QUICK-GUIDE
FASTENING FOR CONCRETE & STEEL
WHICH SIZE OF NAIL SHOULD I CHOOSE ?
CALCULATION OF NAIL SIZE APPLICATION
THICKNESS OF APP.
Concrete
+ + +
Steel
Nail length
Thickness of application
Approx. 20 mm depth of drive
Approx. 7 mm depth of drive
Thin steel
Nail length
Thickness of application
(thicker than 3 mm)
10 mm depth of drive
Nail length
Thickness of application
(1-4 mm)
DEPTH OF DRIVE
approx. 20 mm
approx. 7 mm
10 mm
= = =
NAIL LENGTH
Fastening on a layer of steel and concrete
Fastening on a layer of steel and concrete
MAX HN 120
TJEP CP-40 • TJEP CP-40 GAS
CPPW CONCRETE-/STEELPIN
CPX CONCRETE PIN
Dimension
Item no.
EAN no.
Pcs./box Box/pal.
CPPW 34/30
839504
5702558395045
1.000
CPPW 34/35
839507
5702558395076
CPPW 34/50
839510
5702558395106
Dimension
Item no.
EAN no.
96
CPX 26/16
839216
5702558392167
500
960
1.000
96
CPX 26/20
839219
5702558392198
500
960
1.000
96
CPX 26/25
839224
5702558392242
500
960
CPX 26/30
839229
5702558392297
500
960
CPX 26/35
839234
5702558392341
500
960
CPX 26/40
839239
5702558392396
500
960
Fastening on a layer of thin steel and concrete MAX HN 120
Pcs./box Box/pal.
CPX STEEL-/CONCRETE PIN
CPPW TWISTED STEELPIN Dimension
Item no.
EAN no.
Pcs./box Box/pal.
CPPW 34/38
839522
5702558395229
1.000
96
CPPW 34/50
839524
5702558395243
1.000
96
CPPW 34/65
839526
5702558395267
1.000
96
Dimension
Item no.
EAN no.
Pcs./box Box/pal.
CPX 30/15
839215
5702558392150
500
960
CPX 30/20
839220
5702558392204
500
960
CPX 30/25
839225
5702558392259
500
960
CPX 30/30
839230
5702558392303
500
960
CPX 30/35
839235
5702558392358
500
960
Fastening on a layer of steel and concrete MAX HN25C • MAKITA AN250HC HP
Fastening on a layer of thin steel, 1-3 mm MAX HN25C • MAKITA AN610H HP
CPPW CONCRETE-/STEELPIN Dimension
Item no.
EAN no.
CPPW 30/19
839280
5702558392808
1.000
240
Dimension
Item no.
EAN no.
CPPW 30/22
839282
5702558392822
1.000
240
FB 23/30
839538
5702558395380
6.000
40
CPPW 30/25
839284
5702558392846
1.000
240
FB 29/38
839540
5702558395403
6.000
40
www.tjep.de
Pcs./box Box/pal.
FB STEEL NAIL Pcs./box Box/pal.
NEW 3
4
1
2
-15°
TJEP CP-40 GAS 2G
0°
1
Adjustable depth control
L: 15 - 40 mm Ø: 2.6 - 3.0 mm
2
Support bracket
3
Non-slip grip
4
Rubber cap protection
CPX Concrete Pins
SPECIFICATIONS Item no.
100245
EAN no.
5702551002452
Nail length
15 - 40 mm
Size (L×W×H)
327×130 × 385 mm
Weight
3.80 kg 2
1
1
ACCESSORIES Description
Item no.
TJEP fuel cell, orange ring, 165 mm
100853
TJEP all‑season fuel cell, red ring, 165 mm
100856
Driver unit
875754
© KYOCERA UNIMERCO 03.19 016_2685
USED FOR Concrete, Drywall steel rails.
www.tjep.de www.tjep.de
KYOCERA UNIMERCO Fastening A/S Drejervej 2 · DK-7451 Sunds Tel. +45 97 14 14 40 tjep@kyocera-unimerco.com
