dual fan kit adds over 1080 CFM of constant airflow to further the cooling system. Detailed instructions included. 1999–2004 F-150 LIGHTNING / HARLEY DIMENSIONS SATIN FINISH PRICE BLACK FINISH PRICE LIGHTNING HEAT EXCHANGER (L - 26-3/8”) X (W - 3”) X (H - 8-7/8”)* 80245N $489.99 80245NB $689.99 DOUBLE PASS LIGHTNING HEAT EXCHANGER (L - 26-3/8”) X (W - 3”) X (H - 8-7/8”)* 80249N $499.99 80249NB $699.99 DOUBLE PASS LIGHTNING HEAT EXCHANGER W/ FAN KIT** (L - 26-3/8”) X (W - 5-3/8”) X (H - 8-7/8”)* 80249N-FS $799.99 80249N-FSB $999.99 LIGHTNING HEAT EXCHANGER FAN KIT ONLY (L - 22-11/32”) X (W - 2-5/32”) X (H - 8-7/8”)* 80249NFAN*** $369.99 80249NFANB*** $569.99 *OUTSIDE DIMENSIONS TANK TO TANK, TOP TO BOTTOM & FRONT TO BACK OF CORE. **WIDTH MEASUREMENTS INCLUDE FAN WIDTH. ***FAN KIT IS NOT COMPATIBLE WITH STANDARD STYLE 80245N.
80249N
80249N-FS
80249NB
80249N-FSB
‘10 - ‘14 SUPERCHARGED F-150/RAPTOR HEAT EXCHANGERS The 80284 is over 3 times thicker than competitor heat exchangers. The 80284 offers increased surface area, volume, and a double pass design (uses a baffle to pass the coolant through the core twice) to help reduce coolant temperatures by as much as 30°F. The 80284PRO comes with the dual fans which adds over 1600 CFM of constant airflow (800 CFM per fan) to reduce heat soak when there is reduced air flow through the heat exchanger. The heat exchanger can be installed in approximately 1 hour. These heat exchangers will fit Roush or Whipple supercharger kits. Whipple installations require extra mounting brackets. There is no drilling, cutting, or fabrication required. Detailed instructions included. 2010 & UP SUPERCHARGED F-150 / RAPTOR DIMENSIONS DOUBLE PASS F150/RAPTOR HEAT EXCHANGER (L - 26”) X (W - 3”) X (H - 15-3/32”)* DOUBLE PASS F150/RAPTOR HEAT EXCHANGER W/ FAN KIT (L - 26”) X (W - 5”) X (H - 15-3/32”)* WHIPPLE MOUNTING BRACKET KIT *OUTSIDE DIMENSIONS TANK TO TANK, TOP TO BOTTOM & FRONT TO BACK OF CORE.
SATIN FINISH PRICE 80284NDP $489.99 80284PRO $799.99 80284WHIPPLE $99.99
BLACK FINISH PRICE 80284NDPB $689.99 80284PROB $999.99
80284NDP
80284PRO
CONNECT WITH AFCO www.AFCOracing.com 800-632-2320
COOLING
81
