Crown Molding Crown Molding - Abbreviations and Symbols
The following symbols and abbreviations may appear on profile drawings in this section and indicate the following: • X Molding can accept an additional accent or dentil molding (See Section N.9 for options). • (D) Depth of molding when installed. • (H) Height of molding when installed. • FRC Fastener Relief Cut. • Spring Angle • C Molding is available convex / concave. • Molding is available with 3D laminate (RTF) Note: All moldings are drawn at full scale unless noted otherwise. Combine Moldings
Dimensions (Installed)
Fastener Relief Cut
#2795
F R
#958
Spring Angle
C
#829
X
#119 PC: M101 Sq Ft: 1.34 115/32"D 113/32"H
Not to Scale
Face Frame Not to Scale
Crown Molding
N
C
#1808 PC:M101 Sq Ft: 2.36 21/2"D 21/2"H
F R
F R
#1361 PC: M101 Sq Ft: 1.45 19/16"D 11/2"H
#958 PC:M101 Sq Ft: 1.75 29/32"D 115/32"H
C F R
C
C
#1924 PC: M103 Sq Ft: .75 11/8"D 11/4"H
#2556 PC: M103 Sq Ft: 1.46 23/16"D 1"H
#1925 PC: M103 Sq Ft: 1.25 17/8"D 11/4"H
FRC = Fastener Relief Cut.
C = Available for Convex/Concave products.
= Available with 3D Laminate/RTF.
► For PRICING ► See Section N.1 in our current Wholesale Pricing Catalog. N.1.3
