True to form, with the majority of the community in lockdown and working from home, operational staff are still out in the field on a daily basis, continuing to deliver high quality and safe water and wastewater services to our communities. That so few in the community even think about or recognise the fact that there is an army of operators keeping everything running around the clock, does not detract from the importance of your task and we applaud and appreciate your ongoing efforts. Like many other businesses, the COVID-19 pandemic has had a major impact on WIOA and our operations. With the majority of WIOA’s engagement with our members done through face-to-face events such as conferences, seminars and interest days, all these activities have needed to be suspended, hopefully only temporarily.
digital platforms to allow us to continue with our important role of collecting and sharing information in support of our members. We plan to continue to deliver our webinars along with other initiatives to increase engagement with our members and the broader water community. We have created a page on the website that we are regularly updating which includes links to the latest information on the pandemic from a variety of trusted sources. We will continue liaising with other water industry peak bodies, including the various Water Directorates, to ensure that we can share appropriate information or provide any assistance when required. Our congratulations are extended to Heidi Josipovic from Albury City Council who was recently re-elected as WIOA President for another year. Heidi is an integral part of WIOA’s Diversity and Inclusion working group doing some great work to assist the association with initiatives to ensure that we have an inclusive culture that embraces diversity, celebrates our differences and encourages and supports participation. The group is focussing on new initiatives, activities and events to promote and celebrate diversity in our industry.
Unfortunately, WIOA had no choice but to cancel the 2020 New South Wales, Queensland and South Australian conferences and exhibitions. We have also rescheduled the 2020 Victorian Conference that was to be held in September to the last week of November to give the event the greatest chance of proceeding. As the country comes out of lockdown in the coming months, we will monitor the situation and keep our members informed. In response to the social distancing restrictions and the cancellation of events, WIOA is now investigating the use of
WIOA President Heidi Josipovic on International Women’s Day – #IWD2020 #EachforEqual.
