2019 TUSA scuba diving catalog by Tabata Europe Corp.

3D Mask Strap

TRI-MIX Frame FEATURES

3 distinct layers combined to produce one superior frame structure. Polyurethane (PuRiMaX) material bumper protection and a cross-beam metal frame structure combined with the superior toughness of the polycarbonate frame bolted together to create a seriously tough mask.

Added to the hugely popular TUSA Freedom Mask series, the NEW Fit II technology adds strength and rigidness to the skirt for use in tough environments. Of course, it inherits the fit and unprecedented comfort from TUSA’s Freedom Technology.

UV 420 Lens Treatment

+ Anti-Reflective Lens

+ CrystalView Optical Glass

UV 420 Lens Treatment protects against harmful high-energy visible (HEV) light and its potential to damage the Retina. HEV light is not just present on sunny days, but overcast days as well. Therefore, it is extremely important to protect your eyes against UV and HEV light in all weather conditions when diving.

8.0 oz / 227 g

Non-Reflective Lens for M2001SQB/SQW

• UV Lens Treatment with A/R and CrystalView Glass

• Left and Right separate lenses

• Compatible Mask: M2001SQB/SQW

• Recommended for UW Photography Professionals and Diving Instructors

Freedom Technology with Fit II

Adds strength and rigidness to the skirt for use in tough environments.

TRI-MIX Frame

Three (3) distinct layers combined to produce one superior frame structure.

UV 420 Lens Treatment

Protects against harmful high-energy visible (HEV) light.

Angle Strap Adjustor with Side Hold

The Skirt Mounted Five (5) Angle Strap Adjustor ensures proper strap angle.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Anti-Reflective (A/R) Lens Treatment

Anti-reflective coating enhances overall vision.

Corrective Lens

Lenses in a variety of diopters to match your prescription.

CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

SQW-WWA

Corrective Lenses for M2001SQB/SQW

• UV 420 Lens Treatment with A/R and CrystalView Glass

• Left and Right dual-use lens

• Negative Diopters: -1.5 to -6.0

• Compatible Mask: M2001SQB/SQW

Each person has a unique facial structure and every diver experiences either some level of discomfort, or “pressure” and “squeeze” while wearing a typical mask underwater.

TUSA engineers wanted to solve these problems and spent several years analyzing mask fit, facial bone structure and mouth movement. The result is Freedom Technology, a set of revolutionary new mask features which deliver superior fit, comfort and increased performance.

Freedom Fit

Dimpled Skirt:

Key areas around the forehead and cheek bones have been designed with dimples which combine to increase the skirt’s softness, flexibility and skin surface contact. This also greatly reduces leakage and enhances comfort.

Stability Ridges:

As water pressure increases a mask will compress inwards toward the face often causing further leakage. Areas under the cheek bones have been reinforced with stability ridges to minimize this compression maintaining ideal skin surface contact.

Varied Silicone Thickness:

When in usage, a regulator or snorkel mouthpiece can distort areas of the nose pocket and mouth section causing leakage and discomfort.

Freedom Dry

Freedom Dry enhances comfort and fit by utilizing a revolutionary low friction skirt surface.

The skirt fitting line (shown in red) features a low friction surface that delivers a superior seal and increases the facial area contact patch while significantly reducing excess skin tension. The result is a soft and supple feeling mask with a dramatically improved seal.

Low Friction Skirt

Light and compact design, the best selling TUSA mask.

Internal Volume: 11.0 ci / 180 cc

Frame Dimension: 2.8 in x 6.2 in / 72 mm × 157 mm

Fitting Dimension: 4.4 in x 5.1 in / 113 mm × 130 mm

Weight: 6.5 oz / 184 g

Freedom Technology

Four (4) technologies to enhance fit and performance exclusive to TUSA.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Corrective Lens

Lenses in a variety of diopters to match your prescription.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Anti-Reflective (A/R) Lens Treatment

Anti-reflective coating enhances overall vision.

CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

UV Lens Treatment

Lens treatment to eliminate 100% of UVA and UVB rays from the sun.

Internal Volume: 11.3 ci / 185 cc

Frame Dimension: 3.1 in x 6.3 in / 79 mm × 159 mm

Fitting Dimension: 4.4 in x 5.1 in / 113 mm x 130 mm

Weight: 6.5 oz / 185 g

CRYSTALVIEW AR / UV Lens Features

Harmful UV Rays are blocked, and Visible Light trasmitted!

U.V. (ULTRAVIOLET) LENS TREATMENT

Increased exposure to UV light can damage the eyes especially in marine environments where reflectivity is high. TUSA’s UV Lens Treatment provides 100% protection from harmful UVA and UVB rays. Blocking the ultraviolet spectrum (10~400nm) provides greater eye protection without sacrificing light transmission or vision.

Freedom Technology

Four (4) technologies to enhance fit and performance exclusive to TUSA.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Anti-Reflective (A/R) Lens Treatment

Anti-reflective coating enhances overall vision.

CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

UV Lens Treatment

Lens treatment to eliminate 100% of UVA and UVB rays from the sun.

A.R. (ANTI-REFLECTIVE) LENS TREATMENT

Standard glass lenses can reflect up to 10% of available light reducing vision underwater. TUSA’s Anti-Reflective (A/R) Lens Treatment decreases internal and external reflected light. This reduction increases light transmission up to 95% resulting in significantly enhanced color, clarity, contrast and better overall vision underwater.

CRYSTALVIEW OPTICAL GLASS

TUSA’s CrystalView optical glass lenses provide superior clarity, color and transmission of light over standard glass lenses used by the competition. Up to 15% of available light can be lost with a standard glass lens due to impurities and reflectivity. TUSA’s CrystalView lenses with UV/AR treatment transmit up to 95% of available light to the diver for clear, crisp vision.

COMPARISON WITH OTHER PRODUCTS

TUSA’s CrystalView Optical Glass with AR / UV treatment lens demonstrates outstanding UV blocking effect. It boasts excellent ultraviolet block rate in a wide range of wavelengths compared with other lenses equipped with other typical UV-cut glasses. Also, it has better trasmission range in the visible light region where higher transmission is better.

CrystalView Glass

Ultra-wide panoramic view with Freedom technology.

Internal

ULTRA-WIDE THREE (3)-LENS MASK

Unlike conventional three-lens masks with blind spots, TUSA M3001 mask’s side domed windows reduce the blind spots, creating a wide-angle panoramic view.

Four (4) technologies to enhance fit and performance exclusive to TUSA.

3D Mask Strap

Freedom Technology CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

Panoramic View

TUSA’s unique 3D design contours to the shape of your head. Mask providing an extra wide field of view.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

QUICK-ADJUST BUCKLE SYSTEM

The Quick-Adjust Buckle System incorporates a newly-designed low-profile buckle. The result is a compact, lightweight, technologically advanced mask design that can be easily and quickly adjusted for a perfect fit.

Metal parts in ultraslim frame, ultra-wide and stylish one-window mask.

Freedom Technology

Four (4) technologies to enhance fit and performance exclusive to TUSA.

Internal Volume: 16.2 ci / 265 cc

Frame Dimension: 4.3 in x 6.8 in / 109 mm x 173 mm

Fitting Dimension: 5.1 in x 5.0 in / 130 mm x 127 mm

Weight: 9.5 oz / 270 g

FREEDOM BUCKLE

5 Step Variable Strap Adjuster Function

180-degree buckle movement for enhanced fit.

3D Mask Strap

Five (5) position adjustor ensures proper strap angle.

Panoramic View

TUSA’s unique 3D design contours to the shape of your head. Mask providing an extra wide field of view.

180 Buckle System Angle Strap Adjustor Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

The Five (5) Angle Strap Adjustor rotates a full 180 degrees and allows for microadjustments, which accommodates varying head sizes while reducing face pressure, maintaining optimum fit, and preventing unnecessary damage to the buckle.

Vertical Axis Rotation Function

By fixing the angle of the strap in five (5) stages on the left and right from the upper position to the lower position, it is possible to micro adjust varying pressure points of the mask seal.

METAL PARTS

The buckles move inwards and outwards, so the straps fit perfectly to people with large or small faces. The folding buckles make the mask compact for carrying.

PAT. P.

M1001

PAT.

Internal Volume: 13.4 ci / 220 cc

Frame Dimension: 3.7 in x 6.3 in / 95 mm x 161 mm

Fitting Dimension: 4.4 in x 5.1 in / 113 mm x 130 mm

Weight: 8.2 oz / 233 g

ROUND-EDGE SKIRT

The TUSA mask features a round mold, special cross-sectionally shaped skirt fitting line (the outer end part of the silicone skirt touching the face) and molded by rolling the edge to the outside. When the skirt portion of the mask touches the face, the conventional mask is fitted with thin edge lines (Fig. 1), whereas with the TUSA mask, round-edge skirt is fitted on the face (Fig. 2), resulting in a soft-fit suppressing pressure and reducing creasing left on the face. This “planar fit, instead of linear fit” silicone skirt maintains a great seal and unprecedented comfort.

Edge

Conventional Mask Skirt

TUSA RoundEdge Skirt

(Fig. 1) (Fig. 2) Fitting line

(Forehead)

3D MASK STRAP

(Forehead)

TUSA’s revolutinary 3D Mask Strap fits snugly fits againast the head’s curvature for superior comfor fit and unprecedented fit. TUSA 3D Mask Strap

Four (4) technologies to enhance fit and performance exclusive to TUSA.

Freedom Technology 3D Mask Strap

180-degree buckle movement for enhanced fit.

TUSA’s unique 3D design contours to the shape of your head.

180 Buckle System Angle Strap Adjustor

Five (5) position adjustor ensures proper strap angle.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Mask Strap FRAME SIZE COMPARISON

M1003QB

M1003

Low profile one-window mask with accessory dock option.

Internal

ACCESSORY DOCK

TUSA M1002 Tina mask includes a stylish accessory for you to decorate your mask. You can also replace and install any earphone jack compatible accessories for mobile phones. There are a variety of choices such as in-jack, string, non-metal chain, etc.

Freedom Technology

Four (4) technologies to enhance fit and performance exclusive to TUSA.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

CRYSTAL CUT

Placed on the bottom left of the mask frame, a set of uniquely designed crystals sparkles and shines the light like a rhinestone.

Tear-drop design four-window mask with increased peripheral view.

Freedom Technology

Four (4) technologies to enhance fit and performance exclusive to TUSA.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

Panoramic View

Mask providing an extra wide field of view.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Freedom Quad

Low profile one-window mask with increased peripheral view.

Internal Volume: 13.1 ci / 215 cc

Frame Dimension: 3.7 in x 7.0 in / 93.5 mm x 178 mm

Fitting Dimension: 4.5 in x 4.8 in / 114 mm x 121 mm

Weight: 8.5 oz / 240 g

One-window mask for small faces.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Anti-Reflective (A/R) Lens Treatment

Anti-reflective coating enhances overall vision.

CrystalView Optical Glass

Provides superior clarity, color and transmission of light.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

UV Lens Treatment

Lens treatment to eliminate 100% of UVA and UVB rays from the sun.

CRYSTALVIEW OPTICAL GLASS

Normal Glass

CrystalView Glass

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Internal Volume: 12.5 ci / 205 cc

Frame Dimension: 3.2 in x 6.0 in / 82 mm x 152 mm

Fitting Dimension: 3.9 in x 4.6 in / 100 mm x 116 mm

Weight: 7.0 oz x 199 g

Kleio II

Corrective Lens

Lenses in a variety of diopters to match your prescription.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Corrective Lens

Lenses in a variety of diopters to match your prescription.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

See Page 6 for the

SKIRT MOUNTED QUICK-ADJUST BUCKLE SYSTEM

The skirt mounted quick adjust buckle system incorporates a low-profile buckle into the crystal silicone skirt of the mask. The result is a compact, lightweight, technologically advanced mask design that allows for automatic depth-compensation, and can be easily and quickly adjusted for a perfect fit.

3D Mask Strap

TUSA’s unique 3D design contours to the shape of your head.

Quick-Adjust Buckle System

Low profile buckle system allowing for quick and easy adjustments.

Imprex 3D

HYPERDRY SYSTEM (ONE-WAY PURGE VALVE)

Clearing a mask has never been easier thanks to our patented Hyperdry system featured on the IMPREX 3D Hyperdry. With the Hyperdry system you simply breathe out through your nose and any water that has accumulated in your mask is forced out through a one-way valve. Once the mask is clear, the valve seals shut.

Hyperdry Purge

A purge valve in the nose pocket allows user to clear mask with ease.

Panoramic View

Mask providing an extra wide field of view.

Round Edge Skirt

Round edge skirt improves both seal and comfort of the mask.

Panthes

A hydrophilic film that makes it easy to remove dirt, oil, or other substances that can cause mask lens fogging.

The TA-200A and TA0801 anti-fog films will keep your favorite mask fog-free while diving underwater. Made with long-lasting durable material, the Freedom Film can be installed easily, and is reusable with proper care. TA-200A is for any 2-window, and TA0801 is for any 1-window mask.

• Easy installation

• Prevents fogging

• Reusable

• Easy to clean

• Long-lasting durable material

For 1-Window Masks

TA-200A

For 2-Window Masks (2 pieces - Left and Right) (1 piece)

Clean the inside of lens thoroughly. Gently apply the film to the center of the lens.

Hold down the film, and repeatedly slide the fingertip outwards to remove any air bubbles.

Once the air bubbles have been pressed out, then you’re now ready to dive!

Clean the inside of each lens thoroughly. Gently apply the film to the center of the lens.

Hold down the film, and repeatedly slide the fingertip outwards to remove any air bubbles.

Once the air bubbles have been pressed out, then you’re now ready to dive!

Mask Strap Cover Super Anti-Fog Treatment

Durable strap cover to prevent twisting of the strap, and enhances comfort and fit.

Prevents the mask

clouding.

• Enhances comfort and fit

• Attaches over standard mask strap

• Made from durable neoprene

• Hook & loop fastener

Spread evenly on the inside of underwater mask or swimming goggle.

Rinse lightly with fresh water.

You will see the antifog effect.

• Non-irritating solution

• Long lasting

• High viscosity coat-on type

• Great for masks and goggles

TEC-52A

Hyperdry Elite Top keeps the water out, maintaining the superior dry performance.

Hyperdry Elite II

Internal Volume: 9.1 ci / 149 cc

Dimension: 17.9 in x 3.5 in / 454 mm x 89 mm

Weight: 5.7 oz x 161 g

• Durable silicone mouthpiece with comfort fit.

• Three-dimensional pipe curve designed to minimize water resistance.

• One-touch adapter that can be easily detached and attached to a mask.

• Flexible silicone joint reduces strain on the mouth.

HYPERDRY ELITE DRY TOP

Hyperdry Elite Dry Top Internal Structure

HIGH FLOW PURGE VALVE

The Hyperdry Elite maintains the same superior dry performance and keeps the snorkel completely void of water by quickly and efficiently closing the float when submerged or hit by waves. The periphery of the valve always remains at the lowest point even when snorkeling upright at the water surface, so water is easily cleared at all times. It prevents gurgling or sucking water when breathing.

Lifting the float will close the valve and prevent water from flooding.

Comfort Swivel

Snorkel keeper swivels to enhance comfort and fit.

High Flow Purge

Large diameter purge valve allows for easy snorkel clearing.

Hyperdry Elite Dry Top

TUSA’s exclusive dry-top for snorkels.

SP0101QB

SP0101QW SP0101QID

Superior design and functionality helps the snorkel clear water easily.

Comfort Swivel

Snorkel keeper swivels to enhance comfort and fit.

High Flow Purge

Large diameter purge valve allows for easy snorkel clearing.

Hyperdry System

Internal Volume: 9.2 ci / 150 cc Dimension: 16.7 in x 4.3 in / 425 mm x 110 mm Weight: 5.7 oz / 163 g

TUSA’s exclusive splash guard for snorkels.

• Durable silicone mouthpiece with comfort fit.

• Three-dimensional pipe curve designed to minimize water resistance.

• One-touch adapter that can be easily detached and attached to a mask.

• Flexible silicone joint reduces strain on the mouth.

HYPERDRY SYSTEM

The Hyperdry System keeps the main pipe dry by ejecting water through an independent escape pipe. This unique design utilizes the angle of the snorkel pipe and the resilience of the water surface to eject water.

COMFORT SWIVEL

The Comfort Swivel adapter makes it possible to slip the mask strap into the slit with no hassles. The twopart construction allows the snorkel to rotate and can be attached in a horizontal position.

1. This mechanism allows the snorkel to swivel to the optimum angle to reduce tension and stress for enhanced comfort and performance (Fig. 2) as compared to earlier models (Fig. 3).

2. Adjustments are made by sliding the adaptor’s position forward or backward - a forward or rearward position may be selected (Fig. 4).

SP-170QID

Imprex II Hyperdry

Internal Volume: 8.4 ci / 138 cc

Dimension: 16.9 in x 4.8 in / 430 mm x 122 mm

Weight: 5.5 oz / 156 g

High Flow Purge

Large diameter purge valve allows for easy snorkel clearing.

Hyperdry System

TUSA’s exclusive splash guard for snorkels.

SP-121QB

Internal Volume: 7.1 ci / 116 cc

Dimension: 15.1 in x 5.1 in / 385 mm x 129 mm

Weight: 3.7 oz / 105 g

• Low profile J-type snorkel

• Orange hologram top reflector for high visibility

• Cross cut bore design for easy clearing

• High grade silicone mouthpiece for ultimate comfort

Swivel

Flow Purge

SP-121QB

Award-winning fins with a stiffer blade for the advanced diver.

Angled Blade Design (A.B.D.)

Angled fin blade lengthens the stroke of the kick cycle.

Bungee Strap

Elastic bungee strap for quick donning and doffing of the fin.

Polyurethane materials increase fin response and performance.

Vortex Generator

TUSA’s exclusive technology providing a more efficient kick cycle.

SWITCH PRO BLADE

The TUSA Hyflex Switch PRO offers a 20% stiffer blade compound for the advanced diver. The PuRiMaX “Polyurethane Blade System” generates great forward propulsion and provides a quick “snappy” response to the diver’s every movement.

20% stiffer

Generating a more powerful kick.

A NEW ERA OF FINS

Separate the fin blade from the foot pocket for a compact and lightweight travel package.

It’s a brilliantly convenient way to travel with your essential dive gear in a carry-on sized suitcase. That’s the TUSA HyFlex fin system.

BUNGEE STRAP

TFY

Top quality Polyurethane material provides a quicker response to movement over competition.

Angled Blade Design (A.B.D.)

Angled fin blade lengthens the stroke of the kick cycle.

Bungee Strap

Elastic bungee strap for quick donning and doffing of the fin.

Polyurethane materials increase fin response and performance.

Vortex Generator

TUSA’s exclusive technology providing a more efficient kick cycle.

XS 21.9 x 8.0 in

TUSA HYFLEX SYSTEM

Separate the fin blade from the foot pocket for a compact and lightweight travelfriendly package.

“Carry-On” size

SF0104 (Separated)

Roller Bag 3mm allen-wrench (1) included.

Made with TUSA’s proprietary polyurethane material “PuRiMAX” provides a quicker reponse to movement over rubber and plastic fins. Highly durable polyurethane material can withstand tough conditions over time.

OFFSET BLADE DESIGN

Conventional 20-degree Angled Blade Design is further offset (parallel shifting) by placing a large vent hole between the blade and the foot pocket. This unique design can reduce the resistance that occurs near the toe surface area, and ultimately helps to kick easier.

TUSA SF0104

Offset Blade Position

Conventional Blade Position

Six (6) performance ridges positioned behind the blade vent reduce resistance, creating a smoother and more efficient kick cycle.

SF0104

Pivot blade system offers smooth and powerful kick.

Active Pivoting System

TUSA’s exclusive technology generates more forward propulsion.

Anatomic Fin Strap

TUSA’s fin strap design for improved comfort and stability.

Angled Blade Design (A.B.D.)

Angled fin blade lengthens the stroke of the kick cycle.

TUSA Direct Reflect

TUSA HYFLEX SYSTEM

Separate the fin blade from the foot pocket for a compact and lightweight travelfriendly package.

allen-wrench (1) included.

The combination of uniquely positioned holes that reduce drag while maintaining constant propulsion and the built-in fin stop creates a soft kick that produces great power.

Direct Reflect’s

Reflective material providing high visibility in low light conditions.

EZ Strap and Buckle System

Allows fins to be quickly and easily adjusted with minimal effort.

Superior propulsion from a multi-compound fin.

Size

XS 21.9 x 8.5

M 23.9 x 8.8 in 607 x 224 mm

Anatomic Fin Strap

TUSA’s fin strap design for improved comfort and stability.

Angled Blade Design (A.B.D.)

Angled fin blade lengthens the stroke of the kick cycle.

EZ Strap and Buckle System

Allows fins to be quickly and easily adjusted with minimal effort.

ForcElast

TPE compound delivers superior propulsion, efficiency and speed.

FORCELAST STRUCTURE

A proprietary Thermoplastic Elastomer (TPE) compound precisely positioned in an advanced blade and foot pocket structure. In addition to dual ribs that make full use of the rebound resilience of soft materials, hard materials are placed in flexible materials in an optimum balance. As a result, ForcElast delivers superior propulsion, efficiency and speed even with moderate power input.

BLADE LENGTH

With conventional diving fins, as the foot pocket size increases, the blade size also increases, resulting in insufficient kicking underwater. For SF - 22, however the blade size remains relatively compact even when the foot pocket size increases, resulting in comfortable and efficient kicking.

COLLABORATIVE RESEARCH WITH TOKYO INSTITUTE OF TECHNOLOGY

TUSA R&D team conducted collaborative research on propulsion evaluation with the Tokyo Institute of Technology during the fin development. Analysis of information on fins such as fin shape, flexural hardness (static load), rebound resilience (dynamic flexibility), in addition to diver’s physique (body shape) and joint movement (swimming direction) was studied. The SF - 22 Solla fin was the result of persistant scientific evaluation tests such as swimming speed, thrust, propulsion efficiency, and joint torque.

Solla

Angled Blade Design (A.B.D.)

Angled fin blade lengthens the stroke of the kick cycle.

Allows fins to be quickly and easily adjusted with minimal effort.

Anatomic Fin Strap

EZ Strap and Buckle System

TUSA’s fin strap design for improved comfort and stability. Allows fins to be quickly and easily adjusted with minimal effort.

Angled Blade Design Propeller Technology

EZ Strap and Buckle System EZ Strap and Buckle System

Angled fin blade lengthens the stroke of the kick cycle. Efficiency is increased while drag and effort is reduced.

TPE compound delivers superior propulsion, efficiency and speed.

Allows fins to be quickly and easily adjusted with minimal effort.

ForcElast

X-Pert Z-3 Zoom

Liberator X-Ten SF-5500

Replacement fin straps that require no length adjustment with smooth removeability.

Universal Bungee Strap

TA0902

Compatible with TUSA Open-Heel Fins

Universal Spring Strap

Compatible with TUSA Open-Heel Fins

TUSA Chico Sticker

• Adjustable bungee strap

• One size fits all with five (5) adjustable positions

• Comfort-flex hinge

• Will fit on most open heel fins available on the market

• Rubber heel cup with finger loop for easy fit

Lightweight and stylish. Flexible synthetic rubber strap. Steel spring type fin strap that is easy to remove and does not require length adjustment.

• Will fit on most open heel fins available on the market

• Fit automatically adjusts to changing conditions

• Durable stainless steel coil spring will not rust or break

• Rubber heel cup with finger loop for easy fit

Make your diving more fun with creative TUSA Chico stickers on your scuba tank.

• Vibrant full-color, full-bleed printing

• Easy peel-and-stick

• Waterproof and scratch-resistant

• Glossy vinyl finish

Cold Water Ready

Environmentally Sealed

DIN Available

RS-790 RS1001 RS-681

Adjustable Control Knob

Advanced Flow System

Teflon Coated Plate

Click Spring Adjustment

Ortho-Conscious Mouthpiece

Pneumatically Balanced

Sequence Exhaust Assist System

Swivel Hose

Venturi Flow System

Top performing pneumatic regulator.

1ST STAGE

DRY AMBIENT PRESSURE CHAMBER

The dry ambient pressure chamber on the R-700 prevents water contact with the diaphragm and spring maximizing performance, at any depth, in cold water conditions below 50° F / 10° C.

IDEAL FOR COLD WATER ENVIRONMENTS

The R-700 is engineered for cold water diving. It features a ribbed top cap section that acts like a radiator to increase the surface area for heat transfer. This design allows warming of the critical internal first stage parts that can freeze due to the gas pressure drops and low temperatures.

HIGH FLOW PORTS

Two (2) high flow low pressure ports are available on the R-700 in addition to two (2) standard LP ports and two (2) HP ports. The high flow ports are positioned near the diaphragm and offer up to a 15% increase in air flow.

2ND STAGE

Advanced Flow System

Grants smoother air delivery due to the curved housing structure.

Cold Water Ready

Cold water ready for water temperatures below 50°F / 10°C.

Environmentally Sealed 1st Stage

First stage is sealed against contaminants and freezing water.

Ortho-Conscious Mouth Piece

Reduces bite tension in the jaw.

Pneumatically Balanced 2nd Stage

Provides optimal breathing resistance at any depth.

Venturi Flow Adjustment

Air assist on inhalation improves breathing resistance.

DIN

PNEUMATICALLY BALANCED SYSTEM

The S-90 second stage is a pneumatically balanced design. A small chamber positioned at the end of the poppet assembly traps air and forces the poppet back against the intermediate pressure orifice. This provides decreased inhalation resistance and increases smooth breathing in all conditions.

VENTURI ADJUSTMENT LEVER

The S-90 is equipped with a built-in Venturi adjustment lever. Two (2) positions are selectable by the diver. Use Surface or the minimum setting when entering the water or on the surface, reducing the sensitivity and possible free flow of the second stage. Use the Dive or maximum setting for maximum air flow during the dive.

Ceramic Moisture Plate

The ceramic moisture plate prevents “dry mouth.”

Click Spring Adjustment

Adjustment knob to control breathing resistance.

Environmentally Sealed 1st Stage

First stage is sealed against contaminants and freezing water.

Ortho-Conscious Mouth Piece

Reduces bite tension in the jaw.

Sequence Exhaust Assist System

Dual exhaust system improves the breathing cycle.

Venturi Flow Adjustment

Air assist on inhalation improves breathing resistance.

Cold Water Ready

Cold water ready for water temperatures below 50°F / 10°C.

Ortho-Conscious Mouth Piece

Reduces bite tension in the jaw.

Venturi Flow Adjustment

Air assist on inhalation improves breathing resistance.

IDEAL FOR COLD WATER ENVIRONMENTS

The cold water ready feature enables the regulator to be used in waters below 50°F / 10°C tested to a temperature of 39°F / 4°C.

ORTHO-CONSCIOUSLY DESIGNED MOUTH PIECE

The new mouth piece, developed on the basis of ergonomic engineering, further enhances the comfort of bite, fit, and stability. Even with a light bite, a high level of stability is achieved, so there is no fatigue from long periods of usage.

Reusable mouth piece strap

High performance Octo

• Lightweight, compact composite case design

• Left or Right hand configuration

• Venturi adjustment lever

• Ortho-consciously designed mouthpiece

Alternate Power Inflator

• Downstream alternate air source

• Air balanced power inflator

• Large diameter purge button

• With special quick disconnect coupler

• Medium pressure hose length: 28 inch / 71 cm

• High density low profile silicone mouthpiece

3D Hybrid Cubic Air Cell

RiteTite Buckle

Ultimate

Waist Support System

Lift Capacity

Weight (Dry) and Waist (Est.)

A high-cut waist designed BC for women.

External Fabric: 500D CORDURA ®

Internal Fabric: 500D CORDURA ® Dump Valves: 3 (O.P.E.V. + 2)

D-Rings: 2 stainless, 4 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

Advanced Weight Loading System III (A.W.L.S. III)

Easy loading, single locking weight integrated BCD system.

Independent Harness System (I.H.S.)

Harness and air cell move independently for advanced control.

RiteTite Buckle

A 2-position cam strap for quick and easy adjustment.

Ultimate Stabilizing Harness (U.S.H.)

Completely eliminates tank roll.

Waist Support System (W.S.S.)

Enhanced comfort and fit due to advanced weight distribution.

TUSA Duo Air II (SS0002), integrated second stage regulator/power inflator is compatible.

HIGH-CUT WAIST DESIGN

A high-cut waist designed for women eliminates discomfort when wearing lead weight.

New Repositionable D-Rings and Snap Hooks offer the ability to customize your TUSA BC’s accessory attachment points.

COMFORT BACK AND SHOULDER PADDING

Ergonomically and comfort designed, quick drying shoulder and back pads with enhanced cushioning.

ADVANCED WEIGHT LOADING SYSTEM

(A.W.L.S. III)

A secure single locking integrated weight system that allows you to quickly and easily secure your weight pockets. The A.W.L.S. allows the diver to insert weights into the weight-cartridges and loading them easily into the front of the BC jacket.

TILT INFLATOR / O.P.E.V.

New slim design shoulder dump valve and inflator assembly.

External Fabric: 500D CORDURA ®

Internal Fabric: 500D CORDURA ®

Dump Valves: 3 (O.P.E.V. + 2)

D-Rings: 1 stainless, 5 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

Advanced Weight Loading System III (A.W.L.S. III)

Easy loading, single locking weight integrated BCD system.

Independent Harness System (I.H.S.)

Harness and air cell move independently for advanced control.

RiteTite Buckle

A 2-position cam strap for quick and easy adjustment.

Ultimate Stabilizing Harness (U.S.H.)

Completely eliminates tank roll.

Waist Support System (W.S.S.)

Enhanced comfort and fit due to advanced weight distribution.

TUSA Duo Air II (SS0002), integrated second stage regulator/power inflator is compatible.

New Repositionable D-Rings and Snap Hooks offer the ability to customize your TUSA BC’s accessory attachment points.

ADVANCED WEIGHT LOADING SYSTEM (A.W.L.S. III)

INDEPENDENT HARNESS SYSTEM

The Independent Harness System isolates the BC jacket’s harness from the air cell, tightly supporting the tank even with changes in air cell inflation/deflation. The I.H.S. prevents tank slippage and eliminates any gaps between the tank and your back.

ULTIMATE STABILIZING HARNESS

TUSA’s Ultimate Stabilizing Harness completely eliminates tank roll and delivers an amazing fit. The U.S.H. securely holds the air cylinder in place with optimally placed rails and brings the tank closer to the body increasing tank control while reducing weight.

RITETITE BUCKLE

The RiteTite Buckle is a 2-position cam strap for quick and easy adjustment. While the strap is being looped through the buckle, the buckle stays in place without needing to be held. This allows for more control and stability. This feature is part of all TUSA BC’s.

PAT.

External Fabric: 840D Nylon

Internal Fabric: 420D Nylon

Dump Valves: 4 (O.P.E.V. + 3)

D-Rings: 4 stainless, 1 resin

3D Hybrid Cubic Air Cell

Combining the feel of a rear inflate and full jacket style BCD.

Active Purge Assist (A.P.A.)

Pneumatically assisted power inflator.

Advanced Weight Loading System II (A.W.L.S. II)

Locking weight integrated BCD system with rotating release feature.

Independent Harness System (I.H.S.)

Harness and air cell move independently for advanced control.

RiteTite Buckle

A 2-position cam strap for quick and easy adjustment.

Ultimate Stabilizing Harness (U.S.H.)

Completely eliminates tank roll.

Waist Support System (W.S.S.)

Enhanced comfort and fit due to advanced weight distribution.

TUSA Duo Air II (SS0002), integrated second stage regulator/power inflator is compatible.

External Fabric: 500D CORDURA ® Nylon

Internal Fabric: 420D Nylon

Dump Valves: 3 (O.P.E.V. + 2)

D-Rings: 1 stainless, 4 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

Advanced Weight Loading System III (A.W.L.S. III)

Easy loading, single locking weight integrated BCD system.

RiteTite Buckle

A 2-position cam strap for quick and easy adjustment.

Ultimate Stabilizing Harness (U.S.H.)

Completely eliminates tank roll.

TUSA Duo Air II (SS0002), integrated second stage regulator/power inflator is compatible.

New Repositionable D-Rings and Snap Hooks offer the ability to customize your TUSA BC’s accessory attachment points.

Advanced Weight Loading System III

Advanced Weight Loading System II

AUS ONLY BC0201B with Tilt Inflator

Liberator

X-Wing

External Fabric: 500D CORDURA ® Nylon

Internal Fabric: 500D CORDURA ® Nylon

Dump Valves: 4 (O.P.E.V. + 3)

D-Rings: 2 stainless, 3 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

Active Purge Assist (A.P.A.)

Pneumatically assisted power inflator.

Advanced Weight Loading System II (A.W.L.S. II)

Locking weight integrated BCD system with rotating release feature.

Independent Harness System (I.H.S.)

Harness and air cell move independently for advanced control.

RiteTite Buckle

A 2-position cam strap for quick and easy adjustment.

Ultimate Stabilizing Harness (U.S.H.)

Completely eliminates tank roll.

TUSA Duo Air II (SS0002), integrated second stage regulator/power inflator is compatible.

External Fabric: 500D CORDURA ® Nylon

Internal Fabric: 420D Nylon

Dump Valves: 2 (O.P.E.V. + 1)

D-Rings: 1 stainless, 4 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

XS 80N / 18.0 lbf / 8.2 kgf

S 100N / 22.5 lbf / 10.2 kgf

M 140N / 31.5 lbf / 14.3 kgf

L 170N / 38.2 lbf / 17.3 kgf

Advanced Weight Loading System II (A.W.L.S. II)

Locking weight integrated BCD system with rotating release feature.

RiteTite Buckle

External Fabric: 500D CORDURA ® Nylon

Internal Fabric: 420D Nylon

Dump Valves: 2 (O.P.E.V. + 1)

D-Rings: 4 resin

CORDURA ® is a registered trademark of INVISTA Corporation in the United States.

XS 80N / 18.0 lbf / 8.2 kgf

S 100N / 22.5 lbf / 10.2 kgf

M 140N / 31.5 lbf / 14.3 kgf

L 170N / 38.2 lbf / 17.3 kgf

XL 205N / 46.1 lbf / 20.9 kgf

Buckle Ultimate Stabilizing Harness (U.S.H.) Ultimate Stabilizing Harness (U.S.H.)

A 2-position cam strap for quick and easy adjustment. A 2-position cam strap for quick and easy adjustment. Completely eliminates tank roll. Completely eliminates tank roll.

Active Purge Assist (A.P.A.)

• Revolutionary pneumatic assisted purge system for TUSA BC’s

• Increased flow rates (inflate/deflate) for better performance over standard inflators

• Newly designed OPEV immediately responds to user input

• Utilizes stainless steel cable

RiteTite

RELIABILITY, TAKEN TO NEW HEIGHTS

This is the height of enlightened technology. No batteries to change. No seals to break. A dive computer so advanced, it’s simple. For a level of reliability that goes far below the surface.

• Solar rechargeable battery design eliminates the need to charge or replace battery.

• Dive log transferable to smartphone using Bluetooth® SMART technology (TUSA Diving Log app required).

• Supports four (4) individual gas mixtures, including nitrox (enriched air) gas, and enables accelerated decompression (oxygen concentration ratio from 21% to 100%) in full scale.

• AA Buhlmann ZHL-16C Decompression algorithm for safe and simple ascents.

• 1/10 second measurement stopwatch, timer, alarm, and world time (up to 48 cities).

• Built-in full auto calendar up to year 2099.

• Gauge mode can be used as a simple and diving depth gauge.

• Convenient free diving mode for skin diving and free diving enthusiasts.

• Depth interval alarm function gives you a warning sound at each preset water depth.

• TUSA’s exclusive M value warning function is available aiding in the prevention of decompression sickness below the depth of 66 ft / 20 m.

• Full-auto LED backlight illumination.

• Factory-sealed, durable, and compact design using metal parts.

Bluetooth® SMART Technology and Diving Log App

• Transfer the dive log data to the smartphone using the Bluetooth ® SMART function and the FREE smartphone app “Diving Log.”

• Recordable information: basic dive data (dive point, entry and exit time, total diving time, maximum water depth, average water depth, water temperature), location information of the dive point using the map function, and handwritten signature of the instructor.

• Dive log data can be shared with friends through various social medias.

Solar Rechargeable

Bluetooth ® SMART 4 Gas Mix

Equipped with advanced Bluetooth technology.

Allows the diver to preset four (4) individual gas mixtures.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Audible Alarm

Audible alarms equipped.

Backlit Display

Back light equipped.

Free Dive Mode

Free dive mode equipped.

2 Gas Mix

Allows the diver to preset two (2) Nitrox gas mixtures.

Audible Alarm

Audible alarms equipped.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Backlit Display

Back light equipped.

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

PC Downloadable

Transfer log data from the dive computer to a personal computer.

User Replaceable Battery

Replaceable battery can be changed by user.

2 Gas Mix

Allows the diver to preset two (2) Nitrox gas mixtures.

Audible Alarm

Audible alarms equipped.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Backlit Display

Back light equipped.

Dual Time Display

Dual Time zones may be displayed simultaneously.

Free Dive Mode

Free dive mode equipped.

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

PC Downloadable

Transfer log data from the dive computer to a personal computer.

Step-Back Feature

Allows user to navigate forward or backward through the menus.

User Replaceable Battery

Replaceable battery can be changed by user.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

User Replaceable Battery

Replaceable battery can be changed by user.

Talis

3 Gauge

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• IQ-750 Element II computer module

• 5000psi/400bar (4350psi/300bar max)

pressure gauge

• Compass module equipped with ratcheting bezel and top or side-view

• Luminescent dial is easy to read in dark or low visibility conditions

• Available in Metric (SCA-362E) or Imperial (SCA-362U)

2 Gas Mix

Allows the diver to preset two (2) Nitrox gas mixtures.

Audible Alarm

Audible alarms equipped.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Backlit Display

Back light equipped.

2 Gauge

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• IQ-750 Element II computer module

• 5000psi/400bar (4350psi/300bar max) pressure gauge

• Luminescent dial is easy to read in dark or low visibility

• Available in Metric (SCA-282E) or Imperial (SCA-282U)

2 Gas Mix

Allows the diver to preset two (2) Nitrox gas mixtures.

Audible Alarm

Audible alarms equipped.

Altitude Smart Mode

Automatic adjustment for altitude diving.

Backlit Display

Back light equipped.

3 Gauge

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

PC Downloadable

Transfer log data from the dive computer to a personal computer.

User Replaceable Battery

Replaceable battery can be changed by user.

• IQ-650 Element computer module

• 5000psi/400bar (4350psi/300bar max) pressure gauge

• Compass module equipped with ratcheting bezel and top or side-view

• Luminescent dial is easy to read in dark or low visibility conditions

• Available in Metric (SCA-361E) or Imperial (SCA-361U)

Altitude Smart Mode

Automatic adjustment for altitude diving.

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

User Replaceable Battery

Replaceable battery can be changed by user.

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

PC Downloadable

Transfer log data from the dive computer to a personal computer.

User Replaceable Battery

Replaceable battery can be changed by user.

N/A EUR N/A EUR Element

SCA-281

2 Gauge

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• IQ-650 Element computer module

• 5000psi/400bar (4350psi/300bar max) pressure gauge

• Rental unit reset option

• Available in Metric (SCA-281E) or Imperial (SCA-281U)

Altitude Smart Mode

Optional Deep Stop

Optional deep safety stop on dive depths greater than 80 ft / 25 m.

User Replaceable Battery Automatic adjustment for altitude diving.

Replaceable battery can be changed by user.

3 Gauge 2 Gauge SPG Combo SPG

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• Low-profile 3 gauge analog console includes a depth gauge, highpressure gauge and compass

• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge

• Compass module equipped with ratcheting bezel and top or sideview

SCA-160

Compass

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• Compact 2 gauge analog console includes a depth gauge and a highpressure gauge

• Luminescent dial is easy to read in dark or low visibility

• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge

Dimension: 14.8 in x 2.4 in 375 mm x 60 mm

• Durable boot with strap

• Lockable bezel with side window for easy reading

• Luminescent dial face

Dimension: 7.1 in x 2.2 in 180 mm x 55 mm

• Mini 3 gauge console includes a depth gauge, high-pressure gauge and compass

• Luminescent dial is easy to read in dark or low visibility

• 400bar pressure gauge

• 70m depth gauge

Dimension: 6.9 in x 2.8 in 175 mm x 70 mm

• Compact 2 gauge console includes a high-pressure gauge and compass

• Luminescent dial is easy to read in dark or low visibility

• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge

Dimension: 7.1 in x 2.2 in 180 mm x 55 mm

• Mini 2 gauge console includes a depth gauge and high-pressure gauge

• Luminescent dial is easy to read in dark or low visibility

• 400bar pressure gauge

• 70m depth gauge

Dimension: 4.4 in x 2.6 in 113 mm x 65 mm

• Luminescent dial is easy to read in dark or low visibility

• 5000psi/400bar (4350psi/300bar max) pressure gauge

• Gauge boot includes rings for attachment of BCJ hooks, etc.

Dimension: 4.9 in x 2.2 in 125 mm x 55 mm

• Mini size, lightweight and reliable design

• Streamlined, low drag

• Luminescent dial face

• 400bar pressure gauge (350bar max)

SAV-7 EVO3

Dimension (L x W):

28.4 in × 13.4 in

720 mm × 340 mm

Weight (with battery):

45 lbs / 20.4 kg

Submerged unit weight:

1.1 lbs / 0.5 kg

Speed: 0 ~ 2.8mi/h (4.5km/h)

Active depth:

Approx. 230 ft / 70 m

Active range: 5.9 mi / 9,400 m

Body: Shock resistant ABS resin

Motor: 24V Brushless motor

REV reducer:

- Ring epicyclical gear speed reducer

Speed adjuster:

- Rotational speed control

- Variable pitch-type propeller (3 steps)

Safety devices:

- Sensation current shut-down device

- Water leakage sensor function turns on warning lamp when water enters the motor or battery housing, and automatically shuts down operations

Accessories:

- Water-cooling motor deployment

- O-ring seal for the main body

- O-ring seal for the propeller end of the body

- Silicone grease

Diver Propulsion Vehicle / Underwater Scooter

Hands-free riding with the scooter saddle

Quick and smooth speed control is now at your finger tip. Speed adjustments are made via an accelerator lever that changes the rotational speed of motor while vehicle is in use. Adjustments are very smooth, allowing user to fine-tune speed. This new design provides a far more advanced control system than other underwater scooters.

When the main switch is turned on, the battery indicator lights up. An LED indicator displays the battery level.

Before riding, rotate the variable pitch dial in advance. You can adjust the angle of the propeller in three (3) steps. By adjusting the propeller characteristics according to the usage environment. Fine speed adjustment is possible.

Hands-free is an innovative riding style that allows an operator to steer the scooter with body movement; much like a seal. This inline body placement is more streamlined to effectively decrease fatigue, reduce air consumption, and extend your dive time. Go further, get there faster, and have a lot more fun along the way. The hands-free riding style increases your options while diving. You are no longer limited to the hands-on riding style required by other vehicles. The possibilities are endless.

The SAV-7 EVO2 underwater vehicle improves your ability to transport items underwater. Your hands are free to carry what you need. Additionally, fold out wings on both sides of the saddle are available for towing divers or attaching other items of equipment.

To minimize underwater resistance and to allow for effortless underwater maneuvering, the scooter is designed to be steered hands-free. In doing so, the saddle helps to hold the diver in place, and allows the diver to steer the scooter freely. Even relatively sharp turns are made possible when riding hands free.

Carrying Triple Riding

Multi-usage mesh backpack with a drybag.

BA0106

Mesh Backpack with Drybag

• Both side mesh pockets of outer mesh bag can insert fins

• Inner dry bag and outer mesh bag can be used separately

• Mesh bags can carry the light equipment and towels together

• The dry bag can carry with wet clothes

• Flexible usage according to scenes and people to use

BA0301

Mesh Roller Bag

• Large outer pocket

• One (1) internal pocket

• Adjustable shoulder strap

• One (1) top and two (2) side carry handles

Adjustable shoulder strap

Smooth-running wheels

BA0103

Mesh Backpack

Padded shoulder strap

• Large outer pocket (Hook-and-Loop fastener)

• One (1) internal zippered pocket

• Padded shoulder straps

• Wide access extended main zipper

Mesh Backpack Drybag

• Extendable heavy duty pull handle

• Four (4) compression straps

• Two (2) carry handles

• Two (2) internal zippered pockets

• One (1) mesh zippered pocket

• Large outer double-zippered pocket

• Small outer double-zippered pocket

• “Carry-on” size (BA0204)

• Water resistant back

• One (1) carrying handle

• Large outer double-zippered pocket

• Heavy duty, smooth gliding wheels

• Fully lined with thick padding

• Durable zipper with pull tabs

• Internal pocket for log / manuals

• Shoulder strap included

• Tough, nylon-reinforced, PVC-construction

• Large easy-to-access top opening

• Roll down and quick-snap closure top

• Rectangular shaped base

• 6-4Ti (Ti-6Al-4V) highly corrosion resistant titanium drop point blade

• Ergonomic grip with counterweight

• Includes a serrated edge plus a line cutter

• Single button sheath lock release

• Easy-to-adjust buckle and strap allow for a comfortable fit

• Disassembling capability for easy cleaning and maintenance

• 6-4Ti (Ti-6AI-4V) highly corrosion resistant titanium drop point blade

• Includes a serrated edge

• Sheath locking tab holds knife securely in place, then releases at a touch

• Optional BC attachment available (TC-752)

• 420 stainless steel blade

• Disassembling capability for easy cleaning and maintenance

• Includes a serrated edge plus a line cutter

• Sheath lock button holds knife securely in place, then releases at a touch

• Easy-to-adjust buckle and strap allow for a comfortable fit

• 420 stainless steel blade

• Ergonomic grip with counterweight

• Includes a serrated edge plus a line cutter

• Single button sheath lock release

• Easy-to-adjust buckle and strap

• Disassembling capability for easy cleaning and maintenance

• 304 stainless

• Includes a serrated edge plus a line cutter (FK-11)

• Sheath locking tab holds knife securely in place, then releases at a touch

• Optional BC attachment available (TC-752)

Lightweight titanium alloy

Blunt tip blade

Lightweight titanium alloy

• 450 Lumen high-powered LED

• Beam angle: 60 degrees

• 3 power levels: 100%, 30%, Strobe

• Burn time: 100% (105 min.)

• Switch: Slide magnetic on/off

• Depth rating: 400 ft / 120 m

• Body: Rugged anodized aluminum

DG-5600

• Battery compartment: Triple O-Ring, Screwed

• Accessories: Wrist Lanyard (included)

• Batteries: 3 AAA (Not included)

• Overall Length: 5.1 in / 130 mm

• SOS feature

• 450 Lumen high-powered LED

• Beam angle: 7 degrees

• 3 power levels: 100%, 30%, Strobe

• Burn time: 100% (105min.)

• Switch: Slide magnetic on/off

• Depth Rating: 400 ft / 120 m

• Body: Rugged anodized aluminum

DG-5100

• Battery compartment: Triple O-Ring, Screwed

• Accessories: Wrist Lanyard (included)

• Batteries: 3 AAA (Not included)

• Overall Length: 5.1 inch / 130 mm

• SOS feature

• Soft stretchable poly mesh backing for added comfort

• Non-slip poly vinyl textured palm for protection

• Adjustable Hook & Loop fastener

• 2.0mm neoprene backing for added comfort and warmth

• Reinforced synthetic suede palm for comfort and protection

• Adjustable hook & loop fastener

Proprietary design. Protects your feet from rugged surface.

• Injection molded sole with super traction

• 5.0 mm neoprene/nylon jersey

• Zipper with hook-and-loop lock

Proprietary design. Protects your feet from rugged surface.

• Injection molded sole with super traction

• 3.0 mm neoprene/nylon jersey

• Slip-on

Tropical Glove

Warm Water Glove

5mm Dive Boot

3mm Dive Slipper

WIDE SPOT

Size XS S M L XL

ClearVU Tempered Glass Pure Silicone EZ Strap Hyperdry Elite

UC-3125QB

Visio Tri-Ex Adult Combo

UM-31

USP-250

Mask Fitting:

Adult Medium to Large faces

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered Glass

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Purge valve for clearing water.

UC2425MQB

Powerview Adult Dry Combo

UM-24

Adult Medium to Large faces 3-window design for maximum field of view.

Mask Fitting:

USP-250

Low-profile 2-window design for maximum field of view.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered Glass

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Purge valve for clearing water.

Mirror Lens

Stylish mirror coating.

UC-1625QB

Serene Adult Combo

Compact, low-profile 1-window design.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered Glass

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Serene Adult Combo UM-16

Purge valve for clearing water.

UC1625MQB

UM-16

Compact, low-profile 1-window design.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered Glass

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Purge valve for clearing water.

Mirror Lens

Stylish mirror coating.

ADULT PRO Series ADULT PRO Series

Imprex 3D Dry Adult Combo

3-Window design with enchanced panoramic view.

TUSA’s exclusive dry-top for snorkels.

Pure silicone FDA regulation compliant.

Superior clarity, color, and transmission of light.

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

Three-dimensional pipe curve for ergonomic fit.

Powerview Adult Dry Combo

Low-profile 2-window design for maximum field of view.

TUSA’s exclusive dry-top for snorkels.

Pure silicone FDA regulation compliant.

Superior clarity, color, and transmission of light.

Three-dimensional pipe curve for ergonomic fit.

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

Available Colors Available Colors

HYPERDRY PURGE

With the Hyperdry Purge system, you simply breathe out through your nose and any water that has accumulated in your mask is forced out through a oneway valve. Once the mask is clear, the valve seals shut.

PANORAMIC VIEW

Side window provides bright and clear wide field of view.

Silicone

Silicone ClearVu Tempered Glass

Tempered Glass

EZ Strap and Buckle

High Flow Purge High Flow Purge Hyperdry Elite - Dry Top Hyperdry Elite - Dry Top

Quick and easy adjustment with minimal effort.

Purge valve for clearing water.

Flexible silicone joint reduces strain on the mouth.

One touch adapter that can be easily detached and attached to a mask.

Splendive Adult Combo

Low-profile 2-window design for maximum field of view.

Hyperdry Semi - Dry Top

TUSA’s exclusive splash guard for snorkels.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVu Tempered Glass

Superior clarity, color, and transmission of light.

ADULT ELITE Series

Liberator Adult Dry Combo

Low-profile 2-window design for maximum field of view.

Hyperdry Semi - Dry Top TUSA’s exclusive splash guard for snorkels.

Three-dimensional pipe curve for ergonomic fit.

One touch adapter that can be easily detached and attached to a mask.

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

Three-dimensional pipe curve for ergonomic fit.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVu Tempered Glass

Superior clarity, color, and transmission of light.

One touch adapter that can be easily detached and attached to a

Pure Silicone Pure Silicone

High Flow Purge

Purge valve for clearing water.

Available Colors

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

High Flow Purge

Purge valve for clearing water.

Available Colors

mask.

EZ Strap and Buckle Quick and easy adjustment with minimal effort.

Flexible silicone joint reduces strain on the mouth.

YOUTH PRO Series YOUTH ELITE Series

YOUTH ELITE Series

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

- Dry

TUSA’s exclusive splash guard for

TUSA’s exclusive splash guard for snorkels.

Superior clarity, color, and transmission of light.

EZ Strap and Buckle

Quick and easy adjustment with minimal effort.

Pure Silicone

ClearVu Tempered Glass

ClearVu Tempered Glass Superior clarity, color, and transmission of light.

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

EZ Strap and Buckle

Quick and easy adjustment with minimal effort.

Pure silicone FDA regulation compliant. Excellent durability with comfort fit.

ClearVu Tempered Glass

EZ Strap and Buckle

Quick and easy adjustment with minimal effort.

Pure Silicone Pure Silicone

HYPERDRY ELITE DRY TOP

The Hyperdry Elite maintains the same superior dry performance and keeps the snorkel completely void of water by quickly and efficiently closing the float when submerged or hit by waves.

Lifting the float will close the valve and prevent water from flooding.

Pure silicone FDA regulation compliant.

Excellent durability with comfort fit.

Elite Dry Top Internal Structure

N/A USA Panthes Adult Combo

Freediving Freediving Spearfisihing Spearfisihing

Ultra low-profile 2-window mask with exceptional field-of-vision.

Cross-cut barrel design for easy clearing.

Universal Optical Frame and Lens

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVu Tempered Glass

Superior clarity, color, and transmission of light.

EZ Strap and Buckle

Quick and easy adjustment with minimal effort.

FITS MOST MASKS

Excellent durability with comfort fit. One touch adapter that can be easily detached and attached to a mask.

Skirt mounted quick-adjust buckle system

Frame Material: POM

Frame Dimension (H x W x D):

3.2 × 5.6 × 0.5 in 79 × 141 × 11 mm

Weight: 0.3 oz / 6 g

Lens Material: PC

Lens Dimension (H x W x D): 2.0 × 2.3 × 0.5 in 49 × 58 × 11 mm

• Universal optical frame with corrective lenses for most masks

• Available only as assembled with a frame and a pair of same diopter lenses

• Easy drop-in installation

UP-3521QB

Visio Tri-Ex Adult Travel Sets

UM-31

USP-250

UF-21

Serene Adult Travel Sets Mask Mask

Mask Fitting:

3-window design for maximum field of view.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Purge valve for clearing water.

Hybrid Blade System (H.B.S.)

Improved propulsion, efficiency and power transfer.

Travel Friendly Blade Design

Compact and travel friendly design.

UP-1521QB

UM-16

USP-250

Adult Medium to Large faces Adult Small to Medium faces Snorkel Snorkel

Mask Fitting:

UF-21

Low-profile 1-window design for maximum field of view.

Pure Silicone

Pure silicone FDA regulation compliant.

ClearVU Tempered

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System

Quick and easy adjustment with minimal effort.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

Protective Mouth-Piece Cover

Protective cover for the mouthpiece.

High Flow Purge

Purge valve for clearing water.

Hybrid Blade System (H.B.S.)

Improved propulsion, efficiency and power transfer.

Travel Friendly Blade Design

Compact and travel friendly design.

ADULT PRO Series ADULT PRO Series

Splendive Adult Dry Set

Low-profile 2-window design for maximum field of view.

Hyperdry Elite - Dry Top

Threedimensional pipe curve for ergonomic fit.

UP-2521B

Powerview Adult Dry Travel Set

Adult Medium to Large faces

Low-profile 2-window design for maximum field of view.

Hyperdry Elite - Dry Top

TUSA’s exclusive dry-top for snorkels.

TUSA’s exclusive dry-top for snorkels. Pure Silicone Pure Silicone Pure silicone FDA regulation compliant. Pure silicone FDA regulation compliant.

ClearVu Tempered Glass

Superior clarity, color, and transmission of light.

Quick and easy adjustment with minimal effort.

Improved propulsion, efficiency and power transfer.

One touch adapter that can be easily detached and attached to a mask.

Threedimensional pipe curve for ergonomic fit.

ClearVu Tempered Glass

Superior clarity, color, and transmission of light.

Quick and easy adjustment with minimal effort.

High Flow Purge

One touch adapter that can be easily detached and attached to a mask.

Available Colors and Sizes

High Flow Purge Purge valve for clearing water. Purge valve for clearing water.

and travel friendly design.

Improved propulsion, efficiency and power transfer.

and travel friendly design.

Available Colors and Sizes

Travel Friendly Blade Design

Hybrid Blade System

EZ Strap and Buckle

ADULT ELITE Series YOUTH ELITE Series

Low-profile 2-window design for maximum field of view.

Hyperdry Semi - Dry Top

Low-profile 1-window design for maximum field of view.

Hyperdry Semi - Dry Top TUSA’s exclusive splash guard for snorkels. TUSA’s exclusive splash guard for snorkels. Pure Silicone Pure silicone FDA regulation compliant.

Available Colors and Sizes

and Sizes

Snorkel

Travel Friendly Blade Design

Hybrid Blade System Hybrid Blade System Compact and travel friendly design. Compact and travel friendly design.

Improved propulsion, efficiency and power transfer.

One touch adapter that can be easily detached and attached to a mask.

EZ Strap and Buckle

EZ Strap and Buckle Quick and easy adjustment with minimal effort. Quick and easy adjustment with minimal effort.

One touch adapter that can be easily detached and attached to a mask.

Tempered ClearVU Tempered

Superior clarity, color, and transmission of light.

EZ Strap and Buckle System EZ Strap and Buckle System

Dry Snorkel

Three-dimensional pipe curve for ergonomic fit.

Hyperdry Elite - Dry Top

High Flow Purge TUSA’s exclusive dry-top for snorkels.

Purge valve for clearing water.

One touch adapter that can be easily detached and attached to a mask.

• Short blade design

• Soft all-rubber construction

• Open-toe, full foot length for maximum performance

• Low-ankle slip on

• Ideal for snorkeling and tropical diving

• Soft, full foot pocket design

• Hydrofoil design and hybrid ribs produce greater forward propulsion

• Vented blade design reduces fatigue

• Lightweight and travel friendly

• Advanced Multi-Flex compact design

• Thrust Channel Technology

• Maximum propulsion and comfort

• Soft comfortable open-heel foot pocket with adjustable silicone strap

• Travel friendly

Boots not required.

Compact Snorkeling Fin

EUR

• Travel-friendly short blade design

• Soft comfortable open-heel foot pocket with adjustable silicone strap

• Enhanced rib design and multi-compound blade for extra power

Boots not required.

Long Blade Snorkeling Fin

• Innovative hydrofoil design and hybrid rib produce greater forward motion (lift) both on the surface and underwater

• Propeller-fin technology and super lightweight design to achieve the ultimate performance

Platina Full Foot Fin

• 20 degree Angled Blade Design for maximum efficiency and propulsion

• Open-toe full foot pocket provides superb comfort and support

Snorkeling Backpack

• 100% nylon with mesh details

• Adjustable shoulder strap

• Front storage pocket with hook-and-loop closure

• Bottom Drain

SV-2500

Youth

Snorkeling Vest

Fabric: Nylon (210 Denier), PU coated

Dimension: 37.5 x 59.1 in 95 x 150 cm

Buoyancy: 12.0 lbs / 5.4 kg

• High-visibility yellow air cell

• Quick-release buckles on back and crotch strap

• 6” inflator valve for easy operation

• Compact for easy storage during travel

Snorkeling Vest

Fabric: Nylon (210 Denier), PU coated

Dimension: 55.2 x 72.9 in 140 x 185 cm

Buoyancy: 23.0 lbs / 10.4 kg

• High-visibility yellow air cell

• Quick-release buckles on back and crotch strap

• 6” inflator valve for easy operation

• Compact for easy storage during travel

• Great for beach, pool, boats or any watersports activity

• Quick-drying jersey and mesh upper

• Quick-adjust pull lace closure system

• Easy slip-on

TUSA performance TECHNOLOGY FEATURES

MASKS

Freedom Technology

Freedom Technology is a set of four (4) technologies to enhance fit and performance exclusive to TUSA. Freedom model masks feature a dimpled skirt surface with varied silicone thicknesses and stability ridges in addition to a proprietary low-friction skirt surface on the fitting line.

Freedom Technology with Fit II

Freedom Technology is a set of technologies to enhance fit and performance exclusive to TUSA. Freedom model masks feature a dimpled skirt surface with varied silicone thicknesses and stability ridges in addition to a proprietary low-friction skirt surface on the fitting line. The new Fit II technology adds strength and rigidness to the skirt for use in tough environments.

TRI-MIX Frame

Three (3) distinct layers combined to produce one superior frame structure. Polyurethane (PuRiMaX) material bumper protection and a cross-beam metal frame structure combined with the superior toughness of the polycarbonate frame bolted together to create a seriously tough mask.

UV 420 Lens Treatment

180 Buckle System

The buckle rotates a full 180 degrees to accommodate varying head sizes for optimum fit. The thin frame and rotation of the buckle allows the mask to be folded into a compact size.

3D Mask Strap

TUSA’s patented 3D Strap is a true three-dimensional design that snugly fits against the head’s natural curvature. The 3D strap offers unprecedented comfort and fit unlike standard flat mask straps.

Angle Strap Adjustor

The Five (5) Angle Strap Adjustor allows for a five position micro-adjustment on both the left and right sides of the mask. This enables vertical (up/down) and horizontal (left/right) pressure on the face to be delicately adjusted for the optimum fit.

Angle Strap Adjustor with Side Hold

The Skirt Mounted Five (5) Angle Strap Adjustor allows for a five position microadjustment on both the left and right sides of the mask. This enables vertical (up/down) and horizontal (left/right) pressure on the face to be delicately adjusted for the optimum fit.

SNORKELS

Comfort Swivel

The Comfort Swivel adapter makes it possible to slip the mask strap into the slit with no hassles. The two-part construction allows the snorkel to rotate and can be attached in a horizontal position.

High Flow Purge

The High Flow Purge design used on TUSA snorkels offers a covered large diameter purge valve for simple, quick clearing, reducing the amount of water remaining in the mouthpiece in an instant.

FINS

Active Pivoting System

The combination of uniquely positioned holes that reduce drag while maintaining constant propulsion and the built-in fin stop creates a soft kick that produces great power.

Anatomic Fin Strap

The AFS is anatomically shaped to offer a balance of flexibility and control to increase comfort, power transfer and to significantly reduce heel slippage found in many standard flat fin straps.

Angled Blade Design (A.B.D.)

The Angled Blade Design accommodates for this anatomical characteristic and ensures maximum efficiency throughout the kicking cycle.

Bungee Strap

The heavy duty elastic fin strap provides easy donning and doffing of fins. The quick adjustment accommodates five (5) adjustable positions.

EZ Strap and Buckle System

TUSA’s EZ strap and Buckle System allows fins to be quickly and easily adjusted with minimal effort. Adjustment can be made while the fins are worn, allowing for a precise fit and ease of removal when necessary.

REGULATORS

Adjustable Control Knob

The Adjustable Control Knob designed to better control breathing resistance.

Advanced Flow System

The Advanced Flow System allows ease of air flow and makes air delivery smoother due to the curved housing structure.

Teflon Coated Plate

The Teflon Coated Plate prevents “dry mouth.” Condensation forms on the brass plate adding moisture to the dry air released from scuba cylinders.

Anti-Reflective (A/R) Lens Treatment

TUSA’s Anti-Reflective (A/R) Lens Treatment decreases internal and external reflected light. This reduction increases light transmission to 95% resulting in significantly enhanced color, clarity, contrast and better overall vision underwater.

Corrective Lens

Corrective Lenses are offered on several styles of masks. This option allows the diver to choose right and left lens powers in both a variety of diopters for maximum flexibility and for a custom fit.

CrystalView Optical Glass

CrystalView optical glass lenses provide superior clarity, color and transmission of light over standard glass lenses used by the competition. Up to 15% of available light can be lost with a standard glass lens due to impurities and reflectivity. TUSA’s CrystalView lenses transmit up to 95% of available light to the diver for clear crisp vision. CrystalView lenses are used in all PRO models masks

Hyperdry Purge

Clearing a mask has never been easier thanks to our patented Hyperdry System. Simply breathe out through your nose and any water that has accumulated in your mask is forced out through a one-way purge valve. Once the mask is clear, the valve seals shut.

Panoramic View

Panoramic View masks feature a variety of designs offering an incredibly wide fieldof-view. Several designs incorporate minimum frame volumes, domed side-windows, reduced frame structures as well as three and four window styles for maximum vision.

Quick-Adjust Buckle System

Round Edge Skirt

TUSA’s Round Edge Skirt features a proprietary round edge cross-sectionally shaped skirt. This rounded edge results in a soft fit that suppresses pressure and reduces creasing left on the face. The “planar fit, instead of linear fit” silicone skirt maintains great fit and unprecedented comfort.

UV Lens Treatment

TUSA’s UV Lens Treatment provides 100% protection from harmful UVA and UVB rays. Blocking of the ultraviolet spectrum (under 400nm) provides greater eye protection without sacrificing light transmission or vision.

Hyperdry Elite Dry Top

The Hyperdry Elite maintains the same superior dry performance and keeps the snorkel completely void of water by quickly and efficiently closing the float when submerged or hit by waves.

Hyperdry System

The Hyperdry System keeps the main pipe dry by ejecting water through an independent escape pipe. This unique design utilizes the angle of the snorkel pipe and the resistance of the water surface to eject water.

ForcElast Technology

A proprietary thermoplastic elastomer (TPE) compound precisely positioned in an advanced blade and foot pocket structure. ForcElast delivers superior propulsion, efficiency and speed even with moderate power input.

Propeller Technology

TUSA’s advanced split fins employ Propeller-Fin™ Technology, which delivers ultrahigh performance with a low amplitude rapid flutter kick. As the fin moves through the water its two wing-shaped surfaces create lift and forward propulsion like a propeller. Efficiency is increased while drag and effort is reduced.

The fin blade is made of top quality Polyurethane material that provides a quicker response to movement over rubber and plastic fins.

TUSA Direct Reflect

This advanced reflective material brightly reflects 180 degrees back to the original light source. Providing high visibility in low light conditions.

Vortex Generator

Six (6) performance ridges positioned behind the blade vent reduce resistance, creating a smoother and more efficient kick cycle.

Click Spring Adjustment

The Click Spring Adjustment feature is exclusive to TUSA. It is a five (5)-position adjustment knob designed to better control breathing resistance.

Cold Water Ready

The Cold Water Ready feature enables the diver to use the regulator in water temperatures below 50° F / 10° C.

Environmentally Sealed 1st Stage

The use of a secondary diaphragm and piston sealing the 1st stage preventing contamination or freezing when the regulator is submersed in contaminated or freezing water.

TUSA performance TECHNOLOGY FEATURES

REGULATORS (cont.)

Ortho-Conscious Mouth Piece

The Ortho-Conscious Mouth Piece feature prevents jaw fatigue. The ridges and flexible material allow the diver to have more control of the mouth piece and reduces tension in the jaw.

Pneumatically Balanced 2nd Stage

A balance chamber added to the regulator 2nd stage, providing equal pressure to both sides of the LP seat greatly reducing inhalation effort.

B.C.JACKETS

3D Hybrid Cubic Air Cell

The 3D Hybrid Cubic Air Cell combines the features of a wrap-around style BCJ and a back-inflation BCJ into a unique streamlined hybrid design. The air cell offers increased lift capacity over standard back-inflation jackets and a more streamlined, comfortable fit underwater and on the surface.

Active Purge Assist (A.P.A.)

Exclusive to TUSA, the Active Purge Assist is a pneumatically assisted power inflator. Using a piston, the power inflator activates a stainless steel cable connected to the shoulder dump valve. The APA assures a quick response when deflating air from the BC.

Advanced Weight Loading System II (A.W.L.S. II)

The 2nd generation A.W.L.S. continues to enhance TUSA weight integrated BC jackets by incorporating an ergonomic handle grip and quick-lock feature. Release the weight cartridges with ease by simply turning the handle grip vertically 90° in either direction.

Advanced Weight Loading System III (A.W.L.S. III)

A secure single locking integrated weight system that allows you to quickly and easily secure your weight pockets.

DIVE COMPUTERS / GAUGES

4 Gas Mix

This advanced feature allows the diver to preset four individual gas mixtures (Mix 1, Mix 2, Mix 3, Mix 4) from 21-100% for easy switching during the dive.

2 Gas Mix

This feature allows the diver to preset two Nitrox gas mixtures (Mix 1 and Mix 2) for easy switching during the dive as necessary. Mix 1: 21 to 50%, Mix 2: 21 to 99%.

Altitude Smart Mode

The Altitude Smart Mode allows the computer to automatically adjust for altitude diving.

Audible Alarm

TUSA’s computers feature Audible and Visual Alarms for the most important dive data warnings. Ascent rate, maximum depth, no decompression limits, safety stop and several other key data can be set to alert the diver.

Backlit Display

Several TUSA computer instruments feature a Backlit Display for night diving or low-light situations. The bright backlight is activated by a touch of a button and the duration can be set for up to 10 seconds in length enabling the diver to view critical dive data easily and quickly.

Bluetooth ® SMART

Bluetooth ® SMART technology enables smartphones or tablets with the Diving LOG app downloaded to receive dive log data from the IQ1204 DC Solar Dive Computer via Bluetooth ®

Dual Time Display

Dual Time Display offers two time zones to be displayed simultaneously on the LCD.

TUSA SPORT

Pure Silicone

“Pure silicone FDA regulation compliant. (Rubber articles intended for repeated use / 21 CFR 177.2600) TUSA Sport uses pure silicone for the snorkel mouth-piece and mask skirt.”

ClearVU Tempered Glass

ClearVu tempered glass lenses provide superior clarity, color, transmission of light and safety over standard glass.

EZ Strap and Buckle System

Allows masks to be quickly and easily adjusted with minimal effort. Allowing for a precise fit and ease of removal when necessary.

High Flow Purge

A large diameter purge valve for simple, quick clearing, reducing the amount of water remaining in the mouth-piece.

Sequence Exhaust Assist System

The Sequence Exhaust Assist System gives the diver less resistance when exhaling due to its unique double exhaust design. The diver experiences smooth breathing cycles reducing air consumption and fatigue.

Swivel Hose

The Swivel Hose gives maneuverability to the 2nd stage. The hose can rotate 360 degrees allowing it to move freely with the diver’s head motions.

Venturi Flow Adjustment

The Venturi Flow Adjustment allows for ease of breathing by controlling the direction of air through the mouthpiece.

Independent Harness System (I.H.S.)

RiteTite Buckle

The RiteTite Buckle is a two (2)-position cam strap for quick and easy adjustment. While the strap is being looped through the buckle, the buckle stays in place without needing to be held. This allows for more control and stability. This feature is part of all TUSA BC’s.

Ultimate Stabilizing Harness (U.S.H.)

Waist Support System (W.S.S.)

The Waist Support System significantly enhances comfort and fit by dispersing the weight load around the hips. The W.S.S. integrates the adjustable shoulder harness system with the rear stabilizing plate and cummerbund to effectively unload the hips while ensuring a snug fit.

Free Dive Mode

The Free Dive Mode calculates dive times and surface intervals for free diving.

Optional Deep Stop

An optional safety stop on No Deco dives exceeding a depth of 80 feet.

PC Downloadable

TUSA’s PCLogbook, TUSA DataLog PC, and DiverLog Mac interfaces allow the diver to transfer complete log and profile history from the dive computer to a personal computer or upload user settings to the computer. A PC interface unit is sold separately.

Solar Rechargeable

Rechargeable by sunlight or indoor fluorescent light. The solar rechargeable feature eliminates the need for battery replacements.

Step-Back Feature

The Step-Back Feature allows user to navigate forward or backward through the menus.

User Replaceable Battery

Convenience and ease-of-maintenance is imperative in the design of today’s dive computer. Each of TUSA’s computers offer a user-friendly replaceable battery that can be changed on a moment’s notice using standard widely-distributed batteries.

Hybrid Blade System (H.B.S.)

The patented Hybrid Blade System offers unparalleled propulsion, efficiency and power transfer in a multi-compound design. The H.B.S. is composed of incredibly stiff side rails and an ultra-responsive membrane blade giving unlimited kicking potential.

Hyperdry Elite - Dry Top

The latest innovation in dry snorkel technology utilizing an independent high buoyancy float for superior dry performance. This keeps the snorkel completely dry by quickly and efficiently closing the tube opening.

Hyperdry Semi - Dry Top

Keeps the main snorkel pipe dry by ejecting water through an independent escape pipe.

Protective Mouth-Piece Cover

Helps to maintain and extend the life of the snorkel’s mouth-piece.

Travel Friendly Blade Design

A compact blade design allows your snorkel gear to be an easy and light travel option. Giving you more flexibility when packing for your next adventure.

Designed and engineered to the industry’s highest standards,TUSA’s state-of-the-art facilities are ISO 9001 certified to ensure quality second to none.

We, at Tabata Co., Ltd., would like to extend our thanks for your past and continued support. At Tabata, our goal has always been to provide our users with innovative equipment of the highest quality. As testimony to our commitment of developing and manufacturing high quality equipment with exacting standards, Tabata has been certified by the international standards organization quality standards ISO 9001 for Tabata Japan and Tabata Taiwan. The ISO certification is synonymous with international quality assurance standards and embodies our goal to excel in the development of innovative products with unsurpassed quality. “Providing the quality that represents our commitment to the user,” we express as the “Heart and Quality.”

Once again, we thank you for your continued support. The “Heart and Quality” will continue through future product innovation and our relations with you, our valued customer.

TABATA USA, INC.

2380 Mira Mar Ave., Long Beach, CA 90815 U.S.A.

Toll Free: 800-482-2282 T: 562-498-3708 (Country Code: 1) F: 562-344-9458 (Sales) 562-498-1390 (Accounting) info@tusa.com

TABATA JAPAN CO., LTD.

1-3-17, Higashikomagata, Sumida-ku, Tokyo, Japan 130-0005 T: 03-3624-2816 F: 03-3623-9902 (Country Code: 81) www.tabata.jp pr@tabata.co.jp

TABATA JAPAN MFG. (IBARAKI FACTORY)

651-2 Industrial Park, Hitachiomiya City, Ibaraki, Japan 319-2134 T: 02-95-53-3135 (Country Code: 81)

TABATA AUSTRALIA PTY. LTD.

4D James Ruse Business Park, 6 Boundary Road, Northmead, NSW 2152 T: (0)2-9890-4555 F: (0)2-9890-5222 (Country Code: 61) info@tabata.com.au

TABATA EUROPE CORPORATION B.V.

Watervoort 2, 1046 BG, Amsterdam, The Nederlands T: 020-58-11-280 (Country Code: 31) info@tusa.nl

TABATA TAIWAN MFG. CO., LTD.

256, Huanqu W. Rd. Dayuan Township, Taiyuan County, 33742 Taiwan, R. O. C. T: 03-386-5100 F: 03-386-5103 (Country Code: 886) info@tabata.com.tw
