REGULATORS
Cold Water Ready
Environmentally Sealed
FIRST STAGE
(Available EK600)
(Available EK600)
DIN Available -
SECOND STAGE
Adjustable Control Knob
Advanced Flow System
Teflon Coated Plate
Click Spring Adjustment
Ortho-Conscious Mouthpiece
Pneumatically Balanced
Sequence Exhaust Assist System
Swivel Hose
Venturi Flow System
INFLATOR
Air balanced power inflator
Large diameter purge button
Low profile mouthpiece
Lightweight Demand Valve
Large Diameter Purge Button
Left or Right Hose Layout
OCTO
Lightweight Demand Valve
Lightweight Demand Valve
Large Diameter Purge Button Venturi Breathing Adjustment Lever
Left or Right Hose Layout
Adjustable Control Knob
The Adjustable Control Knob designed to better control breathing resistance.
Advanced Flow System
The Advanced Flow System allows ease of air flow and makes air delivery smoother due to the curved housing structure.
Teflon Coated Plate
The Teflon Coated Plate prevents “dry mouth.” Condensation forms on the ceramic plate adding moisture to the dry air released from scuba cylinders.
Click Spring Adjustment
The Click Spring Adjustment feature is exclusive to TUSA. It is a 5 position adjustment knob designed to better control breathing resistance.
Cold Water Ready
The Cold Water Ready feature enables the diver to use the regulator in water temperatures below 50°F/10°C.
Environmentally Sealed 1st Stage
The use of a secondary diaphragm and piston sealing the 1st stage preventing contamination or freezing when the regulator is submersed in contaminated or freezing water.
Ortho-conscious Mouth Piece
The Ortho-Conscious Mouth Piece feature prevents jaw fatigue. The ridges and flexible material allow the diver to have more control of the mouth piece and reduces tension in the jaw.
Pneumatically Balanced 2nd Stage
A balance chamber added to the regulator 2nd stage, providing equal pressure to both sides of the LP seat greatly reducing inhalation effort.
Sequence Exhaust Assist System
The Sequence Exhaust Assist System gives the diver less resistance when exhaling due to its unique double exhaust design. The diver experiences smooth breathing cycles reducing air consumption and fatigue.
Swivel Hose
The Swivel Hose gives maneuverability to the 2nd stage. The hose can rotate 360 degrees allowing it to move freely with the diver’s head motions.
Venturi Flow Adjustment
The Venturi Flow Adjustment allows for ease of breathing by controlling the direction of air through the mouthpiece.
RS1001
• Balanced diaphragm first stage
• Two (2) H.P. ports and four (4) L.P. (2 high flow / 2 standard) ports
• Left or Right hand configuration
• Venturi adjustment lever
RS-812S
• Compact and reliable balanced piston first stage
• Two (2) H.P. ports and four (4) L.P. ports
• Breathing resistance adjustment knob
• Universal swivel hose
RS-811S
• Compact and reliable balanced piston first stage
• Two (2) H.P. ports and four (4) L.P. ports
• Venturi adjustment lever
• A.F.S. Advanced Flow System
RS-681
• Ultra-compact balanced diaphragm first stage
• Two (2) HP and four (4) LP ports
• Elliptical low-profile case design
• S.E.A. – Sequential Exhaust Assist technology (Pat P.)
• Balanced diaphragm first stage with anti-freeze system
• Two (2) H.P. ports and four (4) L.P. (2 high flow / 2 standard) ports
• Pneumatically balanced system
• Venturi adjustment lever R-700 DIN N/A AUS
SS0002
• Downstream alternate air source
• Air balanced power inflator
• Large diameter purge button
• Low profile mouthpiece
SS-11
• Lightweight, compact composite case design
• Left or Right hand configuration
• Venturi adjustment lever
• Ortho-consciously designed mouthpiece
• Lightweight demand valve second stage
• Large diameter purge button
• Venturi breathing adjustment lever
SS-60
• Lightweight demand valve second stage
• Left and right hose layout compatibility
• Venturi breathing adjustment lever
BUOYANCY COMPENSATORS
3-D Hybrid Cubic Air Cell
A.P.A. Compatible (Active Purge Assist)
A.W.L.S. (Advanced Weight Loading System)
A.W.L.S. II
(Advanced Weight Loading System)
Back Plate
BCJ Donut Bladder
Dual Tank
Independent Harness System
RiteTite Buckle
Ultimate Stabilizing Harness
Waist Support System
FEATURES
/ 420D Nylon
Cordura
Nylon
Cordura
Nylon
Cordura
3-D Hybrid Cubic Air Cell
The 3-D Hybrid Cubic Air Cell combines the features of a wrap-around style BCJ and a back-inflation BCJ into a unique streamlined hybrid design. The air cell offers increased lift capacity over standard back-inflation jackets and a more streamlined, comfortable fit underwater and on the surface.
A.P.A. (Active Purge Assist)
Exclusive to TUSA, the Active Purge Assist is a pneumatically assisted power inflator. Using a piston, the power inflator activates a stainless steel cable connected to the shoulder dump valve. The APA assures a quick response when deflating air from the BC.
A.W.L.S. (Advanced Weight Loading System)
TUSA’s patented Advanced Weight Loading System (A.W.L.S.) allows the diver to insert weight into both left and right weight cartridges eliminating the need for a weight belt. Rear trim pockets combine with the A.W.L.S. to optimally balance the weight load on each TUSA integrated BC jacket.
A.W.L.S. II (Advanced Weight Loading System)
The 2nd generation A.W.L.S. continues to enhance TUSA weight integrated BC jackets by incorporating a newly designed ergonomic handle grip and quick-lock feature. Release the weight cartridges with ease by simply turning the handle grip vertically 90° in either direction.
Back Plate
The aluminum back plate design allows the user to dive with single or double tanks.
BCJ Donut Bladder
The Donut Bladder creates a circular air ring providing more stability and control for the user. The air can move around the bladder as the diver shifts and moves in the water improving diver buoyancy.
Dual Tank
The Dual Tank feature allows for twin tank configuration.
Independent Harness System (I.H.S.)
The Independent Harness System isolates the BC jacket’s harness from the air cell, tightly supporting the tank even with changes in air cell inflation/deflation. The I.H.S. prevents tank slippage and eliminates any gaps between the tank and your back.
RiteTite Buckle
The RiteTite Buckle is a 2-position cam strap for quick and easy adjustment. While the strap is being looped through the buckle, the buckle stays in place without needing to be held. This allows for more control and stability. This feature is part of all TUSA BCJ’s.
Ultimate Stabilizing Harness (U.S.H.)
TUSA’s Ultimate Stabilizing Harness completely eliminates tank roll and delivers an amazing fit. The U.S.H. securely holds the air cylinder in place with optimally placed rails and brings the tank closer to the body increasing tank control while reducing weight.
Waist Support System (W.S.S.)
The Waist Support System significantly enhances comfort and fit by dispersing the weight load around the hips. The W.S.S. integrates the adjustable shoulder harness system with the rear stabilizing plate and cummerbund to effectively unload the hips while ensuring a snug fit.
BC0201B without A.P.A. (Tilt)
BC0201C with A.P.A.
• Hybrid 3-D Bladder design
• NEW - Harness System provides ultimate tank stability and unsurpassed buoyancy control
• NEW - Advanced Weight Loading System (A.W.L.S. II)
• Resin D-Rings (4)
BC0601
• Ultimate Stabilizing Harness
• 2 Large hook and loop fastener Pockets
• Quick Inflate/Deflate System
• Resin D-Rings (4)
• NEW - Ultimate Stabilizing Harness
• Low profile wrap-around bladder
• 3-Dimensional foam padded lumbar and back pad area
• NEW - A.W.L.S. II Advanced Weight Loading System
BC0501B
• Fully featured rear inflation tech style BC
• Aluminum Back Plate and Tank Plate Design
• Quick change Dual Tank system
• Adjustable shoulder belt system
• Ultimate Stabilizing Harness
• 2 large double zippered pockets
• A.W.L.S. Advanced Weight Loading System
• 2 dump valves (OPEV + 1)
BCJ-4000
• 3-Dimensional foam padded lumbar and backpad area
• Deep padded shoulder straps provide excellent comfort
• 4 zippered pockets: 2 large and 2 lower accessory
• Integrated Console Sleeve for routing of gauges
BCJ-8000C
• Fully featured rear inflation tech style BCJ
• Independent Harness System
• A.W.L.S. II integrated weight-loading system
• Removable roll out mesh accessory pocket
BCJ-1800
• Weighs 4.4lbs / 2kg, designed for travel
• 2 main 3-D mesh pockets and 1 lower accessory zippered pocket, console sleeve
A.P.A.
Active Purge Assist
• Revolutionary pneumatic assisted purge system for TUSA BCJ’s
• Increased flow rates (inflate/ deflate) for better performance over standard inflators
• Newly designed OPEV immediately responds to user input
INSTRUMENTS
Altitude
Water
3 Gas Mix
This advanced feature allows the diver to preset three individual gas mixtures (Mix 1, Mix 2, Mix 3) from 21-100% for easy switching during the dive as necessary.
2 Gas Mix
This feature allows the diver to preset two Nitrox gas mixtures (Mix 1 and Mix 2) for easy switching during the dive as necessary. Mix 1: 21 to 50%, Mix 2: 21 to 99%.
Air Integration
TUSA’s Zen Air Integration technology allows a diver to monitor depth, dive time and up to 3 tank pressures accurately and safely in a single glance. The need for bulky analog gauge consoles is gone. TUSA’s alphanumeric digital display conveys air data efficiently each updated second.
Altitude Smart Mode
The Altitude Smart Mode allows the computer to automatically adjust for altitude diving.
Audible Alarm
TUSA’s computers feature Audible And Visual Alarms for the most important dive data warnings. Ascent rate, maximum depth, no decompression limits, safety stop and several other key data can be set to alert the diver.
Backlit Display
Several TUSA computer instruments feature a Backlit Display for night diving or low-light situations. The bright backlight is activated by a touch of a button and the duration can be set for up to 10 seconds in length enabling the diver to view critical dive data easily and quickly.
Dual Time Display
Dual Time Display offers two time zones to be displayed simultaneously on the LCD.
Free Dive Mode
The Free Dive Mode calculates dive times and surface intervals for free diving.
Hoseless Transmitter
Hoseless Transmitter technology combines the accuracy of air integration with wireless data transmission resulting in a next generation ultra-compact wrist-top dive computer – the Zen Air.
Optional Deep Stop
An optional safety stop on No Deco dives exceeding a depth of 80 feet.
PC Downloadable
TUSA’s PCLogbook, TUSA DataLog PC, and DiverLog Mac interfaces allow the diver to transfer complete log and profile history from the dive computer to a personal computer or upload user settings to the computer. A PC interface unit is sold separately.
Step-Back Feature
The Step-Back Feature allows user to navigate forward or backward through the menus.
User Replaceable Battery
Convenience and ease-of-maintenance is imperative in the design of today’s dive computer. Each of TUSA’s computers offer a userfriendly replaceable battery that can be changed on a moment’s notice using standard widely-distributed batteries.
IQ-950
• Advanced air-integrated hoseless watch computer
• Air, Nitrox, Gauge, Free Dive, and Watch Operating Modes
• 3 Gas Mix Feature: Mix 1 (Air, 21-50%), Mix 2 (21100%), Mix 3 (21-100%)
• Hoseless Switching Technology to monitor up to 3 transmitters
IQ1201
• Advanced 2 gas watch computer
• Air, Nitrox, gauge, Free Dive, and Watch Operating Modes
• 2 mix switch feature
• Dual time capable
IQ-950-030 Transmitter
IQ-750
• Advanced 2 button puck-style module in wrist boot
• Air, Nitrox, and Gauge Operating Modes
• 2 Mix Switching Feature: Mix 1 (Air, 21-50%), Mix 2 (Air, 21-100%)
• Deep Stop Feature and Safety Stop
IQ-650
• Single button puck-style module in wrist boot
• Air and Nitrox (21-50%) Operating Modes
• Deep Stop Feature and standard Safety Stop
• User-replaceable battery with hot-swap (Battery: CR2450, 3V)
SCA-282
2 Gauge
• IQ-750 Element II computer module
• 5000psi/400bar (4350psi/300bar max) pressure gauge
• Luminescent dial is easy to read in dark or low visibility
• Available in Metric (SCA-282E) or Imperial (SCA-282U)
SCA-281
2 Gauge
• IQ-650 Element computer module
• 5000psi/400bar (4350psi/300bar max) pressure gauge
• Rental unit reset option
• Available in Metric (SCA-281E) or Imperial (SCA-281U)
SCA-362
3 Gauge
• IQ-750 Element II computer module
• 5000psi/400bar (4350psi/300bar max) pressure gauge
• Luminescent dial is easy to read in dark or low visibility
• Compass module equipped ratcheting bezel and top or side-view
SCA-361
3 Gauge
• IQ-650 Element computer module
• 5000psi/400bar (4350psi/300bar max) pressure gauge
• Compass module equipped ratcheting bezel and top or side-view
• Single button puck-style module in wrist boot
SCA-360
3 Gauge
• Low-profile 3 gauge analog console includes a depth gauge, high-pressure gauge and compass
• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge
• Compass module equipped with ratcheting bezel and top or side-view
SCA-330T
EUR Only
• Mini 3 gauge console includes a depth gauge, high-pressure gauge and compass
• Luminescent dial is easy to read in dark or low visibility
• 400bar pressure gauge
• 70m depth gauge
SCA-280 2 Gauge
• Compact 2 gauge analog console includes a depth gauge and a high-pressure gauge
• Luminescent dial is easy to read in dark or low visibility
• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge
SCA-230T
EUR Only
• Mini 2 gauge console includes a depth gauge and high-pressure gauge
• Luminescent dial is easy to read in dark or low visibility
• 400bar pressure gauge
• 70m depth gauge
SCA-270 SPG Combo
• Compact 2 gauge console includes a high-pressure gauge and compass
• Luminescent dial is easy to read in dark or low visibility
• 5000psi/400bar (4350psi/300bar max) pressure gauge and 200ft/60m depth gauge
SCA-110T
EUR Only
• Luminescent dial is easy to read in dark or low visibility
• 5000psi/400bar (4350psi/300bar max) pressure gauge
• Gauge boot includes rings for attachment of BCJ hooks, etc.
• Available in Metric (SCA150E) or Imperial (SCA150U)
SCA-160 Compass
• Mini size, lightweight and reliable design
• Streamlined, low drag
• Luminescent dial face
• 400bar pressure guage (350bar max)
N/A AUS
• Durable boot with strap
• Lockable bezel with side window for easy reading
• Luminescent dial face
• Colors: Black
Freedom Technology
180O Buckle System
3-D Strap
Angle Strap Adjustor
A/R Lens
Corrective Lens
FEATURES
Quick-Adjust Buckle System
Round Edge Skirt
Treatment
Freedom Technology
Freedom Technology is a set of revolutionary features offering superior fit, comfort and increased performance in TUSA masks. Freedom model masks feature a dimpled skirt surface with varied silicone thicknesses and stability ridges in addition to a proprietary low-friction skirt surface on the fitting line.
180 Buckle System
The buckle rotates a full 180 degrees to accommodate varying head sizes for optimum fit. The thin frame and rotation of the buckle allows the mask to be folded into a compact size.
3-D Strap
TUSA’s patented 3-D Strap is a true three-dimensional design that snugly fits against the head’s natural curvature. The 3-D strap offers unprecedented comfort and fit unlike standard flat mask straps.
Angle Strap Adjustor
The Five (5) Angle Strap Adjustor allows for a five position microadjustment on both the left and right sides of the mask. This enables vertical (up/down) and horizontal (left/right) pressure on the face to be delicately adjusted for the optimum fit.
Anti-Reflective (A/R) Lens Treatment
TUSA’s Anti-Reflective (A/R) Lens Treatment decreases internal and external reflected light. This reduction increases light transmission to 95% resulting in significantly enhanced color, clarity, contrast and better overall vision underwater.
Corrective Lens
Corrective Lenses are offered on several styles of masks. This option allows the diver to choose right and left lens powers in both a variety of diopters for maximum flexibility and for a custom fit.
CrystalView Optical Glass
CrystalView Optical Glass lenses provide superior clarity, color and transmission of light over standard glass lenses used by the competition. CrystalView lenses are used in all PRO models masks and also in the M3001 and M-41 masks.
Hyperdry Purge
Clearing a mask has never been easier thanks to our patented Hyperdry System. Simply breathe out through your nose and any water that has accumulated in your mask is forced out through a one-way purge valve. Once the mask is clear, the valve seals shut.
FEATURES
Panoramic View
Panoramic View masks feature a variety of designs offering an incredibly wide field-of-view. Several designs incorporate minimum frame volumes, domed side-windows, reduced frame structures as well as three and four window styles for maximum vision.
Round Edge Skirt
TUSA’s Round Edge Skirt features a proprietary round edge cross-sectionally shaped skirt. This rounded edge results in a soft fit that suppresses pressure and reduces creasing left on the face. The “planar fit, instead of linear fit” silicone skirt maintains great fit and unprecedented comfort.
Quick-Adjust Buckle System
The Quick-Adjust Buckle System incorporates a newly-designed low-profile buckle. The result is a compact, lightweight, technologically advanced mask design that can be easily and quickly adjusted for a perfect fit.
UV Lens Treatment
TUSA’s UV Lens Treatment provides 100% protection from harmful UVA and UVB rays. Blocking 100% of the ultraviolet spectrum (under 400nm) provides greater eye protection without sacrificing light transmission or vision.
Revolutionary Features for Optimum Performance [M1001 and M1003]
Parts Stainless steel allows for a slim design while providing stability and security.
The Five (5) Angle Strap Adjuster rotates a full 180O and allows for microadjustments, which accommodates varying head sizes while reducing face pressure, maintaining optimum fit, and preventing unnecessary damage to the buckle.
Metal
Freedom Buckle
M1001 Only
Special
Features of
A set of revolutionary new features enhancing mask fit, comfort and performance!
Each person has a unique facial structure and every diver experiences either some level of discomfort, or “pressure” and “squeeze” while wearing a typical mask underwater. TUSA engineers wanted to solve these problems and spent several years analyzing mask fit, facial bone structure and mouth movement. The result is Freedom Technology, a set of revolutionary new mask features which deliver superior fit, comfort and increased performance. Experience Freedom today.
Dimpled Skirt:
Key areas around the forehead and cheek bones have been designed with dimples which combine to increase the skirt’s softness, flexibility and skin surface contact. This also greatly reduces leakage and enhances comfort.
Varied Silicone Thickness:
When in usage, a regulator or snorkel mouthpiece can distort areas of the nose pocket and mouth section causing leakage and discomfort.
Stability Ridges:
As water pressure increases a mask will compress inwards toward the face often causing further leakage. Areas under the cheek bones have been reinforced with stability ridges to minimize this compression maintaining ideal skin surface contact.
Freedom Dry enhances comfort and fit by utilizing a revolutionary low friction skirt surface.
The skirt fitting line (shown in red) features a low friction surface that delivers a superior seal and increases the facial area contact patch while significantly reducing excess skin tension. The result is a soft and supple feeling mask with a dramatically improved seal.
M1002QB
BK
• Low profile 1-window design
• Equipped with Freedom Technology
• Crystal accent
• Accessory dock for personalization
M3001
M3001QB
• Ultra-wide panoramic view
• New domed side windows reduce blind spots
• Equipped with Freedom Technology
• Skirt mounted Quick-Adjust Buckle System
M1002 Accessory
TUSA M1002 Tina mask includes a stylish accessory for you to decorate your mask. You can also replace and install any earphone jack compatible accessories for mobile phones. There are a variety of choices such as injack, string, non-metal chain, etc.
M1003QB
• Wide field of view single lens
• Equipped with Freedom Technology
• 180° Rotational Buckle System
• 3-D mask strap
M1001
M1001QB
• Incredibly wide field of view
• 180° Rotational Buckle System
• Large frame with minimal internal volume
• Five-position strap angle adjuster for micro-adjustment
• Low profile 4-window teardrop design
• Equipped with Freedom Technology
• CrystalView Optical Glass lenses
• Skirt mounted Quick-Adjust Buckle System
M-211
• Low profile, low-volume 2-window teardrop design
• Equipped with Freedom Technology
• Skirt mounted Quick-Adjust Buckle System
• PRO Version (M-211S) with CrystalView AR/UV lenses
M-211SQB
• Low profile, low-volume 2-window teardrop design
• Equipped with Freedom Technology
M-111
M-111QB
• Low profile 1-window design
• Round-edge skirt for maximum fit and comfort
• Skirt mounted Quick-Adjust Buckle System
• Fits small to medium size faces, ideal for youth M-212SQB
• Accepts MC-7500 Corrective Lenses and ML-7500S AR/UV lenses
• PRO Version (M-212S) with CrystalView AR/UV lenses
M-28QB
MDR MS
• Lightweight composite frame for enhanced grip and shock protection
• Low profile, low volume 2-window design
• Skirt mounted Quick-Adjust Buckle System
• Accepts MC-7500 Corrective Lenses
M-31
• 168° panoramic view through 1-window lens
• Patented domed side windows
• Reduced frame structure to reduce blind spots
• Five-position strap angle adjustor for micro-adjustment
M-210QB
• Low profile, 1-window teardrop design
• TUSA CrystalView Optical Glass Lens (pat p.)
• Anti-Reflective and UV Lens Treatments
• Special Edition Chrome Frame
M-32
• 3-window design with enhanced panoramic view and peripheral vision
• Hyperdry System for ease of mask clearing
• Round-edge skirt for maximum comfort and fit
• Low volume design for snug fit and easy clearing
• Low profile 2-window design for freediving/spearfishing
• Extremely wide field-of-view for compact design
• Low internal volume (approx 120cm³/7in³)
• Wide nose pocket area for fast equalization with 5mm gloves
TM-5700Q
• 2-window design with wide field of front vision
• Low volume design for snug fit and easy clearing
• Corrective lenses available (MC-5000)
MC-7500
Corrective Lenses for M-212/M-28
MC-5000 L/R
Corrective Lenses for TM-5700Q
• -1.0, -1.5, -2.0, -2.5, -3.0, -3.5, -4.0, -4.5, -5.0, -5.5, -6.0, -6.5, -7.0, -7.5, -8.0, +1.0, +1.5, +2.0, +2.5, +3.0, +3.5, +4.0, +4.5 • -1.0, -1.5, -2.0, -2.5, -3.0, -3.5, -4.0, -4.5, -5.0, -5.5, -6.0, -6.5, -7.0, -7.5, -8.0
FREEDOM FILM
TA-200A
The TA-200A and TA0801 anti-fog films will keep your favorite mask fog-free while diving underwater. Made with long-lasting durable material, the Freedom Film can be installed easily, and is reusable with proper care. TA-200A is for any 2-window, and TA0801 is for 1-window mask.
• Easy installation
• Prevents fogging
• Reusable
• Easy to clean
• Long-lasting durable material
TA0801
SP0101 SP-170 SP-580 SP-300
SP0101QB SP-170QB SP-580QB SP-121QB
FEATURES
Comfort Swivel
High Flow Purge
Hyperdry Elite Top
Hyperdry System -
Comfort Swivel
The Comfort Swivel adapter makes it possible to slip the mask strap into the slit with no hassles. The two-part construction allows the snorkel to rotate and can be attached in a horizontal position.
High Flow Purge
The High Flow Purge design used on TUSA snorkels offers a covered large diameter purge valve for simple, quick clearing, reducing the amount of water remaining in the mouthpiece in an instant.
Hyperdry Elite Dry Top
A more refined and streamlined version of the Hyperdry MAX, the Hyperdry Elite maintains the same superior dry performance and keeps the snorkel completely void of water by quickly and efficiently closing the gasket when submerged or hit by waves.
Hyperdry System
The Hyperdry System keeps the main pipe dry by ejecting water through an independent escape pipe. This unique design utilizes the angle of the snorkel pipe and the resilience of the water surface to eject water.
SP0101QB
• Low profile dry top keeps water out
• Ortho-consciously designed mouthpiece for comfort and reduced jaw fatigue
• Angled purge chamber for efficient and easy clearing
• Detachable two-section swivel adapter for free movement
SP-170
SP-170QB
• Hyperdry system with three current rectifying plates
• High flow and angled purge valve
• Ortho-consciously designed mouthpiece for ultimate comfort
• Detachable two-section swivel adapter for free movement
SP-580QB
• Hyperdry System
• Large capacity drain chamber and oval purge valve with internal purge channel
• Ortho-consciously designed mouthpiece for ultimate comfort
• Crystal silicone flexible neck
SP-300
SP-121QB
USA Only BK
• Hologram top reflector for high visibility
• Large capacity drain chamber for easy clearing
• Hypo-allergenic high grade silicone mouthpiece for ultimate comfort
• Crystal silicone flexible neck
• Orange hologram top reflector for high visibility
• Cross cut bore design for easy clearing
• Hypo-allergenic high grade silicone mouthpiece for ultimate comfort
Active Pivoting System
The combination of uniquely positioned holes that reduce drag while maintaining constant propulsion and the built-in fin stop creates a soft kick that produces great power.
TUSA Direct Reflect
Enhanced Foot Pocket
FEATURES
Anatomic Fin Strap Compatible Compatible
Bungee Strap Compatible Compatible - Compatible Compatible
Active Pivoting System
Angled Blade Design
EZ Strap and Buckle System
ForcElast Technology
Propeller Technology
TUSA Direct Reflect
US (M) US (F) EUR CM
Active Pivoting System
The combination of uniquely positioned holes that reduce drag while maintaining constant propulsion and the built-in fin stop creates a soft kick that produces great power.
Anatomic Fin Strap
TUSA open-heel fins are equipped with a newly designed Anatomic Fin Strap (AFS). The AFS is anatomically shaped to offer a balance of flexibility and control to increase comfort, power transfer and to significantly reduce heel slippage found in many standard flat fin straps.
Angled Blade Design (A.B.D.)
The Angled Blade Design accommodates for this anatomical characteristic and ensures maximum efficiency throughout the kicking cycle.
Bungee Strap
The heavy duty elastic fin strap provides easy donning and doffing of fins. The quick adjustment accommodates 3 sizes S, M, and L.
SIZE CHART
9-11 10.5-12 44-45 27-27.5
12-13 13.5-15
EZ Strap and Buckle System
TUSA’s EZ strap and Buckle System allows fins to be quickly and easily adjusted with minimal effort. Adjustment can be made while the fins are worn, allowing for a precise fit and ease of removal when necessary.
ForcElast Technology
A proprietary thermoplastic elastomer (TPE) compound precisely positioned in an advanced blade and foot pocket structure. FoceElast delivers superior propulsion, efficiency and speed even with moderate power input. ForcElast technology is found in TUSA high performance fins like the SF-22 and FF-23.
Propeller Technology
TUSA’s advanced split fins employ Propeller-Fin™ Technology, which delivers ultra-high performance with a low amplitude rapid flutter kick. As the fin moves through the water its two wing-shaped surfaces create lift and forward propulsion like a propeller. Efficiency is increased while drag and effort is reduced.
TUSA Direct Reflect
This advanced reflective material brightly reflects 180° back to the original light source. Providing high visibility in low light conditions.
• Powered by APS “Active Pivoting System”
• NEW - TUSA Direct Reflect keeps you visible in low light or at night
• Newly designed “Comfort Foot Pocket” enhances performance
• Standard with Universal Bungee Strap (TA0902)
SF0102
• Advanced Multi-Flex Blade design
• Two-material design for high performance
• 20° Angled Blade Design (A.B.D.)
• EZ Strap and buckle system
• Powered by ForcElast Technology
• 20° Angled Blade Design (A.B.D.)
• Multi-compound foot pocket increases power transfer to the fin blade
• Standard with Anatomic Fin Strap (A.F.S.)
FF-23
• Full foot version of SF-22 Solla
• Powered by ForcElast Technology
• 20° Angled Blade Design (A.B.D.)
• Three channel blade with crescent tip maximizes propulsion
• Three material design for increased performance compared to standard split fins
• 27° Angled Blade Design
• Enhanced propeller-fin technology optimizes efficiency
TA0902
Universal Bungee Strap
• Adjustable bungee strap
• Non-Vented hyrodynamic design for maximum propulsion
• Balanced Flexibility gives powerful propulsion without fatigue
• Easy-to-adjust strap features quick release buckles
• Accommodates 3 different sizes (S, M, and L)
• Will fit on most open heel fins available on the market
• Rubber heel grip with finger loop for easy fit
TA-81
Universal Spring Straps
• Will fit on most open heel fins available on the market
• Fit automatically adjusts to changing conditions
• Durable stainless steel coil spring will not rust or break
• Rubber heel grip with finger loop for easy fit
ACCESSORIES
SAV-7 EVO2
• Speed: 0 - 2.8 mph / 4.5 km
• Range in Open Water: 4.5miles / 7200m
BA0102
Mesh Backpack
• 100% Nylon with rubberized mesh
• Large front pocket with hook and loop fastener closure
• Padded shoulder straps and carrying handle
• Large internal zippered pocket
RD-2
Roller Duffel Bag
• Run Time in Open Water: 120 minutes
• Battery Type: Lithium-Ion
BA0201
Roller Bag
• 6,100 cubic inches of storage
• Expandable heavy duty pull handle
• 2 internal zippered pockets
• Heavy duty, smooth gliding wheels
RMB-1
Mesh Roller Bag
• Water resistant back
• One Carrying handle
• Large outer double-zippered pocket
• Heavy duty, smooth gliding wheels
• 5,600 cubic inches total storage space
• Adjustable shoulder strap
• Side zippered accessory pocket
• Heavy duty wheels and zippers
Saddle
L.E.D. Battery Indicator
SB-2 (RCB-1)
Regulator Carrying Case
• Fully lined with thick padding
• Durable zipper with pull tabs
• Internal pocket for log / manuals
• Shoulder strap included
TUL-600
LED Light
• 600 lumens
• Compact lightweight design
• Beam Angle: 12 degrees
• 3 Power Levels with LED Indicator: 100%, 50%, 25%
MS-20
Mask Strap Cover
Mesh Backpack
• 100% nylon with mesh details
• Adjustable shoulder straps
• Water resistant back
• Mesh drain grommets located on bottom
TUL-400
Compact LED Light - Wide Beam
• 165 Lumen high-powered LED
• Beam Angle: 60 degrees
• 3 Power Levels: 100%, 30%, Strobe
• Run Time: 100%: 120 mins, 30%: 420 mins
TEC-52A
• Enhances comfort and fit
• Attaches over standard mask strap
• Made from durable neoprene
• Hook & loop fastener
Waterproof Bag
• Tough, nylon-reinforced, PVCconstruction
• Large easy-to-access top opening
• Roll down and quick-snap closure top
• Rectangular shaped base
TUL-410
Compact LED Light - Spot Beam
• 220 Lumen high-powered LED
• Beam Angle: 5-7 degree spot beam
• 3 Power Levels: 100%, 30%, Strobe
• Run Time: 100%: 120 mins, 30%: 420 mins
Super Anti-Fog Treatment
• Non-irritating solution
• Long lasting
• High viscosity coat-on type
TEC-52A
MDR MS
• 6-4Ti (Ti-6Al-4V) highly corrosion resistant titanium drop point blade
• Newly designed ergonomic grip with counterweight
FK-14
MDR MS
• 6-4Ti (Ti-6Al-4V) highly corrosion resistant titanium drop point blade
• A serrated edge
• Locking Sheath
• Blade Length: 2 7/8” / 7cm
DG-5600
• 420 Stainless Steel blade
• Ergonomic grip with counterweight
• Includes a serrated edge plus a line cutter
FK-11/10
• A serrated edge plus a line cutter (FK-11 only)
• Sheath locking tab holds knife securely in place, then releases at a touch
DG-5100
Tropical Glove Warm Water glove
SIZES XS - XL SIZES XS - XL
• Soft stretchable poly mesh backing for added comfort
• 2.0mm neoprene backing for added comfort and warmth
• Disassembling capability for easy cleaning and maintenance
• Includes a serrated edge plus a line cutter
SIZES 4 - 13
*Size 4 = N/A USA
• Injection molded sole with super traction
• 5.0 mm neoprene/nylon jersey
SIZES 4 - 13
• Injection molded sole with super traction
• 3.0 mm neoprene/nylon jersey
FEATURES
PRO series
The PRO series features the latest designs and innovations including 100% Crystal Silicone, ClearVu tempered glass and the Hyperdry Elite Dry Top snorkel technology. Designed for performance.
ELITE series
Featuring 100% Crystal Silicone, ClearVu tempered glass and the Hyperdry Semi-Dry Top snorkel technology, the Elite series offers excellent performance and value.
ADVANCED series
Silicone, ClearVu tempered glass for the entry-level watersports enthusiast.
ClearVU Tempered Glass ClearVu tempered glass lenses provide superior clarity, color, transmission of light and safety over standard glass.
Crystal Silicone
Made from Hypoallergenic 100% pure surgical grade crystal silicone offering unsurpassed comfort, fit and performance. It resists stretching and fatigue from extended use, reducing leakage and the need for replacement.
EZ Strap and Buckle System
Allows masks to be quickly and easily adjusted with minimal effort. Allowing for a precise fit and ease of removal when necessary.
FEATURES
High Flow Purge
A large diameter purge valve for simple, quick clearing, reducing, the amount of water remaining in the mouth-piece.
Hyperdry Elite - Dry Top
The latest innovation in dry snorkel technology utilizing an independent high buoyancy float for superior dry performance. This keeps the snorkel completely dry by quickly and efficiently closing the tube opening.
Hyperdry Semi - Dry Top
Keeps the main snorkel pipe dry by ejecting water through an independent escape pipe.
Protective Mouth-Piece Cover
Helps to maintain and extend the life of the snorkel’s mouthpiece.
Travel Friendly Blade Design
A compact blade design allows your snorkel gear to be an easy and light travel option. Giving you more flexibility when packing for your next adventure.
UC-3125QB
Visio Tri-Ex Adult Combo
Mask UM-31
Snorkel USP-250 Elite Dry
UC-1625QB
Serene Adult Combo
Mask UM-16
Snorkel USP-250 Elite Dry
UC-2014
Mini-Kleio Youth Combo
Mask UM-2000
Snorkel USP-140 Hyperdry
UC-1214
UC-2022
Mini-Kleio Youth Dry Combo
Mask UM-2000
Snorkel USP-220 Elite Dry
Mini Platina Youth Combo
Mask UM-12
Snorkel USP-140 Hyperdry
UC-7519
Splendive Adult Combo N/A USA
Mask UM-7500
Snorkel USP-190 Hyperdry
Capri Adult Combo
Mask UM-25
Snorkel USP-460 Hyperdry
SK
UC-2425
Powerview Adult Dry Combo
Mask UM-24
Snorkel USP-250 Elite Dry
Imprex 3-D Dry Adult Combo
UC-3325 BKBK BKFY CLB
Mask UM-33
Snorkel USP-250 Elite Dry
SK
UC-5019
Powerview Adult Dry Combo
Mask UM-5000
Snorkel USP-190 Hyperdry
BKBK CLB SK
UC-2112
UA0510
Panthes Adult Combo Universal Optical Frame and Lens
Mask UM-210
Snorkel USP-121 Cross-cut Bore
• Universal optical frame with corrective lenses for TUSA Sport masks
• Available only as assembled with a frame and a pair of same diopter lenses
• -2.0, -3.0, -4.0, -5.0
UP-3521QB
UP-1521QB
UP0101
UP-2521B
• Soft, full foot pocket design
• Hydrofoil design and hybrid ribs produce greater forward propulsion
• Vented blade design reduces fatigue
UF0103
UF-21
• Travel-friendly short blade design
• Soft comfortable open-heel foot pocket with adjustable silicone strap
• Enhanced rib design and multi-compound blade for extra power
RF-20
• 20 degree Angled Blade Design for maximum efficiency and propulsion
• Open-toe full foot pocket provides superb comfort and support
• Advanced Multi-Flex long blade design
• Thrust Channel Technology
• Maximum propulsion and comfort
• Soft comfortable open-heel foot pocket with adjustable silicone strap
FF-19
• Innovative hydrofoil design and hybrid rib produce greater forward motion (lift) both on the surface and underwater
• Propeller-fin technology and super lightweight design to achieve the ultimate performance
Sport Fin
Snorkel Fin
Platina Full Foot Fin
Propeller Fin
Long Blade Snorkel Fin
SV-2500 SV-4500
Snorkeling Vest - Youth Snorkeling Vest - Adult
• High-visibility yellow air cell
• Quick-release buckles on back and crotch snap
• 6” inflator valve for easy operation
• Compact for easy storage during travel
RTB-7
Snorkeling Backpack
• 100% nylon with mesh details
• Adjustable shoulder strap
MBP-1
Mesh Backpack
• 100% nylon with mesh details
• Adjustable shoulder straps
• Water resistant back
• Mesh drain grommets located on bottom
US 3 - 13
EUR 28, 30, 32, 34, 35-45
• Great for beach, pool, boats or any watersports activity
• Quick-drying jersey and mesh upper
• Quick-adjust pull lace closure system
Mask and Snorkel Combo Set
and Fin Travel Set
Cozumel is Mexico’s third largest island, located in the Caribbean Sea, and known to be one of the best places in the world to practice scuba diving because of its warm, crystal clear, and turquoise blue color waters.
elite Dive Center is the first one on the island to offer international standards of service, quality, and professionalism for you and your family to have fun and enjoy your vacation safely.
• reCreational Diving
• CertifiC ation Diving Courses
• unDerwater viDeos anD P hotos
• sP eCial events
• teChniC al Dive
• rebreather
TUSA (TABATA USA, INC.)
2380 Mira Mar Ave., Long Beach, CA 90815 U.S.A.
Toll Free: 800-482-2282 T: 562-498-3708 F: 562-498-1390 (Country Code: 1) info@tusa.com
TABATA CO., LTD. JAPAN
1-3-17, Higashikomagata, Sumida-ku, Tokyo, Japan 130-0005 T: 03-3624-2816 F: 03-3623-9902 (Country Code: 81) www.tabata.jp
TABATA MFG. JAPAN (IBARAKI FACTORY)
651-2 Industrial Park, Hitachiomiya City, Ibaraki, Japan 319-2134 T: 02-95-53-3135 (Country Code: 81)
TABATA AUSTRALIA PTY. LTD.
4D James Ruse Business Park, 6 Boundary Road, Northmead, NSW 2152 T: (0)2-9890-4555 F: (0)2-9890-5222 (Country Code: 61)
T.E.C. (TABATA EUROPE CORPORATION) B.V. Den Brielstraat 2b, 1055RV, Amsterdam, The Nederlands T: 020-58-11-280 F: 020-58-11-285 (Country Code: 31)
TABATA MFG. (TAIWAN) CO., LTD.
54-8 Hsutsogang, Nankang Vil., Tayuan Hsiang, Tao Yuan Hsien, Taiwan R.O.C. T: 03-386-5100 F: 03-386-5103 (Country Code: 886)
