1. Wooden window with insulating glazing
2. Floding window shutter, timber
3. Exterior wall, plasterboard 15mm, OSB panel 15mm, Insulation 200mm, OSB panel 20mm, Breathable membrane, 25x50 treated battens vertical, 25x50 treated battens horizontal, vertical open joint timber cladding
4. Timber frame door, door leaf; re resistant plywood panel, 15mm Vapour barrier Thermal insulation, mineral wool, 54mm Fire resistant plywood panel, 15mm
5. Mezzanine oor, three-layered CLT panel, 80mm 170 x 140mm timber joists at both end
6. Floor Linoleum 4mm, Chipbard 16mm, Impact-sound insulation, 34mm, Thermal insulation, mineral wool, 100mm, 80 x 100mm timber joists, Timber battens, Ceiling plasterboard, 15mm
7. Corridor oor Timber oor board, 29mm Impact-sound insulation, 34mm, 80 x 100mm timber joists, Timber battens,
8. Glulam beam, 250 x 300mm
9. Glulam Post, 250 x 250mm
10. Glulam bracing, 200 x 200mm
11. Open tread imber staircase, tread width 1200mm, tread thickness 21mm
Axonometric Structural Strategy
Glulam post and beam structure with cross bracings over existing concrete structure.
4.
5. Exterior wall, plasterboard 15mm, OSB panel 15mm, Insulation 200mm, OSB panel 20mm, Breathable membrane, 25x50 treated battens vertical, 25x50 treated battens horizontal, vertical open joint timber cladding
9. Floor
Linoleum 4mm, Chipbard 16mm, Impact-sound insulation, 34mm, Thermal insulation 100mm, 80 x 100mm timber joists, imber battens, Ceiling plasterboard
1. Glulam Column, 250 x 250 x 4400mm
2. Metal glulam connector
3. Glulam beam,
Partition wall, Soundbloc plasterboard 12.5mm x 2 Glulam cross bracing, Insulation 240mm Soundbloc plasterboard 12.5mm x 2
6. Double glazed window, wooden frame
7. Folding window shutters, wooden
8. Mezzanine oor, three-layered CLT panel, 80mm 170 x 140mm timber joists at both end
Seaweed for Well-being Centre
Flashing with cricket/diverter
Double glazed skylight window
blocking to suit roo ng pro le height
Trim-out opening frame
Timber truss top chord
1.Roof buildup
Standing seam external metal roof, underside coated
Seperation layer
OSB structural support deck panel, 18mm
Counter timber batten, 50mm ventilating air layer
Breather membrane
Mineral wool insulation, 270mm
Vapour control layer
OSB structural panel, 18mm
Timber truss
2. Hidden gutter, 120m width, Copper lining
3. Perforated Zinc shading panel, metal batten
4. Single leaf perforated brick wall, supporting shading panel
5. Wall buildup
Brick outer leaf, 102.5mm
50mm clear cavity
low emissivity breather membrane
OSB sheathing board, 9mm
140mm x 38mm timber studs
Rigid insulation tted between studs, 140mm
Rigid insulation, 50mm
low emissivity vapour control layer
35mm service cavity
White plasterboard, 12mm
6. In-situ concrete footing, In-situ concrete stem wall,
Polyethylene vapour retarder, 6mm
Sill seal
Termite shield
Sill seal
38mm x 140mm timber base plate x 2
7. Slab-on-grade foundation with stem walls gravel layer, 100mm
extruded Polystyrene insulation, 25mm
Concrete slab
Polyethylene vapour retarder, 6mm
Concrete slab, 250mm
Rigid insulation, 150mm
Vapour control membrane
60mm screed with 15mm diameter under oor heating pipes embedded
Lining
brick outer leaf, 215mm x 102.5mm
re resisting cavity barrier with integral dpc
1.Cavity wall build up Red brick outer leaf, 102.5mm
Wall tie
50mm clear cavity, Insulated double leaf steel lintel low emissivity breather membrane, Rigid insulation, 50mm low emissivity vapour control layer Red brick Inner leaf, 102.5mm
2. Perforated bricks screen
3. Roof buildup
Galvanized steel roof valley ush
Standing seam external metal roof, underside coated
Seperation layer
OSB structural support deck panel, 18mm Counter timber batten, 50mm ventilating air layer
Breather membrane
Mineral wool insulation, 270mm
Vapour control layer
OSB structural panel, 18mm Timber truss
4. Single red brick leaf, 102.5mm Fire cavity barrier Red brick double leaf, 215mm
5. Creamic tiles, 10mm 63mm screed with under oor heating, waterproof membrane structural oor deck, 15mm 235mm x 38mm timber joist
6. Floor buildup
175 ~ 230 mm screed, Jack arch brick ceiling with Steel I beams, Steel cellular beam supporting jack arches, Concrete Padstone
