WOOD FIRES

There is something incredible about the look, feel and sound of an open woodburning fireplace. It is therapeutic to be around flickering flames, adding an instant ambience to a room while encouraging conversation, contemplation, romance and relaxation.

General with traditional grate

General SI

The General SI wood fire is built for efficiency, durability, and ease of use. It was the first fireplace designed and manufactured by Warmington in 1994. The innovatively designed multi-tube heat exchanger extracts more heat from the flames. It has internal fire bricks that aid in heat retention, and the full-width damper blade gives control across the entire width of the fire back. It has a wetback option to aid with water heating and lower your power bill.

ESTIMATED HEAT OUTPUT: 15 - 25kW

SIZES IN WIDTH:

Single flue: 440-600-700-700T-780-780T-900-1100-1250-1500mm

Double flue: 1100-1250-1500-2000mm n CAITEC Technology* n Sidebricks in firebox for heat retention

General SI 1100 with traditional grate n Full-width damper blade n Multi-tube heat exchanger n Customisable flue offset adapter options provide design freedom n Two grate options (Classic or Traditional) n Optional built-in gas log lighter available for easy ignition

* We use advanced CAITEC (Combustion Air Intake Technology). Air is drawn from an external source to ensure that the open fire has pre-heated combustion air. This maximises efficiency while maintaining the home at constant pressure equilibrium and reduces the risk of back drafting.

Twin with traditional grate

Twin

The Twin sided wood fire is based on the General SI design and can be built into a dividing wall between two rooms sharing the same air space. It creates a great visual connection and enjoyment in both rooms. One side of this fire is open, and the other has a beautiful glass swing door with a wooden handle. The Twin fire works well in a large area creating two designated smaller areas, or between two rooms. This fire is also available in a freestanding option making it the perfect room divider in a large open-plan area.

ESTIMATED HEAT OUTPUT: 15 - 25kW

SIZES IN WIDTH: 780-780T-900-1100mm n CAITEC Technology* n Twin-sided fireplace n Sidebricks in firebox for heat retention n Full-width damper blade n Multi-tube heat exchanger n Two grate options (Classic or Traditional) n Optional built-in gas log lighter available for easy ignition

Corner

The Corner wood fire has a distinctive look with two sides open. Available in the General SI and Traditional, it offers a large view of the fire and produces increased radiant heat because of its design. With a choice of a left-sided or right-sided design, this fire provides a creative way to connect two spaces and create interesting focal points in your living space. An optional gas log lighter is available.

ESTIMATED HEAT OUTPUT: 18kW

SIZES IN WIDTH:

780mm n CAITEC Technology* n Left-hand or Right-hand option n Multi-tube heat exchanger n Two grate options (Classic or Traditional) n Optional built-in gas log lighter available for easy ignition

The Traditional wood fireplace brings modern-day technology to the classic open brick fireplace of the past. You can customise your fireplace to your specific interior style. You have the choice between Traditional or Westminister firebox shape, a selection of brick profile size and pattern and a choice of grate type. Custom sizes available.

ESTIMATED HEAT OUTPUT: 15 - 25kW

SIZES IN WIDTH:

Single flue: 800-1000-1200mm

Double flue: 1500-1800-2000mm n CAITEC Technology* n Traditional open brick fire with nostalgic look n Flexible firebox shape (Westminister or Traditional) n Fully brick-lined with choice of bricking styles (Stacker, Stretcher or Herringbone) n Full-width damper blade n Customisable flue offset adapter options providing design freedom n Three grate options (Classic, Modern or Fortress) n Optional built-in gas log lighter available for easy ignition

Evoque

The Evoque enclosed wood fire is the perfect choice if you are looking for the flexibility of an open fire combined with the efficiency of an enclosed wood burner. It uses a controlled air supply, which maximises the amount of heat produced and keeps wood consumption, ash and soot to a minimum. It is a statement piece with a full firebrick interior. The large glass door can slide up for an unrestricted view of the fire and swing open for easy firewood loading and maintenance. The drop-down glass pane can be utilised as a spark guard to ensure safety when the fire is unattended. Rural only.

ESTIMATED HEAT OUTPUT: 25kW n CAITEC Technology* n Fully brick-lined n Double action glass door that can slide up and swing open n Unique Evoque grate & ash pan n Large viewing window n Gas ignition (T-bar) available

SIZES IN WIDTH: 1300mm. Customisable sizes available.

The Rumford wood fire has a tall and shallow firebox with angled sides maximising heat retention and reflecting heat back into the room. It was named after Count Rumford (Sir Benjamin Thompson) who designed it to achieve maximum heat and a large view of the flames. The shape of the firebox, combined with the straight back and narrow chimney opening, gives it an extraordinary look.

ESTIMATED HEAT OUTPUT: 15 - 25kW

SIZES IN WIDTH: 600-760-920-1050-1220-1500-1800-2100-2400mm n CAITEC Technology* n Unique American design n Tall and shallow firebox shape n Fully brick-lined with choice of bricking styles (Stacker, Stretcher or Herringbone) n Three grate options (Classic, Modern or Fortress) n Optional built-in gas log lighter available for easy ignition

Freestanding Cabinet

The Freestanding wood fire makes a grand statement and feature in any room. It consists of the firebox of either the General SI or the Twin fire with a cabinet built around it. It is available in a Square or Taper Top Cabinet design.

The glass door is only available on the double sided Twin freestanding fire making it the perfect room divider in a large open area.

SIZES IN WIDTH:

Single sided: 440-600-700-700T-780-780T-900-1100mm

Twin sided: 780-780T-900-1100mm n Twin-sided option n Square or Taper Top design
