DIFFERENT PARTS MAKING UP COMPLETE ARCHITECTURAL HOUSE PLANS

The type of house determines architectural house plans.

All the basic inclusions of the small house plans are the cabins, narrow house lots, and cottages. But the large house plans include luxury, unique and modern house plans.

As the good house plans make constructions of great houses, they are even determined by the material to be used, location, personal preferences and house size.

Foundation Plans Foundation Plan Presentation indicate the foundation’s general design intent.

Basement, crawl space and slab are shown.

Based on the purchased foundation, the footing layout, structural slab extension, and post and beams are typically included.

Floor Plans Dimensioned Floor plans are the overhead view of the house, indicating The room’s layout Doors Windows Walls

Roof Flan Describing the elements making up the roof, the Roof Plan illustrates Ridges, Valley and Hips.

Even it indicates the roofing materials and roof surfaces slopes, chimneys and decorative elements.

Extension Elevation The 2D representation of the house's each side is the elevations, indicating materials for walls, roof and all other elements.

Building Sections The cut-away view through the house shows the spaces adjacencies are the building sections.

These depict the relation between the ground to the house and the roof.

Electrical Plans The electrical plans drawings indicate the location of the switches, outlets and switches.

These show the lighting design intent and layout.

Building Cross Sections Cross-sections show the home's view if it had been sliced down to the centre.

Viewing the home from the side helps in better understanding the relativity of varying floor heights, rafter lengths and the related structural elements.

Construction Notes and Details All these details are contained in the Construction Notes and Details Foundation Interior walls Floors Stairways Roof Details.

The unique design preferences include Garages Staircases Fireplaces Attics Patios Reading Rooms Game Areas Swimming Pools Jacuzzis And more

The architects offer each set of constructions for providing the investors with all the needed information for building a home. Before the construction commences, certain adjustments might have to be made to the house plans for meeting specific local building codes.
