Adjustable Control Knob
The adjustable knob designed to better control breathing resistance.
Advanced Flow System
The advanced flow system allows ease of air flow and makes air delivery smoother due to the curved housing structure.
Ceramic Moisture Plate
The ceramic moisture plate prevents “dry mouth”. Condensation forms on the ceramic plate adding moisture to the dry air released from scuba cylinders.
Click Spring Adjustment
The click spring adjustment feature is exclusive to TUSA. It is a 5 position adjustment knob designed to better control breathing resistance.
Cold Water Ready
The cold water ready feature enables the diver to use the regulator in water temperatures below 50°F/10°C.
Environmentally Sealed 1st Stage
The use of a secondary diaphragm and piston sealing the 1st stage preventing contamination or freezing when the regulator is submersed in contaminated or freezing water.
Ortho-conscious Mouth Piece
The ortho-conscious mouth piece feature prevents jaw fatigue. The ridges and flexible material allow the diver to have more control of the mouth piece and reduces tension in the jaw.
Pneumatically Balanced 2nd Stage
A balance chamber added to the regulator 2nd stage, providing equal pressure to both sides of the LP seat greatly reducing inhalation effort.
Sequence Exhaust Assist System
The sequence exhaust assist system gives the diver less resistance when exhaling due to its unique double exhaust design. The diver experiences smooth breathing cycles reducing air consumption and fatigue.
Swivel Hose
The swivel hose gives maneuverability to the 2nd stage. The hose can rotate 360 degrees allowing it to move freely with the diver’s head motions.
Venturi Flow Adjustment
The venturi flow adjustment allows for ease of breathing by controlling the direction of air through the mouthpiece.
IR-3
The IR-3 is a second stage regulator and a power inflator combination.
RS-460II
RS-670 IR-3
RS-812
1st Stage
• Compact and reliable balanced piston first stage
• Instant delivery of air and high airflow for superior performance
• Two H.P. ports and four L.P. ports
2nd Stage
• Compact case design
• Ortho-consciously designed mouthpiece
• Breathing resistance adjustment knob
• Venturi adjustment lever
• A.F.S. Advanced Flow System
• Universal swivel hose
RS-811
1st Stage
• Compact and reliable balanced piston first stage
• Instant delivery of air and high airflow for superior performance
• Two H.P. ports and four L.P. ports
2nd Stage
• Compact case design
• Ortho-consciously designed mouthpiece
• Venturi adjustment lever
• A.F.S. Advanced Flow System
1st Stage
• Compact balanced diaphragm first stage
• Lightweight R-600 – 630g
• Two H.P. ports and Four L.P. ports
• EK-600 cold water kit available for temperatures below 50°F/10°C
2nd Stage
• Elliptical low-profile case design
• S.E.A. – Sequential Exhaust Assist System (Pat P.)
• Venturi adjustment lever
• Built-in moisture exchange plate
• Attached to MIFLEX® hose for exceptional flexibility
R-600 Options
EK-600 cold water kit (shown) - USA ONLY USA only
DIN-R600 conversion kit (300bar/4350psi)
1st Stage
• Balanced diaphragm first stage with anti-freeze system
• Dry ambient pressure chamber ideal for temperatures below 50°F/10°C
• Ribbed section to increase heat transfer and resist freezing
2nd Stage
• Lightweight, compact composite case design
• Pneumatically balanced system
• Venturi adjustment lever
• Ortho-consciously designed mouthpiece S-90
The RS-790 is available in a DIN version (300bar/4350psi)
1st Stage
• Compact and reliable balanced piston first stage
• Instant delivery of air and high airflow for superior performance
• Two H.P. ports and four L.P. ports
2nd Stage
• Lightweight compact case design
• Venturi breathing adjustment lever
• Left or right hose layout
• Ortho-consciously designed mouthpiece
RS-860 DIN - N/A in AUS
The RS-860 is available in a DIN version (300bar/4350psi)
1st Stage
• Over-balanced diaphragm first stage
• 2 high flow pressure ports, 1 standard L.P. and 1 H.P. port
• Cold water insulation system
• Available in DIN version as RS-460II DIN R-400 II
2nd Stage
• Lightweight compact case design
• Venturi breathing adjustment lever
• Left or right hose layout
• Ortho-consciously designed mouthpiece S-60
1st Stage
• Ultra-compact balanced diaphragm first stage
• Lightweight R-600 – 630g
• Two H.P. ports and Four L.P. ports
• EK-600 cold water kit available for temperatures below 50°F/10°C
2nd Stage
• Ortho-consciously designed mouthpiece
• Universal swivel hose joint
• Breathing resistance adjustment knob
The IR-3 is a downstream backup regulator that also provides you with easy-to-operate buoyancy control. The Inflator Regulator is positioned at the end of the buoyancy compensator hose -- the ideal location for quick, efficient use.
• Air balanced power inflator valve
SS-11
• Lightweight demand valve second stage
• Large diameter purge button
• Left and right hose layout compatibility
• 33inch/84cm hose length
SS-60
• Lightweight compact case design
• High-visibility yellow purge cover
• Venturi breathing adjustment lever
• 39in/99cm hose length
• Left or right hose layout
3-D Hybrid Cubic Air Cell
The 3-D Hybrid Cubic Air Cell combines the features of a wrap-around style BCJ and a back-inflation BCJ into a unique streamlined hybrid design. The air cell offers increased lift capacity over standard back-inflation jackets and a more streamlined, comfortable fit underwater and on the surface.
3-D Air Cell
The 3-D Cubic Air Cell allows for greater internal volume (lift) in a more compact and streamlined design. The 3-D cell increases diver comfort by expanding outwardly away from the body eliminating that "squeezed" feeling upon inflation. It also maximizes efficiency by keeping you more streamlined underwater.
A.P.A. (Active Purge Assist)
Exclusive to TUSA, the Active Purge Assist is a pneumatically assisted power inflator. Using a piston, the power inflator activates a stainless steel cable connected to the shoulder dump valve. The APA assures a quick response when deflating air from the BC.
A.W.L.S. (Advanced Weight Loading System)
TUSA's patented Advanced Weight Loading System (A.W.L.S.) allows the diver to insert weight into both left and right weight cartridges eliminating the need for a weight belt. Rear trim pockets combine with the A.W.L.S. to optimally balance the weight load on each TUSA integrated BC jacket.
A.W.L.S. II (Advanced Weight Loading System II)
The 2nd generation A.W.L.S. continues to enhance TUSA weight integrated BC jackets by incorporating a newly designed ergonomic handle grip and quick-lock feature. Load and release the weight cartridges with ease by simply turning the handle grip vertically 90° in either direction.
Back Plate
The aluminum back plate design allows the user to dive with single or double tanks.
BCJ Donut Bladder
The BCJ Donut Bladder creates a circular air ring providing more stability and control for the user. The air can move around the bladder as the diver shifts and moves in the water improving diver buoyancy.
Dual Tank
The dual tank feature allows for twin tank configuration.
Independent Harness System
(I.H.S.)
The Independent Harness System isolates the BC jacket's harness from the air cell, tightly supporting the tank even with changes in air cell inflation/deflation. The I.H.S. prevents tank slippage and eliminates any gaps between the tank and your back.
RiteTite Buckle
The RiteTite Buckle is a 2-position cam strap for quick and easy adjustment. While the strap is being looped through the buckle, the buckle stays in place without needing to be held. This allows for more control and stability. This feature is part of all TUSA BCJ's.
Ultimate Stabilizing Harness (U.S.H.)
TUSA's Ultimate Stabilizing Harness completely eliminates tank roll and delivers an amazing fit. The U.S.H. securely holds the air cylinder in place with optimally placed rails and brings the tank closer to the body increasing tank control while reducing weight.
Waist Support System (W.S.S.)
The Waist Support System significantly enhances comfort and fit by dispersing the weight load around the hips. The W.S.S. integrates the adjustable shoulder harness system with the rear stabilizing plate and cummerbund to effectively unload the hips while ensuring a snug fit.
IR-3
The IR-3 is a second stage regulator and a power inflator combination.
JACKET LINE-UP
BC0501B
BC0101B
FABRICS • DUMP VALVES
M/L (67 lbf.=30.6 kgf.=300N)
XL/XXL (67 lbf.=30.6 kgf.=300N)
Fabrics: 840D Nylon
Dump Valves: 4 (O.P.E.V.+3)
XS (18 lbf.=8.2 kgf.=80N)
S (22 lbf.=10.2 kgf.=100N)
M (31 lbf.=14.3 kgf.=140N)
L (38 lbf.=17.3 kgf.=170N)
XL (46 lbf.=21 kgf.=205N)
Fabrics:
Out side: 500D Cordura® Nylon
Inner side: 420D Nylon
Dump Valves: 2 (O.P.E.V.+1)
BCJ-8000C
BCJ-4000
BCJ-7000C
BCJ-9300C BCJ-9300 FOR WOMEN
BCJ-1800
BCJ-6910
S (29 lbf.=13.3 kgf.=130N)
M (29 lbf.=13.3 kgf.=130N)
L (40 lbf.=18.4 kgf.=180N)
XL (40 lbf.=18.4 kgf.=180N)
Fabrics: 500D Cordura® Nylon
Dump Valves: 4 (O.P.E.V.+3)
XS (24 lbf.=10.7 kgf.=105N)
S (29 lbf.=13.3 kgf.=130N)
M (36 lbf.=16.3 kgf.=160N)
L-XL(44 lbf.=19.9 kgf.=195N)
Fabrics: 500D Cordura® Nylon
Dump Valves: 3 (O.P.E.V.+2)
XS-S(37 lbf.=16.8 kgf.=165N)
M (37 lbf.=16.8 kgf.=165N)
L (50 lbf.=22.4 kgf.=220N)
XL (50 lbf.=22.4 kgf.=220N)
Fabrics: 840D/420D Nylon
Dump Valves: 4 (O.P.E.V.+3)
XS (19 lbf.=8.7 kgf.=85N)
S (24 lbf.=10.7 kgf.=105N)
M (28 lbf.=12.8 kgf.=125N)
L (32 lbf.=14.3 kgf.=140N)
Fabrics: 840D/420D Nylon
Dump Valves: 3 (O.P.E.V.+2)
XS (16 lbf.=7.7 kgf.=75N)
S (21 lbf.=9.2 kgf.=90N)
M (25 lbf.=11.2 kgf.=110N)
L-XL (33 lbf.=14.8 kgf.=145N)
Fabrics: 840D/420D Nylon
Dump Valves: 2 (O.P.E.V.+1)
XS (32 lbf.=14.3 kgf.=140N)
S (32 lbf.=14.3 kgf.=140N)
M (32 lbf.=14.3 kgf.=140N)
L (32 lbf.=14.3 kgf.=140N)
Fabrics: 420D Nylon
Dump Valves: 4 (O.P.E.V.+3)
XS (18 lbf.=8.2 kgf.=80N)
S (23 lbf.=10.2 kgf.=100N)
M (32 lbf.=14.3 kgf.=140N)
L (38 lbf.=17.3 kgf.=170N)
XL (46 lbf.=20.9 kgf.=205N)
Fabrics: 840D Nylon
Dump Valves: 2 (O.P.E.V.+1)
A.P.A. - Active Purge Assist
BCJ-2100
11 JACKETS
BC0501B USA ONLY
• Fully featured rear inflation tech style BC
• 67 lbf. Three-dimensional doughnut style bladder with bungee
• Aluminum Back Plate and Tank Plate design
• Quick change Dual Tank system
• 3-Dimensional foam padded lumbar and back pad area
• A.W.L.S. integrated weight loading system
• Removable rear trim pockets
• Sternum strap with safety whistle
• Adjustable shoulder belt system
• 8 stainless steel D-rings
• 4 dump valves (OPEV + 3)
• 840D Nylon
Sizes
M/L
XL/XXL Lift Capacity
67 lbf. (=30.6 kgf., =300N)
67 lbf. (=30.6 kgf., =300N)
BC0101B
• Ultimate Stabilizing Harness
• 2 large double zippered pockets
• A.W.L.S. Advanced Weight Loading System
• 2 dump valves (OPEV + 1)
• 1 stainless steel and 4 resin D-rings
• Out side: 500D Cordura® Nylon
• Inner side: 420D Nylon
Sizes
XS S M L XL Lift Capacity
18 lbf. (=8.2 kgf., =80N)
22 lbf. (=10.2 kgf., =100N)
31 lbf. (=14.3 kgf., =140N)
38 lbf. (=17.3 kgf., =170N)
46 lbf. (=21 kgf., =205N)
BCJ-8000C
The BCJ-8000C X-Wing rear-inflation BC jacket is an ideal combination of technical and recreational. TUSA’s patented Independent Harness System and Ultimate Stabilizing Harness is mated with a newly designed 500D Cordura® nylon horseshoe bladder offering excellent lift, comfort and freedom of movement.
• Fully featured rear inflation tech style BCJ
• Independent Harness System
• Ultimate Stabilizing Harness
• 3-Dimensional foam padded lumbar and backpad area
• Standard with A.P.A. system (Active Purge Assist)
• A.W.L.S. II integrated weight-loading system
• Newly designed adjustable sternum strap with safety whistle
• 420D/840D nylon harness for superior strength and durability
• 500D Cordura® nylon horseshoe shaped bladder with bungee
• Removable rear trim pockets
• Depth-compensating cummerbund
• Removable roll out mesh accessory pocket
• Knife grommets for FK-10/11 (Use TC-752 knife mount)
• 2 stainless steel and 3 resin D-rings
• 4 dump valves (OPEV + 3)
• Standard with A.P.A. system (Active Purge Assist)
Sizes
Lift Capacity
29 lbf. (=13.3 kgf., =130N)
29 lbf. (=13.3 kgf., =130N)
40 lbf. (=18.4 kgf., =180N)
40 lbf. (=18.4 kgf., =180N)
BCJ-4000
• Ultimate stabilizing harness
• Waist Support System
• Depth-compensating cummberbund
• 3-Dimensional foam padded lumbar & backpad area
• Deep padded shoulder straps provide excellent comfort
• Advanced weight loading system (A.W.L.S.) with rear trim pockets
• 500D Cordura® Nylon shell for superior strength and durability
Sizes XS
Lift Capacity
24 lbf. (=10.7 kgf., =105N)
29 lbf. (=13.3 kgf., =130N)
36 lbf. (=16.3 kgf., =160N)
44 lbf. (=19.9 kgf., =195N)
BCJ-7000C
• Hybrid 3-D bladder design
• Standard with A.P.A. system (Active Purge Assist)
• Advanced Weight Loading System (A.W.L.S.)
• Two position chest strap adjustment
• Knife grommets for FK-10/11 (use TC-752 knife mount)
• Drop down right-side mesh pocket
• Mini retractor pocket option
• Enhanced lumbar and backpad for maximum comfort
• Independent harness system
• Depth-compensating cummerbund
• 4 zippered pockets, 2 main and 2 lower accessory
• 5 stainless steel D-rings
• 4 Dump Valves (OPEV + 3)
Sizes
XS-S
Lift Capacity
37 lbf. (=16.8 kgf., =165N)
37 lbf. (=16.8 kgf., =165N)
50 lbf. (=22.4 kgf., =220N)
50 lbf. (=22.4 kgf., =220N)
BCJ-9300C
• Anatomically cut and designed for females
• Ultimate stabilizing harness
• Independent harness system
• Enhanced lumbar and backpad for maximum comfort
• Deep padded shoulder straps provide excellent comfort
• Standard with A.P.A. system (Active Purge Assist)
• Advanced Weight Loading System (A.W.L.S.) with rear trim pockets
• Heavy duty 840D/420D Nylon shell for superior strength and durability
• 4 zippered pockets - 2 large and 2 lower accessory
• Drop-down right side mesh pocket
• Knife grommets for FK-10/11 (Use TC-752 knife mount)
• Adjustable sternum strap
• 3 stainless steel D-rings
• 3 Dump Valves (OPEV + 2)
Sizes
XS
Lift Capacity
19 lbf. (=8.7 kgf., =85N)
24 lbf. (=10.7 kgf., =105N)
28 lbf. (=12.8 kgf., =125N)
32 lbf. (=14.3 kgf., =140N)
BCJ-9300 EUROPE ONLY
• Sold in Europe as BCJ-9300 with standard inflator
• Weighs 4.4lbs/2kg, designed for travel
• Independent harness system
• Ultimate stabilizing harness
• Weight Loading System (W.L.S.)
• 0.2lbs/0.1kg of inherent buoyancy
• Enhanced lumbar and backpad for maximum comfort
• 2 main and 1 lower accessory zippered pockets
16 lbf. (=7.7kgf., =75N)
21 lbf. (=9.2kgf., =90N)
25 lbf. (=11.2kgf., =110N)
33 lbf. (=14.8kgf., =145N)
• Ultimate Stabilizing Harness
• 2 large zippered pockets
• 2 Dump Valves (OPEV + 1)
• 4 resin D-Rings
• 840D Nylon shell
• Shoulder strap marked with size, ideal for rental or pool stock
• Contoured for female divers
• Ultimate stabilizing harness
• 3-Dimensional bladder design
• 2 zippered pockets
• Rolled edge neckline
• Enhanced lumbar and backpad for maximum comfort
• 4 D-Ring accessory attachments
• 4 Dump Valves (OPEV + 3)
32 lbf. (=14.3kgf., =140N)
32 lbf. (=14.3kgf., =140N)
32 lbf. (=14.3kgf., =140N)
32 lbf. (=14.3kgf., =140N) Sizes
18 lbf. (=8.2kgf., =80N)
23 lbf. (=10.2kgf., =100N)
32 lbf. (=14.3kgf., =140N)
38 lbf. (=17.3kgf., =170N)
46 lbf. (=20.9kgf., =205N)
• Revolutionary pneumatic assisted purge system for TUSA BCJ’s
• Increased flow rates (inflate/deflate) for better performance over standard inflators
• Newly designed OPEV immediately responds to user input
• Streamlined design reduces drag and bulkiness
• Achieve perfect buoyancy with precise fingertip controls
BCJ-2100
3 Gas Mix
This advanced feature allows the diver to preset three individual gas mixtures (Mix 1, Mix 2, Mix 3) from 21-100% for easy switching during the dive as necessary.
2 Gas Mix
This feature allows the diver to preset two Nitrox gas mixtures (Mix 1 and Mix 2) for easy switching during the dive as necessary. Mix 1: 21 to 50%, Mix 2: 21 to 99%.
Air Integration
TUSA’s Zen Air Integration technology allows a diver to monitor depth, dive time and up to 3 tank pressures accurately and safely in a single glance. The need for bulky analog gauge consoles is gone. TUSA’s alphanumeric digital display conveys air data efficiently each updated second.
Altitude Smart Mode
The altitude smart mode allows the computer to automatically adjust for altitude diving.
Audible Alarm
TUSA’s computers feature audible and visual alarms for the most important dive data warnings. Ascent rate, maximum depth, no decompression limits, safety stop and several other key data can be set to alert the diver.
Backlit Display
Several TUSA computer instruments feature a backlit display for night diving or low-light situations. The bright backlight is activated by a touch of a button and the duration can be set for up to 10 seconds in length enabling the diver to view critical dive data easily and quickly.
Dual Time Display
Dual Time offers 2 time zones to be displayed simultaneously on the LCD.
Free Dive Mode
The free dive mode calculates dive times and surface intervals for free diving.
Hoseless Transmitter
Hoseless transmitter technology combines the accuracy of air integration with wireless data transmission resulting in a next generation ultra-compact wrist-top dive computer – the Zen Air.
Optional Deep Stop
An optional safety stop on No Deco dives exceeding a depth of 80 feet.
PC Downloadable
TUSA’s PCLogbook and TUSA DataLog PC interfaces allow the diver to transfer complete log and profile history from the dive computer to a personal computer or upload user settings to the computer. A PC interface unit is sold separately.
Step-Back Feature
The Step-back feature allows user to navigate forward or backward through the menus.
User Replaceable Battery
Convenience and ease-of-maintenance is imperative in the design of today’s dive computer. Each of TUSA’s computers offer a user-friendly replaceable battery that can be changed on a moment’s notice using standard widely-distributed batteries.
IQ1201 IQ-950
• Advanced 3 gas air-integrated wireless watch computer
• Air, Nitrox, gauge, free dive and watch operating modes
• 3 Mix switching feature: Mix 1 (Air, 21-50%), Mix 2 (21-100%), Mix 3 (21-100%)
• Available as watch unit only without transmitter (IQ-950W)
FEATURES
Algorithm
Control Buttons
Mounting Options
Altitude Auto Adjustment
Water Activation
PC Downloadable
Log Mode
History Mode
User Changeable Battery
Battery Type
Deep Stop
Safety Stop
Operating Modes
Variable Ascent Rate Nitrox
Nitrox Mixes
Gas Switching
Alarms
Backlight
NDL Conservative Factor
Digital Watch Functions
Time Zone
Hoseless Air Integrated
# Transmitters Available
Buddy Pressure Check
Download Cable Included
Dual Time
Step-Back Feature
IQ-900
• Advanced 2 gas watch computer
• Air, Nitrox, gauge, free dive and watch operating modes • 2 Mix switching feature: Mix 1 (Air, 21-50%), Mix 2 (Air, 21-100%)
/ Visual
• Advanced 2 gas watch computer
• Air, Nitrox, gauge, free dive and watch operating modes
• 2 mix switch feature
• Mix 1 (Air, 21 – 50%), Mix 2 (Air, 21 – 100%)
• Step-Back feature / Dual Time capable • Color Accents included: Blue and Pink
IQ-750
• Advanced 3 button puck-style module in wrist boot
• Air, Nitrox, gauge, free dive operating modes
• 2 Mix switching feature: Mix 1 (Air, 21-50%), Mix 2 (Air, 21-100%)
• Manual or water-activation
II 2 Gauge
SCA-282 N/A in EUROPE
• Same computer features as IQ-750 Element II
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
II 3 Gauge
SCA-362 N/A in EUROPE
• Same computer features as IQ-750 Element II
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• Updated compass module equipped with luminescent floating card for night visibility, top or side view, and ratcheting bezel
• Single button puck-style module in wrist boot
• Air and Nitrox (21-50%) operating modes
• Manual or water-activation
• Deep Stop feature and standard safety stop
SCA-281 N/A in EUROPE
• Same computer features as IQ-650 Element
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
2 Gauge 3 Gauge
SCA-361 N/A in EUROPE
• Same computer features as IQ-650 Element
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• Updated compass module equipped with luminescent floating card for night visibility, top or side view, and ratcheting bezel
IQ-650
3 Gauge
• Compact 3 gauge analog console includes a depth gauge, a high-pressure gauge and a back-mounted compass
• 200ft/60m depth gauge with max depth indicator
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
• 5000psi/400bar pressure gauge (4350psi/300bar max)
2 Gauge
• 200ft/60m depth gauge with max depth indicator
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
• 5000psi/400bar pressure gauge (4350psi/300bar max)
SPG Combo SPG
• Compact 2 gauge analog console includes a high-pressure gauge and a compass
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
• Luminescent light-storage dial is easy to read in dark or low visibility conditions
• 5000psi/400bar pressure gauge (4350psi/300bar max)
• One high-pressure gauge
SCA-360
SCA-280
SCA-270
SCA-150
• Mini size, lightweight and reliable design
• Streamlined, low drag console with high pressure, depth and back mounted compass
• Colorful dial for easy-reading
• 200ft/70meter depth gauge
• Mini size, lightweight and reliable design
• Streamlined, low drag console with high pressure and depth gauges
• Colorful dial for easy-reading
• 200ft/70meter depth gauge
• Luminescent dial face
• Mini size, lightweight and reliable design
• Streamlined, low drag
• Luminescent dial face
• 400bar pressure gauge (350bar max)
• Durable boot with strap
• Lockable bezel with side window for easy reading
• Luminescent dial face
SCA-330T N/A in AUSTRALIA
SCA-230T N/A in AUSTRALIA
SCA-110T N/A in USA
SCA-160 Compass
Freedom Freedom technology is a set of revolutionary features offering superior fit, comfort and increased performance in TUSA masks. Freedom model masks feature a dimpled skirt surface with varied silicone thicknesses and stability ridges in addition to a proprietary low-friction skirt surface on the fitting line.
180 Buckle System
The buckle rotates a full 180˚ to accommodate varying head sizes for optimum fit. The thin frame and rotation of the buckle allows the mask to be folded into a compact size.
3-D Strap
TUSA's patented 3-D strap is a true three-dimensional design that snugly fits against the head's natural curvature. The 3-D strap offers unprecedented comfort and fit unlike standard flat mask straps.
Angle
Strap Adjustor
TUSA's patented 5 Angle Strap Adjustor allows for a five position micro-adjustment on both the left and right sides of the mask. This enables vertical (up/down) and horizontal (left/right) pressure on the face to be delicately adjusted for the optimum fit.
Anti-Reflective (A/R) Lens Treatment
Standard glass lenses can reflect up to 15% of available light reducing vision underwater. TUSA’s Anti-Reflective (A/R) Lens Treatment decreases internal and external reflected light. This reduction increases light transmission to 95% resulting in significantly enhanced color, clarity, contrast and better overall vision underwater.
Corrective Lens
Corrective lenses are offered on several styles of masks. This option allows the diver to choose right and left lens powers in both a variety of diopters for maximum flexibility and for a custom fit.
CrystalView Optical Glass
CrystalView optical glass lenses provide superior clarity, color and transmission of light over standard glass lenses used by the competition. Up to 15% of available light can be lost with a standard glass lens due to impurities and reflectivity. TUSA’s CrystalView lenses transmit 92% of available light to the diver for clear crisp vision. CrystalView lenses are used in all PRO models masks and also in the M-41 Freedom Quad.
Hyperdry Purge
Clearing a mask has never been easier thanks to our patented Hyperdry System. Simply breathe out through your nose and any water that has accumulated in your mask is forced out through a one-way purge valve. Once the mask is clear, the valve seals shut.
Panoramic View
Panoramic View masks feature a variety of designs offering an incredibly wide field-of-view. Several designs incorporate minimum frame volumes, domed side-windows, reduced frame structures as well as three and four window styles for maximum vision.
Round Edge Skirt
TUSA's patented Round Edge Skirt features a proprietary round edge cross-sectionally shaped skirt. This rounded edge results in a soft fit that suppresses pressure and reduces creasing left on the face. The "planar fit, instead of linear fit" silicone skirt maintains great fit and unprecedented comfort.
Quick-Adjust Buckle System
The Quick-Adjust Buckle System incorporates a newlydesigned low-profile buckle into the mask. The result is a compact, lightweight, technologically advanced mask design that can be easily and quickly adjusted for a perfect fit.
UV Lens Treatment
Increased exposure to UV light can damage the eyes especially in marine environments where reflectivity is high. TUSA’s UV Lens Treatment provides 100% protection from harmful UVA and UVB rays. Blocking 100% of the ultraviolet spectrum (under 400nm) provides greater eye protection without sacrificing light transmission or vision.
M-212/M-212QB M-212SQB
M-24/M-24QB
M28/M-28QB/M-28SQB
M-31/M-31QB
M16/M-16QB
A set of revolutionary new features enhancing mask fit, comfort and performance!
Each person has a unique facial structure and every diver experiences some level of discomfort or “pressure” and “squeeze” while wearing a typical mask underwater. TUSA engineers wanted to solve these problems and spent several years analyzing mask fit, facial bone structure and mouth movement. The result is Freedom Technology, a set of revolutionary new mask features which deliver superior fit, comfort and increased performance. Experience Freedom today.
Dimpled Skirt:
Key areas around the forehead and cheek bones have been designed with dimples which combine to increase the skirt’s softness, flexibility and skin surface contact. This also greatly reduces leakage and enhances comfort.
Varied Silicone Thickness:
A regulator or snorkel mouthpiece, when in use, can cause areas of the mouth and nose section to distort causing leakage and discomfort. Varied thicknesses of silicone in these key areas reduce leakage and provide for a better fit.
Stability Ridges:
As water pressure increases a mask will compress inwards toward the face often causing further leakage. Areas under the cheek bones have been reinforced with stability ridges to minimize this compression maintaining ideal skin surface contact.
Freedom Film:
The TA-200A and TA0801 anti-fog films will keep your favorite mask fog-free while diving underwater. Made with long-lasting durable material, the Freedom Film can be installed easily, and is reusable with proper care. TA-200A is for any 2-window, and TA0801 is for 1-window mask.
Dimpled Skirt, Varied Silicone Thicknesses and Stability Ridges
Freedom Dry enhances comfort and fit by utilizing a revolutionary low friction skirt surface.
The skirt fitting line (shown in red) features a low friction surface that delivers a superior seal and increases the facial area contact patch while significantly reducing excess skin tension. The result is a soft and supple feeling mask with a dramatically improved seal.
Front and Side View: Freedom Fit features shown illustrating key areas designed for increased fit, comfort and skin surface contact.
with Film without Film
• Incredibly wide field of view
• Equipped with Freedom Technology
• 180° Rotational Buckle System
• Large frame with minimal internal volume
• Five-position strap angle adjustor for micro-adjustment
• Round edge skirt, 3D mask strap
• Low profile low volume 2 window teardrop design
• Equipped with Freedom Technology
• PRO Version with CrystalView AR/UV lenses
• Low profile 4 window teardrop design
• Equipped with Freedom Technology
• CrystalView Optical Glass lenses
• Low profile low volume 2 window design
• Equipped with Freedom Technology
• PRO Version with CrystalView AR/UV lenses
TA-200A and TA0801
TUSA’s anti-fog film will keep your favorite mask fog-free while diving underwater. Made with long-lasting durable material, it can be installed easily on any mask and is reusable with proper care.
• Easy installation
• Prevents Fogging
• Reusable
• Easy to clean
• Long-lasting durable material
• Low profile 1-window design
• Round-edge skirt for maximum fit and comfort
• Skirt mounted Quick-Adjust Buckle System
• Fits small to medium size faces, ideal for youth
• Low profile, single window teardrop design
• TUSA CrystalView Optical Glass Lens
• Anti-Reflective and UV Lens Treatments
• Low profile, single window teardrop design
• Skirt mounted Quick-Adjust Buckle System
M-110QB N/A in USA M-24 N/A in AUSTRALIA M-210QB
• Low profile 2-window design for freediving
• Extremely wide field-of-view for compact design
• Low internal volume (approx 120cm³/7in³)
• 2 material frameless mask
• Low profile, low volume single window design
• 1.3x wider-angle of view over 2-window masks
• 2-window design offers exceptional visibility
• 30% increase in field of vision
• Round edge skirt for superior seal and comfort
M-24QB
M-17QB
M-110SQB-CR
EUROPE ONLY
• Lightweight composite frame for enhanced grip and shock protection
• Low profile, low volume 2 window design
• Round-edge skirt for maximum fit and comfort
• M-28SQB with CrystalView AR/UV lenses
• Round edge skirt for superior seal
• 1-window design with wide field vision
• Five angle strap adjustor
N/A in EUROPE
• 2-window square design for precise fit and vision
• Low volume design for snug fit and easy clearing
• Ultra-wide panoramic view of 168 degrees
• Domed side windows reduce blind
• Round edge skirt for superior seal and comfort
• Easy installation of corrective lenses Corrective Lenses -1.0 ~ -8.0 and +1.0 ~ +4.5 in 0.5 increments
L/R
AR/UV Corrective Lenses: -1.0 ~ -8.0 in 0.5 increments
N/A in AUSTRALIA
• Hyperdry system (One-way purge valve) for easy clearing
• 3-window design with extra wide field of vision
• Flexible external nose equalization area
• High-tech design for the ultimate comfort
• Direct sashing 2-window design for super-thin form
• The narrow center joints eliminate the vision field Corrective Lenses: -1.5 ~ -8.0 and +1.0 ~ +4.5 in 0.5 increments
L/R
Comfort Swivel
The Comfort Swivel offers a more comfortable fit since it creates no load on the mouthpiece, straightens out during diving and doesn't get in the way. The swivel adapter makes it possible to slip the mask strap into the slit with no hassles. The two-part construction allows the snorkel to rotate and can be attached in a horizontal position.
High Flow Purge
The High Flow Purge design used on TUSA snorkels offers a covered large diameter purge valve for simple, quick clearing, reducing the amount of water remaining in the mouthpiece in an instant.
Hyperdry ELITE
A more refined and streamlined version of the Hyperdry MAX, the Hyperdry Elite maintains the same superior dry performance and keeps the snorkel completely void of water by quickly and efficiently closing the gasket when submerged or hit by waves.
Hyperdry MAX Dry Top System
TUSA’s Hyperdry MAX System (patented) is the latest innovation in dry snorkel technology utilizing two independent high buoyancy floats for superior dry performance. This revolutionary design keeps the snorkel completely dry by quickly and efficiently closing the gasket when waves or water hit the snorkel.
Hyperdry System
The Hyperdry System keeps the main pipe dry by ejecting water through an independent escape pipe. This unique design utilizes the angle of the snorkel pipe and the resilience of the water surface to eject water.
SP-460 SP-460QB SP-580 SP-580QB SP-300 SP-121QB SP0101 SP0101QB SP-200 SP-200QB
SP-170 SP-170QB
• Low profile dry top keeps water out
• Ortho-conscious mouthpiece for comfort & reduced jaw fatigue
• Angled purge chamber for efficient and easy clearing
• TUSA Hyperdry MAX system (patented)
• Large bore high-flow pipe
• Detachable comfort swivel
• Hyperdry technology
• Three-dimensional curve for optimal angle and performance
• Ortho-conscious mouthpiece for ultimate comfort and reduced jaw fatigue
• Hypo-allergenic high-grade silicone mouthpiece and flex joint
• Hyperdry system
• Large capacity drain chamber and purge valve for easy clearing
• Hologram top reflector for superior identification
• One-touch adaptor for easier attachment
• Hypo-allergenic high-grade silicone mouthpiece and flex joint
• Hyperdry technology
• Oversized drain chamber and oval purge valve for easy clearing
• Pre-angled ortho-conscious mouthpiece designed for a natural fit
• Hyperdry Elite dry top technology
• Hypoallergenic crystal silicone flex neck
• Large capacity drain chamber and oval purge valve
• Ortho-consciously designed mouthpiece for ultimate comfort
• Super Flex pipe
• Cross-cut bore design
• Flash orange colored top for superior identification
• One-touch adaptor for easier attachment
Anatomic Fin Strap
TUSA open-heel fins are equipped with a newly designed Anatomic Fin Strap (AFS). The AFS is anatomically shaped to offer a balance of flexibility and control to increase comfort, power transfer and to significantly reduce heel slippage found in many standard flat fin straps.
Angled Blade Design (A.B.D.)
TUSA’s Angled Blade Design is employed on the SF-22, FF-23 and SF-15 fins. A standard flat fin inhibits propulsion solely by fault of design. An angle between the heel of the foot and the calf of the leg remains when the leg is extended to kick. This angle causes 10% of the propulsion to be lost. The Angled Blade Design accommodates for this anatomical characteristic and ensures maximum efficiency throughout the kicking cycle.
EZ Strap and Buckle System
TUSA's EZ strap and Buckle System allows fins to be quickly and easily adjusted with minimal effort. Adjustment can be made while the fins are worn, allowing for a precise fit and ease of removal when necessary.
ForcElast
A proprietary TPR compound molded into an advanced blade and foot pocket structure offers superior propulsion, efficiency and power transfer. ForcElast powers TUSA high performance fins like the SF-22 and FF-23.
Propeller Technology
TUSA’s advanced split fins employ Propeller-FinTM Technology, which delivers ultra-high performance with a low amplitude rapid flutter kick. As the fin moves through the water its two wing-shaped surfaces create lift and forward propulsion like a propeller. Any water traveling over the top of the blade is funneled into and out of the split between the blades. Efficiency is increased while drag and effort is reduced.
SF-22
SF-15
SF-5000
SF-5500
FF-23
SF-22
The SF-22 Solla combines TUSA’s rich history of performance fin design with the latest advanced materials and hydrodynamic innovations. A completely new design, the Solla has several unique features that deliver superior propulsion, speed and maneuverability.
The SF-22 is powered by ForcElast technology which offers unparalleled performance and efficiency previously unseen in a traditional blade fin. In addition to ForcElast technology, the Solla features TUSA’s 20° Angled Blade Design (A.B.D.), an optimized three channel crescent shaped blade with reinforced side-rails and vents, a multi-compound anatomic foot pocket and TUSA’s Anatomic Fin Strap (A.F.S.) and EZ buckle system.
• Powered by ForcElast Technology
• 20° Angled Blade Design (A.B.D.)
• Multi-compound foot pocket increases power transfer
• Newly designed anatomic foot pocket enhances comfort
• Three channel blade with crescent tip maximizes propulsion
• Reinforced blade side-rails and vents fine-tune performance
• Standard with Anatomic Fin Strap (A.F.S.)
• EZ buckle system
Size S - small fits
Size M - medium fits
Size L - large fits
Universal Spring Straps
The TA-81 spring straps are perfect for any open-heel scuba fin available on the market.
Features
• Will fit on most any fins available on the market
• Fit automatically adjusts to changing conditions
• Durable stainless steel coil spring will not rust or break
• Rubber heel grip with finger loop for easy fit
• Also available in White
FF-23
The FF-23 is the full foot version of the SF-22 Solla. It is powered by ForcElast technology which offers unparalleled performance and efficiency previously unseen in a traditional blade fin. In addition to ForcElast technology, the Solla features TUSA’s 20° Angled Blade Design (A.B.D.), an optimized three channel crescent shaped blade with reinforced side-rails and vents and a soft anatomic foot pocket.
• Full foot version of the SF-22 Solla
• Powered by ForcElast Technology
• 20° Angled Blade Design (A.B.D.)
• Soft anatomic foot pocket enhances comfort
• Three channel blade with crescent tip maximizes propulsion
• Reinforced blade side-rails and vents fine-tune performance
• Three material design for increased performance compared to standard split fins
• Enhanced Propeller-Fin® technology optimizes efficiency
• Multi-compound foot pocket increases power transfer to the blade
SF-5000/5500
• Easy-to-adjust strap with quick-release buckles
• Super comfortable open heel foot pocket
• Non-vented hydrodynamic design for maximum propulsion
SF-5000 SF-5500 Regular Small BK
SF-15
UNDERWATER VEHICLE
3 Speed Adjustment - Propeller Pitch Assembly. It is possible to easily vary the propeller’s pitch, which allows for even more fine-tuning of the scooter’s speed.
Features
• 10% more torque than SAV-7
• Increased usage of 80 minutes (Lead battery)
• Maximum speed of 2.6 mph (4.2 km/h)
• Increased cruising range of 12,000-14,000ft (3,500-4,000 meters)
• Upgraded motor and internal assembly
Newly re-designed 8 level progressive acceleration system allows for precise changes to speed while in motion. As a guide, MIN to level 3 is for deceleration and level 4 to MAX is for diving operation.
Saddle
By using the EVO saddle wings, it’s possible to pull 2 divers in addition to the operator. The speed and distance is not significantly reduced with 3 divers when compared to a single scooter operator without saddle.
ACCESSORIES LINE-UP
MBP-1
SB-2DRYBAG-1
TUL-1000
TUL-400
TUL-410 MS-20
DG-5100
DB0201
DB0101
DG-5600
FK-920 / FK-910
FK-940Ti
FK-220 / FK-210
FK-11 / FK-10
RMB-1
FK-920FK-910
FK-920, FK-910
• FK-910 features drop point blade, FK-920 features blunt tip blade
• 4 ½”(11cm) blade length / 10”(25cm) overall length
FK-940Ti
FK-220, FK-210
• FK-210 features drop point blade, FK-220 features blunt tip blade
• FK-210 - Efficient 5-3/8"(14cm) blade length / 10-1/2"(27cm) overall length
• FK-220 - Efficient 4-7/8"(13cm) blade length / 10-1/8"(26cm) overall length
• 6-4Ti (Ti-6Al-4V) highly corrosion resistant titanium drop point blade
• 4 ½”(11cm) blade length / 10”(25cm) overall length
MESH ROLLER BAG
FK-11FK-10
FK-11, FK-10
TC-752 (optional) for BCJ’s equipped with knife grommets
• FK-10 features drop point blade, FK-11 features blunt tip blade
• 2-7/8"(7cm) blade length / 6-3/8"(16cm) overall length
ROLLER BAG
• Sizes: 29.5”(L) x 14”(W) x 13.6”(H) / 75cm x 35cm x 32cm
• 5,600 cubic inches total storage space
REGULATOR CARRY BAG
SB-2 N/A in AUSTRALIA
• 12"(H) x 12"(W) x 4"(D) / 31cm x 31cm x 11cm
• Fully lined with thick padding
• Durable #10 YKK zipper with pull tabs
• Internal pocket for log/manuals
• Shoulder strap included
DRY BAG MESH BACKPACK
FK-220FK-210 Roll down and quick-snap closure top
DRYBAG1 N/A in AUSTRALIA RMB-1 MBP-1
• Sizes: 28"(H)x18"(W)x14"(D) / 71cm x 46cm x 36cm
• 100% nylon with mesh details
RB-10 N/A in AUSTRALIA
• Sizes: 26”(H) x 18”(W) x 13”(D) / 66cm x 46cm x 33cm
• 6,100 cubic inches total storage space
• 21"(H) x 9.5"(W) x 6"(D) / 54cm x 25cm x 16cm
• Tough, nylon-reinforced, PVC-construction
• 1000 Lumen flood, 520 Lumen spot primary LED • Compact lightweight body with pistol grip
• Enhances comfort and fit
• Made from durable neoprene
Tusa Sport Technology
ClearVu Tempered Glass
ClearVu tempered glass lenses provide superior clarity, color, transmission of light and safety over standard inferior glass.
Crystal Silicone
Made from Hypoallergenic 100% pure surgical grade crystal silicone offering unsurpassed comfort, fit and performance. It resists stretching and fatigue from extended use, reducing leakage and the need for replacement.
EZ Strap and Buckle System
Allows masks to be quickly and easily adjusted with minimal effort. Allowing for a precise fit and ease of removal when necessary.
High Flow Purge
A large diameter purge valve for simple, quick clearing, reducing, the amount of water remaining in the mouthpiece.
Hyperdry Elite - Dry Top
The latest innovation in dry snorkel technology utilizing an independent high buoyancy fl oat for superior dry performance. This keeps the snorkel completely dry by quickly and efficiently closing the gasket.
Hyperdry Semi - Dry Top
Keeps the main snorkel pipe dry by ejecting water through an independent escape pipe.
Travel Friendly Blade Design
A compact blade design allows your snorkel gear to be an easy and light travel option. Giving you more flexibility when packing for your next adventure.
Tusa Sport Series
PRO
PRO series
The PRO series features the latest designs and innovations including 100% Crystal Silicone, ClearVu tempered glass and the Hyperdry Elite Dry Top snorkel technology. Designed for performance.
ELITE
ELITE series
Featuring 100% Crystal Silicone, ClearVu tempered glass and the Hyperdry Semi-Dry Top snorkel technology, the Elite series offers excellent performance and value.
ADVANCED
ADVANCED series
Silicone, ClearVu tempered glass for the entry-level watersports enthusiast.
