Platinum Automotive Product Guide

Page 1

PRODUCT GUIDE AUTOMOTIVE

START/STOP PLUS AGM PRODUCTS

AGM (Absorbed Glass Mat) is manufactured specifically for Micro-Hybrid vehicles fitted with the Start/Stop, Brake Energy Regeneration and other technologies designed to reduce fuel consumption.

The Platinum Start/Stop Plus AGM batteries have increased cyclic performance. Not only can they cope with increased demand from fuel saving devices on the vehicle, they are also able to power a wider range of ancillary equipment, even when the engine is in the idle position.

LOWERS

CO 2 EMISSIONS (5-8%)

INCREASES

FUEL EFFICIENCY (5-8%)

FULLY SEALED

BATTERY 100%

AUXILIARY BATTERIES IN RANGE

PLEASE NOTE AGM batteies can be fitted on all Start / Stop vehicles but you must replace ‘like for like’ where AGM was originally fitted.

START/STOP AFB

AFB (Advanced Flooded Battery), also known as ECM (Enhanced Cyclic Mat) or EFB (Enhanced Flooded Battery), is an evolution of the traditional lead-acid battery that has been designed to meet the requirements of the new Start/ Stop Micro-Hybrid compact vehicles that have entered the market.

The Start/Stop AFB is a reliable power source that supplies all ancillary equipment, including all ‘in car electrical loads’, even when the engine is in an idle/

off position and offers twice the cyclic capability of standard wet flooded batteries.

MAINTENANCE

LOWERS CO 2 Emissions (3-6%)

INCREASES FUEL EFFICIENCY (3-6%)

SPILL PROOF TO A 55 Degree Angle

PLEASE NOTE you can replace AFB batteries with AFB (ECM/ EFB) or AGM batteries only.

The Platinum Prestige Plus range has been specifically designed to exceed O.E specification & offer superior performance, with increased service life, in even the most demanding conditions.

The Platinum Prestige Plus range is fitted with a sealed, maintenance free lid, which encompasses the use of labyrinth technology and brings added safety. Apart from being maintenance impossible, this technology is vital when the battery is installed in the cabin rather than under the bonnet.

PRESTIGE PLUS PRESTIGE

The Platinum Prestige ranges are manufactured to original equipment specifications and quality standards. This commitment ensures high performance, long service life & improved reliability making the Platinum Prestige range ideal for the vehicles of today.

The entire range benefits from Calcium technology, which provides longer shelf life, greater resistance to high under bonnet temperatures and reduced water loss throughout its life.

WASTE BATTERIES

IT'S A LEGAL REQUIREMENT

We provide a fully legally compliant scrap battery collection service.

DUTY OF CARE

Protect our environment by recycling responsibly.

85% + CAR PARC COVERAGE +30% POWER SEALEDMAINTENANCE FREE 97% + CAR PARC COVERAGE MAINTENANCE FREE DIESEL APPROVED
Reference ETN ref DIN Ref Voltage Ah (C20) CCA (EN) Length (mm) Width (mm) Case height (mm) Height (mm) Platinum AGM Car AGM019E 595901085 59501 12 95 850 354 175 190 190 AGM020E 605901095 60501 12 105 950 393 175 190 190 AGM027E 560901068 56001 12 60 680 242 175 190 190 AGM079E 550901054 55001 12 50 540 207 175 190 190 AGM096E 570901076 57001 12 70 760 278 175 190 190 AGM115E 580901080 58005 12 80 800 317 175 190 190 Platinum AGM Auxiliary AGM043E 545904037 54504 12 45 370 236 127 200 224 AGM044E 545903037 54503 12 45 370 236 127 200 224 AGM054E 535001034 53501 12 35 340 197 129 203 227 AGM055E 535002034 53502 12 35 340 197 129 203 227 AGM158E 545901037 54501 12 45 370 236 127 200 224 AGM159E 545902037 54502 12 45 370 236 127 200 224 AUX-CTMX14-BS 12 12 170 150 87 145 145 AUX-CTMX9-BS 12 9 120 150 87 107 107 Platinum AFB AFB005LE 565000056 56500 12 65 560 230 172 202 223 AFB005RE 565001056 56510 12 65 560 230 172 202 223 AFB019E 595707085 59507 12 95 850 353 175 190 190 AFB027E 560500056 56000 12 60 560 242 175 190 190 AFB030E 580020064 58012 12 80 640 255 172 202 223 AFB031E 580000064 58002 12 80 640 255 172 202 223 AFB044E 555000043 55500 12 55 430 238 129 202 225 AFB054E 540026040 54026 12 40 400 187 127 202 225 AFB055E 540027040 54027 12 40 400 187 127 202 225 AFB096E 570500065 57000 12 70 650 278 175 190 190 AFB100E 565500065 56501 12 65 650 278 175 175 175 AFB110E 575500073 57501 12 75 730 317 175 175 175 AFB115E 580500073 58000 12 80 730 317 175 190 190 AFB158E 555021043 55521 12 55 430 238 129 202 225 AFB249E 595000078 59500 12 95 780 304 174 202 225 Platinum Prestige Plus 017SPPLA 590125080 59025 12 90 800 354 175 175 175 019SPPLA 600402085 60002 12 100 850 354 175 190 190 027SPPLA 563400057 56302 12 63 570 242 175 190 190 063SPPLA 548401046 54816 12 48 460 207 175 175 175 075SPPLA 563400060 56304 12 63 600 242 175 175 175 079SPPLA 550113042 55013 12 50 420 207 175 190 190 096SPPLA 577400070 57700 12 77 680 278 175 190 190 100SPPLA 574402070 57413 12 74 700 278 175 175 175 Platinum Prestige 004LE 545041042 54541 12 45 420 200 172 202 223 004RE 545042042 54542 12 45 420 200 172 202 223 005LE 560410051 56068 12 60 510 230 172 202 223 005RE 560411051 56069 12 60 510 230 172 202 223 017E 588403076 58820 12 88 760 354 175 175 175 018E 588110076 58830 12 88 760 354 175 175 175 019E 590402080 59033 12 90 800 354 175 190 190 020E 610402090 61054 12 110 900 393 175 190 190 027E 560408054 56019 12 60 540 242 175 190 190 030E 570412059 57088 12 70 590 255 172 202 223 031E 570413059 57089 12 70 590 255 172 202 223 037E 535082030 53582 12 35 300 239 133 180 200 038E 535080030 53580 12 35 300 239 133 180 200 043E 545157039 54523 12 45 390 238 129 202 225 044E 545155039 54524 12 45 390 238 129 202 225 048E 545077035 54577 12 45 350 220 135 202 225 049E 545079035 54579 12 45 350 220 135 202 225 054E 538126034 53820 12 38 340 187 127 202 225 054HDE 538125034 53804 12 38 340 187 135 202 225 055E 538127034 53822 12 38 340 187 127 202 225 063E 544402038 54405 12 44 380 207 175 175 175 065E 555101049 55519 12 55 490 242 175 175 175 068E 570029059 57029 12 70 590 270 175 200 222 069E 570024059 57024 12 70 590 270 175 200 222 072E 570072056 57072 12 70 560 262 175 205 205 075E 560409055 56020 12 60 550 242 175 175 175 077E 544413038 54413 12 44 380 207 175 175 175 078E 555127049 55508 12 55 490 242 175 175 175 079E 545401040 54559 12 45 400 207 175 190 190 085E 544012038 54417 12 44 380 207 175 175 175 086E 572013064 57233 12 72 640 278 175 190 190 095E 565014059 56514 12 65 590 278 175 175 175 096E 574012068 57412 12 74 640 278 175 190 190 097E 560091053 56091 12 60 530 242 175 175 175 100E 572409065 57244 12 72 650 278 175 175 175 101E 526015029 52615 12 26 290 186 123 163 181 101RE 526016029 52616 12 26 290 186 123 163 181 110E 580406076 58014 12 80 760 317 175 175 175 111E 560017056 56017 12 60 560 235 183 160 175 113E 560016056 56016 12 60 560 235 183 160 175 115E 580400074 58042 12 80 740 317 175 190 190 116E 580402074 58046 12 80 740 317 175 190 190 158E 545156039 54551 12 45 390 238 129 202 225 159E 545158039 54578 12 45 390 238 129 202 225 202E 540400034 54008 12 40 340 175 175 190 190 249E 590404074 59004 12 90 740 304 174 202 225 250E 590405074 59005 12 90 740 304 174 202 225 700E 550115056 55022 12 50 560 208 179 185 185 800E 554104050 55404 12 54 500 230 180 185 185 900DTE 570111066 57011 12 70 660 260 180 185 205 MX5E 532022047 53222 12 32 420 195 134 175 175 S101E 532030031 53230 12 32 310 197 129 157 185 S101RE 532034031 53234 12 32 310 197 129 157 185 404E 077015036 07715 6 77 360 215 170 160 180 421E 063017027 06317 6 63 270 162 165 190 210
