WOODCUTTING BLADES, KNIVES AND DRILLS

EUROPE • woodmizer.eu | AFRICA • woodmizerafrica.com | ASIA • woodmizerasia.com


2


A growing brand of wood processing tools No matter what kind of machine you have, or what kind of wood you are cutting, you can get all your circular blades, frame saw blades, drills, planer knives, and wideband blades directly from Wood-Mizer! Wood-Mizer TOOLS are already being used by our customers throughout Europe, Africa, and North America. Check with your local Wood-Mizer representative to compare prices from your current supplier, and try out some Wood-Mizer TOOLS! The product range covers just about every sawblade size and application required, and the product range is expanding all the time. The product range is designed to cover highly specific needs of our customers, not just to supply the most popular profiles, and so we are flexible depending on your needs to prepare specific products and quotations.

Wood-Mizer TOOLS advantages

QUALITY: High quality German & Swedish steel tools. DURABILTY: Higher quality manufacturing processes deliver higher durability, and customers agree that they get better performance with Wood-Mizer TOOLS. PRICE: High performance drills, knives, saws and other cutting TOOLS at reasonable cost.

EUROPE • woodmizer.eu | AFRICA • woodmizerafrica.com | ASIA • woodmizerasia.com

3


How to read circular saw blade part numbers Example: TM A350.016.70 Standard order format TMA

Multi-Rip for softwood -blackened

TMB

Multi-Rip for hardwood - blackened

TR

Ripping

TC

Cross Cutting

TLP

Plywood

TLM

Panel Sizing – Main Line

TLH

Panel Sizing - Super Line

350

Outside diameter - mm

16

Quantity of teeth

70

Bore diameter - mm

Example: TMB350.018. 70S/4.2/2.8/4R Special order format TMB

Multi-Rip for hardwood

350

Outside diameter - mm

18

Number of teeth

70

Bore diameter – mm

4,2

Width of carbide - mm

2,8

Body thickness - mm

4R

Number of raker teeth

S

Polished version

4R

Quantity of raker teeth

This format is useful when reordering special order blades. Use the item from your previous order to order the same blades again.

4


Explanation of symbols Two-sided melamine

Ripping plywood

Scoring saw blades

Crosscutting plywood

Ripping

Ripping & crosscutting plywood

Crosscutting

Wooden mouldings and PVC

Multi-ripping

Tungsten carbide-tipped

Low noise saw blade

High speed steel

Dry softwood

Dry hardwood

Wet softwood

Wet hardwood

Chipboard

Laminated

Glued wood

MDF

Dowell drills

Through drills

Cylinder boring bits

Mechanical feed

Carbide

Carbide monolith

EUROPE • woodmizer.eu | AFRICA • woodmizerafrica.com | ASIA • woodmizerasia.com

5


CIRCULAR SAW BLADES

6


CIRCULAR SAW BLADES

RPM for required cutting speed and tool diameter D[mm]

n [RPM] 1500

2000

2800

3500

4500

6000

8000

10000

13000

100

8

11

15

18

24

31

42

53

63

150

12

16

22

27

35

47

63

79

94

200

16

21

29

37

47

63

84

105

250

20

26

37

46

59

79

105

300

24

32

44

55

71

94

350

28

37

51

64

82

110

400

32

42

59

73

94

450

36

47

66

82

106

500

40

52

73

92

550

43

58

81

101

600

47

63

88

650

51

68

95

700

55

73

103

Selecting cutting parameters for different materials Material

Cutting speed [m/s]

Softwood

60 – 100

Wet softwood

70 – 100

Hardwood

50 – 90

Chipboard

60 – 80

MDF board

60 – 80

Hard fibreboard

50 – 80

Soft fibreboard

60 – 100

Plywood

50 – 80

Non-ferrous metals

40 – 60

Plastic

50 – 80

Cutting speed formula:

V=

60 × 1000

[m/s]

D – tooth diameter [mm] n – revolution [min-1] V – cutting speed [m/s]

EUROPE • woodmizer.eu | AFRICA • woodmizerafrica.com | ASIA • woodmizerasia.com

7


CIRCULAR SAW BLADES

Recommended flange diameter depending on diameter of circular saws and slotting saws Outside dia [mm]

Hole dia [mm]

100 125 125 150 180 200 250 300 350 400 450 500

20 20 30 30 30 30 30 30 30 30 30 30

Flange diameter min [mm] 50 50 60 80 80 90 90 100 110 120 120 130

max [mm] 50 50 60 80 90 100 110 120 130 140 150 160

Recommended flange diameter depending on diameter of circular saws for multi-blade tools Outside dia [mm]

Hole dia [mm]

225 225 250 250 250 300 300 300 350 350 350 400 400 400 450 450 500 500 500

40 60 40 60 80 60 80 90 60 80 90 60 80 100 80 100 70 100 150

Flange diameter min [mm] 80 90 90 100 100 100 100 110 100 110 120 110 120 130 120 130 120 130 190

max [mm] 80 120 110 120 120 120 120 130 120 130 140 130 150 160 150 160 150 160 220

Tooth patterns and blade structure 1. Teeth with positive hook angle 2. Teeth with positive hook angle and anti-kickback 3. Teeth with negative hook angle 4. Teeth with positive hook angle and irregular pitch 5. Expansion slot 6. Cooling slot 7. Wiper slot 8. Keyway 9. Pin hole 10. Countersink holes 11. Noise reducing laser cut

8


CIRCULAR SAW BLADES

Types of teeth ATB α

FTG α K

TCG α

K

K β=0˚

β

P

β

P

Alternate top bevel grind

β

P

Flat top grind

Triple chip grind (trapezoidal)

Table abbreviations α

Hook angle

B

Bore diameter

β

Type of tip grind

D

Diameter

K

Kerf thickness

mm P RPM Z

Millimeters Plate thickness Revolutions per minute Number of teeth

Pin holes 2/10/60

2

Number of pin holes

10

Pin hole diameter

60

Distance between the centers of holes

Combination of pin holes COMBO3

2/7/42 + 2/9/46,4 + 2/10/60

COMBO3 2/7/42

2/9/46,4

2/10/60

EUROPE • woodmizer.eu | AFRICA • woodmizerafrica.com | ASIA • woodmizerasia.com

9


MULTIRIP SAW BLADES

CIRCULAR SAW BLADES

SAW BLADES FOR PANELS

CROSSCUT SAW BLADES

RIP SAW BLADES

Multirip saw blades for softwood

APPLICATION: ripping with raker teeth MACHINES: multirip machines with one or two arbors α

SCORING BLADES

K β=0˚

BEST FOR:

FRAME SAW BLADES

PLANER AND JOINTER KNIVES

DRILLS

P

D [mm]

B [mm]

Pin holes

Z

K

P

α

β

Cat number

200

70

4x20x5

16+2

2,5

1,8

23°

FTG

TMA200.016.70

250

70

4x20x5

18+2

3,1

2,2

23°

FTG

TMA250.018.70

250

70

4x20x5

16+2

3,1

2,2

23°

FTG

TMA250.016.70

300

70

4x20x5

18+4

3,1

2,2

23°

FTG

TMA300.018.70

300

70

4x20x5

16+4

3,1

2,2

23°

FTG

TMA300.016.70

315

70

4x20x6

18+4

3,8

2,5

23°

FTG

TMA315.018.70

350

70

4x20x5

18+4

3,9

2,5

23°

FTG

TMA350.018.70

350

70

4x20x5

16+4

3,9

2,5

23°

FTG

TMA350.016.70

400

70

4x20x5

18+4

4,2

2,8

23°

FTG

TMA400.018.70

400

70

4x20x5

16+4

4,2

2,8

23°

FTG

TMA400.016.70

450

70

4x20x5

18+4

5,0

3,2

23°

FTG

TMA450.018.70

450

70

4x20x5

16+4

5,0

3,2

23°

FTG

TMA450.016.70

500

70

4x20x5

18+6

5,2

3,2

23°

FTG

TMA500.018.70

500

70

4x20x5

16+6

5,2

3,2

23°

FTG

TMA500.016.70

550

70

4x20x5

18+6

5,5

3,2

23°

FTG

TMA550.018.70

600

70

4x20x5

18+6

6,2

4,0

23°

FTG

TMA600.018.70

600

70

4x20x5

20+6

6,2

4,0

23°

FTG

TMA600.020.70

Production of special bores available upon request.
