VCPG LED Parking Garage
Specifications
Shipped installed
UPL1 Up-Light: 500 lumens 3
UPL2 Up-Light: 700 lumens 4
E8WC Emergency battery backup, Certified in CA Title 20 MAEDBS (8W,
E10WH Emergency battery backup, Certified in CA Title 20 MAEDBS (10W,
HA High ambient (50°C, only P1-P4)
SF Single fuse (120V, 277V, 347V)
DF Double fuse (208V, 240V, 480V)
SPD10KV 10KV Surge Pack
LDS36 36in (3ft) lead length
LDS72 72in (6ft) lead length
LDS108 108in (9ft) lead length
DMG External 0-10V leads (no controls)8
TP Tamper proof screws
CCE Coastal Construction
Shipped Separately
WG Wire Guard
BDS Bird Shroud 9
HS House Side Shield
BSW Bird Spikes
Introduction
The all new VCPG LED (Visually Comfortable Parking Garage) luminaire is designed to bring glare control, optical performance and energy savings into one package. The recessed lens design of VCPG LED minimizes high angle glare, while its precision molded acrylic lens eliminates LED pixilation and delivers the required minimums, verticals and uniformity. The dedicated up-light module option reduces the contrast between the luminaire and the ceiling creating a more visually comfortable environment.
The VCPG LED delivers up to 87% in energy savings when replacing 175W metal halide luminaires. With over 100,000 hour life expectancy (12+ years of 24/7 continuous operation), the VCPG LED luminaire provides significant maintenance savings over traditional luminaires.
Standalone Sensors/Controls1
PIR Motion/ambient sensor for 8-15' mounting heights
PIRH Motion/ambient sensor for 15-30' mounting heights
PIR3FC3V Motion/ambient sensor for 8-15’ mounting heights, pre programmed to 3fc and 35% light output
PIRH3FC3V Motion/ambient sensor for 15-30’ mounting heights, pre programmed to 3fc and 35% light output
Networked Sensors/Controls1
NLTAIR2 PIR nLIGHT AIR Wireless enabled motion/ambient sensor for 8-15' mounting heights
NLTAIR2 PIRH nLIGHT AIR Wireless enabled motion/ambient sensor for 15'-30' mounting heights
NLTAIREM2 PIR nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 8-15' mounting heights 10
NLTAIREM2 PIRH nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 15'-30' mounting heights 10
separately YK Yoke/trunnion mount2
DWHXD White
DNAXD Natural aluminum
DDBXD Dark bronze
DBLXD Black (blank) Job Pack/Units (ships as job pack of 18pcs per; balance in units) U Unit packs only
A+ Capable options indicated by this color background.
HOUSING
- Heavy duty die cast aluminum housing
- White finish standard, black and dark bronze also available
-Mounting Bracket suitable for JBox mounting -Supports pendant mounting
CODE COMPLIANCE
- cULus Listed for Wet Locations
-DLC Listed
WARRANTY
- 5 Year
ORDERING INFORMATION
OPTIONS (Factory Installed)
OCS -Occupancy Sensor
-Battery Backup (900 lumens)
VCPG LED Parking Garage
Specifications
Shipped installed
UPL1 Up-Light: 500 lumens 3
UPL2 Up-Light: 700 lumens 4
E8WC Emergency battery backup, Certified in CA Title 20 MAEDBS (8W,
E10WH Emergency battery backup, Certified in CA Title 20 MAEDBS (10W,
HA High ambient (50°C, only P1-P4)
SF Single fuse (120V, 277V, 347V)
DF Double fuse (208V, 240V, 480V)
SPD10KV 10KV Surge Pack
LDS36 36in (3ft) lead length
LDS72 72in (6ft) lead length
LDS108 108in (9ft) lead length
DMG External 0-10V leads (no controls)8
TP Tamper proof screws
CCE Coastal Construction
Shipped Separately
WG Wire Guard
BDS Bird Shroud 9
HS House Side Shield
BSW Bird Spikes
Introduction
The all new VCPG LED (Visually Comfortable Parking Garage) luminaire is designed to bring glare control, optical performance and energy savings into one package. The recessed lens design of VCPG LED minimizes high angle glare, while its precision molded acrylic lens eliminates LED pixilation and delivers the required minimums, verticals and uniformity. The dedicated up-light module option reduces the contrast between the luminaire and the ceiling creating a more visually comfortable environment.
The VCPG LED delivers up to 87% in energy savings when replacing 175W metal halide luminaires. With over 100,000 hour life expectancy (12+ years of 24/7 continuous operation), the VCPG LED luminaire provides significant maintenance savings over traditional luminaires.
Standalone Sensors/Controls1
PIR Motion/ambient sensor for 8-15' mounting heights
PIRH Motion/ambient sensor for 15-30' mounting heights
PIR3FC3V Motion/ambient sensor for 8-15’ mounting heights, pre programmed to 3fc and 35% light output
PIRH3FC3V Motion/ambient sensor for 15-30’ mounting heights, pre programmed to 3fc and 35% light output
Networked Sensors/Controls1
NLTAIR2 PIR nLIGHT AIR Wireless enabled motion/ambient sensor for 8-15' mounting heights
NLTAIR2 PIRH nLIGHT AIR Wireless enabled motion/ambient sensor for 15'-30' mounting heights
NLTAIREM2 PIR nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 8-15' mounting heights 10
NLTAIREM2 PIRH nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 15'-30' mounting heights 10
separately YK Yoke/trunnion mount2
DWHXD White
DNAXD Natural aluminum
DDBXD Dark bronze
DBLXD Black (blank) Job Pack/Units (ships as job pack of 18pcs per; balance in units) U Unit packs only
A+ Capable options indicated by this color background.
HOUSING
- Heavy duty die cast aluminum housing
- White finish standard, black and dark bronze also available
-Mounting Bracket suitable for JBox mounting -Supports pendant mounting
CODE COMPLIANCE
- cULus Listed for Wet Locations
-DLC Listed
WARRANTY
- 5 Year
ORDERING INFORMATION
OPTIONS (Factory Installed)
OCS -Occupancy Sensor
-Battery Backup (900 lumens)
VCPG LED Parking Garage
Specifications
Shipped installed
UPL1 Up-Light: 500 lumens 3
UPL2 Up-Light: 700 lumens 4
E8WC Emergency battery backup, Certified in CA Title 20 MAEDBS (8W,
E10WH Emergency battery backup, Certified in CA Title 20 MAEDBS (10W,
HA High ambient (50°C, only P1-P4)
SF Single fuse (120V, 277V, 347V)
DF Double fuse (208V, 240V, 480V)
SPD10KV 10KV Surge Pack
LDS36 36in (3ft) lead length
LDS72 72in (6ft) lead length
LDS108 108in (9ft) lead length
DMG External 0-10V leads (no controls)8
TP Tamper proof screws
CCE Coastal Construction
Shipped Separately
WG Wire Guard
BDS Bird Shroud 9
HS House Side Shield
BSW Bird Spikes
Introduction
The all new VCPG LED (Visually Comfortable Parking Garage) luminaire is designed to bring glare control, optical performance and energy savings into one package. The recessed lens design of VCPG LED minimizes high angle glare, while its precision molded acrylic lens eliminates LED pixilation and delivers the required minimums, verticals and uniformity. The dedicated up-light module option reduces the contrast between the luminaire and the ceiling creating a more visually comfortable environment.
The VCPG LED delivers up to 87% in energy savings when replacing 175W metal halide luminaires. With over 100,000 hour life expectancy (12+ years of 24/7 continuous operation), the VCPG LED luminaire provides significant maintenance savings over traditional luminaires.
Standalone Sensors/Controls1
PIR Motion/ambient sensor for 8-15' mounting heights
PIRH Motion/ambient sensor for 15-30' mounting heights
PIR3FC3V Motion/ambient sensor for 8-15’ mounting heights, pre programmed to 3fc and 35% light output
PIRH3FC3V Motion/ambient sensor for 15-30’ mounting heights, pre programmed to 3fc and 35% light output
Networked Sensors/Controls1
NLTAIR2 PIR nLIGHT AIR Wireless enabled motion/ambient sensor for 8-15' mounting heights
NLTAIR2 PIRH nLIGHT AIR Wireless enabled motion/ambient sensor for 15'-30' mounting heights
NLTAIREM2 PIR nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 8-15' mounting heights 10
NLTAIREM2 PIRH nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 15'-30' mounting heights 10
separately YK Yoke/trunnion mount2
DWHXD White
DNAXD Natural aluminum
DDBXD Dark bronze
DBLXD Black (blank) Job Pack/Units (ships as job pack of 18pcs per; balance in units) U Unit packs only
A+ Capable options indicated by this color background.
HOUSING
- Heavy duty die cast aluminum housing
- White finish standard, black and dark bronze also available
-Mounting Bracket suitable for JBox mounting -Supports pendant mounting
CODE COMPLIANCE
- cULus Listed for Wet Locations
-DLC Listed
WARRANTY
- 5 Year
ORDERING INFORMATION
OPTIONS (Factory Installed)
OCS -Occupancy Sensor
-Battery Backup (900 lumens)
VCPG LED Parking Garage
Specifications
Shipped installed
UPL1 Up-Light: 500 lumens 3
UPL2 Up-Light: 700 lumens 4
E8WC Emergency battery backup, Certified in CA Title 20 MAEDBS (8W,
E10WH Emergency battery backup, Certified in CA Title 20 MAEDBS (10W,
HA High ambient (50°C, only P1-P4)
SF Single fuse (120V, 277V, 347V)
DF Double fuse (208V, 240V, 480V)
SPD10KV 10KV Surge Pack
LDS36 36in (3ft) lead length
LDS72 72in (6ft) lead length
LDS108 108in (9ft) lead length
DMG External 0-10V leads (no controls)8
TP Tamper proof screws
CCE Coastal Construction
Shipped Separately
WG Wire Guard
BDS Bird Shroud 9
HS House Side Shield
BSW Bird Spikes
Introduction
The all new VCPG LED (Visually Comfortable Parking Garage) luminaire is designed to bring glare control, optical performance and energy savings into one package. The recessed lens design of VCPG LED minimizes high angle glare, while its precision molded acrylic lens eliminates LED pixilation and delivers the required minimums, verticals and uniformity. The dedicated up-light module option reduces the contrast between the luminaire and the ceiling creating a more visually comfortable environment.
The VCPG LED delivers up to 87% in energy savings when replacing 175W metal halide luminaires. With over 100,000 hour life expectancy (12+ years of 24/7 continuous operation), the VCPG LED luminaire provides significant maintenance savings over traditional luminaires.
Standalone Sensors/Controls1
PIR Motion/ambient sensor for 8-15' mounting heights
PIRH Motion/ambient sensor for 15-30' mounting heights
PIR3FC3V Motion/ambient sensor for 8-15’ mounting heights, pre programmed to 3fc and 35% light output
PIRH3FC3V Motion/ambient sensor for 15-30’ mounting heights, pre programmed to 3fc and 35% light output
Networked Sensors/Controls1
NLTAIR2 PIR nLIGHT AIR Wireless enabled motion/ambient sensor for 8-15' mounting heights
NLTAIR2 PIRH nLIGHT AIR Wireless enabled motion/ambient sensor for 15'-30' mounting heights
NLTAIREM2 PIR nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 8-15' mounting heights 10
NLTAIREM2 PIRH nLIGHT AIR Wireless enabled, UL924 Listed motion/ ambient sensor for 15'-30' mounting heights 10
separately YK Yoke/trunnion mount2
DWHXD White
DNAXD Natural aluminum
DDBXD Dark bronze
DBLXD Black (blank) Job Pack/Units (ships as job pack of 18pcs per; balance in units) U Unit packs only
A+ Capable options indicated by this color background.
HOUSING
- Heavy duty die cast aluminum housing
- White finish standard, black and dark bronze also available
-Mounting Bracket suitable for JBox mounting -Supports pendant mounting
CODE COMPLIANCE
- cULus Listed for Wet Locations
-DLC Listed
WARRANTY
- 5 Year
ORDERING INFORMATION
OPTIONS (Factory Installed)
OCS -Occupancy Sensor
-Battery Backup (900 lumens)
FEATURES & SPECIFICATIONS
INTENDED USE — A general purpose and energy-efficient surface-mounted or suspended LED fixture, suitable for wet, damp and/or cold locations. For vapor-tight demanding environments where moisture or dust is a concern and where relatively low fixture mounting heights and wide fixture spacing are common. Not for use or installation in direct outdoor sunlight. Must be installed under canopy or covered ceiling. For direct sunlight installations, please refer to the FEX product family. Typical applications include industrial facilities, parking garages, retail malls, multi-purpose rooms, garden centers, and food processing. Certain airborne contaminants can diminish the integrity of acrylic and/or polycarbonate. Click here for AcrylicPolycarbonate Compatibility table for suitable use.
Certain airborne contaminants may adversely affect the functioning of LEDs and other electronic components, depending on various factors such as concentrations of the contaminants, ventilation, and temperature at the end-user location. Click here for a list of substances that may not be suitable for interaction with LEDs and other electronic components.
CONSTRUCTION — One-piece 5VA fiberglass housing with integral perimeter channel utilizing continuous poured-in-place NEMA 4X gasket. Approved for through wiring. Captive polymeric latches are standard. Stainless steel latches (#316) available as an option for food processing or more demanding applications. Power connection is easily accomplished through pre-drilled holes.
OPTICS — Injection molded, acrylic lens (.080" thick) provides high impact-resistance comparable to 100% DR. A UV stabilized polycarbonate diffuser is available (.080" thick) in clear or frosted for additional impact strength where vandal protection is desired.
Expected service life of 60,000 hours at 80% lumen maintenance (L80); predicted life of more than 100,000 hours.
ELECTRICAL — Utilizes high-efficiency LEDs mounted to core circuit boards. High-efficiency drivers operate 120-277 (MVOLT) and 347-480 (HVOLT) offered with 0-10 volt dimming, dims to 10%. Standard Luminaire Surge Protection Level: 6kV/3kA Surge Rated per ANSI C82.77-5-2015.
INSTALLATION — A pair of stainless steel surface mount brackets (SMB) are included (unless another mounting option is chosen) allowing for surface (ceiling) or suspension mount applications using included bail with aircraft cable or chain. Optional pair of dual pendant mount brackets (DPMB) are available for surface (ceiling) or suspension mount applications using either 3/8" threaded rod or included bail with aircraft cable or chain. Optional pair of angle mounting brackets (ANGBKT) for horizontal wall mount applications. LISTINGS — CSA Certified to UL and C-UL Standards. Suitable for wet location. IP65, IP66, IP67 rated. NSF Splash Zone 2 and Non-Food Zone rated. NEMA 4X rated. Sensors maintain IP65 and IP66 only. See chart on page 5 for Ambient Temperatures.
DesignLights Consortium® (DLC) Premium qualified product and DLC qualified product. Not all versions of this product may be DLC Premium qualified or DLC qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
GOVERNMENT PROCUREMENT — BAA – Product with the BAA option qualifies as a domestic end product under the Buy American Act as implemented in the FAR and DFARS. Product with the BAA option also qualifies as manufactured in the United States under DOT Buy America regulations. BABA – Build America Buy America: Product with the BAA option also qualifies as produced in the United States under the definitions of the Build America, Buy America Act. Please refer to www.acuitybrands.com/buy-american for additional information.
WARRANTY — 5-year limited warranty. This is the only warranty provided and no other statements in this specification sheet create any warranty of any kind. All other express and implied warranties are disclaimed. Complete warranty terms located at: www.acuitybrands.com/support/warranty/terms-and-conditions
NOTE: Actual performance may differ as a result of end-user environment and application. All values are design or typical values, measured under laboratory conditions at 25 °C. Specifications subject to change without notice.
Stock configurations are offered for shorter lead times:
Items marked by a shaded background qualify for the Design Select program and ship in 15 days or less. To learn more about Design Select, visit www.acuitybrands.com/designselect.
*See ordering tree for details
Capable Luminaire
This item is an A+ capable luminaire, which has been designed and tested to provide consistent color appearance and out-of-the-box control compatibility with simple commissioning.
• All configurations of this luminaire meet the Acuity Brands’ specification for chromatic consistency
• This luminaire is part of an A+ Certified solution for nLight® control networks marked by a shaded background*
To learn more about A+, visit www.acuitybrands.com/aplus
*See ordering tree for details
LEDVANCE LUMINAIRES
LEDVANCE LUMINAIRE SPECIFICATION DATA
Catalog #
Project
Type
Prepared by
APPLICATION
Comments
Ideal in new construction and retrofit applications, the Performance Class Dual Selectable Vapor Tight ILT features dual selectability and is offered in three sizes — 2', 4', and 8'.
Useful in tunnels, manufacturing, and a variety of other wet or dusty applications, this product boasts an IP66 rating to ensure a robust and durable product as well as DLC 5.1 listing to maximize rebate opportunities.
BENEFITS & FEATURES
Up to 140 LPW
Selectable color temperature: 3500/4000/5000K
— CRI >80
Selectable wattage and lumens:
– 15/20/25W | 2130/2820/3500 lm
– 20/30/40/50W | 2860/4260/5640/7000 lm
– 70/80/90/100W | 10,010/11,360/12,690/14,000 lm
— DLC 5.1 Listing assures high energy efficiency and qualifies this product for utility rebates
Optional field installable motion/daylight sensor or integrated emergency battery back-up offer further potential energy savings
— Integrated tray and lens for easy and quick installation
Stainless steel clips and UV stabilized polycarbonate lens
E10WMCP EM Self-diagnostics battery pack, MVOLT, 10W, Constant Power Certified in the California Title 20 Modernized Appliance Efficiency Database (MAEDBS) ‡
BE6WCP Cold Weather EM battery pack, 120/277V, 6W, Constant Power Certified in the California Title 20 Modernized Appliance Efficiency Database (MAEDBS) ‡
BGTDGenerator transfer device
Other Options:
ANGBKT Angle bracket shipped with fixture ‡
BAA Buy America(n) Act and/or Build America Buy America Qualified
Versatile round, directional 120V-277V LED modern accent light for commercial and large residential architectural outdoor and landscape lighting environments.
• 5W, 7W, 10W, 14W integrated HK LED delivering 400-1400 lumens 2200-4000K CCT, including specialty Amber and RGBW options.
Wet Location Listed, IP67 Standard.
• Machined from solid aircraft grade (6061-T6), corrosion-resistant aluminum, then anodized and powder coated to create a highly durable, marine grade finish.
• 180º vertical and 360º horizontal adjustment via locking swivel stem design.
Modular components, field changeable LED optical beams, and lenses.
Available with adjustable Angled, Long, and Short Glare Shields and ground, surface, and canopy mounting options.
Every fixture tested end of line for water tightness and light quality.
Readymade eligible configurations ship in 2 to 4 weeks, complete with selected accessories installed.
Aluminum materials are first anodized and then powder coated for a robust, marine grade finish. Stainless steel and brass models are provided with brushed surface.
Hood and Glare Shield
Weeping and Non-weeping Hood Styles. Set screw or threaded Angled, Short, or Long Glare Shields. (See page 4 for details). Voltage 120V - 277V AC
Wattage
5, 7, 10 or 14W HK LED delivers 400 - 1400 lumens.
Light Engine
Innovative HK LED Light module operates like a lamp and can be easily changed in the field. CRI 90 Standard. Available in CRI 80 or CRI 95 upon request. Standard CCT options are 2700K, 3000K, 3500K, 4000K. Specialty 2200K, 2400K, 2500K, Amber, and RGBW options available. Consult factory for specialty LED specification details.
Listngs
ETL Listed for Wet Location, IP67 Standard. RoHS Compliant.
Driver/ Dimming
Onboard, Integrated LED Driver Phase Control @ 120V, 0V-10V @120V-277V, DALI or DMX control available, consult factory for details.
Optics
Narrow (20º), Medium (33º), Wide (44º), and Extra Wide (57º) beam spread options available. Accepts up to 3 optical accessories (hexcel louver, optical lenses, dichroic color filters, etc.) Secured place with metal snap ring.
Mounting
Mounts using 1/2"-14 NPS male fitting compatible with all HK Lighting mounting accessories. (See page 4 for details).
Type:
Model:
BODACIOUS Integrated LED Uplight
SPECIFICATIONS
VOLTAGE:
12V AC/DC
HOUSING:
Cast brass with removable 3” shroud. Optional 6” shroud available.
Threaded with 1/2” NPT. May be mounted into threaded hubs in junction boxes or mounting accessories. Heavy-duty composite stake included.
WIRING:
Pre-wired with a five-foot pigtail of 18/2 cable.
WARRANTY: 10-year warranty
Opt. 6” extended shroud 3W & 6W #490260
DIMENSIONS:
Opt. 6” extended shroud 8W, 12W & 16W #490261
SPECIFICATION SHEET
The Bodacious uplight features an integrated LED source available in 3, 8, 6,12 or 16 watts. 2700K, 3000K and 5000K options. 30-, 45-, 65- and 100-degree beam spreads.
STYLE S Standard F Finned VOLTAGE 120V 120V (Phase
Readymade eligible configurations ship in 2 to 4 weeks
1 Consult factory for specialty finish quoting and lead times
2 For Specialty AM (Amber LED) and RG (RGBW LED), select SPW (Specialty) for Wattage. Consult factory for LED technical details before Specification or Order.
Versatile round, directional 120V-277V LED modern accent light for commercial and large residential architectural outdoor and landscape lighting environments.
• 5W, 7W, 10W, 14W integrated HK LED delivering 400-1400 lumens 2200-4000K CCT, including specialty Amber and RGBW options.
Wet Location Listed, IP67 Standard.
• Machined from solid aircraft grade (6061-T6), corrosion-resistant aluminum, then anodized and powder coated to create a highly durable, marine grade finish.
• 180º vertical and 360º horizontal adjustment via locking swivel stem design.
Modular components, field changeable LED optical beams, and lenses.
Available with adjustable Angled, Long, and Short Glare Shields and ground, surface, and canopy mounting options.
Every fixture tested end of line for water tightness and light quality.
Readymade eligible configurations ship in 2 to 4 weeks, complete with selected accessories installed.
Aluminum materials are first anodized and then powder coated for a robust, marine grade finish. Stainless steel and brass models are provided with brushed surface.
Hood and Glare Shield
Weeping and Non-weeping Hood Styles. Set screw or threaded Angled, Short, or Long Glare Shields. (See page 4 for details). Voltage 120V - 277V AC
Wattage
5, 7, 10 or 14W HK LED delivers 400 - 1400 lumens.
Light Engine
Innovative HK LED Light module operates like a lamp and can be easily changed in the field. CRI 90 Standard. Available in CRI 80 or CRI 95 upon request. Standard CCT options are 2700K, 3000K, 3500K, 4000K. Specialty 2200K, 2400K, 2500K, Amber, and RGBW options available. Consult factory for specialty LED specification details.
Listngs
ETL Listed for Wet Location, IP67 Standard. RoHS Compliant.
Driver/ Dimming
Onboard, Integrated LED Driver Phase Control @ 120V, 0V-10V @120V-277V, DALI or DMX control available, consult factory for details.
Optics
Narrow (20º), Medium (33º), Wide (44º), and Extra Wide (57º) beam spread options available. Accepts up to 3 optical accessories (hexcel louver, optical lenses, dichroic color filters, etc.) Secured place with metal snap ring.
Mounting
Mounts using 1/2"-14 NPS male fitting compatible with all HK Lighting mounting accessories. (See page 4 for details).
Type:
Model:
BODACIOUS Integrated LED Uplight
SPECIFICATIONS
VOLTAGE:
12V AC/DC
HOUSING:
Cast brass with removable 3” shroud. Optional 6” shroud available.
Threaded with 1/2” NPT. May be mounted into threaded hubs in junction boxes or mounting accessories. Heavy-duty composite stake included.
WIRING:
Pre-wired with a five-foot pigtail of 18/2 cable.
WARRANTY: 10-year warranty
Opt. 6” extended shroud 3W & 6W #490260
DIMENSIONS:
Opt. 6” extended shroud 8W, 12W & 16W #490261
SPECIFICATION SHEET
The Bodacious uplight features an integrated LED source available in 3, 8, 6,12 or 16 watts. 2700K, 3000K and 5000K options. 30-, 45-, 65- and 100-degree beam spreads.
STYLE S Standard F Finned VOLTAGE 120V 120V (Phase
Readymade eligible configurations ship in 2 to 4 weeks
1 Consult factory for specialty finish quoting and lead times
2 For Specialty AM (Amber LED) and RG (RGBW LED), select SPW (Specialty) for Wattage. Consult factory for LED technical details before Specification or Order.
Integral optics providing available beam spread of 30°, 45°, 65° and 100°
COLOR TEMPERATURES:
Color temperature options provide the following qualities: 2700K, 3000K and 5000K.
FIXTURE ORDERING INFORMATION
To order a fixture with mounting options, select the appropriate choice from each column as in the following example:
EXAMPLE: 490020-490261-490039-PM
BLANK
CONTINUED FROM PREVIOUS PAGE
2” brass riser 490039
3” brass riser 490031
6” brass riser 490032
12” brass riser 490033
24” brass riser
MS Heavy-duty slotted mounting stake (incl.) 490034
EX Excalibur Post Stake 490037
TR Trident HD 3-Prong Stake 490036
PM Pier Mount 490057
TSM Tapered Surface Mount 490048
EM Round Electrical Mounting Plate 490043
RMP Rectangular Electrical Mounting Plate 490044
BLANK
NO SPEC
301 MADEIRA
NIO-4RNDC
4" Iolite Round Reflector with Round Aperture
Source: 14W to 28W LED 800lm to 2500lm
PRODUCT DESCRIPTION
4" Iolite LED downlights require a dedicated Iolite new construction or remodel housing. Deep regressed cone reflectors optimize visual cut-off.
FEATURES
800lm, 1000lm, 1500lm, 2000lm or 2500lm LED packages
2700K, 3000K, 3500K, 4000K, 5000K @ 90+ CRI
Comfort Dim (warm dimming) also available in 800lm only
Flood optic, narrow flood and spot optics (included)
5-Year limited warranty
SPECIFICATION
Construction: Trims are constructed of heat dissipating, die-cast aluminum. The aluminum die-cast LED heat sink is threaded to fit the trim and transfer heat.
Mounting: Luminaire includes friction blades to mount securely to housing.
OPTICS
800-1000lm: Three field changeable optics (spot, narrow flood and flood) are included with each LED module. Premium 10° TIR narrow spot optic assembly also available (Click Here for more information). Optional frosted and TIR optics are also available.
1500-2500lm: Three field changeable TIR optics (spot, narrow flood and flood) are included with each LED module.
Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
Color Rendering Index: 90+CRI
Operating Temperature: Specified by housing
Lifetime: 50,000 hours @ L70
Comfort Dim: Comfort Dim color tunes the temperature from a bright 3100K, to a romantic and comfortable 2000K on a gradual, even curve. Available in 800lm only
Dimming: Specified by housing
COMPATIBLE HOUSINGS
Luminaires are compatible with respective Iolite housings manufactured by Nora Lighting.
CATALOG NO. DESCRIPTION LUMENS / WATTAGE
NHIOICD-48 ICAT New Construction 800-1000lm / 14W
NHIOICDCP-48 Chicago Plenum 800-1000lm / 14W
NHRIOIC-48 ICAT Remodel 800-1000lm / 14W
NHIOICD-415 ICAT New Construction 1500lm / 20W
NHIOICDCP-415 Chicago Plenum 1500lm / 20W
NHIOICD-420 ICAT New Construction 2000lm / 24W
NHIOICDCP-420 Chicago Plenum 2000lm / 24W
NHIOICD-425 ICAT New Construction 2500lm / 28W
NHIOICDCP-425 Chicago Plenum 2500lm / 28W
Accessories: Luminaires can accommodate (1) hex louver and (1) translucent deco collar or opaque snoot, no accessory holder is required, see accessories page. Flush mount mud ring is available to give the appearance of a trimless, compatible with new construction housing only.
LABELS AND LISTINGS
cULus Listed for Wet Locations ENERGY STAR certified 5-Year Limited Warranty RoHS Compliant Certified to the high efficacy requirements of California Title 24 JA8-2022
6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 www.noralighting.com
e-mail: nora@noralighting.com
Compatible Housings
/ 14W NHRIOIC-48 = ICAT Remodel / 800-1000lm
BLANK
301 MADEIRA
NHIOICD-48 / NHIOICDCP-48
4" Iolite IC Air-Tight New Construction Housing
Source: 12W or 13W LED 800lm or 1000lm
PRODUCT DESCRIPTION
New construction housing for use in insulated ceilings can be in direct contact with insulation. Air-tight construction provides energy savings by reducing the flow of air through the ceiling. Patented design allows for easy, tool-less removal of the driver.
SPECIFICATION
Housing: 0.040 " Aluminum shallow housing can be installed in 1/2" ceiling thickness, an extension collar (NIO- 4 EXTC2) is available for ceiling thickness up to 2".
Patented Driver Assembly: Allows driver to slide out of housing without tools from the room side.
Air Flow Restriction: Meets requirments of Air-Tight (AT) <2CFM (cubic feet per minute) in accordance with ASTM283 Air-Tight requirements.
Clearance: “IC” Insulated ceiling housings are direct contact rated. Not to be used in direct contact with spray foam insulation.
Bar Hangers: Two 13- 3/4" to 24- 1/2 " adjustable bar hangers with captive nails are included on housing. Bar hangers are parallel to junction box, but can be repositioned 90° perpendicular to junction box if desired. “L”-shaped bar hanger foot to align to bottom of construction joist. A T-bar notch allows for easy installation in a suspended ceiling.
Junction Box: Pre-wired 25 cubic inch 0.064" thick galvanized steel, with seven 1/2 " knockouts, four Romex® pryouts, and snap on covers. All leads are #18AWG wire, the ground wire is connected to the bottom, and quick connectors are supplied on all leads. Maximum of 8 no. 12 AWG through branch circuit conductors suitable for at least 90°C permitted in junction box. Junction box is accessible from the room side through housing opening.
EMERGENCY
Pre-Wired: Housing can be specified with connections for emergency battery installation. Requires access above ceiling. Must specify battery with remote test switch separately (NEPK- 07LEDUNV ).
Note: Pre-Wired is not compatible with Chicago Plenum housings Integrated: Compact emergency driver is mounted directly to the junction box allowing below ceiling access. Compared to traditional emergency driver that are larger and remote mounted which requires access above ceiling. 90 minute illumination time with 6W output in emergency mode. Battery requires 24 hours to recharge and consumes 3W when charging. Remote test switch and 3' cable included.
ELECTRICAL LE3 LE4 LUPEQ
Input Voltage 120V 120-277V 120/277V
Input Power 13W 12W 13W
Power Factor ≥0.90
Dimming Triac / ELV Triac / ELV / 0-10V Lutron EcoSystem
PULSAR Architectural LED Post Mount Luminaire, suitable for wet locations. Perfect for lighting up Residential Exteriors, Walkways, Perimeters, School Campuses, Industrial/Commercial Spaces, Parking Lots, Recreational Parks.
-Dark Sky compliant
-10 Year /100,000 warranty.
FEATURES:
•Energy Savings: Over 66% compared to HID light sources
-, Product meets Buy American Actrequirementswithin ARRA.
-, 5-year warranty.
-, Marine Grade finish.
� Suitable for Natatorium applications.
FINISHES
• AN-96/Irongray/Textured
0 GR-94/Aluminummetallic/Textured
0 WH-87/White/Textured
• BK-81/Black/Textured
• RB-10/Ironrust/Textured
BLANK
Order Guide - lnsert+2
Order code example
NO SPEC
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLEFINISHES:
Flue
WS-W36406
PRODUCTDESCRIPTION
Fundamental geometry. An opaque triangular shade shelters LED light sources, providing diffused downward illumination while protecting the nighttime sky. FEATURES
• ACLED driverless technology
• Downward illlumination
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• 0-10V dimming option available (special order), unit dimensions: 3.4" x 1.2" x 0.5" (model#LDS065M010AFE-LO1)
• IDA Dark Sky compliant in color temperatures of 3000K or lower
Central Distribution Center: 1600 Distribution Ct, Lithia Springs, GA 30122 Western Distribution Center: 1750 Archibald Avenue, Ontario, CA 91760
NO SPEC
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLEFINISHES:
Flue
WS-W36406
PRODUCTDESCRIPTION
Fundamental geometry. An opaque triangular shade shelters LED light sources, providing diffused downward illumination while protecting the nighttime sky. FEATURES
• ACLED driverless technology
• Downward illlumination
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• 0-10V dimming option available (special order), unit dimensions: 3.4" x 1.2" x 0.5" (model#LDS065M010AFE-LO1)
• IDA Dark Sky compliant in color temperatures of 3000K or lower
Central Distribution Center: 1600 Distribution Ct, Lithia Springs, GA 30122 Western Distribution Center: 1750 Archibald Avenue, Ontario, CA 91760
NO SPEC
ThermaLED Round Flat
Top Bollards
The Eco-Revolution ThermaLED Bollards with choice of optics and lenses are designed to replace HID lighting systems up to 70w MH or HPS. These fixtures are ideal for retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities.
Housing:
Listing & Ratings:
Finish:
Extruded Aluminum Housing with Flush Mounting Base & Vandal-Resistant Screws, Flat Top, Internal Ballast Tray for Easy Maintenance. Bollards Can Be Cut to Custom Lengths Upon Request.
ETL: Listed for Wet Locations, ANSI/UL 1598, 8750 IP65 Sealed LED Compartment.
Textured Architectural Bronze or Black Powdercoat Finish Over a Chromate Conversion Coating. Custom Colors Available Upon Request.
Style: Clear Prismatic Borosilicate Glass Refractor, Specially Designed Cone Reflector or Internal Louvers
Electronic Driver, 120-277V, 50/60Hz or 347V, 50/60Hz (15w Only); Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 2kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
Fixtures Ordered with Factory-Installed Motion Sensor Controls are Internally Wired for Switching and/or 1-10V Dimming Within the Housing. Remote Direct Wired Interface of 1-10V Dimming is Not Implied and May Not Be Available, Please Consult Factory. Fixtures are Tested with Eco-Revolution Controls and May Not Function Properly With Controls Supplied By Others. Fixtures are NOT Designed for Use with Line Voltage Dimmers.
Warranty: 5-Year Warranty for -40°C to +40°C Environment.
Certification & Listings:
Specifications subject to change without notice.
Shown with GFCI
Shown with "S5" Sensor
SoftLED LumaLens Opal Array Lens
(Dome Top Shown for Visual Concept)
BLANK
ThermaLED Round Flat
Mounting Accessories (Order Separately, Field Installed)
ECBOLAN4Mounting Kit, Includes Bracket & Three (3) 4˝ Zinc-Plated Anchor Bolts
ECBOLAN8Mounting Kit, Includes Bracket & Three (3) 8˝ Zinc-Plated Anchor Bolts
ECBOLAN12Mounting Kit, Includes Bracket & Three (3) 12˝ ZincPlated Anchor Bolts
ECBOLAN15Mounting Kit, Includes Bracket & Three (3) 15˝ ZincPlated Anchor Bolts
ECBREBASE* Bollard Retrofit Base Kit Adapts New Bollards to Most Existing Bolt Patterns. Fits all Eco-Revolution Bollards. Die Cast with Powdercoat Finish, Hardware Included. 11½ Dia. x 1½ H
Accessories & Replacement Parts:
*Specify Color: Z=Bronze, B=Black, C=Custom (Consult Factory) Accessories (Order Separately, Field Installed) ECP17126 Remote Programming Tool for ECP17125 ECBOLAN ECBREBASE*
ECBORBASE* Die Cast Base Plate with Powdercoat Finish Over a Chromate Conversion Coating.
ECBOADP1 Adapter Plate with Gaskets for Outlet Boxes. Fits Eco-Revolution Round Bollards. Die Cast with Bronze Powdercoat Finish.
*Specify Color: Z=Bronze, B=Black, C=Custom (Consult Factory) For Replacement Battery Backup, see the Eco-Revolution LED Battery Backup Specification Sheet.
ECBOLPCLL
NO SPEC
NO SPEC
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLEFINISHES:
Flue
WS-W36406
PRODUCTDESCRIPTION
Fundamental geometry. An opaque triangular shade shelters LED light sources, providing diffused downward illumination while protecting the nighttime sky. FEATURES
• ACLED driverless technology
• Downward illlumination
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• 0-10V dimming option available (special order), unit dimensions: 3.4" x 1.2" x 0.5" (model#LDS065M010AFE-LO1)
• IDA Dark Sky compliant in color temperatures of 3000K or lower
Central Distribution Center: 1600 Distribution Ct, Lithia Springs, GA 30122
Distribution Center: 1750 Archibald Avenue, Ontario, CA 91760
NO SPEC
Select Series Stair Lighter
Product Specifications
TCP’s Select Series Stair Lighter features a lightweight aluminum body while maintaining a durable construction, a classic 4FT length, and up to 7,425 lumen light output. With an efficiency of up to 135 lumens per watt, the Stair Lighter is designed to deliver a robust performance while maximizing energy savings.
TCP’s Select Series Stair Lighter is wattage selectable, color selectable and includes a bi-level dimming microwave motion sensor standard. Other available add-ons, such as the factoryinstalled battery backup, ensure your stairwells are always bright.
Reasons to choose the Select Series Stair Lighter from TCP
• Wattage selectable 35/45/55W
• Color Se lectable 35/40/50K
• Optional battery backup
Ideal Applications
• Commercial settings
• Stairwa ys
• Bi-level dimming microwave motion sensor
• Surface or pendant mounting
• Industrial settings
• Warehouses
BLANK
Select Series Stair Lighter
Specifications
Input Line Voltage
120-277 VAC
Input Line Frequency (Hz) 50/60HZ
Wattage (W)
35W/45W/55W
Lumens (L) 4725L/6075L/7425L
Lumens per Watt (LPW) 135 LPW (80 CRI)
CCT 3500K/4000K/5000K Selectable
Rated Life 50,000 hours
Minimum Starting Temperature 20°C (-4°F)
Maximum Operating Temperature 50°C (122°F)
CRI >80
Power Factor >0.95
THD <20%
Ratings cULus, Damp location rated
Controls 0-10V dimming (standard)
Features
• Lightweight, quick-install construction
• Standard frosted lens for glare control
• No shadows; smooth, even lighting
• Damp location rated
• 0-10V smooth, no-flicker dimming
• Operating temperature: -4°F to 122°F
• Sharkward bi-level dimming microwave motion sensor included
COLOR TEMPERATURE (K): WATTAGE (W): VOLTAGE (V): CRI:
DIMMING:
DELIVERED LUMENS: DIMENSIONS: D: 11.75" L: 11.75"
RATED LIFE (Y): CONSTRUCTION: FRAME: PLASTIC MOUNTING:
CERTIFICATIONS
- 20%
W: 11.75" H: 5/8" 50,000
LENS: POLYCARBONATE HARDWIRED
TECHNICAL DRAWING
DIMENSIONS
NO SPEC
LED SURFACE MOUNT LINEAR VAPOR TIGHT - HIGH OUTPUT
BLANK
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
LED96/VT/3CCT/3WO/UNV/HO
LED96/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
PHOTOMETRIC
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
NO SPEC
LED SURFACE MOUNT LINEAR VAPOR TIGHT - HIGH OUTPUT
BLANK
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
LED96/VT/3CCT/3WO/UNV/HO
LED96/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
PHOTOMETRIC
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
NO SPEC
LED SURFACE MOUNT LINEAR VAPOR TIGHT - HIGH OUTPUT
BLANK
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
LED96/VT/3CCT/3WO/UNV/HO
LED96/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
PHOTOMETRIC
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
NO SPEC
LED SURFACE MOUNT LINEAR VAPOR TIGHT - HIGH OUTPUT
BLANK
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
LED96/VT/3CCT/3WO/UNV/HO
LED96/VT/3CCT/3WO/UNV/HO+EM
LED48/VT/3CCT/3WO/UNV/HO
LED48/VT/3CCT/3WO/UNV/HO+EM
PHOTOMETRIC
LED48/VT/3CCT/3WO/UNV/HO+EM+MS
LED48/VT/3CCT/3WO/UNV/HO+MS
NO SPEC
NE-612LED
Compact Dual Head LED Emergency Light with Optional Remote Capability
Source: (2) 0.9W or 1W LED (2)90lm to 150lm
PRODUCT DESCRIPTION
Luminaire provides 90 minutes of light from two adjustable heads for illuminating paths of egress upon failure of normal power. Emergency unit is available in higher lumen output and remote capability.
FEATURES
Compact housing with (2) adjustable LEDs Lightweight snap together design
Self-diagnostic and self-testing option available Ceiling or wall mounted
Universal 120/277VAC input
Remote capability
SPECIFICATION
Construction: Injection-molded thermoplastic ABS housing. Plastic enclosure with 5VA flame retardant. Quick connector design for easy installation. Two fully adjustable glare-free round heads for emergency lighting.
Mounting: Plastic enclosure includes a top and side knockout for conduit application. Suitable for wall mounting or ceiling mounting. Waterproof vandal resistant enclosure available, must specify NEG-602.
Operation: Luminaire will operate for a minimum of 90 minutes during a loss of power with a 24-hour maximum recharge time per battery.
ELECTRICAL
Input Voltage: 120/277VAC 60Hz
Lumens / Wattage:
NE-612LED: (2) 110lm / 0.9W
NE-612LEDRC: (2) 90lm / 0.9W
NE-612LEDHORC: (2) 150lm / 1W
Color Temperature: 5700K
Operating Temperature: 10˚C to 40˚C ambient temperature (-25°C to 50°C when used with NEG-602)
Batteries: NiMH 3.6V 2W maintenance-free
Remote Option: Luminaire is capable of including an additional 3.6V / 4W battery. Additional battery is used to power an additional remote emergency light. Upon power failure, each additional battery requires an additional 24 hours to recharge.
LABELS AND LISTINGS
· cULus Listed for Damp Locations (Wet Location Listed when used with NEG-602)
Meets or exceeds all requirements in NFPA 70, NFPA 101 life safety code 3-Year Limited Warranty
Notes
PRODUCT IMAGES & DIMENSIONS
NFPA 101 requires 1.0 foot-candle average and 0.1 foot-candle minimum with a 40:1 maximum/minimum ratio. Below is a recommended mounting height and spacing on surface with reflectance at 80% ceiling, 50% walls, and 20% floor.
Compact
Dual Head LED Emergency Light Optional Accessory
Description
NE-612LEDB = (2) 0.9W / 110lm LED Heads without Battery for Remote Capability, Black Finish
NE-612LEDW = (2) 0.9W / 110lm LED Heads without Battery for Remote Capability, White Finish
NE-612LEDRCW = (2) 0.9W / 90lm LED Heads with 3.6V / 2W Battery for Remote Capability and Self-Diagnostics / Self-Testing, White Finish
NE-612LEDRCW
= (2) 1W /
with
/ 2W Battery for Remote Capability and Self-Diagnostics / Self-Testing, White Finish
NE-612LEDHORCW = (2) 1W / 150lm LED Heads with 3.6V / 2W Battery for Remote Capability and Self-Diagnostics / Self-Testing, White Finish
= Waterproof Vandal Resistant Enclosure
with Remote (RC)
Example: NE-612LEDHORCW = Compact Dual Head LED Emergency Light with (2) 1W / 150lm LED Heads with 3.6V / 2W Battery for Remote Capability and Self-Diagnostics / Self-Testing, White finish
COLOR TEMPERATURE (K): WATTAGE (W): VOLTAGE (V): CRI:
DIMMING:
DELIVERED LUMENS: DIMENSIONS: D: 11.75" L: 11.75"
RATED LIFE (Y): CONSTRUCTION: FRAME: PLASTIC MOUNTING:
CERTIFICATIONS
- 20%
W: 11.75" H: 5/8" 50,000
LENS: POLYCARBONATE HARDWIRED
TECHNICAL DRAWING
DIMENSIONS
NO SPEC
L-810 LED Night Vision Compatible Steady-Burning Red Obstruction Light
Compliance and Applications
• ETL Certified L-810: FAA AC 150/5345-43J; EB-67D
• IP67 Certified
• Certified FCC 47 CFR, Part 15:2020, §15.107 and §15.109, Class A
Compliant to:
• ICAO Annex 14, Low Intensity Obstacle Light, Type B
• DGAC of Mexico
• MIL-C-7989
Our Night Vision Compatible, omni-directional, red, steady-burning, LED obstruction light is designed for marking tall structures such as buildings, towers, masts, cranes, meteorological towers, chimneys and other hazards to aircraft. This energy-saving LED light is a direct replacement for incandescent fixtures, providing years of reliable and maintenance-free operation. Available in single, double, and retrofit configurations; optional solar drive package.
What Does NVG Friendly Mean?
Both the FAA and Transport Canada have issued safety alerts warning that common LED obstruction lights pose a hazard to pilots using Night Vision Goggles (NVGs). This is due to the fact that NVGs typically use filters to block cockpit lighting from saturating the imaging system. This has the unintended effect of making LED obstruction lights invisible to pilots. In response, we have incorporated NVG Friendly technology into our fixture (IR 860 nm peak intensity), giving pilots using night vision goggles unmatched visibility of airfield perimeters, buildings, and towers. The L810LEDNV light is the first LED L-810 available to ensure that your structure is visible to all pilots, making it the first true LED replacement for incandescent obstruction lights.
Why Our L810LEDNV is Better
• Direct replacement for existing incandescent light
• Lasts up to 10 times longer than an incandescent light
• Uses 96% less power than an incandescent light
• Night Vision Goggle & NVIS Compatible
• No regular maintenance
• Available in single and dual configurations with bottom or side conduit outlets
• Can be operated in steady-burning or flashing mode (controller not supplied)
Marine Treated Option:
• Recommended for harsh, high-salt coastal and marine environments.
• Protects fixture finish from salt damage and prevents corrosion.
• 3-Step Powder Coat: 1) Primer, 2) Epoxy powder base coat and glossy polyester gray (RAL 7030) powder finish coat, 3) Oven curing.
• Photocell option for automatic activation at night
• Wind Loading: Effective Projected Area of the L-810 with single mounting base is 23.125 square-inches
Night Vision Compatible Obstruction Light
Optional Low Surface Mount
Single L-810 LED Night Vision Compatible Obstruction Light
Shown with Riser, Frangible Coupling and Floor Flange
Optional 2" Pole Mount
BLANK
Spare Parts
FL-810LEDNV-AC 100-277 VAC LED NV
Replacement Light Head
FL-810LEDNV-DC 12-48 VDC LED NV
Replacement Light Head
Alarm Line Option:
For AC and DC model fixtures, the blue wire (18AWG) is defined as the Alarm Line. When the red LED fails, the fixture’s input voltage for the fixture will be present at this wire. For AC and DC model fixtures, during normal operation (LED ON), it will have 0 VAC and 0 VDC respectively at the blue wire; in case of LED failure (turning off), it will energize the blue wire to the fixture’s input voltage, 100-277 VAC for AC models and 12-48 VDC for DC model fixtures.
L-810 LED Ordering Codes
Shipping Information:
Single: 3.2 lb. (1.45 kg); 10" x 10" x 10" Carton
Double: 7 lb. (3.17 kg); 15" x 15" x 10" Carton
2" Pole Mount3
1 1-1/2" Frangible Coupling (FL-FC1.5) UNF threads are not compatible with NPT threaded junction boxes. 2 For single option only. 3 2-3/8" O.D. tenon adjustable for 2.25"-2.75" poles. 4 CAUTION! For AC model fixtures, the Alarm Line (blue wire) will be energized to a high AC voltage (fixture’s input voltage 120-277VAC) during a failure of the LED.
Obstruction Lighting Controls
Lighting controls are designed for use when multiple obstruction light fixtures are to be controlled with common electronics. The electronic control module comes in a cast iron device box with threaded hubs on both top and bottom. Replacement modules (controls without device box) are also available upon request.
Photocells
• Model 81020: 105-305VAC, 1000W photocell. FAA style photocells activate at 35 ft-cd and turn off at 52 ft-cd. Instant ON photocell has 3-5 second time delay that prevents activation and de-activation from momentary light conditions. Does not come with device box, includes 1/2" threaded male fitting.
• Model 81021: 120/240VAC, 4800W photocell. Meets FAA/FCC requirements for obstruction lighting. Energized at 35 ft-cd and de-energized at 60 ft-cd. Time delay eliminates contact chatter. Contains dual 20A load contacts. Front plastic housing mounts to cast aluminum junction box (included).
• Model 81022: Hazardous Location Photocontrol Unit. Outdoor lighting control for exterior lighting in hazardous locations: explosion proof, dust-ignition proof, and weatherproof. Nominal Voltage 50/60 Hz: 120/208/240/277VAC. Voltage Range: 105-305. Housing: sand cast copper-free aluminum - epoxy powder coated.
Photocell Ordering Codes
Part
FL-81020
FL-81021
FL-81021-2
FL-81022
Photocell only (105-305VAC, 1000W max)
Photocell with aluminum box (120VAC, 4800W max)
Photocell with aluminum box (240VAC, 4800W max)
Hazardous Location Photocontrol Unit (120/208/240/277VAC)
Model 81020
Model 81021
Model 81022
Red
Black
Green
Black
White GRD: Green
100-277 VAC
Alarm Line: Blue
Alarm Line: Blue
Wire Color Guide
NO SPEC
BLANK
PHOTOMETRIC
DESCRIPTION
LEDSWP75/3WO/3CCT/B/D
LEDSWP75/3WO/3CCT/B/D+EM
LEDSWP120/3WO/3CCT/B/D
LEDSWP120/3WO/3CCT/B/D+EM
DIMENSIONS
SOFT WHITE
COOL WHTIE
BRIGHT WHITE
SOFT WHITE
COOL WHTIE
BRIGHT WHITE SOFT WHITE
COOL WHTIE
BRIGHT WHITE
SOFT WHITE
COOL WHTIE
BRIGHT WHITE
NO SPEC
BLANK
PHOTOMETRIC
DESCRIPTION
LEDSWP75/3WO/3CCT/B/D
LEDSWP75/3WO/3CCT/B/D+EM
LEDSWP120/3WO/3CCT/B/D
LEDSWP120/3WO/3CCT/B/D+EM
DIMENSIONS
SOFT WHITE
COOL WHTIE
BRIGHT WHITE
SOFT WHITE
COOL WHTIE
BRIGHT WHITE SOFT WHITE
COOL WHTIE
BRIGHT WHITE
SOFT WHITE
COOL WHTIE
BRIGHT WHITE
NO SPEC
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLEFINISHES:
Flue
WS-W36406
PRODUCTDESCRIPTION
Fundamental geometry. An opaque triangular shade shelters LED light sources, providing diffused downward illumination while protecting the nighttime sky. FEATURES
• ACLED driverless technology
• Downward illlumination
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• 0-10V dimming option available (special order), unit dimensions: 3.4" x 1.2" x 0.5" (model#LDS065M010AFE-LO1)
• IDA Dark Sky compliant in color temperatures of 3000K or lower
Central Distribution Center: 1600 Distribution Ct, Lithia Springs, GA 30122 Western Distribution Center: 1750 Archibald Avenue, Ontario, CA 91760
NO SPEC
Project:
Location:
Fixture Type:
Catalog Number:
AVAILABLEFINISHES:
Flue
WS-W36406
PRODUCTDESCRIPTION
Fundamental geometry. An opaque triangular shade shelters LED light sources, providing diffused downward illumination while protecting the nighttime sky. FEATURES
• ACLED driverless technology
• Downward illlumination
• Built in color temperature adjustability. Switch from 2700K/3000K/3500K/4000K
• Option to pre-select color temperature or adjust in the field
• 0-10V dimming option available (special order), unit dimensions: 3.4" x 1.2" x 0.5" (model#LDS065M010AFE-LO1)
• IDA Dark Sky compliant in color temperatures of 3000K or lower
Central Distribution Center: 1600 Distribution Ct, Lithia Springs, GA 30122 Western Distribution Center: 1750 Archibald Avenue, Ontario, CA 91760
NO SPEC
Surface Adjustable LED Edge-Lit Exit Sign
Source: 5W LED
PRODUCT DESCRIPTION
Architectural acrylic edge-lit sign for applications requiring low-profile, yet decorative appearance. Uses included, but are not limited to museums, galleries, office building lobbies, etc. Incorporates 25+ year LED source. AC, 2-Circuit, and Battery Backup configurations are available with letters in either green or red color.
BODY
Extruded aluminum housing and acrylic panel.
FACE
Edge-lit Exit is available in either single or double face. Face is constructed with 0.40 clear acrylic with rounded and finished edge for attractive appearance. Face contains red or green 6” high and 3/4” thick lettering inside face to comply with NFPA requirements. Reflective stick-on chevrons provided and are applied to rear of panel in order for light to reflect off the inner face of the chevron tape to provide a similiar effect as the lettering embedded inside the acrylic. Face can be adjusted in the field from 0º to 90º for wall, ceiling or sloped applications.
MOUNTING
Mounting hardware consist of 0.06 steel universal junction box bracket, 7/8” profile 0.11 die-cast aluminum bracket cover, screws, wire nuts, and silver-finished plastic plugs that are used to eliminate remaining knocouts once mounting configuration is selected.
ELECTRICAL
Voltage: Dual 120V/277V (0.038A / 0.017A)
LED Wattage: 3 Watts normal / 5 Watts emergency operation
Emergency Circuit (NX-811-LED): 2nd circuit for input from external EPS or other alternative emergency power source or generator
Battery (NX-812-LED): Replaceable Ni-Cad battery provides 90 minutes of illumination during emergency operation
Testing: High charge / ready operation indicator light with test button and automatic reset
Circuit Protection: Isolated surge / short circuit protection (Disconnect for deep discharge)
Life Expectancy: 25 Years with no change in illumination level
LABELS AND LISTINGS
UL List ed
NEC
NFPA
State & Municipal
· 5-Year Limited Warranty
Certi fied to the energy efficiency standards of California Title 20
6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 | www.noralighting.com | e-mail: nora@noralighting.com
Type Project
Catalog No.
Notes
PRODUCT IMAGES AND DIMENSIONS
NO SPEC
NX-603D-LED
Thermoplastic Dual Color (Red/Green) LED Exit Sign with Battery Backup
PRODUCT DESCRIPTION
A compact exit sign with dual color LEDs, allows end user to change the color from Red to Green in the field. The exit sign includes a maintenance-free NiCad battery to power the fixture during power loss for 90 minutes on a full charge. LED light sources require no maintenance for 25 years–saving greatly on maintenance and upkeep costs. LED exits are ideal for commercial and industrial standard non-emergency applications where low maintenance and operating costs are a must.
BODY
• 11-13/16 " Width X 7-1/4" Height X 1-13/16" Depth
• Injection-molded thermoplastic housing
• Black or Whi te housing finish
FACE
• 6" high text w ith color diffusion
• Both doubl e and a blank face are included
• Snap-in dir ection indicators
MOUNTING
• Wall, side , or ceiling
• Mounting hardware and canopy included
ELECTRICAL
Voltage: 120/277VAC Input
Wattage: 3W
Light Source: LED
Operating Temperature: 10°C - 40°C
Remote Capability: None
BATTERY
During loss of power, 3.6V 300mAh NiCad battery will operate LED exit sign for 90 minutes. Battery requires 24 hours to recharge when power is restored.
ACCESSORIES
NEG-60 : Wet Location Enclosure for wall mounting only
LABELS AND LISTINGS
· UL 924
· Rated for Damp Locations (Wet Location when used with NEG-60)
5-Year Limited Warranty
NFPA
Certified t o the energy efficiency standards of California Title 20
LED exit sign with battery backup for illumination during power loss. Luminaire is powered by LED sources for maximum life without maintenance. Ideal for egress lighting where splashing, non-corrosive liquids, and dripping may occur.
FEATURES
Universal Mounting - Wall, Ceiling, or Side Mounting
UL List ed and meets or exceeds UL 924, NFPA 70 and NFPA 101 Life Safety Code requirements
· Self- Diagnostic Testing
Polyc arbonate plastic enclosure with flame retardant and wet location rated
Push-To-Test Switch
High temperature maintenance free NiCad battery 120/2 77VAC input
6" Lett ers and 3/4" stroke
Cold we ather option includes heating pad to maintain operating temperature
ELECTRICAL
Voltage: 120/277VAC 60Hz input
Wattage: 2.2W
Battery: 3.6V Replaceable 400mAh NiCad battery
Recharge Time: 24 hours
Operating Temperature:
Standard: 0°C to 50°C
Cold Weather Option: -25°C to 50°C
FACE
Impact resistant polycarbonate white face plate with flame retardant and internal gasket for wet location rating. Optional dual face plate included. Fully illuminated 6" letters with 3/4" stroke and field selectable directional chevrons included.
EMERGENCY
During loss of power, NiCad battery will operate LED exit sign for 90 minutes. Battery requires 24 hours to recharge when power is restored.
MOUNTING
Mounting hardware included for ceiling, wall, or side mount applications. Listed for installations indoor, outdoor or wet locations.
BROWNOUT CIRCUIT
Brownout circuit monitors the flow of AC current to the unit and triggers the exit light once a set reduction of AC power occurs. This dip in the voltage will cause many fixtures to extinguish causing loss of normal lighting even though a total power failure has not occurred.
SHORT CIRCUIT PROTECTION
Overload monitoring system is a solid-state circuit which monitors the load and disconnects from the battery should an overload or short circuit occur. The overload current protection eliminates the need for fuses or circuit breakers for the DC load.
TESTING
Luminaire includes manual test button for manual verification the transfer circuit and battery operate correctly. Luminaire also performs self-tests and diagnostics on battery, charging board, transfer circuit, and exit sign.
If a failure is detected, an indicator LED will blink red until fault is corrected. A solid green indicator LED indicates no faults and blinked green indicates a test is in progress.
COLD WEATHER OPTION
Exit sign can be used in cold weather locations with heating pad accessory, must specify -CC suffix. When exit sign reaches a low temperature a heating pad will keep the battery within operating temperature, allowing the exit sign to work in temperatures down to -25°C.
LABELS AND LISTINGS UL 924 Listed for Wet Locations NFPA 70 & NFPA 101 Life Safety Code
LED exit sign with battery backup for illumination during power loss. Luminaire is powered by LED sources for maximum life without maintenance. Ideal for egress lighting where splashing, non-corrosive liquids, and dripping may occur.
FEATURES
Univer sal Mounting - Wall, Ceiling, or Side Mounting
UL Liste d and meets or exceeds UL 924, NFPA 70 and NFPA 101 Life Safety Code requirements
· Self-Diagnostic Testing
Polycarbonate plastic enclosure with flame retardant and wet location rated
Push-To-Test Switch
High temperature maintenance free NiCad battery 120/27 7VAC input
6" Letters and 3/4" stroke
Cold wea ther option includes heating pad to maintain operating temperature
ELECTRICAL
Voltage: 120/277VAC 60Hz input
Wattage: 2.2W
Battery: 3.6V Replaceable 400mAh NiCad battery
Recharge Time: 24 hours
Operating Temperature:
Standard: 0°C to 50°C
Cold Weather Option: -25°C to 50°C
FACE
Impact resistant polycarbonate white face plate with flame retardant and internal gasket for wet location rating. Optional dual face plate included. Fully illuminated 6" letters with 3/4" stroke and field selectable directional chevrons included.
EMERGENCY
During loss of power, NiCad battery will operate LED exit sign for 90 minutes. Battery requires 24 hours to recharge when power is restored.
MOUNTING
Mounting hardware included for ceiling, wall, or side mount applications. Listed for installations indoor, outdoor or wet locations.
BROWNOUT CIRCUIT
Brownout circuit monitors the flow of AC current to the unit and triggers the exit light once a set reduction of AC power occurs. This dip in the voltage will cause many fixtures to extinguish causing loss of normal lighting even though a total power failure has not occurred.
SHORT CIRCUIT PROTECTION
Overload monitoring system is a solid-state circuit which monitors the load and disconnects from the battery should an overload or short circuit occur. The overload current protection eliminates the need for fuses or circuit breakers for the DC load.
TESTING
Luminaire includes manual test button for manual verification the transfer circuit and battery operate correctly. Luminaire also performs self-tests and diagnostics on battery, charging board, transfer circuit, and exit sign.
If a failure is detected, an indicator LED will blink red until fault is corrected. A solid green indicator LED indicates no faults and blinked green indicates a test is in progress.
COLD WEATHER OPTION
Exit sign can be used in cold weather locations with heating pad accessory, must specify -CC suffix. When exit sign reaches a low temperature a heating pad will keep the battery within operating temperature, allowing the exit sign to work in temperatures down to -25°C.
LABELS AND LISTINGS
UL 924 Lis ted for Wet Locations NFPA 70 & NF PA 101 Life Safety Code California Energy Commission (CEC) Compliant ·
A 24VDC high transmission, flexible linear ‘neon’ tape that is field cuttable and joinable. Designed for applications that require ultra-rich light and color saturation that is characteristic of neon. TopFlex enables vertical bending that conforms tape around curvilinear surfaces.
FEATURES
•24VDC operation
•Wet location - IP65
•Multiple power feed options
•Tape encased in UV stable silicone (UV protected)
•Dimmable
•Wireless control with LUXcontrol App and controller
•3000K or 4000K / Amber, Blue, Green or Red
•120° viewing angle
•Maximum run: 32’-8”
•Field cuttable and joinable in 2 inch increments while retaining IP65
•Each run requires an end cap (sold separately)
•No tools required for capping and joining
•Mounting clips included (recommend use 1 per foot)
SPECIFICATIONS
ELECTRICAL
•24VDC
•3.0 watts per foot
•90+ CRI
WARRANTY
•5-year warranty when paired with GM power supply OPTICS
ACCESSORIES
•LineDRIVE 24V Power Supplies
•Aluminum Channels (below)
•Connectors (below)
•Tape Cutting Tool (below)
CONTROLLERS
NO SPEC
120V Horizontal / Vertical / Louver
SPECIFICATION SHEET
PRODUCT OVERVIEW
GM Lighting’s new take on step lighting has resulted in this extensive collection of modern step lights that fits standard junction boxes. Available in horizontal and vertical formats, open lensed, vertical and horizontal louvers, and in horizontal scoop formats. Perfect for step lighting, path lighting, deck lighting in stairs, posts or railings.
FEATURES
•Suitable for wet location
•No visible mounting hardware
•Mounts to standard J-box (by others)
•Optimized for indoor use
SPECIFICATIONS
ELECTRICAL
•2W
•120V
•Rated life: 50,000 hrs.
OPTICS
•80+ CRI
•3000K
CERTIFICATIONS
•ETL listed
WARRANTY
•5 years
Available in louvered lens (above), scoop lens (right) and starndard trim (far right) in either horizontal or vertical formats.
Note: Not suitable for salt water or chlorine pool environments.
NO SPEC
301 MADEIRA
NIO-4RNDC
4" Iolite Round Reflector with Round Aperture
Source: 14W to 28W LED 800lm to 2500lm
PRODUCT DESCRIPTION
4" Iolite LED downlights require a dedicated Iolite new construction or remodel housing. Deep regressed cone reflectors optimize visual cut-off.
FEATURES
800lm, 1000lm, 1500lm, 2000lm or 2500lm LED packages
2700K, 3000K, 3500K, 4000K, 5000K @ 90+ CRI
Comfort Dim (warm dimming) also available in 800lm only
Flood optic, narrow flood and spot optics (included)
5-Year limited warranty
SPECIFICATION
Construction: Trims are constructed of heat dissipating, die-cast aluminum. The aluminum die-cast LED heat sink is threaded to fit the trim and transfer heat.
Mounting: Luminaire includes friction blades to mount securely to housing.
OPTICS
800-1000lm: Three field changeable optics (spot, narrow flood and flood) are included with each LED module. Premium 10° TIR narrow spot optic assembly also available (Click Here for more information). Optional frosted and TIR optics are also available.
1500-2500lm: Three field changeable TIR optics (spot, narrow flood and flood) are included with each LED module.
Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
Color Rendering Index: 90+CRI
Operating Temperature: Specified by housing
Lifetime: 50,000 hours @ L70
Comfort Dim: Comfort Dim color tunes the temperature from a bright 3100K, to a romantic and comfortable 2000K on a gradual, even curve. Available in 800lm only
Dimming: Specified by housing
COMPATIBLE HOUSINGS
Luminaires are compatible with respective Iolite housings manufactured by Nora Lighting.
CATALOG NO. DESCRIPTION LUMENS / WATTAGE
NHIOICD-48 ICAT New Construction 800-1000lm / 14W
NHIOICDCP-48 Chicago Plenum 800-1000lm / 14W
NHRIOIC-48 ICAT Remodel 800-1000lm / 14W
NHIOICD-415 ICAT New Construction 1500lm / 20W
NHIOICDCP-415 Chicago Plenum 1500lm / 20W
NHIOICD-420 ICAT New Construction 2000lm / 24W
NHIOICDCP-420 Chicago Plenum 2000lm / 24W
NHIOICD-425 ICAT New Construction 2500lm / 28W
NHIOICDCP-425 Chicago Plenum 2500lm / 28W
Accessories: Luminaires can accommodate (1) hex louver and (1) translucent deco collar or opaque snoot, no accessory holder is required, see accessories page. Flush mount mud ring is available to give the appearance of a trimless, compatible with new construction housing only.
LABELS AND LISTINGS
cULus Listed for Wet Locations ENERGY STAR certified 5-Year Limited Warranty RoHS Compliant Certified to the high efficacy requirements of California Title 24 JA8-2022
6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 www.noralighting.com
e-mail: nora@noralighting.com
Compatible Housings
NHIOICD-48 = ICAT New Construction / 800-1000lm / 14W NHIOICDCP-48 = Chicago Plenum / 800-1000lm / 14W NHRIOIC-48 = ICAT Remodel / 800-1000lm
BLANK
NHIOICD-48 / NHIOICDCP-48
4" Iolite IC Air-Tight New Construction Housing
Source: 12W or 13W LED 800lm or 1000lm
PRODUCT DESCRIPTION
New construction housing for use in insulated ceilings can be in direct contact with insulation. Air-tight construction provides energy savings by reducing the flow of air through the ceiling. Patented design allows for easy, tool-less removal of the driver.
SPECIFICATION
Housing: 0.040 " Aluminum shallow housing can be installed in 1/2" ceiling thickness, an extension collar (NIO- 4 EXTC2) is available for ceiling thickness up to 2".
Patented Driver Assembly: Allows driver to slide out of housing without tools from the room side.
Air Flow Restriction: Meets requirments of Air-Tight (AT) <2CFM (cubic feet per minute) in accordance with ASTM283 Air-Tight requirements.
Clearance: “IC” Insulated ceiling housings are direct contact rated. Not to be used in direct contact with spray foam insulation.
Bar Hangers: Two 13- 3/4" to 24- 1/2 " adjustable bar hangers with captive nails are included on housing. Bar hangers are parallel to junction box, but can be repositioned 90° perpendicular to junction box if desired. “L”-shaped bar hanger foot to align to bottom of construction joist. A T-bar notch allows for easy installation in a suspended ceiling.
Junction Box: Pre-wired 25 cubic inch 0.064" thick galvanized steel, with seven 1/2 " knockouts, four Romex® pryouts, and snap on covers. All leads are #18AWG wire, the ground wire is connected to the bottom, and quick connectors are supplied on all leads. Maximum of 8 no. 12 AWG through branch circuit conductors suitable for at least 90°C permitted in junction box. Junction box is accessible from the room side through housing opening.
EMERGENCY
Pre-Wired: Housing can be specified with connections for emergency battery installation. Requires access above ceiling. Must specify battery with remote test switch separately (NEPK- 07LEDUNV ).
Note: Pre-Wired is not compatible with Chicago Plenum housings Integrated: Compact emergency driver is mounted directly to the junction box allowing below ceiling access. Compared to traditional emergency driver that are larger and remote mounted which requires access above ceiling. 90 minute illumination time with 6W output in emergency mode. Battery requires 24 hours to recharge and consumes 3W when charging. Remote test switch and 3' cable included.
ELECTRICAL LE3 LE4 LUPEQ
Input Voltage 120V 120-277V 120/277V
Input Power 13W 12W 13W
Power Factor ≥0.90
Dimming Triac / ELV Triac / ELV / 0-10V Lutron EcoSystem
4" Iolite LED downlights require a dedicated Iolite new construction or remodel housing. Deep regressed cone reflectors optimize visual cut-off.
FEATURES
800lm, 1000lm, 1500lm, 2000lm or 2500lm LED packages
2700K, 3000K, 3500K, 4000K, 5000K @ 90+ CRI
Comfort Dim (warm dimming) also available in 800lm only
Flood optic, narrow flood and spot optics (included)
5-Year limited warranty
SPECIFICATION
Construction: Trims are constructed of heat dissipating, die-cast aluminum. The aluminum die-cast LED heat sink is threaded to fit the trim and transfer heat.
Mounting: Luminaire includes friction blades to mount securely to housing.
OPTICS
800-1000lm: Three field changeable optics (spot, narrow flood and flood) are included with each LED module. Premium 10° TIR narrow spot optic assembly also available (Click Here for more information). Optional frosted and TIR optics are also available.
1500-2500lm: Three field changeable TIR optics (spot, narrow flood and flood) are included with each LED module.
Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
Color Rendering Index: 90+CRI
Operating Temperature: Specified by housing
Lifetime: 50,000 hours @ L70
Comfort Dim: Comfort Dim color tunes the temperature from a bright 3100K, to a romantic and comfortable 2000K on a gradual, even curve. Available in 800lm only
Dimming: Specified by housing
COMPATIBLE HOUSINGS
Luminaires are compatible with respective Iolite housings manufactured by Nora Lighting.
CATALOG NO. DESCRIPTION LUMENS / WATTAGE
NHIOICD-48 ICAT New Construction 800-1000lm / 14W
NHIOICDCP-48 Chicago Plenum 800-1000lm / 14W
NHRIOIC-48 ICAT Remodel 800-1000lm / 14W
NHIOICD-415 ICAT New Construction 1500lm / 20W
NHIOICDCP-415 Chicago Plenum 1500lm / 20W
NHIOICD-420 ICAT New Construction 2000lm / 24W
NHIOICDCP-420 Chicago Plenum 2000lm / 24W
NHIOICD-425 ICAT New Construction 2500lm / 28W
NHIOICDCP-425 Chicago Plenum 2500lm / 28W
Accessories: Luminaires can accommodate (1) hex louver and (1) translucent deco collar or opaque snoot, no accessory holder is required, see accessories page. Flush mount mud ring is available to give the appearance of a trimless, compatible with new construction housing only.
LABELS AND LISTINGS
cULus Listed for Wet Locations ENERGY STAR certified 5-Year Limited Warranty RoHS Compliant Certified to the high efficacy requirements of California Title 24 JA8-2022
6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 www.noralighting.com
e-mail: nora@noralighting.com
Compatible Housings
NHIOICD-48 = ICAT New Construction / 800-1000lm / 14W NHIOICDCP-48 = Chicago Plenum / 800-1000lm / 14W NHRIOIC-48 = ICAT Remodel / 800-1000lm
BLANK
NHIOICD-48 / NHIOICDCP-48
4" Iolite IC Air-Tight New Construction Housing
Source: 12W or 13W LED 800lm or 1000lm
PRODUCT DESCRIPTION
New construction housing for use in insulated ceilings can be in direct contact with insulation. Air-tight construction provides energy savings by reducing the flow of air through the ceiling. Patented design allows for easy, tool-less removal of the driver.
SPECIFICATION
Housing: 0.040 " Aluminum shallow housing can be installed in 1/2" ceiling thickness, an extension collar (NIO- 4 EXTC2) is available for ceiling thickness up to 2".
Patented Driver Assembly: Allows driver to slide out of housing without tools from the room side.
Air Flow Restriction: Meets requirments of Air-Tight (AT) <2CFM (cubic feet per minute) in accordance with ASTM283 Air-Tight requirements.
Clearance: “IC” Insulated ceiling housings are direct contact rated. Not to be used in direct contact with spray foam insulation.
Bar Hangers: Two 13- 3/4" to 24- 1/2 " adjustable bar hangers with captive nails are included on housing. Bar hangers are parallel to junction box, but can be repositioned 90° perpendicular to junction box if desired. “L”-shaped bar hanger foot to align to bottom of construction joist. A T-bar notch allows for easy installation in a suspended ceiling.
Junction Box: Pre-wired 25 cubic inch 0.064" thick galvanized steel, with seven 1/2 " knockouts, four Romex® pryouts, and snap on covers. All leads are #18AWG wire, the ground wire is connected to the bottom, and quick connectors are supplied on all leads. Maximum of 8 no. 12 AWG through branch circuit conductors suitable for at least 90°C permitted in junction box. Junction box is accessible from the room side through housing opening.
EMERGENCY
Pre-Wired: Housing can be specified with connections for emergency battery installation. Requires access above ceiling. Must specify battery with remote test switch separately (NEPK- 07LEDUNV ).
Note: Pre-Wired is not compatible with Chicago Plenum housings Integrated: Compact emergency driver is mounted directly to the junction box allowing below ceiling access. Compared to traditional emergency driver that are larger and remote mounted which requires access above ceiling. 90 minute illumination time with 6W output in emergency mode. Battery requires 24 hours to recharge and consumes 3W when charging. Remote test switch and 3' cable included.
ELECTRICAL LE3 LE4 LUPEQ
Input Voltage 120V 120-277V 120/277V
Input Power 13W 12W 13W
Power Factor ≥0.90
Dimming Triac / ELV Triac / ELV / 0-10V Lutron EcoSystem
GM’s Professional Series Flexible LED Tape combines style and technology with reliability. Designed for professional installations that demand a high level of quality, the LTR-P Series includes a wide array of key features and is available in 16’-4” (5M) and 100’ (30M) reels.
FEATURES
• 24VDC models
• 2400K, 2700K, 3000K, 3500K, 4000K and 5000K color temps
• Remote control with GM’s LUXcontrol™ App and controllers
• Dry location
• 120 LEDs per meter
• Cuttable every 2”
• Custom lengths available - consult factory
• Premium diodes
• 120° viewing angle
• Dimmable
• 3M adhesive back
• Maximum run on a given lead is 20’
• Includes Sure-Tite connectors
SPECIFICATIONS
•24V •4.5 watts per foot
•90+ CRI
•-4°F to 122°F
• For proper
BLANK
LTR-P Professional Series ®
4.5W, 24VDC LED Tape
Specification Sheet
Kelvin temperature (color) ±100K. 16’-4” and 100’ reel includes 48” lead affixed to tape. 16’-4” reel includes (3) ESTW-60 Sure-Tite connectors. 100’ reel includes (10) ESTW-60 Sure-Tite connectors
COMPATIBLE CONTROLLERS
SWD-40W-12VDC-DIM SwitchLD All-in-One Dimmer and Driver, 40W, 12VDC
SWD-60W-12VDC-DIM SwitchLD All-in-One Dimmer and Driver, 60W, 12VDC
SWD-60W-24VDC-DIM SwitchLD All-in-One Dimmer and Driver, 60W, 24VDC
SWD-100W-24VDC-DIM SwitchLD All-in-One Dimmer and Driver, 100W, 24VDC
HC-RF-UNV-5CH Universal 1-5 Channel RF Remote Control
CM-RF-UNV-5CH Universal 1-5 Channel Control Module
LineDrive Electronic Dimmable MINI Power Supply, 12VDC/24VDC
LTP Cord and Plug Power Supply, 12VDC/24VDC 25W,
PSD Electronic Dimmable Power Supply, 12VDC/24VDC 15W, 24W, 60W, 90W
NOTE: Please see our website for updated power supply specifications and information.
BLANK
LTR-P Professional Series ®
4.5W, 24VDC LED Tape
Specification Sheet
LED-CHL
LED-CHL-6
Extruded channel. Includes snap-on frosted lens with mounting clips and screws.
Extruded channel. Includes snap-on frosted lens with mounting clips and screws.
LED-CHL-AMC (2) Adjustable mounting brackets for LED-CHL N/A
LED-CHL-EC (2) End caps for LED-CHL - one solid, one with hole. N/A
LED-CHL-MC (2) Additional mounting clips for LED-CHL
45º MINI ANGLE MOUNT
LED-CHL-45-MINI
LED-CHL-45-MINI-B
Extruded angled (45°) silver channel. Includes snap-on white lens with (2) mounting clips and (2) screws. 4'
Extruded angled (45°) black channel. Includes snap-on white lens with (2) mounting clips and (2) screws. 4'
LED-CHL-45-MINI-EC (2) End caps for LED-CHL-45-MINI: light gray, one solid, one with hole N/A
LED-CHL-45-MINI-EC-B (2) End caps for LED-CHL-MINI-B: black, one solid, one with hole N/A
LED-CHL-45-MINI-MC (2) Mounting clips and (2) screws for LED-CHL-45-MINI N/A
LED-CHL-45-M-LENS-BK Lens in black for LED-CHL-45-MINI 4'
NO SPEC
301 MADEIRA
NIO-4RNDC
4" Iolite Round Reflector with Round Aperture
Source: 14W to 28W LED 800lm to 2500lm
PRODUCT DESCRIPTION
4" Iolite LED downlights require a dedicated Iolite new construction or remodel housing. Deep regressed cone reflectors optimize visual cut-off.
FEATURES
800lm, 1000lm, 1500lm, 2000lm or 2500lm LED packages
2700K, 3000K, 3500K, 4000K, 5000K @ 90+ CRI
Comfort Dim (warm dimming) also available in 800lm only
Flood optic, narrow flood and spot optics (included)
5-Year limited warranty
SPECIFICATION
Construction: Trims are constructed of heat dissipating, die-cast aluminum. The aluminum die-cast LED heat sink is threaded to fit the trim and transfer heat.
Mounting: Luminaire includes friction blades to mount securely to housing.
OPTICS
800-1000lm: Three field changeable optics (spot, narrow flood and flood) are included with each LED module. Premium 10° TIR narrow spot optic assembly also available (Click Here for more information). Optional frosted and TIR optics are also available.
1500-2500lm: Three field changeable TIR optics (spot, narrow flood and flood) are included with each LED module.
Color Temperature: 2700K, 3000K, 3500K, 4000K, 5000K
Color Rendering Index: 90+CRI
Operating Temperature: Specified by housing
Lifetime: 50,000 hours @ L70
Comfort Dim: Comfort Dim color tunes the temperature from a bright 3100K, to a romantic and comfortable 2000K on a gradual, even curve. Available in 800lm only
Dimming: Specified by housing
COMPATIBLE HOUSINGS
Luminaires are compatible with respective Iolite housings manufactured by Nora Lighting.
CATALOG NO. DESCRIPTION LUMENS / WATTAGE
NHIOICD-48 ICAT New Construction 800-1000lm / 14W
NHIOICDCP-48 Chicago Plenum 800-1000lm / 14W
NHRIOIC-48 ICAT Remodel 800-1000lm / 14W
NHIOICD-415 ICAT New Construction 1500lm / 20W
NHIOICDCP-415 Chicago Plenum 1500lm / 20W
NHIOICD-420 ICAT New Construction 2000lm / 24W
NHIOICDCP-420 Chicago Plenum 2000lm / 24W
NHIOICD-425 ICAT New Construction 2500lm / 28W
NHIOICDCP-425 Chicago Plenum 2500lm / 28W
Accessories: Luminaires can accommodate (1) hex louver and (1) translucent deco collar or opaque snoot, no accessory holder is required, see accessories page. Flush mount mud ring is available to give the appearance of a trimless, compatible with new construction housing only.
LABELS AND LISTINGS
cULus Listed for Wet Locations ENERGY STAR certified 5-Year Limited Warranty RoHS Compliant Certified to the high efficacy requirements of California Title 24 JA8-2022
6505 Gayhart Street, Commerce, CA 90040 TEL 323.767.2600 www.noralighting.com
e-mail: nora@noralighting.com
Compatible Housings
NHIOICD-48 = ICAT New Construction / 800-1000lm / 14W NHIOICDCP-48 = Chicago Plenum / 800-1000lm / 14W NHRIOIC-48 = ICAT Remodel / 800-1000lm
BLANK
301 MADEIRA
NHIOICD-48 / NHIOICDCP-48
4" Iolite IC Air-Tight New Construction Housing
Source: 12W or 13W LED 800lm or 1000lm
PRODUCT DESCRIPTION
New construction housing for use in insulated ceilings can be in direct contact with insulation. Air-tight construction provides energy savings by reducing the flow of air through the ceiling. Patented design allows for easy, tool-less removal of the driver.
SPECIFICATION
Housing: 0.040 " Aluminum shallow housing can be installed in 1/2" ceiling thickness, an extension collar (NIO- 4 EXTC2) is available for ceiling thickness up to 2".
Patented Driver Assembly: Allows driver to slide out of housing without tools from the room side.
Air Flow Restriction: Meets requirments of Air-Tight (AT) <2CFM (cubic feet per minute) in accordance with ASTM283 Air-Tight requirements.
Clearance: “IC” Insulated ceiling housings are direct contact rated. Not to be used in direct contact with spray foam insulation.
Bar Hangers: Two 13- 3/4" to 24- 1/2 " adjustable bar hangers with captive nails are included on housing. Bar hangers are parallel to junction box, but can be repositioned 90° perpendicular to junction box if desired. “L”-shaped bar hanger foot to align to bottom of construction joist. A T-bar notch allows for easy installation in a suspended ceiling.
Junction Box: Pre-wired 25 cubic inch 0.064" thick galvanized steel, with seven 1/2 " knockouts, four Romex® pryouts, and snap on covers. All leads are #18AWG wire, the ground wire is connected to the bottom, and quick connectors are supplied on all leads. Maximum of 8 no. 12 AWG through branch circuit conductors suitable for at least 90°C permitted in junction box. Junction box is accessible from the room side through housing opening.
EMERGENCY
Pre-Wired: Housing can be specified with connections for emergency battery installation. Requires access above ceiling. Must specify battery with remote test switch separately (NEPK- 07LEDUNV ).
Note: Pre-Wired is not compatible with Chicago Plenum housings Integrated: Compact emergency driver is mounted directly to the junction box allowing below ceiling access. Compared to traditional emergency driver that are larger and remote mounted which requires access above ceiling. 90 minute illumination time with 6W output in emergency mode. Battery requires 24 hours to recharge and consumes 3W when charging. Remote test switch and 3' cable included.
ELECTRICAL LE3 LE4 LUPEQ
Input Voltage 120V 120-277V 120/277V
Input Power 13W 12W 13W
Power Factor ≥0.90
Dimming Triac / ELV Triac / ELV / 0-10V Lutron EcoSystem
Timeless simplicity with versatile purpose is offered with this wall sconce that measures 28 inches in length. Vesta mounts horizontally or vertically from a matching aluminum square affixed in the middle of the rectangular beam of formed aluminum. The concealed LEDs illuminate the mounting plane creating pool of light on the wall. Vesta is available in three different finishes: black or white powder coating and brushed nickel.
CO7W7H is a personal approach to building the perfect fixture for your project. Sconce can be ordered as a stand alone fixture or you can add one of our decorative elements.
REVIT & IES FILES AVAILABLE
MODULE Field Replaceable C10W LED module.
RATED LIFETIME L70 100,000+ hours
SHADE Vandal resistant. IK10 UL Certified. Protected against 20 joules of impact.
CERTIFICATIONS UL Damp Listed, IK10 UL Certified, Title24 Optional JA8
WARRANTY 10 Years
WATTAGE 10W
CRI 90+
DIMMING Triac/ELV
WEIGHT 3 LBS
PROJECTION 4”, ADA Compliant
FIXTURE MODULEWATTS DELIVERED LUMENS: RESIN SHADEDELIVERED LUMENS: WHITE OPAL ACRYLIC
Note: For Gold Shimmer, Linear Cross, and Cayenne resin, multiply delivered lumens by .8
Light reserves the right to change specifications for product improvement without notification.
Cone 7”W x 7”H
CO7W9H is a personal approach to building the perfect fixture for your project. Sconce can be ordered as a stand alone fixture or you can add one of our decorative elements.
IES FILES AVAILABLE
AVAILABLE WITH OPTIONAL DECORATIVE ELEMENTS
See website for all options
MODULE Field Replaceable C10W LED module
RATED LIFETIME L70 100,000+ hours
SHADE IK10 UL Certified high impact resin
CERTIFICATIONS UL Damp Listed, RoHS, IK10 UL Certified, Title24 JA8 Certified, Energy Star
WARRANTY 10 Years
WATTAGE 10W
INPUT VOLTAGE UNV (120-277VAC)
CRI 90+
DIMMING Triac/ELV (120V only)
WEIGHT 3 LBS
PROJECTION 4”, ADA Compliant
Note: For Gold Shimmer, Linear Cross, and Cayenne resin, multiply
Assembly required, refer to installation guide
in Metal Powder Coat Finish:
Architectural Resin
Please Contact Sales Rep for Resin Samples
Last Updated November 2022
510 993 0898 Personalized Collection Modular LED Wall Sconces
SINGLE CANDELABRA, DE10A ENVIRO SATIN BRASS, ESB
MODERN ARMATURE, DE10A BLACK, BLK
WOOD U-CHANNEL SMALL, DE3A SUGAR PALM (HOR), SPH
Wood or Metal Powder Coat Finish:
Metal Powder Coat Finishes
DARK BRONZE, DB
WHITE, WHT BLACK, BLK
Custom RAL colors also available (CP)
ENVIRO SATIN NICKEL, ESN
ENVIRO OIL-RUBBED BRONZE, EOB GRAPHITE, GR
ENVIRO SATIN BRASS, ESB POLISHED NICKEL, PN
WALNUT, W SUGAR PALM (VERT), SPV
SUGAR PALM (HOR), SPH
BAMBOO, BA
Wood Finishes (U-Channel & Door Panel Decorative Elements Only)
AUTUMN, A BURANO (VERT), BV
LINEAR CROSS (VERT), LCV ISLAND BREEZE, IB
GOLD SHIMMER (VERT), GSV CAYENNE (VERT), CYV
CAYENNE (HOR), CYH
WHITE OPAL ACRYLIC, WO
BURANO (HOR), BH
LINEAR CROSS (HOR), LCH GOLD SHIMMER (HOR), GSH
RAIN (VERT), RV
RAIN (HOR), RH
FAUX ALABASTER, FA
IK10 UL Certified High Impact Resin Options
Decorative Element Options
Sconce can be ordered as a stand alone fixture or paired with a decorative element. For full selection of current available DEs please visit alvalight.com/design-your-light
Decorative Element Finish Options DE1A DE10A
4.25”W x 7.5”H x 4” deep (Only available in EOB, ESN, ESB, PN finishes) Modern Armature 5”W x 5”H Face Plate, 12”H Wood U-Channel, Small 6.5”W x 3”H x 1.75”D Ellipse Short
Metal Powder Coat Finishes
Wood Finishes (U-Channel & Door Panel Decorative Elements Only)
Lens Options
BLC Bottom Lens Cover (BLC) TLC Top Lens Cover (TLC) STLC Sealed Top Lens Cover (STLC)
DE3A, SPH
DE1A, ESB
DARK BRONZE, DB WHITE, WHT BLACK, BLK
Custom RAL Powdercoat Colors also available (CP), MOQ may
CANADA: 19054 28TH AVENUE - SURREY, BC V3Z 6M3 USA: 3035 E. LONE MOUNTAIN ROAD - LAS VEGAS, NV 89081 WWW.KUZCOLIGHTING.COM
DESCRIPTION
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
PENDANTS PROJECT
PD87748-BK Black
PD87748-BG BrushedGold
SPECIFICATIONDETAILS
PD87748-WH White
FixtureDimensions D47-1/4"xH1-1/2"
LightSource LEDwithDCDriver
Wattage 125W
TotalLumens 9390lm
DeliveredLumens BG-4350lm*;BK-4350lm*;WH-5850lm*; Voltage 120V
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
CANADA: 19054 28TH AVENUE - SURREY, BC V3Z 6M3
USA: 3035 E. LONE MOUNTAIN ROAD - LAS VEGAS, NV 89081
WWW.KUZCOLIGHTING.COM
2021 KUZCO LIGHTING. ALL RIGHTS RESERVED. COMMENT
CERCHIO PD87736
PENDANTS
PD87736-BG BrushedGold
PD87736-WH White
SPECIFICATIONDETAILS
FixtureDimensions
PD87736-BK Black
PROJECT
D35-3/8"xH1-1/2"
LightSource LEDwithDCDriver
Wattage 84W
TotalLumens 6200lm
DeliveredLumens BG-2750lm*;BK-2750lm*;WH-3720lm*; Voltage 120V
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
Canopy Option
301 MADEIRA
CERCHIO PD87724
PENDANTS PROJECT
PD87724-BG BrushedGold
PD87724-WH White
SPECIFICATIONDETAILS
FixtureDimensions
PD87724-BK Black
D23-5/8"xH1-1/2"
LightSource LEDwithDCDriver
Wattage 63W
TotalLumens 4700lm
DeliveredLumens BG-1920lm*;BK-1920lm*;WH-2585lm; Voltage 120V
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
USA: 3035 E. LONE MOUNTAIN ROAD - LAS VEGAS, NV 89081
CUSTOMIZED
DESCRIPTION
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
COMMENT
CERCHIO PD87736
PENDANTS
PD87736-BG BrushedGold
PD87736-WH White
SPECIFICATIONDETAILS
FixtureDimensions
PD87736-BK Black
PROJECT
D35-3/8"xH1-1/2"
LightSource LEDwithDCDriver
Wattage 84W
TotalLumens 6200lm
DeliveredLumens BG-2750lm*;BK-2750lm*;WH-3720lm*; Voltage 120V
USA: 3035 E. LONE MOUNTAIN ROAD - LAS VEGAS, NV 89081
DESCRIPTION
Extruded and rolled aluminum with rectangular profile. Flush silicone diffuser. Matte powder-coated finish. Up and down light.. Duo canopy mounting style
SKU: 2812.16-6Learn more at: https://sonnemanlight.com/thin-line-led-wall-bar
Description:
A system of minimally scaled LED uplight/downlight wall bars, indirect light wall bars , and pendants, Thin-Line is offered in a variety of lengths, finishes, and lighting configurations. One-sided configurations direct light in a single direction, and can be mounted in an uplight or downlight orientation. Two-sided configurations direct light both up and down.
Type #: Dimensions
Extends: 3.5"
Minimum Extension: 3.5"
Maximum Extension: 3.5"
Size: 6' Two-Sided
Canopy/Backplate/Base Width: 1
Canopy/Backplate/Base Height: 1
Electrical Specs
Bulb(s) Included?: Yes
Bulb 1 Type: Integral LED
Bulb Quantity: 2
Input Voltage: 120VAC
Wattage: 72
Initial Lumens: 4440
Delivered Lumens: 2700
Color Temperature: 3000K
CRI: 90
Power Supply Type: Driver
Power Supply Quantity: 2
Power Supply Location: Remote
Dimming Type: TRIAC/ELV
Bulb Max Wattage: 72
Installation
General Listings
Installation: Licensed electrician required
Installation Orientation: Any Orientation
Shipping
Carton 1 L x W x H: 75" X 7" X 4" Carton 1 Gross Weight: 7 LBS
Shade
Shade 1 Material: Aluminum w/Optical Acrylic
Available Finishes
Available Finishes: Bright Satin Aluminum (.16), Satin Black (.25), Satin White (.03)
Single lamp pendant with steel cylindrical shade embellished by stacked tubular slices. Primary color configurations include black, gray, brushed nickel or gold with a matching interior. Suspended by a black Teflon cable
Ø4-7/8”
CANADA: 19054 28TH AVENUE - SURREY, BC V3Z 6M3
USA: 3035 E. LONE MOUNTAIN ROAD - LAS VEGAS, NV 89081
4" AC Onyx Retrofit Series requires no driver and allow for a sleek design . Spun aluminum construction provides clean sharp edges and is suitable for use with most 4" recessed housings. Deep regressed optics and round aperture deliver even and glare-free illumination.
FEATURES
Up to 700 or 1 000 delivered lumens
2700K, 3 000K, 3500K, 4000K or 5000K @ 90+ CRI
Dimmab le AC LED
· Includes medium base socket adapter for easy retrofitting in 4" recessed housings
Quick connector is compatible with dedicated LED housings
5-year limited warranty Classi fied for wet locations
SPECIFICATION
Reflector: One piece, spun aluminum construction dissipates heat and extends life. Unitized Thermal Management, UTM, provides exceptional cool operation.
Mounting: Two steel, spring mounting blades allow for easy and secure mounting in most 4" housings.
Retrofit: Luminaires include a medium base screw-socket adapter (NRA-211SM) for retrofitting into medium base downlight housings. Intended to be used as a LED lamp replacement. GU24 socket adapter (NRA-212SM) is available
Shade: High Transmission Acrylic Create Excellent Light Distribution and Uniformity
LED: High Efficiency, High CRI, Binned and Mixed to Reach Uniform Light
Electrical
High Power Factor, Low THD
Lamp
LED Type: Built-in (Color Temperature Option – 3000K, 3500K, 4000K, 5000K)
MCT Type: Adjustable Multiple Color Temperature (3000K, 3500K, 4000K)
Fluorescent Type: T5 HO Lamp
Certification
UL/cUL, ETL/cETL Listed, Suitable for Damp Locations
Warranty
5 Years Warranty on Driver and LED Module
LED Type
LED Type, High Lumen
T5 HO Lamp Type
NO SPEC
301 MADEIRA TYPE DD ALT
4" AC Onyx LED Retrofit Reflector
Source: 10.5W or 15W Up to 700lm or 1000lm
PRODUCT DESCRIPTION
4" AC Onyx Retrofit Series requires no driver and allow for a sleek design . Spun aluminum construction provides clean sharp edges and is suitable for use with most 4" recessed housings. Deep regressed optics and round aperture deliver even and glare-free illumination.
FEATURES
Up to 700 or 1 000 delivered lumens
2700K, 3 000K, 3500K, 4000K or 5000K @ 90+ CRI
Dimmab le AC LED
· Includes medium base socket adapter for easy retrofitting in 4" recessed housings
Quick connector is compatible with dedicated LED housings
5-year limited warranty Classi fied for wet locations
SPECIFICATION
Reflector: One piece, spun aluminum construction dissipates heat and extends life. Unitized Thermal Management, UTM, provides exceptional cool operation.
Mounting: Two steel, spring mounting blades allow for easy and secure mounting in most 4" housings.
Retrofit: Luminaires include a medium base screw-socket adapter (NRA-211SM) for retrofitting into medium base downlight housings. Intended to be used as a LED lamp replacement. GU24 socket adapter (NRA-212SM) is available
NRA-211SM = Medium base screw-in socket (included w/ each)
NRA-212SM = Socket adapter for use with GU24 housings
NO SPEC
301 MADEIRA TYPE EE ALT
Source: 10.5W or 15W Up to 700lm or 1000lm
PRODUCT DESCRIPTION
4" AC Onyx Retrofit Series requires no driver and allow for a sleek design . Spun aluminum construction provides clean sharp edges and is suitable for use with most 4" recessed housings. Deep regressed optics and round aperture deliver even and glare-free illumination.
FEATURES
Up to 700 or 100 0 delivered lumens
2700K, 300 0K, 3500K, 4000K or 5000K @ 90+ CRI
Dimmable A C LED
· Includes m edium base socket adapter for easy retrofitting in 4" recessed housings
Quick conn ector is compatible with dedicated LED housings
5-year limited warranty
Classifie d for wet locations
SPECIFICATION
Reflector: One piece, spun aluminum construction dissipates heat and extends life. Unitized Thermal Management, UTM, provides exceptional cool operation.
Mounting: Two steel, spring mounting blades allow for easy and secure mounting in most 4" housings.
Retrofit: Luminaires include a medium base screw-socket adapter (NRA-211SM) for retrofitting into medium base downlight housings. Intended to be used as a LED lamp replacement. GU24 socket adapter (NRA-212SM) is available
COLOR TEMPERATURE (K): WATTAGE (W): VOLTAGE (V): CRI:
DIMMING:
DELIVERED LUMENS: DIMENSIONS: D: 8.75" L: 8.75"
RATED LIFE (Hrs): CONSTRUCTION: MOUNTING:
CERTIFICATIONS
FRAME: PLASTIC
- 20% 1300 W: 8.75" H: 5/8" 50,000
LENS: POLYCARBONATE HARDWIRED
TECHNICAL DRAWING
DIMENSIONS
225mm(8.86")
NO SPEC
3-4048
Wall Mount, Down Light, Outdoor, Wet Location
Features
Housing
Die-cast Aluminum with Powder Coated Finish
Finish Options: -05 Black, -30 Oil Rubbed Bronze Good for Wet Location Applications
Optical Down Light Only
Shade: Clear Glass
Electrical
120V – 277V, Built-in Photo Cell Option High Power Factor, Low THD
Lamp
Integrate LED Module: Color Temperature Option 3000K, 3500K, 4000K, 5000K
Certification
ETL/cETL Listed, Suitable for Wet Locations, CEC Listed
