General
General WARNING DO NOT make repairs or adjustments unless you have both authorization and training. Repairs and adjustments that are not correct can create a dangerous operating condition. DO NOT operate a lift truck that needs repairs. Report the need for repairs to your supervisor immediately. If repair is necessary, put a DO NOT OPERATE tag on the control handle. Remove the key from the key switch.
This manual describes the electrical systems used on the motorized hand lift trucks. Procedures are outlined for the maintenance, adjustment, and repair that may be required when servicing these lift trucks. The drive control for the Motorized Hand Trucks is a Curtis Transistor Motor Controller 1297 Model, also known as a MOSFET or PMC system. See Figure 1, Figure 2, and Figure 3.
