People Counting | Multisensor-TI

PEOPLE COUNTING Multisensor-TI

About Kentix.

Every business is digital business (mission incritical).

Kentix GmbH, based in Idar-Oberstein, Germany, is a manufacturer of professional smart building security products for the physical security of business-critical IT infrastructures.

Kentix systems offer network-based solutions for every requirement and are suitable for use in all sectors of the economy. With Kentix you can easily increase your IT availability and avoid system failures before they happen.

All-in-One!

Multisensor-TI. Every person releases tiny floating particles – aerosols – into the room air by simply speaking and breathing. These are distributed throughout the entire room after a very short time. A single infected person can transmit his infectious viruses to other people in the room via breathed out aerosols.

In the MultiSensor-TI, several intelligent sensors are networked together by means of clever software. These count the number of persons and at the same time measure the air quality according to the IAQ index “Indoor Air Quality”. If the air quality is too bad, the MultiSensor-TI issues a warning and can recommend window ventilation, for example, via a connected monitor. This can quickly reduce the aerosol load in the room and lower the risk of infection for employees, customers and visitors.

Secure

Discrete

Scalable

Multisensor-TI

People counting and air quality measurement with only one sensor.

Secure.

• GDPR compliant.

• Reliable person recognition through thermal image sensor.

• Detects several persons at the same time.

• Warns if minimum distance is not maintained.

Discrete.

• Easy installation via doors.

• Acoustic signal integrated.

• Output on monitor, Web GUI. • DSGVO compliant.

Scalable.

• Presence or passage counting.

• Capture of several entries and exits.

• Easily networkable via LAN.

Multisensor-TI

Integrated Information System.

Inform customers, visitors or employees directly.

External information systems can be directly controlled by the integrated interfaces. Digitally via network and web interfaces or electrically via inputs/outputs.

Multisensor-TI

Reduce aerosols through integrated air quality sensor.

Aerosols are the smallest suspended particles that are released into the air when exhaled. Viruses can sit on these tiny particles. The danger: the more people in a room, the more aerosols are in the air, and in the worst case, more viruses.

The integrated air quality sensor uses certain algorithms to calculate the carbon dioxide content which allows the air quality to be permanently monitored. This allows the user to set the quality level for activating the alarm by himself. The basis are the different levels of the so-called “Air-Quality-Index” (IAQ) from “excellent” to “extremely dirty”.

Accordingly, instructions such as “Improve ventilation” can be displayed on a connected monitor.

Multisensor-TI

Presence Counting.

MultiSensor-TI is able to detect several persons simultaneously, directions of movement and distances. Thus several door areas can be easily connected with each other via the existing house network (LAN). A sensor takes over the management role as a control centre and provides the information via the required interfaces (Web-GUI, API, Mail, SNMP). The display directly via Smart-TV or Digital Signage Displays is therefore very easy.

Multisensor-TI

100% loT Based.

Kentix system are loT solutions and are designed to provide a simple usable Web GUI. The basis is our operating system.

HTTPS

SNMP

API ReST

E-mail

Multisensor-TI

Freely configurable Web-GUI. The presentation of the STOP-GO display for display on a digital signage display can be adapted with your own graphics and colours. You can also display your logo.

Multisensor-TI

High-end thermal sensor with 1024 pixels.

With a resolution of 1024 pixels and the two available viewing angles of 40° or 90°, the MultiSenso-TI covers all requirements for optimum adaptation of the monitoring area.

Multisensor-TI

Compact dimensions, easy mounting.

The MultiSensor measures only 9 x 9 x 45 cm and is supplied with a snap-in mounting bracket and cable cover. Ideally, it should be mounted on the ceiling.

9cm

9cm

Multisensor-TI

Power over Ethernet and External Connections (system socket).

The sensor is simply integrated into the network via Ethernet with PoE. The configurations are carried out via HTTPS and the integrated web server. In addition, the MultiSensor has a system port with two inputs / outputs for connecting external peripherals or alarms.

Multisensor-TI

Black or White.

For discreet mounting depending on the application, the MultiSensor is available in black and white. Thus the sensor is hardly noticeable on dark or light surfaces.

People Counting.

Group Counting.

In & Out.

Recreation Rooms.

Investment.

MARCA

1

2

3

Kentix

TDM

TDM

MODELO

KMS-TI-90-B

INS-SIT

MAN-SIT8x5x72

# DE PARTE

KMS-TI-90-B

DESCRIPCIÓN

MultiSensor-Thermal Image mit 90° optics (Black) 1024 pixel infrared array, measuring range -40 to 1,000°C, detection cone depending on type: 40° or 90°, range up to approx. 6m. Measurement: temperature image, motion/direction of motion, object detection.

CANTIDAD

PRECIO A CLIENTE (USD)

TOTAL (USD)

1

878,91

878,91

SUBTOTAL

878,91

INS-SIT

Instalacion, configuracion y pruebas en sitio de lunes a viernes, dias habiles, de 7:30 AM a 6:00 PM

1

105,47

105,47

MAN-SIT8x5x72

Mantenimiento en sitio por un año que incluye soporte técnico remoto por teléfono, por videoconferencia, en sitio y reemplazo de partes en 72 horas de lunes a viernes, dias habiles, de 7:30 AM a 6:00 PM

1

105,47

105,47

TOTAL

1089,84

Soluciรณn Multisensor-TI. Count People and Ensure Air Quality with One Device!

CALL NOW THE LOWEST PRICE | THE SHORTEST DELIVERY TIME THE BEST SOLUTION | IMMEDIATE ATTENTION BY EXPERTS

CALL US

+52 (55) 1204 0430 www.tdm.com.mx arturo.tdm.com.mx arturo@tdm.com.mx
