MANDARIN ORIENTAL RESORT BODDEN TOWN GRAND CAYMAN

2301 NW 33rd Ct. Unit 112, Pompano Beach, FL 33069 (561) 990-2590 | Toll Free : 1-877-514-2377

TYPE

MFG

PART NUMBER (HYPERLINK TO PAGE IN BLUE)

LUCENT

A963-LED-WH-BC-X-X-35-LH-6.75-09-120-D6

OSRAM

LFP3400TW-G5-927.957-03 L1

OSRAM

LFP1500I-G1 -927-24-06 L1 FS1/FX-QMS -G1-TU16H12-30/FX-QMS-G1-TU16H12-300/FX-QMS-G1-CLT-300

OSRAM

LFP3400TW-G5-927.957-03 L1/LFP3400TW-G5-927.957-03 L1/FXQMS-G1-TU16H12-300/FX-QMS-G1-CFDB-300/FX -QMS-G1-EFGH-TU16H12LS/ADJUSTABLESLIMBRACKET

OSRAM

LFP500I-G1-927-24-09 L1 FS1

OSRAM

LFP1500I-G1-927-24-06 L1 FS1/FX-QMS-G1-T45D19H19-300/FXQMS-G1-CFBDB-300/FX-QMS-G1-EFGP-T45D19H19/FX-QMS-G1EFGH-T45D19H19/FX-QMS-G1-BMZI-T45D19H19

2301 NW 33rd Ct. Unit 112, Pompano Beach, FL 33069 (561) 990-2590 | Toll Free : 1-877-514-2377

TYPE

MFG

PART NUMBER (HYPERLINK TO PAGE IN BLUE)

NORA

NIOC-2RNBMPW/NIOC-24LED930X/NJCB-12/NFC-R313

LUMENTRUSS

CA1200-MCF-DRS-LDWH2465-AIW-FH3/DALI-96W-UNV-24VAOD4IDT8-2CH-BK

LUMENTRUSS

CA1200-MCF-DRS-LDWH2465-AIW-FH3/DALI-96W-UNV-24VAOD4IDT8-2CH-BK

LUMENTRUSS

CA1200-MCF-DRS-LDWH2465-AIW-FH3/DALI-96W-UNV-24VAOD4IDT8-2CH-BK

LUMENTRUSS

2400-PR-45-TW1-HW3-I/DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

LUMENTRUSS

2400-PR-45-TW1-HW3-I/DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

TYPE RB SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RB

North America

+1 518 239 8300

Trim Accent

Trim (Round and Square) provides high performance electronics and architectural aesthetics in 3.8” and 3.8” x 3.8” trim. Trim products include adjustable, fixed and wallwash with flange. Tray, retrofit and housing installation methods (NIC, IC, AT, T24 and CCEA) Lucent modules available in a wide range of color temperatures, beam angles, intensities, and effects (Ambiance WarmDim and Dynamic Tuneable White). MR16 and GU10 LED lamp options available. TRIAC/ Phase, 0-10v/1-10v, DMX and DALI/Digital dimming.

A963-LED Up to 25° tilt Cut-out 3.29” (83.5mm) Ø

LED Source

LED51TW

CCT (5000K - 2000K)

@ 3000K

Drive Current (max per channel)

700mA

Power inc Driver

15.1W

Beam Angle

25°

35°

Delivered Lumens

676

740

Delivered Intensisty cd

2350

1370

Efficacy lm/w

Forward Volt (max per channel)

18.4V

CRI

≥95 CRI

www.lucent-lighting.com/na

Issued: 07/21

Page 1

MANDARIN

TYPE RB ALT

MOGC TYPE-RBHOTEL GUEST ROOMS

NIOC-2RNB

Type

2" Iolite Can-less Round Bullnose Source: 12W LED 1275lm

Project Catalog No. Notes

PRODUCT DESCRIPTION 2" Iolite can-less downlights can be installed in new construction or remodel applications. Deep regressed cone reflectors optimize visual cut-off.

Performance Data Part Numbers

FEATURES · No housing required - IC Air-Tight rated · Easy installation for remodel or new construction applications · Variety of trim accessories to configure desired appearance · Quick disconnect allows for extended lengths · Dedicated CCT or Comfort Dim (warm dim) · Flood optic, narrow flood and spot optics (included) · 5-Year limited warranty · cULus Listed for Wet Locations

PRODUCT IMAGES & DIMENSIONS

Lumens CCT Optic 1283lm 4000K Spot NIOC-2RNBMPW NIOC-24LED940X 1287lm 4000K Narrow NJCB-12 1275lm 4000K Flood Delivered lumens will vary depending on CCT, optic and finish

3.59"

Air Flow Restriction: Luminaire has factory installed gasket to restrict airflow from room into ceiling plenum to <2CFM (cubic feet per minute) in accordance with ASTM-283 Air-Tight requirements.

1.38" 7"

SPECIFICATION Construction: Trims are constructed of heat dissipating, die-cast aluminum. Aluminum die-cast LED module is threaded to fit the trim and transfer heat.

Cut out: 3-1/8" 2.65"

3.65"

Clearance: IC rated luminaires are rated for direct contact with insulation (not spray foam insulation), no minimum clearance is required. Driver Box: Prewired junction box includes 7" quick connect wire to LED module for ease of installation. Junction box includes two 1/2" trade size knockouts and snap on cover. Maximum length between luminaire and driver is 40'. For longer remote driver remote run length, consult factory.

2" Iolite Can-less Round Bullnose Trim

Mounting: No housing is required, two tensions steel spring clips secure luminaire to ceiling. Accommodates ceiling thickness up to 3/4". New construction frame-in kit is available, see accessories. OPTICS Each module includes field changeable optics (spot, narrow flood and flood - preinstalled). ELECTRICAL Input Voltage: 120VAC Lumens / Wattage: 1275lm / 12W Color Temperature: 2700K, 3000K, 3500K or 4000K Color Rendering Index: 90+CRI Operating Temperature: 0°-30°C Lifetime: 50,000 hours @ L70 Comfort Dim: Comfort Dim color tunes the temperature from a bright 3100K, to a romantic and comfortable 2000K on a gradual, even curve. Available in 950lm only. Dimming: Triac or ELV

MPW Matte Powder White

Item Number NIOC-2RNBMPW = Matte Powder White Trim NIOC-2RNBWW = White Trim

2" & 4" Iolite Can-less LED Module

Accessories: Luminaire will accommodate (1) hex louver and (1) translucent deco collar or opaque snoot, no accessory holder is required, see accessories page. LABELS AND LISTINGS · cULus Listed for Wet Locations · 5-Year Limited Warranty · RoHS Compliant · Certified to the high efficacy requirements of California Title 24 JA8-2022

WET

5 YEAR LIMITE D

WARRANTY

TITLE

COMPLIANT

o omfortDim

WW White Reflector

Three field changeable optics included Color Temperature NIOC-24LED927X = 2700K NIOC-24LED930X = 3000K NIOC-24LED935X = 3500K NIOC-24LED940X = 4000K NIOC-24LED9CDX = Comfort Dim (3100K~2000K)

Driver Box

Recreate the Sunset with LED

Wattage NJCB-12 = 12W / 120VAC input / Triac or ELV dimming

Example: NIOC-2RNBMPW / NIOC-24LED930X / NJCB-12 = 2" Iolite Can-less Bullnose Trim, Matte Powder White finish, 3000K LED Module, 12W Driver Box with 120VAC input; Triac or ELV dimming 6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 | www.noralighting.com | e-mail: nora@noralighting.com © 2025 Nora Lighting, Inc. All rights reserved. Specifications subject to change without notice.

050925P1

TYPE RB SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RB

North America

+1 518 239 8300

Project Ref:

Location Ref:

Specify fixture part number (All boxes must be filled in to correctly order) A963-LED

LED51TW

5020

Finish WH

White

Black

Location XX

Dry

Ceiling Thickness SC

Standard Ceiling (1/2”-5/8”-3/4”)

Custom

LED Type LED51TW

LED51TW (95CRI)

CCT 5020

5000K - 2000K

Beam Angles 25

Housing/Tray LMT-13-NIC LH-6.75-NIC LH-8.50-AT/IC

Mounting Tray Non-Insulated ceilings Housing 6.75” Non-Insulated ceilings Housing 8.50” Insulated/Air-tight ceilings and Chicago Plenum

Mounting Hardware 09

9” to 15.25” - Adjustable Bar Hanger Lengths

14” to 24” - Adjustable Bar Hanger Lengths

28” to 36” - Adjustable Bar Hanger Lengths

Butterfly Bracket

Caterpillar Bracket

Supply Voltage 120

120V

277

277V

Dimming Protocol A2

Analogue (0-10V) 2-Channel (0.1% Dimming)

DALI Type 6** (0.1% Dimming)

DALI Type 8** (0.1% Dimming)

Lutron (Consult Factory)

*Refer to Technical Details for more information

Emergency

Louvre/Lens

3hr Emergency

Not required

3hr Self Test

LL45

Honeycomb

LLCC

Warm Tone

LLUV

LLDF

Solite/Diffusing

LLFR

Frosted Lens

LLLS

Linear Spread

LLHS

Heavy Spread

www.lucent-lighting.com/na

Issued: 07/21

Page 2

MANDARIN

TYPE RB ALT

MOGC TYPE-RBHOTEL GUEST ROOMS

Iolite Can-less Accessories

Type

2" Iolite Can-less Round Bullnose

Project Catalog No. Notes

FIELD CHANGEABLE OPTICS Iolite luminaires include spot, narrow flood and flood optics. Optics can be changed in the field by removing LED module from die-cast trim. Optional frosted and TIR optics are also available.

LED Module

Frosted Optics

Optic

NIO-REFL38FR NIO-REFL60FR

Premium TIR Optics 60° Optic 73° Optic

NIO-REFLTIR15 NIO-REFLTIR25

22° Optic 26° Optic

TIR optics are not compatible with hex cell louver accessory.

Die-cast Trim TRIM ACCESSORIES Iolite accessories can be added at any point in the design process. Accessories easily install between LED module and die-cast trim. Luminaire will accommodate (1) hex louver and (1) collar accessory, no accessory holder required.

LED Module Accessory

Die-cast Trim

Translucent Decorative Collar

Opaque Collar Snoot

Hex Cell Louver

NIO-AS14(color) 5/8" length NIO-AS19(color) 3/4" length NIO-AS26(color) 1" length Color: AM (amber), BLU (blue), FR (frosted), R (red)

NIO-AS14(color) 5/8" length NIO-AS19(color) 3/4" length NIO-AS26(color) 1" length Color: MPW (matte powder white), WH (white)

NIO-HC

Translucent collars color the aperture with the specified color while producing white general light. Collars are available in different lengths. Use to add interest, create a theme, match a theme or define a space.

Opaque snoot greatly reduces aperture brightness while preserving light output.

Hex cell louver is not compatible with TIR optics.

Black

Hex cell louver subtly reduces aperture brightness by reducing light output by about 20%.

MOUNTING ACCESSORIES Iolite canless luminaires are ready to be installed out of the box. Additional mounting accessories can be used to assist during installation or extend length between driver box and luminaire.

Quick Connect Extension Cables NCA-EW-4 NCA-EW-10

4' Cable 10' Cable

Use to extend the length between luminaire and driver box. Can be connected together to create custom lengths. Maximum length between luminaire and driver is 40'. For longer remote driver remote run length, consult factory.

New Construction Frame-In

New Construction Frame-In with Collar

NF-R124

NFC-R313

Universal new construction frame-in can be used to assist installing can-less recessed downlighting.

New construction frame-in can be used to assist installing can-less recessed downlighting.

6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 | www.noralighting.com | e-mail: nora@noralighting.com © 2025 Nora Lighting, Inc. All rights reserved. Specifications subject to change without notice.

050925P2

TYPE RC SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RC www.osram.com

LINEARlight FLEX Protect Tunable White IP67/IP66 The perfect cozy atmosphere also for outdoor installations LFP1100/3400TW-G5

Features & Benefits − − − − − − − − − − − − − − − −

Durable IP67 & IP66 fully sealed and filled with crystalline optical grade silicone Outdoor use possible: UV and salt mist tested 1100 / 3400 lm/m Adjustable color temperature via Tunable White: 2700...5700 K, 2500…4000K Color uniformity ≤3 SDCM* CRI90 Lifetime up to 60.000 h L80B10 at Tp, with SDT Technology Dimmable down to 0.1% with OPTOTRONIC® LED drivers Internal constant current regulators on each single cut unit LM80 & LM79 compliant Great design freedom thanks to flexibility and cuttability of the LED strip Easy mounting on many smooth surfaces thanks to selfadhesive tape Top reliability with Reel-to-Reel technology, 186 LED/m High speed protection in case of accidental miswiring up to 25V Pre-soldered wires Made in Italy

Application areas

Dynamic lighting applications in outdoor or wet areas

Standards

CE, ENEC 10 VDE, UL Recognized according UL 8750

Technical data LFP1100TW…09 L2

LFP3400TW…03 L1

Lowest Bending Radius = 50 mm Max. operable length = product length

Beam Angle 120° Nominal Voltage

24.0 V

Accidental reverse voltage protection up to

25.0 V

Temperature range in operation @ Tc point

-20°C...+85°C

Storage Temperature

-40°C...+85°C

Ambient Temperature with profile **

-20°C...+50 °C C0-C180 C90-C270

Specification Sheet – 2020.12.10 – subject to change without notice

cd/1000lm

MANDARIN

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS

1200 PROFILE

Scale 1:1

LINEAR WEIGHT

MAXIMUM LED STRIP WIDTH

0.099 lbs / ft 0.148 kg / m

DRY: 9 / 16 " DRY: 14 mm

LED TAPE COMPATIBILITY 2400K

E491159

CLOSET RATED

E491159

2700K

warmdim

The 1200 series is a rectangular and flangeless profile designed to meet the daily needs of linear accent lighting. The 1200 series offers a wide selection of lenses, mounting options, and LED platforms to choose from for a beautifully finished luminaire with end caps.

DAMP: 3 / 8 " DAMP: 10 mm

3000K

tunable white

3500K

4000K

rgb

5000K rgbw

CHANNEL COLOR OPTIONS aluminum anodized

black anodized

custom RAL color

swivel

millwork

damp

wet

MOUNTING

PRODUCT FEATURES

surface

corner

• Motion sensor ready for static white and warm dim options • Recess into millwork using standard woodworking tools for a 0.75 in. (19 mm) groove • Stainless steel mounting hardware for integration into most surfaces

LOCATION RATING

• Custom lengths with precision to ¹/₁₆ (0.0625) inches • Internal groove guide for easy application of LED strip when field installation is needed • A selection of lenses to meet task at hand

dry

• Aluminum construction for superior heat dissipation

OTHER OPTIONS

• UL 2108 listed - Suitable for storage and closet areas dot-free

motion sensor

USEFUL LINKS

MAXIMUM LED RUN CHART PER DRIVER

VOLTAGE DROP CHART

INSTALLATION SHEET

BULK PARTS LIST

IES FILES

TYPE RC SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RC LFP Tunable White IP67/IP66 | LFP1100/3400TW

Technical data Color Temperature 1

CRI

LFP1100TW-G5-825.940-09 L2

2500-4000 K

1156

9.9

117

LFP1100TW-G5-927.957-09 L2

2700-5700 K

1134

10.2

111

TUNABLE WHITE

Color Temperature

CRI

Luminous Flux Power per meter lm/m W/m

Luminous Performance Temp. Length Efficacy lm/W Tp °C m

LFP3400TW-G5-825.940-03 L1

2500-4000 K

3356

30.9

108

LFP3400TW-G5-927.957-03 L1

2500-3500 K

3356

32.0

105

Technical data per each channel BOTH CHANNELS 50% ON

CH1 = 100% ON, CH2 = OFF

CH1 = OFF, CH2 = 100% ON

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

LFP1100TW-G5-825.940-09 L2

3145

578

5.0

2500

578

5.0

4000

578

5.0

LFP1100TW-G5-927.957-09 L2

3759

567

5.1

2700

567

5.1

5700

567

5.1

TUNABLE WHITE

BOTH CHANNELS 50% ON

CH1 = 100% ON, CH2 = OFF

CH1 = OFF, CH2 = 100% ON

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

LFP3400TW-G5-825.940-03 L1

3115

1678

15.5

2500

1678

15.5

4000

1678

15.5

LFP3400TW-G5-927.957-03 L1

3708

1678

16.0

2700

1678

16.0

5700

1678

16.0

Melanopic effect - Human Centric Lighting

LFP1100TW-G5-825.940-09 L2 LFP1100TW-G5-927.957-09 L2

a 0.325 0.395

b 0.478 0.602

c 0.616 0.771

a 359 436

b 538 665

c 680 851

Spectral data [K] a b c 2500 3145 4000 2700 3759 5700

LFP3400TW-G5-825.940-03 L1 LFP3400TW-G5-927.957-03 L1

0.322 0.410

0.478 0.583

0.605 0.814

355 453

527 643

667 898

2500 2700

ΦV, mel, D65

amel, v

Operating conditions: • • •

a: Ch1=100%, Ch2 OFF b: Ch1=50%, Ch2=50% c: Ch1 OFF, Ch2=100%

Specification Sheet – 2020.12.10 – subject to change without notice

3115 3708

4000 5700

Photometric luminous flux (  ) [lm/m] 578 567 1678 1678

MANDARIN

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS 1200

TUNABLE WHITE / RGB / RGBW ORDERING SHEET

Finish

- MCF

CA1200

Mounting

- DRS

PROFILE & FINISH

Optics

Lumen Package

CCT

Application

- LDWH2465 MOUNTING

- AIW

Power Feed

- FH3

OPTICS

Input / Output

Length, in

Driver / Sensor

Accessories

LUMEN PACKAGE

CA1200 - Anodized aluminum finish

MCF - Flat surface bracket

DCS - Clear lens

LDWM2465 - Dual White - 3.5 W/ft - 260 lm/ft

CA1201 - Anodized black finish

MC3 - 45° Corner bracket

DXS - Optiflex lens

Custom LDWH2465 - Dual White - 8.5W/ft 5.8 W/ft - 427 lm/ft

CA1202- White

MC8 - Swivel 180°

DOS - Opal lens

LRGBLD - RGB - 4.4 W/ft - low density

M3M - Double face mounting tape

DRS - Prime lens

LRGBMD - RGB - 5.8 W/ft - medium density

MNO - No mounting

DBS - Black lens

LRGB30† - RGBW (3000K) 4 in 1 - 4.4 W/ft - 107 lm/ft

CA120X - Custom color provide RAL #

Exact / Optimal

CCT

2400-6500K

APPLICATION

AID - Indoor dry locations AIW - Indoor wet locations

N/A

For wet location applications, LED strip will be put inside a waterproof silicone sheath.

RGB + 3000K

†

AIW option is not available for this selection

DSS - Silens DNO - No lens

POWER FEED

INPUT / OUTPUT

EXACT/OPTIMAL

LENGTH*

FH3 - Hardwire, 3ft wire

WSE - Simple lead-in, end feed

QE - Exact

Length of the luminaire in inches.

FH6 - Hardwire, 6ft wire

WSB - Simple lead-in, back feed

QO - Optimal

FH9 - Hardwire, 9ft wire

WSL - Simple lead-in, side feed 1

*Includes end caps, excludes flanges (when applicable).

FHX - Hardwire, custom length wire

WSR - Simple lead-in, side feed 2

WPB - Pass-through, back feed WPL - Pass-through, side 1

no flange

Optimal - length specified in section 10, rounded down to the closest LED cut section to minimize dark spots.

PND - Non-dimmable

CGAP - Apsis

PDMX - DMX driver

CGLA - Latus

GYPSUM COVES, 8ft

CGNI - Nidus

PNO - No driver

MOTION SENSORS flange

WPE - Pass-through, end feed

Exact - length specified in section 10 with end caps without flanges.

11 DRIVER TYPE / SENSOR

CGSU - Sulcus

PND-SI05 - 30 sec., embedded PND-SE05 - 30 sec., external

length

PND-SI4 - 4 min., embedded PND-SE4 - 4 min., external

WPR - Pass-through, side 2

PND-SIP - proximity motion sensor All motion sensors can only be used with non-dimmable power supplies - 72W / 24V - For indoor dry applications

1200 series

alu. finish

prime lens

2400-6500K

hardwire connection, 6 '

72" fixture (with end caps)

non-dimmable driver

CA1200 - MCF - DRS - LDWH2465 - AID - FH6 - WSB - QO72 PND flat bracket

dual white, high lumen

indoor dry application

back feed lead-in only

optimal length, no dark spots

TYPE RC SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RC

Product - technical datasheet The trusted value of OSRAM Digital Systems continues with Inventronics Global – where experience meets innovation.

LFP3400TW-G5 -927.957-03 L1 LINEARlight FLEX Tunable White Protect | LED modules for professional and industrial applications Product family features - 24 V LED strips flexible and cuttable - Luminous flux: up to 3,400 lm/m - Up to 60,000 h L90/B10 with SDT technology, tested acc. to IEC 62717 on real LED strips - Adjustable color temp. via Tunable White: 2500…4000 K, 2700…5700 K CRI90 - CRI 90 versions available - Stable light flux over length: active constant current regulators (ICs), PWM safe - Embedded automatic quick protection against accidental miswiring up to 25 V - Fully PWM dimmable from zero up to 2.5 kHz, audible noise free, suitable for quite places - IP67 & IP66 - Salt-mist atmosphere resistant (acc. to IEC 60068-2-52, highest severity) - UV radiation resistant (acc. to ISO 4892-2) / Mixed flowing gas corrosion resistant (IEC 60068-2-60) - Designed, engineered and manufactured and tested in Italy (ISO9001, ISO 17025, ACCREDIA, VDE)

Product family benefits - Color uniformity better than 3 SDCM on the entire LED strip and between strips - LED lifetime acc.to IES LM-80 and IES TM-21 standards, and also internal OSRAM LAB tests - Excellent robustness: single reel manufacturing technology (no solder joints on strip) - Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back Product - technical datasheet - Extraordinary design and high quality materials Lifespan Rated lamp life time

60000 h

Number of switching cycles

>15000

Capabilities Lowest bending radius

50 mm

Self-adhesive

Yes

With connection set

Yes

Product - technical datasheet

Certificates & standards Standards

CE / UL / ENEC / EAC

Type of protection

IP67

Logistical data Commodity code

85395100000

Information according 33 of EU Regulation Specifications are subjectArt. to changes without notice.(EC) 1907/2006 licensee(REACh) of the OSRAM brand. OSRAM is a trademark of ams OSRAM www.inventronicsglobal.com Date of Declaration

13-02-2025

Primary Article Identifier Sat Mar 22 15:02:13 CST 2025 Declaration No. in SCIP database

4062172196628 1 / 8 In work

SCIP_STATUS

In work

SCIP_ID

Equipment / Accessories

support@inventronicsglobal.com

MANDARIN 3 - OPTICS

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS

4 - LUMEN PACKAGE

1200

LED TAPE AND OPTICS CHART @ FULL LIGHT OUTPUT LP100

LP200

LP300

LP450

LP750

LW2229

LW2735

LDWM

LDWH

LRGBLD

LRGBMD

LRGB30

5300K

2200K to 2900K

2700K to 3500K

2400K to 6500K

RGB

RGBW 3000K

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

14.5 W/m 4.4 W/ft

LED tape color type 2400K 2700K 3000K 3500K 4000K

CCT Range

6200K

Power

4.8 W/m 1.5 W/ft

9.6 W/m 3.0 W/ft

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

23 W/m 7.0 W/ft

14.5 W/m 4.4 W/ft

11.5 W/m 3.5 W/ft

19.2 W/m 5.8 W/ft

Eﬃcacy

91 lm/W

81 lm/W

76 lm/W

84 lm/W

95 lm/W

< 44 lm/W

< 46 lm/W

74 lm/W

CRI

90+

95+

90+

80+

60+

65+

60+*

Available in IP68 option (silicone sleeve)

LED tape increment

50 mm 1.97 in

33 mm 1.30 in

25 mm 0.98 in

33 mm 1.30 in

50 mm 1.97 in

100 mm 3.94 in

63 mm 2.48 in

100 mm 3.94 in

Quantity of LED chips

120 LED/m 36 LED/ft

180 LED/m 54 LED/ft

240 LED/m 73 LED/ft

60 LED/m 18 LED/ft

112 LED/m 34 LED/ft

60 LED/m 18 LED/ft

LED tape width

8 mm 0.31 in

10 mm 0.39 in

12 mm 0.47 in

Closet Rated

DOT-FREE

VISIBLE DOTS

Compatible with water-proof sheath

Spec sheet LENS

BEAM

*At higher CCT value

xx lm/ft

Tested with LP450

DBS - black

Disappears on dark surfaces when turned off.

59 lm/ft

89 lm/ft

144 lm/ft

207 lm/ft

337 lm/ft

xx lm/ft

rgb

xx lm/ft

86° 30

DSS - silens

98 cd 90

No dots, suitable for direct view, and a continuous lens up to 10M (33ft).

64 lm/ft

100 lm/ft

156 lm/ft

217 lm/ft

370 lm/ft

xx lm/ft

rgb

xx lm/ft

455

113°

60 75

73 cd

DOS - opal

No dots, and suitable for direct view.

74 lm/ft

117 lm/ft

179 lm/ft

259 lm/ft

421 lm/ft

xx lm/ft

rgb

xx lm/ft

114° 330

DRS - prime

Best light output for direct view with higher lumen packages.

100 lm/ft

158 lm/ft

239 lm/ft

342 lm/ft

559 lm/ft

xx lm/ft

rgb

xx lm/ft

104° 150

DXS - optiﬂex

88 cd

Eliminates shadows, best light output for indirect view.

116 lm/ft

183 lm/ft

281 lm/ft

389 lm/ft

649 lm/ft

xx lm/ft

rgb

xx lm/ft

127 cd

90° 200

173 cd

DCS - clear The highest light output for indirect view.

136 lm/ft

213 lm/ft

326 lm/ft

448 lm/ft

745 lm/ft

<192 lm/ft

<202 lm/ft

<260 lm/ft

<427 lm/ft

rgb

107 lm/ft 1600 200

Lumen output tested at 4000K. Use this table to calculate lumen output for different CCTs.

20 120

106°

2400K - 0.89

2700K - 0.91

3000K - 0.95

3500K - 0.96

LUMINOSITY CALCULATION EXAMPLE: According to the above table LP750 lumen package with DRS (prime) lens for CCT 4000K has luminosity of 559 lm/ft at CCT 3000K lumen output is 559 lm/ft * 0.95 = 531 lm/ft

4000K - 1.00

6200K - 1.07

181 cd

IES FILES for other CCTs peak candella

TYPE RC SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RC

Product - technical datasheet Technical data Electrical data Nominal voltage

24.0 V

Type of current

Nominal wattage per meter

32 W

Rated wattage

96.00 W

Input voltage range

23…25 V

Accidental reverse input voltage protection up to

25 V

Photometrical data Color rendering index Ra

Luminous flux per meter

3356 lm

Luminous efficacy

105 lm/W

Light color (designation)

2700…5700 K

Color Temperature

3700

Light technical data LED pitch

10.71 mm

Beam angle

120 °

Starting time

Warm-up time (60 %)

Product - technical datasheet

LED module information Number of LEDs per meter

187

Dimensions & weight Number of LEDs per smallest unit

Length

3000 mm

Length – smallest unit

75.0 mm

Width

11.1 mm

Height

4.5 mm

Product weight

173.00 g

Cable cross-section, input side

0.5 mm²

Colors & materials Cover material

Silicone

Temperatures & operating conditions 1)

Temperature range in operation at Tc point

-30…80 °C

Ambient temperature range

-30…+50 °C

Temperature range at storage

-40…85 °C

1) Exceeding the maximum ratings will reduce expected life time or destroy the LED strip. © 2024, Inventronics GmbH. All rights reserved. Inventronics is a Specifications are subject to changes without notice. licensee of the OSRAM brand. OSRAM is a trademark of ams OSRAM

www.inventronicsglobal.com

support@inventronicsglobal.com 2/8

MANDARIN

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS

7 - POWER FEED

1200

FC3 / FC6 / FC9 / FCX - DC CONNECTORS (static white and Warmdim LED tape only)

FH3 / FH6 / FH9 / FHX - HARDWIRE

FC3 - DC plug, 3ft wire

FC9 - DC plug, 9ft wire

FH3 - Hardwire, 3ft wire

FH9 - Hardwire, 9ft wire

FC6 - DC plug, 6ft wire

FCX - DC plug, custom length wire

FH6 - Hardwire, 6ft wire

FHX - Hardwire, custom length wire

DRY APPLICATIONS

Static white / Warmdim TEW 22 AWG

1.49 [38.0]

0.19 [4.8] 0.18 [4.5]

0.42 [10.7]

Static white / Warmdim TR64 22 AWG

2.83 [71.8]

0.13 [3.3]

DAMP / WET APPLICATIONS

0.62 [15.8]

0.19 [4.8]

0.60 [15.2]

0.20 [5.2]

0.21 [5.3]

0.07 [1.7]

0.25 [6.3]

0.06 [1.6]

0.17 [4.3]

RGB

0.06 [1.6]

RGBW

Static white / Warmdim IP68 (FT4)

1.64 [41.7]

Tunable White

0.09 [2.4]

0.20 [5.2]

3.42 [86.8]

8 - INPUT / OUTPUT 1200 SIMPLE LEAD (ONE SIDE)

WSE

WSB

WSL

WSR

WPE

WPB

WPL

WPR

WSE - End feed (no dark spots) WSB - Back feed (dark spots) WSL - Side feed 1 (dark spots) WSR - Side feed 2 (dark spots)

1200 PASS-THROUGH (TWO SIDES) WPE - End feed (no dark spots) WPB - Back feed (dark spots) WPL - Side feed 1 (dark spots) WPR - Side feed 2 (dark spots)

ORDERING CODE EXAMPLES 120 series

hardwire connection, 6 '

end feed pass-through

120X - XX - XX - XXX XX - XXX - FH6 - WPE - XX - X 120X - XX - XX - XXX XX - XXX - FH3 - WSB - XX - X 120 series

FH6 - 6ft hardwire intput

hardwire connection, 3 '

backw feed simple

FH6 - 6ft hardwire output

WPE - pass-through (input and output) end feed

FH3 - 3ft hardwire intput

WSB - simple (input only) back feed

TYPE RC SPEC

MANDARIN

0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS Slim Profile System | Slim Profile adjustable light angle FX-QMS-G1-TU16H12LS-300

Fitting Reference: RC

Technical drawings Slim Profile System | Slim Profile adjustable light angle FX-QMS-G1-TU16H12LS-300

Slim cover frosted FX-QMS-G1-CFDB-300 Order code 4052899446991

Slim Profile adjustable light angle FX-QMS-G1-TU16H12LS-300 Slim lens cover FX-QMS-G1-CLT-300 Order code 4052899449046 Dimensions: W16 x H8 x L3000 mm

Slim cover clear FX-QMS-G1-CFTL-300 Order code 4052899999749

C0-C180 C90-C270

cd/1000lm

Slim lens cover 10° beam angle

Slim lens cover FX-QMS-G1-CLT-300 Order code 4052899447783

C0-C180 C90-C270

cd/1000lm

Slim lens cover 30° beam angle

Plastic end cap for flat cover FX-QMS-G1-EFGP-TU16H12LS Order code 4052899449183 Plastic end cap for flat cover with hole FX-QMS-G1-EFGH-TU16H12LS Order code 4052899999848

Metal mounting bracket FX-QMS-G1-BMZI-DIV1 Order code 4052899446861

Specification Sheet v. 2

C0-C180 C90-C270

cd/1000lm

Slim lens cover 60° beam angle

C0-C180 C90-C270

Slim lens cover 90° beam angle

Plastic end cap for lens cover FX-QMS-G1-ELGP-TU16H12LS Order code 4052899449879 end cap forwith lensand cover with lens hole cover 10°. Slim Profile Plastic and strip LF1200 without FX-QMS-G1-ELGH-TU16H12LS Order code 4052899999961

Adjustable mounting brackets (90°) ADJUSTABLESLIMBRACKET Order code 4052899600010

cd/1000lm

MANDARIN DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS CLASS 2 CLASSP TYPE HL SELV

2-CHANNELS

A high-efficiency, 2-channel constant voltage driver with full DALI D4i DT6/DT8 compatibility, offering flicker-free dimming from 0.2–100%. Designed for precise control and reliability, it features active PFC, built-in DALI bus power, and intelligent temperature and power monitoring — all in an IP66-rated housing for any environment. FEATURES: • Constant voltage output • 100 - 277VAC (Universal) range • Built-in Power Factor Correction (PFC) function • Efficiency up to 93% • Short circuit, over load, over temperature, over voltage protection • Cooling by free air convection • For dry, damp &wet locations,accord with IP66 • The dimming curve is adjustable, Multi-Chanel output, Multiple frequency options, DT6 and DT8 compatibility • Comes with DALI bus power supply and auxiliary power supply. Power status detection function (D4i function) and lamp temperature detection. Driver parameters can be adjusted in app • DALI dimming (PWM Output) • Min load is 10% • Dimming range: 0.2%-100%(244Hz) 0.2%-100%(800Hz) 0.3%-100%(4KHz) 0.8%-100%(20KHz) • 5 years warranty

1/10

TYPE RC SPEC

MANDARIN

NO SPEC

MANDARIN

TYPE RC ALT

MOGC TYPE-RCHOTEL GUEST ROOMS

DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

Number of channels

2 CHANNELS

LM Number

Output

Input

LM42900-27 DC Voltage

24V

Fine-tune voltage

24V - 26V

Voltage tolerance

± 3%

Voltage regulation

≤ 1%

Load regulation

Rated current

Rated power

96W

Voltage range

100 - 277VAC

Frequency range

47 - 63Hz

Power factor (typ.) @ full load

PF ≥ 0.99 @ 120VAC

PF ≥ 0.96 @ 277VAC

THD (typ.) @ full load

≤ 6% @ 120VAC

≤ 8% @ 277VAC

Efficiency (typ.) @ full load

91% @ 120VAC

93% @ 277VAC

AC current (max.)

< 1A @ 120VAC

<0.5A @ 277VAC

Inrush current (typ.) @ 50% Ipeak

58A,134.4us @ 50%Ipeak 120VAC

123A,205us @ 50%Ipeak 277VAC

Leakage current

<0.5mA

Short circuit

Shut down o/p voltage, recovers automatically after fault condition is removed

Over load

≥ 115% Hiccup mode, recovers automatically after fault condition is removed Ambient temperature over 55°C ± 5°C to reduce output to 50%;

Protection Over temperature

The ambient temperature drops to 45°C ± 5°C and automatically recovers. Ambient temperature over 75°C ± 5°C to reduce output to 0%; The ambient temperature drops to 45°C ± 5°C and automatically recovers.

Environment

Safety & EMC

Weight & Dimensions

Working temperature

-40°C ~ +50°C

Working humidity

20-95% RH non-condensing

Storage temperature, humidity

-40°C ~ +80°C, 10-95% RH non-condensing

Temperature coefficient

±0.03% / °C(0°C - 50°C)

Vibration

10~500Hz, 5G 12min. / 1 cycle, period for 72min. each along X,Y,Z axes

Ambient temperature

50°C

Casing temperature

90°C

Safety standards

UL8750 CAN/CSA-C22.2 No.250.13 (US)

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P:100MΩ / 500VDC / 25°C / 70% RH

EMC Emission

FCC Part 15, Subpart B; ANSI C63.4a-2017; ICES-005 Issue 5

Surge Immunity Test

AC Power Line:Differential Mode 4 kV, Common Mode 6 kV

Net Weight

1.5kg

Dimensions

241 x 125 x 42.7mm (L x W x H)

MCB recommendations MCB Type

C type (Breaking capacity:6KA)

I/P-FG:1.88KVAC

O/P-FG:0.5KVAC (US)

The number of LED Driver matched by circuit breakers is as follows: Level

Number of LED drivers @ 120 VAC

Number of LED drivers @ 277 VAC

10A

13A

16A

20A

25A

1. The above quantities of the led drivers connected on the Type C is recommended base on the maximum ambient temperature is 50 ° C 2. The breaker should be selected according to the input rated voltage, input rated current, ambient temperature, and trip characteristic curve.

2/10

TYPE RD SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RD www.inventronics-light.com

OSRAM Digital System is now Inventronics

LINEARlight FLEX INFINITE 24V – IP66/68 High efficiency flexible LED strip LFP500I/1500I/3000I/4000I-G1-xxx-24 L1

Features & Benefits               

  2000K

Made in ITALY

Up to 25mm

3500K 6500K Custom

CCT

Flexible and cuttable LED strip up to 25mm Luminous flux: up to 4,000 lm/m Dimmable with PWM technology Color uniformity better than 2 SDCM on the entire LED strip and between strips* High color fidelity to beautify every design High luminous flux Large selection of light colors Great design freedom thanks to flexibility and cuttability of module High-performance silicone for extremely long life and flexibility Extraordinary design and high quality materials Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back Pre-wired LED strip, simple and quick plug-and-play installation Outdoor use possible: UV and salt mist resistant (UV acc. to ISO 4892-2 - Method A, salt mist acc. to IEC 60068-2-52 severity Simplified connection with optional matching CONNECTsystem Quick installation with optional SLIM TRACK System Perfectly matched to non-isolated OPTOTRONIC electronic control gears Made in Italy > 9m Custom REEL length

UP to 160lm/W

Technical drawings

LFP500I-G1: L=9000mm LFP1500I-G1: L=6000mm

Lowest Bending Radius = 50 mm Product length = Max. operable length

Specification Sheet – 2023.07.31 – subject to change without notice

MANDARIN

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS

1200 PROFILE

Scale 1:1

LINEAR WEIGHT

MAXIMUM LED STRIP WIDTH

0.099 lbs / ft 0.148 kg / m

DRY: 9 / 16 " DRY: 14 mm

LED TAPE COMPATIBILITY 2400K

E491159

CLOSET RATED

E491159

2700K

warmdim

DAMP: 3 / 8 " DAMP: 10 mm

3000K

tunable white

3500K

4000K

rgb

5000K rgbw

CHANNEL COLOR OPTIONS aluminum anodized

black anodized

custom RAL color

swivel

millwork

damp

wet

MOUNTING

PRODUCT FEATURES

surface

corner

LOCATION RATING

dry

• Aluminum construction for superior heat dissipation

OTHER OPTIONS

• UL 2108 listed - Suitable for storage and closet areas dot-free

motion sensor

USEFUL LINKS

MAXIMUM LED RUN CHART PER DRIVER

VOLTAGE DROP CHART

INSTALLATION SHEET

BULK PARTS LIST

IES FILES

Reverse voltage protection up to

25.0 V

Temperature range in operation @ Tc point

-30 °C…+80 °C

Temperature TYPE RDStorage SPEC

MANDARIN

-40 °C…+85 °C

Ambient Temperature with profile **

-30 °C...+55 °C

*max ambient temperature strongly depends from which kind of profile will be used. For this reason, we always recommend to prepare an installation mockup and measure the Tc. 0766 MANDARIN ORIENTAL GRAND CAYMAN

Technical data

CRI 80+

Nominal CCT

See color output data

500lm/m

LFP500I-G1-824-24-09 L1 Fitting Reference: RD LFP500I-G1-827-24-09 L1

Luminous Power Flux W/m lm/m

Luminous Efficacy lm/W

1500lm/m

Length m

2400 K

510

128

4062172371469

560

140

4062172371483

LFP500I-G1-830-24-09 L1

3000 K

600

150

4062172371506

LFP500I-G1-840-24-09 L1

4000 K

625

156

4062172371520

LFP1500I-G1-824-24-06 L1

2400 K

1250

9,8

128

4062172371643

LFP1500I-G1-827-24-06 L1

2700 K

1370

9,8

140

4062172371667

LFP1500I-G1-830-24-06 L1

3000 K

1470

9,8

150

4062172371681

LFP1500I-G1-840-24-06 L1

4000 K

1570

9,8

160

4062172371704

126

4062172371803

139

4062172371827

149

4062172371841

157

4062172371889

123

4062172372022

LFP Infinite Voltage IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1 Nominal 24.0 V

3 00 0 l m / m

Order Code

2700 K

LFP Infinite IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1

4 00 0 l m / m

ROOMS, SUITES & CONDOS

Performance Temperature °C

LFP3000I-G1-824-24-03 L1 2400 K 2460 19,6 Reverse voltage protection up to 25.0 V 19,6 LFP3000I-G1-827-24-03 L190+ 2700 K 2720 Color output data CRI Temperature range in operation @ Tc point -30 °C…+80 °C 19,6 LFP3000I-G1-830-24-03 L1 3000 K 2920 Storage Temperature -40 °C…+85 °C 19,6 LFP3000I-G1-840-24-03 L1 4000 K 3080 Ambient Temperature with profile ** -30 °C...+55 °C LFP4000I-G1-824-24-03 L1 2400 K 3210 26,2

26,2 136 50 4062172372046 03 LFP4000I-G1-827-24-03 L1 2700 K 3560 *max ambient temperature strongly depends from which kind26,2 of profile will be used. For this always recommend to prepare 145 50reason, we 4062172372060 03 an LFP4000I-G1-830-24-03 L1 3000 K 3800 installation mockup and measure the Tc. 26,2 153 50 4062172372084 03 LFP4000I-G1-840-24-03 L1 4000 K 4000

Technical data

4400 0000l lmm//mm

3300 0000l ml m/ m /m

11550 0 00l ml m/ m/ m

55 0 00 0 l ml m / m/ m

CRI 80+ 90+ CRI LFP500I-G1-924-24-09 L1 L1 LFP500I-G1-824-24-09 LFP500I-G1-927-24-09 L1 LFP500I-G1-827-24-09 L1

5 00 l m / m 1 50 0 l m / m 3 00 0 l m / m

2400 K K 2400 2700 K 2700 K 3000 K K 3000

LFP500I-G1-930-24-09 L1 L1 LFP500I-G1-830-24-09 LFP500I-G1-940-24-09 L1 L1 LFP500I-G1-840-24-09

4000 K K 4000 2400 K K 2400

LFP1500I-G1-924-24-06 L1 L1 LFP1500I-G1-824-24-06 LFP1500I-G1-927-24-06 LFP1500I-G1-827-24-06 L1 L1

2700 K K 2700 3000 K K 3000

LFP1500I-G1-930-24-06 LFP1500I-G1-830-24-06 L1 L1 LFP1500I-G1-940-24-06 LFP1500I-G1-840-24-06 L1 L1

4000 K K 4000 2400 K 2400 K

LFP3000I-G1-924-24-03 LFP3000I-G1-824-24-03 L1 L1 LFP3000I-G1-927-24-03 LFP3000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP3000I-G1-930-24-03 LFP3000I-G1-830-24-03 L1 L1 LFP3000I-G1-940-24-03 LFP3000I-G1-840-24-03 L1 L1

4000 K K 4000 2400 K 2400 K

LFP4000I-G1-924-24-03 LFP4000I-G1-824-24-03 L1 L1 LFP4000I-G1-927-24-03 LFP4000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP4000I-G1-930-24-03 LFP4000I-G1-830-24-03 L1 L1 LFP4000I-G1-940-24-03 LFP4000I-G1-840-24-03 L1 L1

CRI 90+

4 00 0 l m / m

Nominal Nominal CCT CCT

See color output See color output data data

4000 K K 4000 Nominal CCT

See color output data

LFP500I-G1-924-24-09 L1

2400 K

Specification Sheet – 2023.08.28 LFP500I-G1-927-24-09 L1 2700 K

Luminous Luminous Power Power Flux Flux W/m W/m lm/m lm/m 430 510 480 560 515 600

550 625 1060 1250 1160 1370 1270 1470 1370 1570 2100 2460 2300 2720 2490 2920 2700 3080 2750 3210 3000 3560 3220 3800 3480 4000

4 4 4 4 4 4 4 4

9,8 9,8 9,8 9,8 9,8 9,8 9,8 9,8 19,6 19,6 19,6 19,6 19,6 19,6 19,6 19,6 26,2 26,2 26,2 26,2 26,2 26,2 26,2 26,2

Luminous Power Flux W/m lm/m

Luminous Luminous Efficacy Efficacy lm/W lm/W

Performance Performance Temperature Temperature °C °C

138 156 108 128

29 29 34 34

108 128 120 140 129 150

118 140 130 150

140 160 107 126 117 139 127 149 138 157 105 123 115 136 123 145 133 153 Luminous Efficacy lm/W

29 29 29 29 29 29

34 34 34 34

34 34 45 45 45 45 45 45 45 45 50 50 50 50 50 50 50 50

Order Order Code Code 4062172371544 4062172371469 4062172371568 4062172371483 4062172371582 4062172371506 4062172371605 4062172371520 4062172371728 4062172371643 4062172371742 4062172371667 4062172371766 4062172371681 4062172371780 4062172371704 4062172371902 4062172371803 4062172371926 4062172371827 4062172371940 4062172371841 4062172371964 4062172371889 4062172372107 4062172372022 4062172372121 4062172372046 4062172372145 4062172372060 4062172372169 4062172372084

Performance Temperature °C

Order Code

Length Length m m 09 09 09 09 09 09 09 09 06 06 06 06 06 06

06 06 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03

Length m

430

108

4062172371544

480

120

4062172371568

LFP500I-G1-930-24-09 L1

3000 K

515

129

4062172371582

LFP500I-G1-940-24-09 L1

4000 K

550

138

4062172371605

LFP1500I-G1-924-24-06 L1

2400 K

1060

9,8

108

4062172371728

LFP1500I-G1-927-24-06 L1

2700 K

1160

9,8

118

4062172371742

LFP1500I-G1-930-24-06 L1

3000 K

1270

9,8

130

4062172371766

LFP1500I-G1-940-24-06 L1

4000 K

1370

9,8

140

4062172371780

LFP3000I-G1-924-24-03 L1

2400 K

2100

19,6

107

4062172371902

LFP3000I-G1-927-24-03 L1

2700 K

2300

19,6

117

4062172371926

LFP3000I-G1-930-24-03 L1

3000 K

2490

19,6

127

4062172371940

LFP3000I-G1-940-24-03 L1

4000 K

2700

19,6

138

4062172371964

LFP4000I-G1-924-24-03 L1

2400 K

2750

26,2

105

4062172372107

LFP4000I-G1-927-24-03 L1

2700 K

3000

26,2

115

4062172372121

LFP4000I-G1-930-24-03 L1

3000 K

3220

26,2

123

4062172372145

LFP4000I-G1-940-24-03 L1

4000 K

3480

26,2

133

4062172372169

Specification Sheet – 2023.08.28

MANDARIN

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS 1200

TUNABLE WHITE / RGB / RGBW ORDERING SHEET

Finish

CA1200 - MCF

Mounting

PROFILE & FINISH

Optics

- DRS

Lumen Package

CCT

Application

- LDWH2465 MOUNTING

- AIW

Power Feed

- FH3

OPTICS

Input / Output

LUMEN PACKAGE

MCF - Flat surface bracket

DCS - Clear lens

LDWM2465 - Dual White - 3.5 W/ft - 260 lm/ft

CA1201 - Anodized black finish

MC3 - 45° Corner bracket

DXS - Optiflex lens

LDWH2465 - Dual White - 5.8 W/ft - 427 lm/ft

MC8 - Swivel 180°

DOS - Opal lens

LRGBLD - RGB - 4.4 W/ft - low density

M3M - Double face mounting tape

DRS - Prime lens

LRGBMD - RGB - 5.8 W/ft - medium density

MNO - No mounting

DBS - Black lens

LRGB30† - RGBW (3000K) 4 in 1 - 4.4 W/ft - 107 lm/ft

CA120X - Custom color provide RAL #

Length, in

Driver / Sensor

Accessories

CA1200 - Anodized aluminum finish

CA1202- White

Exact / Optimal

CCT

2400-6500K

APPLICATION

AID - Indoor dry locations AIW - Indoor wet locations

N/A

For wet location applications, LED strip will be put inside a waterproof silicone sheath.

RGB + 3000K

†

AIW option is not available for this selection

DSS - Silens DNO - No lens

11 DRIVER TYPE / SENSOR

FH3 - Hardwire, 3ft wire

WSE - Simple lead-in, end feed

QE - Exact

Length of the luminaire in inches.

PND - Non-dimmable

CGAP - Apsis

FH6 - Hardwire, 6ft wire

WSB - Simple lead-in, back feed

QO - Optimal

PDMX - DMX driver

CGLA - Latus

FH9 - Hardwire, 9ft wire

WSL - Simple lead-in, side feed 1

*Includes end caps, excludes flanges (when applicable).

FHX - Hardwire, custom length wire

WSR - Simple lead-in, side feed 2

POWER FEED

INPUT / OUTPUT

WPB - Pass-through, back feed WPL - Pass-through, side 1

EXACT/OPTIMAL

Exact - length specified in section 10 with end caps without flanges. Optimal - length specified in section 10, rounded down to the closest LED cut section to minimize dark spots.

LENGTH*

GYPSUM COVES, 8ft

CGNI - Nidus

PNO - No driver

MOTION SENSORS flange

WPE - Pass-through, end feed

no flange

CGSU - Sulcus

PND-SI05 - 30 sec., embedded PND-SE05 - 30 sec., external

length

PND-SI4 - 4 min., embedded PND-SE4 - 4 min., external

WPR - Pass-through, side 2

PND-SIP - proximity motion sensor All motion sensors can only be used with non-dimmable power supplies - 72W / 24V - For indoor dry applications

1200 series

alu. finish

prime lens

2400-6500K

hardwire connection, 6 '

72" fixture (with end caps)

non-dimmable driver

CA1200 - MCF - DRS - LDWH2465 - AID - FH6 - WSB - QO72 PND flat bracket

dual white, high lumen

indoor dry application

back feed lead-in only

optimal length, no dark spots

TYPE RD SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RD

Product - technical datasheet The trusted value of OSRAM Digital Systems continues with Inventronics Global – where experience meets innovation.

LFP1500I-G1 -927-24-06 L1 FS1 LINEARlight FLEX Infinite Protect | – LED modules for professional and industrial applications Product family features - Flexible and cuttable LED strip - Type of protection (modules): IP66 and IP68 - Dimmable with PWM technology

Product family benefits - Color uniformity better than 2 SDCM on the entire LED strip and between strips - High luminous flux - Large selection of light colors - Great design freedom thanks to flexibility and cuttability of module - High-performance silicone for extremely long life and flexibility - Extraordinary design and high quality materials - Toolless connection only if using the optional CONNECTsystem - Easy mounting on many smooth surfaces thanks to self-adhesive tape at the back - Pre-wired LED strip, simple and quick plug-and-play installation

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS

1 - PROFILE DIMENSIONS

1200

PROFILE

END CAPS

1200

REGULAR

0.74 [18.7]

0.74 [18.7] 0.45 [11.5]

0.14 [3.5] 0.49 [12.5]

0.45 [11.5]

2 - MOUNTING HARDWARE DIMENSIONS CLIP-IN BRACKETS (stainless steel) MCF - FLAT BRACKET

0.85 [21.5]

MC8 - SWIVEL 180˚ BRACKET

MC3 - 45˚CORNER BRACKET

0.79 [20.0]

0.88 [22.3]

0.98 [25.0]

0.33 [8.3]

0.14 [3.5]

0.62 [15.6] 0.45 [11.3]

0.92 [23.3] 1.27 [32.0]

0.93 [23.5]

0.63 [16.0]

0.85 [21.5]

1.22 [31.0]

0.96 [24.3]

0.93 [23.5] 1.27 [32.0]

Scale 1:1

TYPE RD SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RD

Product - technical datasheet Technical data Electrical data Nominal voltage

24.0 V

Type of current

Nominal wattage per meter

9.8 W

Rated wattage

58.80 W

Input voltage range

23…25 V

Accidental reverse input voltage protection up to

25 V

Photometrical data Color rendering index Ra

Luminous flux per meter

1160 lm

Luminous efficacy

118.4 lm/W

Light color (designation)

2700 K

Color Temperature

2700

Light technical data LED pitch

12.5 mm

Beam angle

120 °

Starting time

< 0.5 s

LED module information Number of LEDs per meter

Number of LEDs per smallest unit

Product - technical datasheet

Dimensions & weight Length

6000 mm

Length – smallest unit

50.0 mm

Width

11.1 mm

Height

4.5 mm

Product weight

367.00 g

Cable cross-section, input side

0.5 mm²

Colors & materials Cover material

Silicone

Temperatures & operating conditions Temperature range in operation at Tc point

-30…80 °C 1)

Ambient temperature range

-30…+55 °C

Temperature range at storage

-40…+85 °C

1) Exceeding the maximum ratings will reduce expected life time or destroy the LED strip.

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN 3 - OPTICS

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS

4 - LUMEN PACKAGE

1200

LED TAPE AND OPTICS CHART @ FULL LIGHT OUTPUT LP100

LP200

LP300

LP450

LP750

LW2229

LW2735

LDWM

LDWH

LRGBLD

LRGBMD

LRGB30

5300K

2200K to 2900K

2700K to 3500K

2400K to 6500K

RGB

RGBW 3000K

LED tape color type 2400K 2700K 3000K 3500K 4000K

CCT Range

6200K

Power

4.8 W/m 1.5 W/ft

9.6 W/m 3.0 W/ft

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

23 W/m 7.0 W/ft

14.5 W/m 4.4 W/ft

11.5 W/m 3.5 W/ft

19.2 W/m 5.8 W/ft

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

14.5 W/m 4.4 W/ft

Eﬃcacy

91 lm/W

81 lm/W

76 lm/W

84 lm/W

95 lm/W

< 44 lm/W

< 46 lm/W

74 lm/W

CRI

90+

95+

90+

80+

60+

65+

60+*

Available in IP68 option (silicone sleeve)

LED tape increment

50 mm 1.97 in

33 mm 1.30 in

25 mm 0.98 in

33 mm 1.30 in

50 mm 1.97 in

100 mm 3.94 in

63 mm 2.48 in

100 mm 3.94 in

Quantity of LED chips

120 LED/m 36 LED/ft

180 LED/m 54 LED/ft

240 LED/m 73 LED/ft

60 LED/m 18 LED/ft

112 LED/m 34 LED/ft

60 LED/m 18 LED/ft

LED tape width

8 mm 0.31 in

10 mm 0.39 in

12 mm 0.47 in

Closet Rated

DOT-FREE

VISIBLE DOTS

Compatible with water-proof sheath

Spec sheet LENS

BEAM

*At higher CCT value

Tested with LP450

*At higher CCT value

DBS - black

Disappears on dark surfaces when turned off.

59 lm/ft

89 lm/ft

144 lm/ft

207 lm/ft

337 lm/ft

xx lm/ft

rgb

xx lm/ft

86° 30

DSS - silens

98 cd 90

No dots, suitable for direct view, and a continuous lens up to 10M (33ft).

64 lm/ft

100 lm/ft

156 lm/ft

217 lm/ft

370 lm/ft

xx lm/ft

rgb

xx lm/ft

455

113°

60 75

73 cd

DOS - opal

No dots, and suitable for direct view.

74 lm/ft

117 lm/ft

179 lm/ft

259 lm/ft

421 lm/ft

xx lm/ft

rgb

xx lm/ft

114° 330

DRS - prime

Best light output for direct view with higher lumen packages.

100 lm/ft

158 lm/ft

239 lm/ft

342 lm/ft

559 lm/ft

xx lm/ft

rgb

xx lm/ft

104° 150

DXS - optiﬂex

88 cd

Eliminates shadows, best light output for indirect view.

116 lm/ft

183 lm/ft

281 lm/ft

389 lm/ft

649 lm/ft

xx lm/ft

rgb

xx lm/ft

127 cd

90° 200

173 cd

DCS - clear The highest light output for indirect view.

136 lm/ft

213 lm/ft

326 lm/ft

448 lm/ft

745 lm/ft

<192 lm/ft

<202 lm/ft

<260 lm/ft

<427 lm/ft

rgb

107 lm/ft 1600 200

Lumen output tested at 4000K. Use this table to calculate lumen output for different CCTs.

20 120

106°

2400K - 0.89

2700K - 0.91

3000K - 0.95

3500K - 0.96

4000K - 1.00

6200K - 1.07

181 cd

IES FILES for other CCTs peak candella

TYPE RD SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RD www.osram.com

Slim Profile System Slim Profile 12 mm height FX-QMS-G1-TU16H12-300

Features & Benefits Powerful lighting in compact size. With reduced dimensions, this slim yet powerful profile is ideal to create tailor made general lighting solutions thanks to the different available optics, also in confined spaces, such as coves and furniture. Suitable also for wall grazing and wall washing effects thanks to narrow beam lens cover. Application    

Architectural Integration Shelves, Closets, Showcases, Cabinets Lighting Handrails and Stairs Wall washing

Dimension & Available Covers

Slim profile 12 mm height FX-QMS-G1-TU16H12-300 Dimensions: W16 x H12 x L3000 mm

C0-C180 C90-C270

cd/1000lm

Profile without cover

Slim cover frosted FX-QMS-G1-CFDB-300 Or Slim cover clear FX-QMS-G1-CFTL-300 Dimensions: W11 x H4 x L3000 mm

C0-C180 C90-C270

Slim lens cover FX-QMS-G1-CLT -300 Dimensions: W16 x H8 x L3000 mm

cd/1000lm

Slim cover frosted

C0-C180 cd/1000lm C90-C270

Slim lens cover 10° beam angle

Screw (not included)

Glue Mounting bracket

Installation example – Drop ceiling

Specification Sheet v. 2

Installation example – Wood

Surface installation example

Slim Profile and strip LF1200 with and without frosted cover.

MANDARIN

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS

7 - POWER FEED

1200

FC3 / FC6 / FC9 / FCX - DC CONNECTORS (static white and Warmdim LED tape only)

FH3 / FH6 / FH9 / FHX - HARDWIRE

FC3 - DC plug, 3ft wire

FC9 - DC plug, 9ft wire

FH3 - Hardwire, 3ft wire

FH9 - Hardwire, 9ft wire

FC6 - DC plug, 6ft wire

FCX - DC plug, custom length wire

FH6 - Hardwire, 6ft wire

FHX - Hardwire, custom length wire

DRY APPLICATIONS

Static white / Warmdim TEW 22 AWG

1.49 [38.0]

0.19 [4.8] 0.18 [4.5]

0.42 [10.7]

Static white / Warmdim TR64 22 AWG

2.83 [71.8]

0.13 [3.3]

DAMP / WET APPLICATIONS

0.62 [15.8]

0.19 [4.8]

0.60 [15.2]

0.20 [5.2]

0.21 [5.3]

0.07 [1.7]

0.25 [6.3]

0.06 [1.6]

0.17 [4.3]

RGB

0.06 [1.6]

RGBW

Static white / Warmdim IP68 (FT4)

1.64 [41.7]

Tunable White

0.09 [2.4]

0.20 [5.2]

3.42 [86.8]

8 - INPUT / OUTPUT 1200 SIMPLE LEAD (ONE SIDE)

WSE

WSB

WSL

WSR

WPE

WPB

WPL

WPR

WSE - End feed (no dark spots) WSB - Back feed (dark spots) WSL - Side feed 1 (dark spots) WSR - Side feed 2 (dark spots)

1200 PASS-THROUGH (TWO SIDES) WPE - End feed (no dark spots) WPB - Back feed (dark spots) WPL - Side feed 1 (dark spots) WPR - Side feed 2 (dark spots)

ORDERING CODE EXAMPLES 120 series

hardwire connection, 6 '

end feed pass-through

120X - XX - XX - XXX XX - XXX - FH6 - WPE - XX - X 120X - XX - XX - XXX XX - XXX - FH3 - WSB - XX - X 120 series

FH6 - 6ft hardwire intput

hardwire connection, 3 '

backw feed simple

FH6 - 6ft hardwire output

WPE - pass-through (input and output) end feed

FH3 - 3ft hardwire intput

WSB - simple (input only) back feed

TYPE RD SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RD Slim Profile System | Slim Profile 12 mm height FX-QMS-G1-TU16H12-300

Technical drawings

Slim cover frosted FX-QMS-G1-CFDB-300 Order code 4052899446991 Slim Profile FX-QMS-G1-TU16H12-300 Order code 4052899448964

Slim cover clear FX-QMS-G1-CFTL-300 Order code 4052899999749

Slim lens cover 10° FX-QMS-G1-CLT-300 Order code 4052899447783

Plastic End cap FX-QMS-G1-EFGP-TU16H12LS Order code 4052899449183 Plastic end cap with hole FX-QMS-G1-EFGH-TU16H12LS Order code 4052899999848

Adjustable mounting brackets (90°) ADJUSTABLESLIMBRACKET Order code 4052899600010

Metal mounting bracket FX-QMS-G1-BMZI-DIV1 Order code 4052899446861

Possible combinations of profile and mounting bracket

Order Code Product Code

Description

FX-QMS-G1-TU16H12-300

Product number Dimensions EAN Package content (EAN10) (length x width x height) Slim Profile 12 mm height 4052899448964 3000 x 16 x 12 mm 1x Profile

FX-QMS-G1-CFTL-300

Slim cover clear

1x Cover

Slim cover frosted

4052899999749 4052899446991

3000 x 12 x 4 mm

FX-QMS-G1-CFDB-300

3000 x 11 x 4 mm

1x Cover

FX-QMS-G1-CLT-300

Slim lens cover

4052899447783

3000 x 16 x 8 mm

1x Cover

4052899449183

16 x 9.5 x 12 mm

40x End cap

4052899999848 4052899446861

16 x 9.5 x 12 mm 17 x 20 x 9.5 mm

40x End cap 40x Mounting bracket

4052899600010

20 x 17 x 9.5 mm

40x Tiltable bracket

FX-QMS-G1-EFGP-TU16H12LS End cap FX-QMS-G1-EFGH-TU16H12LS End cap with hole Mounting bracket FX-QMS-G1-BMZI-DIV1 ADJUST ABLESLIMBRACKET

Specification Sheet v. 2

Adjustable mounting bracket

MANDARIN DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

TYPE RD ALT

MOGC TYPE-RDHOTEL GUEST ROOMS CLASS 2 CLASSP TYPE HL SELV

2-CHANNELS

1/10

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF www.osram.com

LINEARlight FLEX Protect Tunable White IP67/IP66 The perfect cozy atmosphere also for outdoor installations LFP1100/3400TW-G5

Features & Benefits − − − − − − − − − − − − − − − −

Application areas

Dynamic lighting applications in outdoor or wet areas

Standards

CE, ENEC 10 VDE, UL Recognized according UL 8750

Technical data LFP1100TW…09 L2

LFP3400TW…03 L1

Lowest Bending Radius = 50 mm Max. operable length = product length

Beam Angle 120° Nominal Voltage

24.0 V

Accidental reverse voltage protection up to

25.0 V

Temperature range in operation @ Tc point

-20°C...+85°C

Storage Temperature

-40°C...+85°C

Ambient Temperature with profile **

-20°C...+50 °C C0-C180 C90-C270

Specification Sheet – 2020.12.10 – subject to change without notice

cd/1000lm

MANDARIN

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS

1200 PROFILE

Scale 1:1

LINEAR WEIGHT

MAXIMUM LED STRIP WIDTH

0.099 lbs / ft 0.148 kg / m

DRY: 9 / 16 " DRY: 14 mm

LED TAPE COMPATIBILITY 2400K

E491159

CLOSET RATED

E491159

2700K

warmdim

DAMP: 3 / 8 " DAMP: 10 mm

3000K

tunable white

3500K

4000K

rgb

5000K rgbw

CHANNEL COLOR OPTIONS aluminum anodized

black anodized

custom RAL color

swivel

millwork

damp

wet

MOUNTING

PRODUCT FEATURES

surface

corner

LOCATION RATING

dry

• Aluminum construction for superior heat dissipation

OTHER OPTIONS

• UL 2108 listed - Suitable for storage and closet areas dot-free

motion sensor

USEFUL LINKS

MAXIMUM LED RUN CHART PER DRIVER

VOLTAGE DROP CHART

INSTALLATION SHEET

BULK PARTS LIST

IES FILES

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF LFP Tunable White IP67/IP66 | LFP1100/3400TW

Technical data Color Temperature 1

CRI

LFP1100TW-G5-825.940-09 L2

2500-4000 K

1156

9.9

117

LFP1100TW-G5-927.957-09 L2

2700-5700 K

1134

10.2

111

TUNABLE WHITE

Color Temperature

CRI

Luminous Flux Power per meter lm/m W/m

Luminous Performance Temp. Length Efficacy lm/W Tp °C m

LFP3400TW-G5-825.940-03 L1

2500-4000 K

3356

30.9

108

LFP3400TW-G5-927.957-03 L1

2500-3500 K

3356

32.0

105

Technical data per each channel BOTH CHANNELS 50% ON

CH1 = 100% ON, CH2 = OFF

CH1 = OFF, CH2 = 100% ON

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

LFP1100TW-G5-825.940-09 L2

3145

578

5.0

2500

578

5.0

4000

578

5.0

LFP1100TW-G5-927.957-09 L2

3759

567

5.1

2700

567

5.1

5700

567

5.1

TUNABLE WHITE

BOTH CHANNELS 50% ON

CH1 = 100% ON, CH2 = OFF

CH1 = OFF, CH2 = 100% ON

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

CCT [K]

lm/m

W/m

LFP3400TW-G5-825.940-03 L1

3115

1678

15.5

2500

1678

15.5

4000

1678

15.5

LFP3400TW-G5-927.957-03 L1

3708

1678

16.0

2700

1678

16.0

5700

1678

16.0

Melanopic effect - Human Centric Lighting

LFP1100TW-G5-825.940-09 L2 LFP1100TW-G5-927.957-09 L2

a 0.325 0.395

b 0.478 0.602

c 0.616 0.771

a 359 436

b 538 665

c 680 851

Spectral data [K] a b c 2500 3145 4000 2700 3759 5700

LFP3400TW-G5-825.940-03 L1 LFP3400TW-G5-927.957-03 L1

0.322 0.410

0.478 0.583

0.605 0.814

355 453

527 643

667 898

2500 2700

ΦV, mel, D65

amel, v

Operating conditions: • • •

a: Ch1=100%, Ch2 OFF b: Ch1=50%, Ch2=50% c: Ch1 OFF, Ch2=100%

Specification Sheet – 2020.12.10 – subject to change without notice

3115 3708

4000 5700

Photometric luminous flux (  ) [lm/m] 578 567 1678 1678

MANDARIN

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS 1200

TUNABLE WHITE / RGB / RGBW ORDERING SHEET

Finish

CA1200 - MCF

Mounting

PROFILE & FINISH

Optics

- DRS

Lumen Package

CCT

Application

- LDWH2465 MOUNTING

- AIW

Power Feed

- FH3

OPTICS

Input / Output

Length, in

Driver / Sensor

Accessories

LUMEN PACKAGE

CA1200 - Anodized aluminum finish

MCF - Flat surface bracket

DCS - Clear lens

LDWM2465 - Dual White - 3.5 W/ft - 260 lm/ft

CA1201 - Anodized black finish

MC3 - 45° Corner bracket

DXS - Optiflex lens

Custom LDWH2465 - Dual White -8.5W/ft 5.8 W/ft - 427 lm/ft

CA1202- White

MC8 - Swivel 180°

DOS - Opal lens

LRGBLD - RGB - 4.4 W/ft - low density

M3M - Double face mounting tape

DRS - Prime lens

LRGBMD - RGB - 5.8 W/ft - medium density

MNO - No mounting

DBS - Black lens

LRGB30† - RGBW (3000K) 4 in 1 - 4.4 W/ft - 107 lm/ft

CA120X - Custom color provide RAL #

Exact / Optimal

CCT

2400-6500K

APPLICATION

AID - Indoor dry locations AIW - Indoor wet locations

N/A

For wet location applications, LED strip will be put inside a waterproof silicone sheath.

RGB + 3000K

†

AIW option is not available for this selection

DSS - Silens DNO - No lens

POWER FEED

INPUT / OUTPUT

EXACT/OPTIMAL

LENGTH*

FH3 - Hardwire, 3ft wire

WSE - Simple lead-in, end feed

QE - Exact

Length of the luminaire in inches.

FH6 - Hardwire, 6ft wire

WSB - Simple lead-in, back feed

QO - Optimal

FH9 - Hardwire, 9ft wire

WSL - Simple lead-in, side feed 1

*Includes end caps, excludes flanges (when applicable).

FHX - Hardwire, custom length wire

WSR - Simple lead-in, side feed 2

WPB - Pass-through, back feed WPL - Pass-through, side 1

no flange

Optimal - length specified in section 10, rounded down to the closest LED cut section to minimize dark spots.

PND - Non-dimmable

CGAP - Apsis

PDMX - DMX driver

CGLA - Latus

GYPSUM COVES, 8ft

CGNI - Nidus

PNO - No driver

MOTION SENSORS flange

WPE - Pass-through, end feed

Exact - length specified in section 10 with end caps without flanges.

11 DRIVER TYPE / SENSOR

CGSU - Sulcus

PND-SI05 - 30 sec., embedded PND-SE05 - 30 sec., external

length

PND-SI4 - 4 min., embedded PND-SE4 - 4 min., external

WPR - Pass-through, side 2

PND-SIP - proximity motion sensor All motion sensors can only be used with non-dimmable power supplies - 72W / 24V - For indoor dry applications

1200 series

alu. finish

prime lens

2400-6500K

hardwire connection, 6 '

72" fixture (with end caps)

non-dimmable driver

CA1200 - MCF - DRS - LDWH2465 - AID - FH6 - WSB - QO72 PND flat bracket

dual white, high lumen

indoor dry application

back feed lead-in only

optimal length, no dark spots

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF

Product - technical datasheet The trusted value of OSRAM Digital Systems continues with Inventronics Global – where experience meets innovation.

60000 h

Number of switching cycles

>15000

Capabilities Lowest bending radius

50 mm

Self-adhesive

Yes

With connection set

Yes

Product - technical datasheet

Certificates & standards Standards

CE / UL / ENEC / EAC

Type of protection

IP67

Logistical data Commodity code

85395100000

13-02-2025

Primary Article Identifier Sat Mar 22 15:02:13 CST 2025 Declaration No. in SCIP database

4062172196628 1 / 8 In work

SCIP_STATUS

In work

SCIP_ID

Equipment / Accessories

support@inventronicsglobal.com

MANDARIN

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS

1 - PROFILE DIMENSIONS

1200

PROFILE

END CAPS

1200

REGULAR

0.74 [18.7]

0.74 [18.7] 0.45 [11.5]

0.14 [3.5] 0.49 [12.5]

0.45 [11.5]

2 - MOUNTING HARDWARE DIMENSIONS CLIP-IN BRACKETS (stainless steel) MCF - FLAT BRACKET

0.85 [21.5]

MC8 - SWIVEL 180˚ BRACKET

MC3 - 45˚CORNER BRACKET

0.79 [20.0]

0.88 [22.3]

0.98 [25.0]

0.33 [8.3]

0.14 [3.5]

0.62 [15.6] 0.45 [11.3]

0.92 [23.3] 1.27 [32.0]

0.93 [23.5]

0.63 [16.0]

0.85 [21.5]

1.22 [31.0]

0.96 [24.3]

0.93 [23.5] 1.27 [32.0]

Scale 1:1

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF

Product - technical datasheet Technical data Electrical data Nominal voltage

24.0 V

Type of current

Nominal wattage per meter

32 W

Rated wattage

96.00 W

Input voltage range

23…25 V

Accidental reverse input voltage protection up to

25 V

Photometrical data Color rendering index Ra

Luminous flux per meter

3356 lm

Luminous efficacy

105 lm/W

Light color (designation)

2700…5700 K

Color Temperature

3700

Light technical data LED pitch

10.71 mm

Beam angle

120 °

Starting time

Warm-up time (60 %)

Product - technical datasheet

LED module information Number of LEDs per meter

187

Dimensions & weight Number of LEDs per smallest unit

Length

3000 mm

Length – smallest unit

75.0 mm

Width

11.1 mm

Height

4.5 mm

Product weight

173.00 g

Cable cross-section, input side

0.5 mm²

Colors & materials Cover material

Silicone

Temperatures & operating conditions 1)

Temperature range in operation at Tc point

-30…80 °C

Ambient temperature range

-30…+50 °C

Temperature range at storage

-40…85 °C

www.inventronicsglobal.com

support@inventronicsglobal.com 2/8

MANDARIN 3 - OPTICS

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS

4 - LUMEN PACKAGE

1200

LED TAPE AND OPTICS CHART @ FULL LIGHT OUTPUT LP100

LP200

LP300

LP450

LP750

LW2229

LW2735

LDWM

LDWH

LRGBLD

LRGBMD

LRGB30

5300K

2200K to 2900K

2700K to 3500K

2400K to 6500K

RGB

RGBW 3000K

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

14.5 W/m 4.4 W/ft

LED tape color type 2400K 2700K 3000K 3500K 4000K

CCT Range

6200K

Power

4.8 W/m 1.5 W/ft

9.6 W/m 3.0 W/ft

14.5 W/m 4.4 W/ft

19.2 W/m 5.8 W/ft

23 W/m 7.0 W/ft

14.5 W/m 4.4 W/ft

11.5 W/m 3.5 W/ft

19.2 W/m 5.8 W/ft

Eﬃcacy

91 lm/W

81 lm/W

76 lm/W

84 lm/W

95 lm/W

< 44 lm/W

< 46 lm/W

74 lm/W

CRI

90+

95+

90+

80+

60+

65+

60+*

Available in IP68 option (silicone sleeve)

LED tape increment

50 mm 1.97 in

33 mm 1.30 in

25 mm 0.98 in

33 mm 1.30 in

50 mm 1.97 in

100 mm 3.94 in

63 mm 2.48 in

100 mm 3.94 in

Quantity of LED chips

120 LED/m 36 LED/ft

180 LED/m 54 LED/ft

240 LED/m 73 LED/ft

60 LED/m 18 LED/ft

112 LED/m 34 LED/ft

60 LED/m 18 LED/ft

LED tape width

8 mm 0.31 in

10 mm 0.39 in

12 mm 0.47 in

Closet Rated

DOT-FREE

VISIBLE DOTS

Compatible with water-proof sheath

Spec sheet LENS

BEAM

*At higher CCT value

xx lm/ft

Tested with LP450

DBS - black

Disappears on dark surfaces when turned off.

59 lm/ft

89 lm/ft

144 lm/ft

207 lm/ft

337 lm/ft

xx lm/ft

rgb

xx lm/ft

86° 30

DSS - silens

98 cd 90

No dots, suitable for direct view, and a continuous lens up to 10M (33ft).

64 lm/ft

100 lm/ft

156 lm/ft

217 lm/ft

370 lm/ft

xx lm/ft

rgb

xx lm/ft

455

113°

60 75

73 cd

DOS - opal

No dots, and suitable for direct view.

74 lm/ft

117 lm/ft

179 lm/ft

259 lm/ft

421 lm/ft

xx lm/ft

rgb

xx lm/ft

114° 330

DRS - prime

Best light output for direct view with higher lumen packages.

100 lm/ft

158 lm/ft

239 lm/ft

342 lm/ft

559 lm/ft

xx lm/ft

rgb

xx lm/ft

104° 150

DXS - optiﬂex

88 cd

Eliminates shadows, best light output for indirect view.

116 lm/ft

183 lm/ft

281 lm/ft

389 lm/ft

649 lm/ft

xx lm/ft

rgb

xx lm/ft

127 cd

90° 200

173 cd

DCS - clear The highest light output for indirect view.

136 lm/ft

213 lm/ft

326 lm/ft

448 lm/ft

745 lm/ft

<192 lm/ft

<202 lm/ft

<260 lm/ft

<427 lm/ft

rgb

107 lm/ft 1600 200

Lumen output tested at 4000K. Use this table to calculate lumen output for different CCTs.

20 120

106°

2400K - 0.89

2700K - 0.91

3000K - 0.95

3500K - 0.96

4000K - 1.00

6200K - 1.07

181 cd

IES FILES for other CCTs peak candella

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF www.osram.com

Slim Profile System Slim Profile 12 mm height FX-QMS-G1-TU16H12-300

Architectural Integration Shelves, Closets, Showcases, Cabinets Lighting Handrails and Stairs Wall washing

Dimension & Available Covers

Slim profile 12 mm height FX-QMS-G1-TU16H12-300 Dimensions: W16 x H12 x L3000 mm

C0-C180 C90-C270

cd/1000lm

Profile without cover

Slim cover frosted FX-QMS-G1-CFDB-300 Or Slim cover clear FX-QMS-G1-CFTL-300 Dimensions: W11 x H4 x L3000 mm

C0-C180 C90-C270

Slim lens cover FX-QMS-G1-CLT -300 Dimensions: W16 x H8 x L3000 mm

cd/1000lm

Slim cover frosted

C0-C180 cd/1000lm C90-C270

Slim lens cover 10° beam angle

Screw (not included)

Glue Mounting bracket

Installation example – Drop ceiling

Specification Sheet v. 2

Installation example – Wood

Surface installation example

Slim Profile and strip LF1200 with and without frosted cover.

MANDARIN

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS

7 - POWER FEED

1200

FC3 / FC6 / FC9 / FCX - DC CONNECTORS (static white and Warmdim LED tape only)

FH3 / FH6 / FH9 / FHX - HARDWIRE

FC3 - DC plug, 3ft wire

FC9 - DC plug, 9ft wire

FH3 - Hardwire, 3ft wire

FH9 - Hardwire, 9ft wire

FC6 - DC plug, 6ft wire

FCX - DC plug, custom length wire

FH6 - Hardwire, 6ft wire

FHX - Hardwire, custom length wire

DRY APPLICATIONS

Static white / Warmdim TEW 22 AWG

1.49 [38.0]

0.19 [4.8] 0.18 [4.5]

0.42 [10.7]

Static white / Warmdim TR64 22 AWG

2.83 [71.8]

0.13 [3.3]

DAMP / WET APPLICATIONS

0.62 [15.8]

0.19 [4.8]

0.60 [15.2]

0.20 [5.2]

0.21 [5.3]

0.07 [1.7]

0.25 [6.3]

0.06 [1.6]

0.17 [4.3]

RGB

0.06 [1.6]

RGBW

Static white / Warmdim IP68 (FT4)

1.64 [41.7]

Tunable White

0.09 [2.4]

0.20 [5.2]

3.42 [86.8]

8 - INPUT / OUTPUT 1200 SIMPLE LEAD (ONE SIDE)

WSE

WSB

WSL

WSR

WPE

WPB

WPL

WPR

WSE - End feed (no dark spots) WSB - Back feed (dark spots) WSL - Side feed 1 (dark spots) WSR - Side feed 2 (dark spots)

1200 PASS-THROUGH (TWO SIDES) WPE - End feed (no dark spots) WPB - Back feed (dark spots) WPL - Side feed 1 (dark spots) WPR - Side feed 2 (dark spots)

ORDERING CODE EXAMPLES 120 series

hardwire connection, 6 '

end feed pass-through

120X - XX - XX - XXX XX - XXX - FH6 - WPE - XX - X 120X - XX - XX - XXX XX - XXX - FH3 - WSB - XX - X 120 series

FH6 - 6ft hardwire intput

hardwire connection, 3 '

backw feed simple

FH6 - 6ft hardwire output

WPE - pass-through (input and output) end feed

FH3 - 3ft hardwire intput

WSB - simple (input only) back feed

TYPE RF SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RF Slim Profile System | Slim Profile 12 mm height FX-QMS-G1-TU16H12-300

Technical drawings

Slim cover frosted FX-QMS-G1-CFDB-300 Order code 4052899446991 Slim Profile FX-QMS-G1-TU16H12-300 Order code 4052899448964

Slim cover clear FX-QMS-G1-CFTL-300 Order code 4052899999749

Slim lens cover 10° FX-QMS-G1-CLT-300 Order code 4052899447783

Plastic End cap FX-QMS-G1-EFGP-TU16H12LS Order code 4052899449183 Plastic end cap with hole FX-QMS-G1-EFGH-TU16H12LS Order code 4052899999848

Adjustable mounting brackets (90°) ADJUSTABLESLIMBRACKET Order code 4052899600010

Metal mounting bracket FX-QMS-G1-BMZI-DIV1 Order code 4052899446861

Possible combinations of profile and mounting bracket

Order Code Product Code

Description

FX-QMS-G1-TU16H12-300

Product number Dimensions EAN Package content (EAN10) (length x width x height) Slim Profile 12 mm height 4052899448964 3000 x 16 x 12 mm 1x Profile

FX-QMS-G1-CFTL-300

Slim cover clear

1x Cover

Slim cover frosted

4052899999749 4052899446991

3000 x 12 x 4 mm

FX-QMS-G1-CFDB-300

3000 x 11 x 4 mm

1x Cover

FX-QMS-G1-CLT-300

Slim lens cover

4052899447783

3000 x 16 x 8 mm

1x Cover

4052899449183

16 x 9.5 x 12 mm

40x End cap

4052899999848 4052899446861

16 x 9.5 x 12 mm 17 x 20 x 9.5 mm

40x End cap 40x Mounting bracket

4052899600010

20 x 17 x 9.5 mm

40x Tiltable bracket

FX-QMS-G1-EFGP-TU16H12LS End cap FX-QMS-G1-EFGH-TU16H12LS End cap with hole Mounting bracket FX-QMS-G1-BMZI-DIV1 ADJUST ABLESLIMBRACKET

Specification Sheet v. 2

Adjustable mounting bracket

MANDARIN

TYPE RF ALT MOGC TYPE-RFHOTEL GUEST ROOMS

DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

CLASS 2 CLASSP TYPE HL SELV

2-CHANNELS

1/10

TYPE RF SPEC

MANDARIN

NO SPEC

MANDARIN

TYPE RF ALT

MOGC TYPE-RFHOTEL GUEST ROOMS

DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

Number of channels

2 CHANNELS

LM Number

Output

Input

LM42900-27 DC Voltage

24V

Fine-tune voltage

24V - 26V

Voltage tolerance

± 3%

Voltage regulation

≤ 1%

Load regulation

Rated current

Rated power

96W

Voltage range

100 - 277VAC

Frequency range

47 - 63Hz

Power factor (typ.) @ full load

PF ≥ 0.99 @ 120VAC

PF ≥ 0.96 @ 277VAC

THD (typ.) @ full load

≤ 6% @ 120VAC

≤ 8% @ 277VAC

Efficiency (typ.) @ full load

91% @ 120VAC

93% @ 277VAC

AC current (max.)

< 1A @ 120VAC

<0.5A @ 277VAC

Inrush current (typ.) @ 50% Ipeak

58A,134.4us @ 50%Ipeak 120VAC

123A,205us @ 50%Ipeak 277VAC

Leakage current

<0.5mA

Short circuit

Shut down o/p voltage, recovers automatically after fault condition is removed

Over load

≥ 115% Hiccup mode, recovers automatically after fault condition is removed Ambient temperature over 55°C ± 5°C to reduce output to 50%;

Protection Over temperature

Environment

Safety & EMC

Weight & Dimensions

Working temperature

-40°C ~ +50°C

Working humidity

20-95% RH non-condensing

Storage temperature, humidity

-40°C ~ +80°C, 10-95% RH non-condensing

Temperature coefficient

±0.03% / °C(0°C - 50°C)

Vibration

10~500Hz, 5G 12min. / 1 cycle, period for 72min. each along X,Y,Z axes

Ambient temperature

50°C

Casing temperature

90°C

Safety standards

UL8750 CAN/CSA-C22.2 No.250.13 (US)

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P:100MΩ / 500VDC / 25°C / 70% RH

EMC Emission

FCC Part 15, Subpart B; ANSI C63.4a-2017; ICES-005 Issue 5

Surge Immunity Test

AC Power Line:Differential Mode 4 kV, Common Mode 6 kV

Net Weight

1.5kg

Dimensions

241 x 125 x 42.7mm (L x W x H)

MCB recommendations MCB Type

C type (Breaking capacity:6KA)

I/P-FG:1.88KVAC

O/P-FG:0.5KVAC (US)

The number of LED Driver matched by circuit breakers is as follows: Level

Number of LED drivers @ 120 VAC

Number of LED drivers @ 277 VAC

10A

13A

16A

20A

25A

2/10

TYPE RG SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RG www.inventronics-light.com

OSRAM Digital System is now Inventronics

LINEARlight FLEX INFINITE 24V – IP66/68 High efficiency flexible LED strip LFP500I/1500I/3000I/4000I-G1-xxx-24 L1

Features & Benefits               

  2000K

Made in ITALY

Up to 25mm

3500K 6500K Custom

CCT

UP to 160lm/W

Technical drawings

LFP500I-G1: L=9000mm LFP1500I-G1: L=6000mm

Lowest Bending Radius = 50 mm Product length = Max. operable length

Specification Sheet – 2023.07.31 – subject to change without notice

MANDARIN

TYPE RG ALT

MOGC TYPE-RGHOTEL GUEST ROOMS

2400 PROFILE 2000 Series

0.787 in. 20.0 mm

Cross-section dimensions:

0.787 in. 20.0 mm

E491159

WELL FOCUSED ON THE TASK! Offering lighting without hot spots at a 45-degree angle from a corner, this series excels at maximizing appeal of the products in POP stands, while maintaining a minimalist style. This profile includes a long lens fitting system to maximize its long term durability. With a type A mounting channel in the back, you can easily join multiple sections with a type A straight joiner or use it to pass and hide the wiring behind the profile.

OPTIONS CUSTOM COLOR

LED ENGINE COMPATIBILITY IP22: Compatible with LED engines up to 12mm wide. LINEAR WEIGHT 0.10 lbs/ft, 0.152 kg/m (without lens)

FEATURES – Offers lighting with a beam oriented at 45 degrees. – Designed to provide a uniform light without hot spots with our Prime lens and an LED engine with 120 led/m density or more*. – Custom length in sections of 2 to 192''. – Application guide for 10mm (3/8-inch) LED engine or less. – Made of ALCOA 6063-T5 aluminum alloy increasing heat dissipation. – Its use increases the lifetime of your LED engine. – Type A mounting channel in the back of the profile – New enhanced mechanical fit for the lens. *Dot free only in certain configurations - contact your sales representatives for information

Reverse voltage protection up to

25.0 V

Temperature range in operation @ Tc point

-30 °C…+80 °C

Temperature TYPE RGStorage SPEC

MANDARIN

-40 °C…+85 °C

Ambient Temperature with profile **

-30 °C...+55 °C

Technical data

CRI 80+

Nominal CCT

See color output data

500lm/m

LFP500I-G1-824-24-09 L1 Fitting Reference: RG LFP500I-G1-827-24-09 L1

Luminous Power Flux W/m lm/m

Luminous Efficacy lm/W

1500lm/m

Length m

2400 K

510

128

4062172371469

560

140

4062172371483

LFP500I-G1-830-24-09 L1

3000 K

600

150

4062172371506

LFP500I-G1-840-24-09 L1

4000 K

625

156

4062172371520

LFP1500I-G1-824-24-06 L1

2400 K

1250

9,8

128

4062172371643

LFP1500I-G1-827-24-06 L1

2700 K

1370

9,8

140

4062172371667

LFP1500I-G1-830-24-06 L1

3000 K

1470

9,8

150

4062172371681

LFP1500I-G1-840-24-06 L1

4000 K

1570

9,8

160

4062172371704

126

4062172371803

139

4062172371827

149

4062172371841

157

4062172371889

123

4062172372022

LFP Infinite Voltage IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1 Nominal 24.0 V

3 00 0 l m / m

Order Code

2700 K

LFP Infinite IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1

4 00 0 l m / m

ROOMS, SUITES & CONDOS

Performance Temperature °C

Technical data

4400 0000l lmm//mm

3300 0000l ml m/ m /m

11550 0 00l ml m/ m/ m

55 0 00 0 l ml m / m/ m

CRI 80+ 90+ CRI LFP500I-G1-924-24-09 L1 L1 LFP500I-G1-824-24-09 LFP500I-G1-927-24-09 L1 LFP500I-G1-827-24-09 L1

5 00 l m / m 1 50 0 l m / m 3 00 0 l m / m

2400 K K 2400 2700 K 2700 K 3000 K K 3000

LFP500I-G1-930-24-09 L1 L1 LFP500I-G1-830-24-09 LFP500I-G1-940-24-09 L1 L1 LFP500I-G1-840-24-09

4000 K K 4000 2400 K K 2400

LFP1500I-G1-924-24-06 L1 L1 LFP1500I-G1-824-24-06 LFP1500I-G1-927-24-06 LFP1500I-G1-827-24-06 L1 L1

2700 K K 2700 3000 K K 3000

LFP1500I-G1-930-24-06 LFP1500I-G1-830-24-06 L1 L1 LFP1500I-G1-940-24-06 LFP1500I-G1-840-24-06 L1 L1

4000 K K 4000 2400 K 2400 K

LFP3000I-G1-924-24-03 LFP3000I-G1-824-24-03 L1 L1 LFP3000I-G1-927-24-03 LFP3000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP3000I-G1-930-24-03 LFP3000I-G1-830-24-03 L1 L1 LFP3000I-G1-940-24-03 LFP3000I-G1-840-24-03 L1 L1

4000 K K 4000 2400 K 2400 K

LFP4000I-G1-924-24-03 LFP4000I-G1-824-24-03 L1 L1 LFP4000I-G1-927-24-03 LFP4000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP4000I-G1-930-24-03 LFP4000I-G1-830-24-03 L1 L1 LFP4000I-G1-940-24-03 LFP4000I-G1-840-24-03 L1 L1

CRI 90+

4 00 0 l m / m

Nominal Nominal CCT CCT

See color output See color output data data

4000 K K 4000 Nominal CCT

See color output data

LFP500I-G1-924-24-09 L1

2400 K

Specification Sheet – 2023.08.28 LFP500I-G1-927-24-09 L1 2700 K

Luminous Luminous Power Power Flux Flux W/m W/m lm/m lm/m 430 510 480 560 515 600

550 625 1060 1250 1160 1370 1270 1470 1370 1570 2100 2460 2300 2720 2490 2920 2700 3080 2750 3210 3000 3560 3220 3800 3480 4000

4 4 4 4 4 4 4 4

9,8 9,8 9,8 9,8 9,8 9,8 9,8 9,8 19,6 19,6 19,6 19,6 19,6 19,6 19,6 19,6 26,2 26,2 26,2 26,2 26,2 26,2 26,2 26,2

Luminous Power Flux W/m lm/m

Luminous Luminous Efficacy Efficacy lm/W lm/W

Performance Performance Temperature Temperature °C °C

138 156 108 128

29 29 34 34

108 128 120 140 129 150

118 140 130 150

140 160 107 126 117 139 127 149 138 157 105 123 115 136 123 145 133 153 Luminous Efficacy lm/W

29 29 29 29 29 29

34 34 34 34

34 34 45 45 45 45 45 45 45 45 50 50 50 50 50 50 50 50

Performance Temperature °C

Order Code

Length Length m m 09 09 09 09 09 09 09 09 06 06 06 06 06 06

06 06 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03

Length m

430

108

4062172371544

480

120

4062172371568

LFP500I-G1-930-24-09 L1

3000 K

515

129

4062172371582

LFP500I-G1-940-24-09 L1

4000 K

550

138

4062172371605

LFP1500I-G1-924-24-06 L1

2400 K

1060

9,8

108

4062172371728

LFP1500I-G1-927-24-06 L1

2700 K

1160

9,8

118

4062172371742

LFP1500I-G1-930-24-06 L1

3000 K

1270

9,8

130

4062172371766

LFP1500I-G1-940-24-06 L1

4000 K

1370

9,8

140

4062172371780

LFP3000I-G1-924-24-03 L1

2400 K

2100

19,6

107

4062172371902

LFP3000I-G1-927-24-03 L1

2700 K

2300

19,6

117

4062172371926

LFP3000I-G1-930-24-03 L1

3000 K

2490

19,6

127

4062172371940

LFP3000I-G1-940-24-03 L1

4000 K

2700

19,6

138

4062172371964

LFP4000I-G1-924-24-03 L1

2400 K

2750

26,2

105

4062172372107

LFP4000I-G1-927-24-03 L1

2700 K

3000

26,2

115

4062172372121

LFP4000I-G1-930-24-03 L1

3000 K

3220

26,2

123

4062172372145

LFP4000I-G1-940-24-03 L1

4000 K

3480

26,2

133

4062172372169

Specification Sheet – 2023.08.28

MANDARIN

TYPE RG ALT MOGC TYPE-RGHOTEL GUEST ROOMS

2000 Profile ordering sheet CORNER ASSEMBLY OPTIONS

2000 Series ADDITIONAL COMMENTS

When ordering an assembly that requires corners, make sure to indicate the correct corner type. In order to do this, please specify the desired lighting layout using the form below.

L-SHAPE

U-SHAPE

RECTANGLE

SIDE EXTERIOR

SIDE INTERIOR

1-855-384-3384 www.lumentruss.com info@lumentruss.com

We reserve the right to change specififcations without prior notification. Last update: June 28, 2021

TYPE RG SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RG

Product - technical datasheet The trusted value of OSRAM Digital Systems continues with Inventronics Global – where experience meets innovation.

LFP500I-G1 -927-24-09 L1 FS1 LINEARlight FLEX Infinite Protect | – LED modules for professional and industrial applications Product family features - Flexible and cuttable LED strip - Type of protection (modules): IP66 and IP68 - Dimmable with PWM technology

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN

TYPE RG ALT

MOGC TYPE-RGHOTEL GUEST ROOMS

2400 Profile ordering sheet PROFILE

LENSES

2000 Series

MOUNTING HARDWARE

LENGTH

2000

Custom length by sections of 2 to 192 inches (5m). PR - Prime lens 2400 - 2400 Profile, alu

45 - 45º corner bracket

OX - Optiflex lens 3M - Mounting tape, double face

NEW 2401 - 2400 Profile, black

NO - No mounting hardware BK - Black lens

NO - No lens 240X - 2400 Profile, custom color IMPORTANT: Give RAL color № See Appendix 1 on page 256

RAL NUMBER

– PROFILE

– LENS

COLOR TEMPERATURE

– MOUNTING HARDWARE

LUMEN PACKAGE*

LENGTH

LEAD IN/OUT

USAGE

POWER SUPPLY/CONTROL

24 - 2400K

LP0 - 119 LM / 1.5W FT / 90+CRI

HW3 - Hardwire 3 FT

27 - 2700K

LP1 - 137 LM / 1.5W FT / 90+CRI

HW6 - Hardwire 6 FT

B - ELV dimming 120V AC

30 - 3000K

LP2 - 234 LM / 3.0W FT / 90+CRI

HW9 - Hardwire 9 FT

C - ELV dimming 120/277 VAC**

35 - 3500K

LP3 - 335 LM / 4.4W FT / 90+CRI

HWX - Hardwire custom FT

D - 0/10V dimming 120/277 VAC

42 - 4200K

LP4 - 488 LM / 5.8W FT / 90+CRI

DC3 - DC plug 3 FT

E - Non-dimming DC plug in

53 - 5300K (LHP only)

LHP - 668 LM / 7.0W FT / 95+CRI

DC6 - DC plug 6 FT

F - DMX

62 - 6200K (LP only)

I - IP22 indoor dry location

A - Non-dimming

DC9 - DC plug 9 FT NO - No lead

For TW or RGB strip options, select either A [Non-dimming] or E [Non-dimming DC plug] in power supply plus the J [Casambi CBU-PWM44CH-Bluetooth 100/277 VAC] controller.

WD3 - 2700-3500K 14W TW1 - Tunable White 11W

Lumen Package selection is not available for WD, TW and RGB color options.

TW2 - Tunable White 19W RGB1 - RGB 14W

** Only available in 96W - 24V Driver.

G -Lutron - HI-LUME PREMIER 0,1% Eco System 24V/96W

DCX - DC plug custom FT WD1 - 2200-2700K 14W

*NOTES *The light output is provided in lumens per foot, for a CCT of 4200K without lens. Please refer to the optics page for CCT and translucency conversion factors.

RGB2 - RGB 19W RGBW2- 3000K 4in1

I- Casambi CBU-A2D-0/10VDALI-Bluetooth 100/277 VAC J- Casambi CBU-PWM4-4CHBluetooth 100/277 VAC K- Casambi CBU-TED-CV-Trail edge dim-Bluetooth 120 VAC NO - No driver

– COLOR TEMPERATURE CCT

– LUMEN PACKAGE

– LEAD IN

LEAD OUT

I USAGE

TYPE RG SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RG

Product - technical datasheet Technical data Electrical data Nominal voltage

24.0 V

Type of current

Nominal wattage per meter

4.0 W

Rated wattage

36.00 W

Input voltage range

23…25 V

Accidental reverse input voltage protection up to

25 V

Photometrical data Color rendering index Ra

Luminous flux per meter

480 lm

Luminous efficacy

120 lm/W

Light color (designation)

2700 K

Color Temperature

2700

Light technical data LED pitch

12.5 mm

Beam angle

120 °

Starting time

< 0.5 s

LED module information Number of LEDs per meter

Number of LEDs per smallest unit

Product - technical datasheet

Dimensions & weight Length

9000 mm

Length – smallest unit

50.0 mm

Width

11.1 mm

Height

4.5 mm

Product weight

542.00 g

Cable cross-section, input side

0.5 mm²

Colors & materials Cover material

Silicone

Temperatures & operating conditions Temperature range in operation at Tc point

-30…80 °C 1)

Ambient temperature range

-30…+55 °C

Temperature range at storage

-40…+85 °C

1) Exceeding the maximum ratings will reduce expected life time or destroy the LED strip.

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

TYPE RG ALT

MOGC TYPE-RGHOTEL GUEST ROOMS CLASS 2 CLASSP TYPE HL SELV

2-CHANNELS

1/10

TYPE RG SPEC

MANDARIN

NO SPEC

MANDARIN

TYPE RG ALT

MOGC TYPE-RGHOTEL GUEST ROOMS

DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

Number of channels

2 CHANNELS

LM Number

LM42900-27

Output

Input

DC Voltage

24V

Fine-tune voltage

24V - 26V

Voltage tolerance

± 3%

Voltage regulation

≤ 1%

Load regulation

Rated current

Rated power

96W

Voltage range

100 - 277VAC

Frequency range

47 - 63Hz

Power factor (typ.) @ full load

PF ≥ 0.99 @ 120VAC

PF ≥ 0.96 @ 277VAC

THD (typ.) @ full load

≤ 6% @ 120VAC

≤ 8% @ 277VAC

Efficiency (typ.) @ full load

91% @ 120VAC

93% @ 277VAC

AC current (max.)

< 1A @ 120VAC

<0.5A @ 277VAC

Inrush current (typ.) @ 50% Ipeak

58A,134.4us @ 50%Ipeak 120VAC

123A,205us @ 50%Ipeak 277VAC

Leakage current

<0.5mA

Short circuit

Shut down o/p voltage, recovers automatically after fault condition is removed

Over load

≥ 115% Hiccup mode, recovers automatically after fault condition is removed Ambient temperature over 55°C ± 5°C to reduce output to 50%;

Protection Over temperature

Working temperature

Environment

Safety & EMC

Weight & Dimensions

-40°C ~ +50°C

Working humidity

20-95% RH non-condensing

Storage temperature, humidity

-40°C ~ +80°C, 10-95% RH non-condensing

Temperature coefficient

±0.03% / °C(0°C - 50°C)

Vibration

10~500Hz, 5G 12min. / 1 cycle, period for 72min. each along X,Y,Z axes

Ambient temperature

50°C

Casing temperature

90°C

Safety standards

UL8750 CAN/CSA-C22.2 No.250.13 (US)

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P:100MΩ / 500VDC / 25°C / 70% RH

EMC Emission

FCC Part 15, Subpart B; ANSI C63.4a-2017; ICES-005 Issue 5

Surge Immunity Test

AC Power Line:Differential Mode 4 kV, Common Mode 6 kV

Net Weight

1.5kg

Dimensions

241 x 125 x 42.7mm (L x W x H)

Level

Number of LED drivers @ 120 VAC

Number of LED drivers @ 277 VAC

10A

13A

16A

20A

25A

MCB recommendations MCB Type

C type (Breaking capacity:6KA)

I/P-FG:1.88KVAC

O/P-FG:0.5KVAC (US)

The number of LED Driver matched by circuit breakers is as follows:

2/10

TYPE RH SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RH www.inventronics-light.com

OSRAM Digital System is now Inventronics

LINEARlight FLEX INFINITE 24V – IP66/68 High efficiency flexible LED strip LFP500I/1500I/3000I/4000I-G1-xxx-24 L1

Features & Benefits               

  2000K

Made in ITALY

Up to 25mm

3500K 6500K Custom

CCT

UP to 160lm/W

Technical drawings

LFP500I-G1: L=9000mm LFP1500I-G1: L=6000mm

Lowest Bending Radius = 50 mm Product length = Max. operable length

Specification Sheet – 2023.07.31 – subject to change without notice

MANDARIN

TYPE RH ALT

MOGC TYPE-RHHOTEL GUEST ROOMS

2400 PROFILE 2000 Series

0.787 in. 20.0 mm

Cross-section dimensions:

0.787 in. 20.0 mm

E491159

OPTIONS CUSTOM COLOR

LED ENGINE COMPATIBILITY IP22: Compatible with LED engines up to 12mm wide. LINEAR WEIGHT 0.10 lbs/ft, 0.152 kg/m (without lens)

Reverse voltage protection up to

25.0 V

Temperature range in operation @ Tc point

-30 °C…+80 °C

Temperature TYPE RHStorage SPEC

MANDARIN

-40 °C…+85 °C

Ambient Temperature with profile **

-30 °C...+55 °C

Technical data

CRI 80+

Nominal CCT

See color output data

500lm/m

LFP500I-G1-824-24-09 L1 Fitting Reference: RH LFP500I-G1-827-24-09 L1

Luminous Power Flux W/m lm/m

Luminous Efficacy lm/W

1500lm/m

Length m

2400 K

510

128

4062172371469

560

140

4062172371483

LFP500I-G1-830-24-09 L1

3000 K

600

150

4062172371506

LFP500I-G1-840-24-09 L1

4000 K

625

156

4062172371520

LFP1500I-G1-824-24-06 L1

2400 K

1250

9,8

128

4062172371643

LFP1500I-G1-827-24-06 L1

2700 K

1370

9,8

140

4062172371667

LFP1500I-G1-830-24-06 L1

3000 K

1470

9,8

150

4062172371681

LFP1500I-G1-840-24-06 L1

4000 K

1570

9,8

160

4062172371704

126

4062172371803

139

4062172371827

149

4062172371841

157

4062172371889

123

4062172372022

LFP Infinite Voltage IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1 Nominal 24.0 V

3 00 0 l m / m

Order Code

2700 K

LFP Infinite IP66/68 | LFP500I-G1 / LFP1500I-G1 / LFP3000I-G1 / LFP4000I-G1

4 00 0 l m / m

ROOMS, SUITES & CONDOS

Performance Temperature °C

Technical data

4400 0000l lmm//mm

3300 0000l ml m/ m /m

11550 0 00l ml m/ m/ m

55 0 00 0 l ml m / m/ m

CRI 80+ 90+ CRI LFP500I-G1-924-24-09 L1 L1 LFP500I-G1-824-24-09 LFP500I-G1-927-24-09 L1 LFP500I-G1-827-24-09 L1

5 00 l m / m 1 50 0 l m / m 3 00 0 l m / m

2400 K K 2400 2700 K 2700 K 3000 K K 3000

LFP500I-G1-930-24-09 L1 L1 LFP500I-G1-830-24-09 LFP500I-G1-940-24-09 L1 L1 LFP500I-G1-840-24-09

4000 K K 4000 2400 K K 2400

LFP1500I-G1-924-24-06 L1 L1 LFP1500I-G1-824-24-06 LFP1500I-G1-927-24-06 LFP1500I-G1-827-24-06 L1 L1

2700 K K 2700 3000 K K 3000

LFP1500I-G1-930-24-06 LFP1500I-G1-830-24-06 L1 L1 LFP1500I-G1-940-24-06 LFP1500I-G1-840-24-06 L1 L1

4000 K K 4000 2400 K 2400 K

LFP3000I-G1-924-24-03 LFP3000I-G1-824-24-03 L1 L1 LFP3000I-G1-927-24-03 LFP3000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP3000I-G1-930-24-03 LFP3000I-G1-830-24-03 L1 L1 LFP3000I-G1-940-24-03 LFP3000I-G1-840-24-03 L1 L1

4000 K K 4000 2400 K 2400 K

LFP4000I-G1-924-24-03 LFP4000I-G1-824-24-03 L1 L1 LFP4000I-G1-927-24-03 LFP4000I-G1-827-24-03 L1 L1

2700 K K 2700 3000 K K 3000

LFP4000I-G1-930-24-03 LFP4000I-G1-830-24-03 L1 L1 LFP4000I-G1-940-24-03 LFP4000I-G1-840-24-03 L1 L1

CRI 90+

4 00 0 l m / m

Nominal Nominal CCT CCT

See color output See color output data data

4000 K K 4000 Nominal CCT

See color output data

LFP500I-G1-924-24-09 L1

2400 K

Specification Sheet – 2023.08.28 LFP500I-G1-927-24-09 L1 2700 K

Luminous Luminous Power Power Flux Flux W/m W/m lm/m lm/m 430 510 480 560 515 600

550 625 1060 1250 1160 1370 1270 1470 1370 1570 2100 2460 2300 2720 2490 2920 2700 3080 2750 3210 3000 3560 3220 3800 3480 4000

4 4 4 4 4 4 4 4

9,8 9,8 9,8 9,8 9,8 9,8 9,8 9,8 19,6 19,6 19,6 19,6 19,6 19,6 19,6 19,6 26,2 26,2 26,2 26,2 26,2 26,2 26,2 26,2

Luminous Power Flux W/m lm/m

Luminous Luminous Efficacy Efficacy lm/W lm/W

Performance Performance Temperature Temperature °C °C

138 156 108 128

29 29 34 34

108 128 120 140 129 150

118 140 130 150

140 160 107 126 117 139 127 149 138 157 105 123 115 136 123 145 133 153 Luminous Efficacy lm/W

29 29 29 29 29 29

34 34 34 34

34 34 45 45 45 45 45 45 45 45 50 50 50 50 50 50 50 50

Performance Temperature °C

Order Code

Length Length m m 09 09 09 09 09 09 09 09 06 06 06 06 06 06

06 06 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03 03

Length m

430

108

4062172371544

480

120

4062172371568

LFP500I-G1-930-24-09 L1

3000 K

515

129

4062172371582

LFP500I-G1-940-24-09 L1

4000 K

550

138

4062172371605

LFP1500I-G1-924-24-06 L1

2400 K

1060

9,8

108

4062172371728

LFP1500I-G1-927-24-06 L1

2700 K

1160

9,8

118

4062172371742

LFP1500I-G1-930-24-06 L1

3000 K

1270

9,8

130

4062172371766

LFP1500I-G1-940-24-06 L1

4000 K

1370

9,8

140

4062172371780

LFP3000I-G1-924-24-03 L1

2400 K

2100

19,6

107

4062172371902

LFP3000I-G1-927-24-03 L1

2700 K

2300

19,6

117

4062172371926

LFP3000I-G1-930-24-03 L1

3000 K

2490

19,6

127

4062172371940

LFP3000I-G1-940-24-03 L1

4000 K

2700

19,6

138

4062172371964

LFP4000I-G1-924-24-03 L1

2400 K

2750

26,2

105

4062172372107

LFP4000I-G1-927-24-03 L1

2700 K

3000

26,2

115

4062172372121

LFP4000I-G1-930-24-03 L1

3000 K

3220

26,2

123

4062172372145

LFP4000I-G1-940-24-03 L1

4000 K

3480

26,2

133

4062172372169

Specification Sheet – 2023.08.28

MANDARIN

TYPE RH ALT

MOGC TYPE-RHHOTEL GUEST ROOMS

2400 Profile ordering sheet PROFILE

LENSES

2000 Series

MOUNTING HARDWARE

LENGTH

2000

Custom length by sections of 2 to 192 inches (5m). PR - Prime lens 2400 - 2400 Profile, alu

45 - 45º corner bracket

OX - Optiflex lens 3M - Mounting tape, double face

NEW 2401 - 2400 Profile, black

NO - No mounting hardware BK - Black lens

NO - No lens 240X - 2400 Profile, custom color IMPORTANT: Give RAL color № See Appendix 1 on page 256

RAL NUMBER

– PROFILE

– LENS

COLOR TEMPERATURE

– MOUNTING HARDWARE

LUMEN PACKAGE*

LENGTH

LEAD IN/OUT

USAGE

POWER SUPPLY/CONTROL

24 - 2400K

LP0 - 119 LM / 1.5W FT / 90+CRI

HW3 - Hardwire 3 FT

27 - 2700K

LP1 - 137 LM / 1.5W FT / 90+CRI

HW6 - Hardwire 6 FT

B - ELV dimming 120V AC

30 - 3000K

LP2 - 234 LM / 3.0W FT / 90+CRI

HW9 - Hardwire 9 FT

C - ELV dimming 120/277 VAC**

35 - 3500K

LP3 - 335 LM / 4.4W FT / 90+CRI

HWX - Hardwire custom FT

D - 0/10V dimming 120/277 VAC

42 - 4200K

LP4 - 488 LM / 5.8W FT / 90+CRI

DC3 - DC plug 3 FT

E - Non-dimming DC plug in

53 - 5300K (LHP only)

LHP - 668 LM / 7.0W FT / 95+CRI

DC6 - DC plug 6 FT

F - DMX

62 - 6200K (LP only)

I - IP22 indoor dry location

A - Non-dimming

DC9 - DC plug 9 FT NO - No lead

For TW or RGB strip options, select either A [Non-dimming] or E [Non-dimming DC plug] in power supply plus the J [Casambi CBU-PWM44CH-Bluetooth 100/277 VAC] controller.

WD3 - 2700-3500K 14W TW1 - Tunable White 11W

Lumen Package selection is not available for WD, TW and RGB color options.

TW2 - Tunable White 19W RGB1 - RGB 14W

** Only available in 96W - 24V Driver.

G -Lutron - HI-LUME PREMIER 0,1% Eco System 24V/96W

DCX - DC plug custom FT WD1 - 2200-2700K 14W

*NOTES *The light output is provided in lumens per foot, for a CCT of 4200K without lens. Please refer to the optics page for CCT and translucency conversion factors.

RGB2 - RGB 19W RGBW2- 3000K 4in1

I- Casambi CBU-A2D-0/10VDALI-Bluetooth 100/277 VAC J- Casambi CBU-PWM4-4CHBluetooth 100/277 VAC K- Casambi CBU-TED-CV-Trail edge dim-Bluetooth 120 VAC NO - No driver

– COLOR TEMPERATURE CCT

– LUMEN PACKAGE

– LEAD IN

LEAD OUT

I USAGE

TYPE RH SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RH

Product - technical datasheet The trusted value of OSRAM Digital Systems continues with Inventronics Global – where experience meets innovation.

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

TYPE RH ALT

MOGC TYPE-RHHOTEL GUEST ROOMS CLASS 2 CLASSP TYPE HL SELV

2-CHANNELS

1/10

TYPE RH SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RH

Product - technical datasheet Technical data Electrical data Nominal voltage

24.0 V

Type of current

Nominal wattage per meter

9.8 W

Rated wattage

58.80 W

Input voltage range

23…25 V

Accidental reverse input voltage protection up to

25 V

Photometrical data Color rendering index Ra

Luminous flux per meter

1160 lm

Luminous efficacy

118.4 lm/W

Light color (designation)

2700 K

Color Temperature

2700

Light technical data LED pitch

12.5 mm

Beam angle

120 °

Starting time

< 0.5 s

LED module information Number of LEDs per meter

Number of LEDs per smallest unit

Product - technical datasheet

Dimensions & weight Length

6000 mm

Length – smallest unit

50.0 mm

Width

11.1 mm

Height

4.5 mm

Product weight

367.00 g

Cable cross-section, input side

0.5 mm²

Colors & materials Cover material

Silicone

Temperatures & operating conditions Temperature range in operation at Tc point

-30…80 °C 1)

Ambient temperature range

-30…+55 °C

Temperature range at storage

-40…+85 °C

1) Exceeding the maximum ratings will reduce expected life time or destroy the LED strip.

Specifications are subject to changes without notice. www.inventronicsglobal.com

support@inventronicsglobal.com

MANDARIN

TYPE RH ALT

MOGC TYPE-RHHOTEL GUEST ROOMS

DALI-96W-UNV-24VAO-D4IDT8-2CH-BK

Number of channels

2 CHANNELS

LM Number

LM42900-27

Output

Input

DC Voltage

24V

Fine-tune voltage

24V - 26V

Voltage tolerance

± 3%

Voltage regulation

≤ 1%

Load regulation

Rated current

Rated power

96W

Voltage range

100 - 277VAC

Frequency range

47 - 63Hz

Power factor (typ.) @ full load

PF ≥ 0.99 @ 120VAC

PF ≥ 0.96 @ 277VAC

THD (typ.) @ full load

≤ 6% @ 120VAC

≤ 8% @ 277VAC

Efficiency (typ.) @ full load

91% @ 120VAC

93% @ 277VAC

AC current (max.)

< 1A @ 120VAC

<0.5A @ 277VAC

Inrush current (typ.) @ 50% Ipeak

58A,134.4us @ 50%Ipeak 120VAC

123A,205us @ 50%Ipeak 277VAC

Leakage current

<0.5mA

Short circuit

Shut down o/p voltage, recovers automatically after fault condition is removed

Over load

≥ 115% Hiccup mode, recovers automatically after fault condition is removed Ambient temperature over 55°C ± 5°C to reduce output to 50%;

Protection Over temperature

Working temperature

Environment

Safety & EMC

Weight & Dimensions

-40°C ~ +50°C

Working humidity

20-95% RH non-condensing

Storage temperature, humidity

-40°C ~ +80°C, 10-95% RH non-condensing

Temperature coefficient

±0.03% / °C(0°C - 50°C)

Vibration

10~500Hz, 5G 12min. / 1 cycle, period for 72min. each along X,Y,Z axes

Ambient temperature

50°C

Casing temperature

90°C

Safety standards

UL8750 CAN/CSA-C22.2 No.250.13 (US)

Withstand voltage

I/P-O/P:1.88KVAC

Isolation resistance

I/P-O/P:100MΩ / 500VDC / 25°C / 70% RH

EMC Emission

FCC Part 15, Subpart B; ANSI C63.4a-2017; ICES-005 Issue 5

Surge Immunity Test

AC Power Line:Differential Mode 4 kV, Common Mode 6 kV

Net Weight

1.5kg

Dimensions

241 x 125 x 42.7mm (L x W x H)

Level

Number of LED drivers @ 120 VAC

Number of LED drivers @ 277 VAC

10A

13A

16A

20A

25A

MCB recommendations MCB Type

C type (Breaking capacity:6KA)

I/P-FG:1.88KVAC

O/P-FG:0.5KVAC (US)

The number of LED Driver matched by circuit breakers is as follows:

2/10

TYPE RH SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RH www.osram.com

Slim Profile System Slim Profile 45°

FX-QMS-G1-T45D19H19-300 Features & Benefits Bring the light to and from every corner, simply and with a pleasant result. Thanks to the compact dimensions, the Slim Profile 45° is ideal for highlight furniture, shelves and closets with minimal space requirements. The high quality of the materials used makes it suitable to be installed in applications where it is directly visible and touchable. Application   

Architectural Integration Shelves, Closets, Showcases, Cabinets Lighting Cove lighting

Dimension & Available Covers

SSlim Profile 45° FX-QMS-G1-T45D19H19-300 DDimensions: W19 x H19 x L3000 mm

C0-C180 C90-C270

cd/1000lm

Profile without cover W

Slim cover frosted FX-QMS-G1-CFDB-300 Or Slim cover clear FX-QMS-G1-CFTL-300 Dimensions: W11 x H4 x L3000 mm

Installation example

Specification Sheet v. 2

C0-C180 C90-C270

cd/1000lm

Slim cover frosted

Slim Profile and strip LF1200 with and without frosted cover.

MANDARIN

TYPE RH ALT

NO SPEC

TYPE RH SPEC

MANDARIN 0766 MANDARIN ORIENTAL GRAND CAYMAN ROOMS, SUITES & CONDOS

Fitting Reference: RH Slim Profile System | Slim Profile 45° FX-QMS-G1-T45D19H19-300

Order Code Product Code

Description

Dimensions

EAN Package content

Slim Profile 45°

Product Number (EAN10) 4052899448667

FX-QMS-G1-T45D19H19-300 FX-QMS-G1-CFTL-300

3000 x 19 x 19 mm

1x Profile

Slim cover clear

4052899999749

3000 x 11 x 4 mm

1x Cover

FX-QMS-G1-CFDB-300

Slim cover frosted

4052899446991

3000 x 11 x 4 mm

1x Cover

FX-QMS-G1-EFGP-T45D19H19

End cap

4052899450028

26 x 17.5 x 10 mm

40x End cap

FX-QMS-G1-EFGH-T45D19H19 FX-QMS-G1-BMZI-T 45D19H19

End cap with hole

4052899999862

26 x 17.5 x 10 mm

40x End cap

Mounting bracket

4052899446960

20 x 20 x 9.5 mm

40x Mounting bracket

Complete System Example

(length x width x height)

Slim Profile FX-QMS-G1-T45D19H19-300

End cap FX-QMS-G1-EFGP-T45D19H19

LED Strip Frosted cover FX-QMS-G1-CFDB-300

For further information please write to flex-support@osram.com or consult our Flex Configurator at www.osram.com/flex-configurator

Disclaimer Subject to change without notice. Errors and omission excepted. Always make sure to use the most recent release.

OSRAM GmbH

Head Office: Marcel-Breuer-Strasse 6 80807 Munich, Germany Phone +49 89 6213-0 Fax

+49 89 6213-2020

www.osram.com Specification Sheet v. 2

MANDARIN

TYPE RH ALT

NO SPEC
