MATERIAL DATA SHEET
SHIELDING TAPE
Product number: SL-140
Material Type: Single Lamination – Film/Foil
Construction: .00092" PET/.00035" Al – Blue Color film side
FINISHED ROLL PROPERTIES
Blue on film side.
1: Peel Strength -- lamination is a permanent bond. When performing peel strength test foil will fail before delamination occurs
2: Delamination Criteria – The finished tape shall show no signs of delamination or breaks in the foil to the naked eye when elongated to the minimum requirement shown above.
Contact Web Industries at +1 508.573.7979 or sales@webindustries.com and learn how our innovative solutions to product development, contract manufacturing, and product life cycle management can help ensure success for your wire & cable product.
PROPERTY US CUSTOMARY METRIC TEST METHOD Thickness .0014" ±10% 36 µm ±10% ASTM D374 Break Strength ≥ 20 Lb./inch ≥ 35N/10 mm ASTM D882 Elongation @ Break ≥ 40% ≥ 40% ASTM D882 Peel Strength Note (1) Note (1) ASTM F904 – 98 Delamination Note (2) Note (2) N/A Dielectric Strength of Film 4KV minimum 4KV minimum ASTM D149 Density 1.73 oz/sq yd ±10% 59 g/m2 Calculated
Wind
3", 6" Core Type
Thickness Fiber / .375” Pad wound finished roll specifications .375” to 4.0” width, Standard finished diameters of 9 to 12” and 16 to 20” . Traverse wound finished specifications .25” to 1” wide. 3, 6 and 12” traverse widths. 9” to 12” standard diameters.
Color
Direction Foil Out. Pad and traverse Wind Standard Core
/ Wall
